Hyundai i30 (2018 year). Instruction - part 8
Convenient features of your vehicle
Distance to empty
Transmission shift indicator
i
Information
Manual transmission shift indi-
•
If the vehicle is not on level ground
cator (if equipped)
or the battery power has been inter-
rupted, the distance to empty func-
tion may not operate correctly.
•
The distance to empty may differ
from the actual driving distance as
it is an estimate of the available
driving distance.
•
The trip computer may not register
additional fuel if less than 6 liters
(1.6 gallons) of fuel are added to the
OPD046138
vehicle.
•
The distance to empty is the esti-
•
The distance to empty may vary sig-
mated distance the vehicle can be
OPDE046142
nificantly based on driving condi-
driven with the remaining fuel.
tions, driving habits, and condition
This indicator informs which gear is
•
If the estimated distance is below
of the vehicle.
desired while driving to save fuel.
1 km (1 mi.), the trip computer will
• Shifting up : ▲2, ▲3, ▲4, ▲5, ▲6
display “---” as distance to empty.
• Shifting down :
▼1, ▼2, ▼3, ▼4, ▼5
3-48
For example
Automatic transmission shift
Dual clutch transmission shift
: Indicates that shifting up to the
indicator (if equipped)
indicator (if equipped)
3rd gear is desired (currently
the shift lever is in the 2nd or
1st gear).
: Indicates that shifting down to
the 3rd gear is desired (current-
ly the shift lever is in the 4th,
3
5th, or 6th gear).
When the system is not working prop-
erly, the indicator is not displayed.
OTL045132
OTL045132
This indicator displays which automat-
This indicator displays which shift
ic transmission shift lever is selected.
lever is selected.
• Park : P
• Park : P
• Reverse : R
• Reverse : R
• Neutral : N
• Neutral : N
• Drive : D
• Drive : D
• Manual shift mode : 1, 2, 3, 4, 5, 6
• Manual shift mode : D1, D2, D3, D4,
D5, D6, D7
3-49
Convenient features of your vehicle
Automatic transmission shift indi-
• Dual clutch transmission shift indi-
cator / Dual clutch transmission
cator
shift indicator (for Europe,
- Shifting up :▲2, ▲3, ▲4, ▲5,
▲
if equipped)
6 ▲7
- Shifting down :
▼1, ▼2, ▼3, ▼4,
▼5, ▼6
For example
: Indicates that shifting up to the
3rd gear is desired (currently
OTL045134
the shift lever is in the 2nd or
1st gear).
Shift Indicator Pop-up (if equipped)
: Indicates that shifting down to
The pop-up that indicates the current
the 3rd gear is desired (current-
gear position is displayed in the clus-
ly the shift lever is in the 4th,
ter for about 2 seconds when shifting
OPDE046142
5th, or 6th gear).
into other positions (P/R/N/D).
In the manual shift mode, this indica-
tor informs which gear is desired
When the system is not working
while driving to save fuel.
properly, the indicator is not dis-
played.
• Automatic transmission shift indi-
cator
- Shifting up : ▲2, ▲3, ▲4, ▲5, ▲6
- Shifting down :
▼1, ▼2, ▼3, ▼4, ▼5
3-50
Warning and indicator lights
Seat Belt Warning Light
Parking Brake & Brake
Fluid Warning Light
i
Information
Make sure that all warning lights are
OFF after starting the engine. If any
This warning light informs the driver
This warning light illuminates:
light is still ON, this indicates a situa-
that the seat belt is not fastened.
•
When you set the ignition switch or
tion that needs attention.
the Engine Start/Stop button to the
3
ON position.
For more details, refer to the “Seat
Air Bag Warning Light
Belts” in chapter 2.
- It illuminates for approximately 3
seconds
- It remains on if the parking brake
is applied.
•
When the parking brake is applied.
This warning light illuminates:
• When you turn the ignition switch
•
When the brake fluid level in the
or the Engine Start/Stop button to
reservoir is low.
the ON position.
- If the warning light illuminates
- It illuminates for approximately 6
with the parking brake released, it
indicates the brake fluid level in
seconds and then goes off.
reservoir is low.
• When there is a malfunction with
the SRS.
In this case, we recommend that
you have the vehicle inspected by
an authorized HYUNDAI dealer.
3-51
Convenient features of your vehicle
If the brake fluid level in the reser-
Also, the vehicle will not stop in as
Anti-lock Brake System
voir is low:
short a distance with only a portion
(ABS) Warning Light
of the brake system working.
1. Drive carefully to the nearest safe
location and stop your vehicle.
If the brakes fail while you are driv-
ing, shift to a lower gear for addition-
2. With the engine stopped, check the
This warning light illuminates:
al engine braking and stop the vehi-
brake fluid level immediately and
•
When you set the ignition switch or
cle as soon as it is safe to do so.
add fluid as required (For more
the Engine Start/Stop button to the
details, refer to “Brake Fluid” in
ON position.
chapter
7). After adding brake
WARNING
- It illuminates for approximately 3
fluid, check all brake components
seconds and then goes off.
for fluid leaks. If a brake fluid leak is
Parking Brake & Brake Fluid
found, or if the warning light
Warning Light
•
When there is a malfunction with
remains on, or if the brakes do not
the ABS (The normal braking sys-
Driving the vehicle with a warn-
operate properly, do not drive the
tem will still be operational without
ing light ON is dangerous. If the
vehicle. We recommend you to
the assistance of the anti-lock
Parking Brake & Brake Fluid
have the vehicle inspected by an
brake system).
Warning Light illuminates with
authorized HYUNDAI dealer.
In this case, we recommend that
the parking brake released, it
you have the vehicle inspected by
indicates that the brake fluid
an authorized HYUNDAI dealer.
Dual-diagonal braking system
level is low.
Your vehicle is equipped with dual-
In this case, we recommend
diagonal braking systems. This
that you have the vehicle
means you still have braking on two
inspected by an authorized
wheels even if one of the dual sys-
HYUNDAI dealer.
tems should fail.
With only one of the dual systems
working, more than normal pedal
travel and greater pedal pressure are
required to stop the vehicle.
3-52
Electronic Brake Force
i
Information - Electronic
WARNING
Distribution (EBD)
Brake Force Distribution
System Warning Light
(EBD) System Warning Light
Electronic Brake Force
Distribution (EBD) System
When the ABS Warning Light is on or
Warning Light
both ABS and Parking Brake & Brake
Fluid Warning Lights are on, the
When both ABS and Parking
speedometer, odometer, or tripmeter
These two warning lights illuminate
Brake & Brake Fluid Warning
3
may not work. Also, the EPS Warning
at the same time while driving:
Lights are on, the brake system
Light may illuminate and the steering
will not work normally and you
• When the ABS and regular brake
effort may increase or decrease.
may experience an unexpected
system may not work normally.
and dangerous situation during
In this case, we recommend you have
In this case, we recommend that
the vehicle inspected by an authorized
sudden braking.
you have the vehicle inspected by
HYUNDAI dealer as soon as possible.
In this case, avoid high speed
an authorized HYUNDAI dealer.
driving and abrupt braking.
We recommend you have the
vehicle inspected by an author-
ized HYUNDAI dealer as soon
as possible.
3-53
Convenient features of your vehicle
Electronic Parking
AUTO HOLD Indicator
Electric Power
Brake (EPB) Warning
EPB
Light (if equipped)
Steering (EPS)
Light (if equipped)
Warning Light
This warning light illuminates:
This indicator light illuminates:
This warning light illuminates:
• When you set the ignition switch or
•
[White] When you activate the auto
•
When you set the ignition switch or
the Engine Start/Stop button to the
hold system by pressing the AUTO
the Engine Start/Stop button to the
ON position.
HOLD button.
ON position.
- It illuminates for approximately 3
•
[Green] When you stop the vehicle
- It illuminates for approximately 3
seconds and then goes off.
completely by depressing the
seconds and then goes off.
• When there is a malfunction with
brake pedal with the auto hold sys-
•
When there is a malfunction with
tem activated.
the EPB.
the EPS.
•
[Yellow] When there is a malfunc-
In this case, we recommend that
In this case, we recommend that
tion with the auto hold system.
you have the vehicle inspected by
you have the vehicle inspected by
an authorized HYUNDAI dealer.
In this case, we recommend that
an authorized HYUNDAI dealer.
you have the vehicle inspected by
an authorized HYUNDAI dealer.
i
Information
The Electronic Parking Brake (EPB)
For more details, refer to “Auto
Warning Light may illuminate when
Hold” in chapter 5.
the Electronic Stability control (ESC)
Indicator Light comes on to indicates
that the ESC is not working properly
(This does not indicate malfunction of
the EPB).
3-54
Malfunction Indicator
NOTICE
Charging System
- Gasoline Engine
Lamp (MIL)
Warning Light
If the Malfunction Indicator Lamp
(MIL) illuminates, potential catalyt-
ic converter damage is possible
This warning light illuminates:
which could result in loss of
This warning light illuminates:
• When you set the ignition switch or
engine power.
• When there is a malfunction with
the Engine Start/Stop button to the
In this case, we recommend that
either the alternator or electrical
3
ON position.
you have the vehicle inspected by
charging system.
- It illuminates for approximately 3
an authorized HYUNDAI dealer as
If there is a malfunction with either
seconds and then goes off.
soon as possible.
the alternator or electrical charging
• When there is a malfunction with
system:
NOTICE
the emission control system.
- Diesel Engine
1. Drive carefully to the nearest safe
In this case, we recommend that
If the Malfunction Indicator Lamp
location and stop your vehicle.
you have the vehicle inspected by
(MIL) blinks, error related to the
2. Turn the engine off and check the
an authorized HYUNDAI dealer.
injection quantity adjustment may
alternator drive belt for looseness
have occurred which could result
or breakage.
NOTICE
in loss of engine power, combus-
If the belt is adjusted properly,
tion noise and poor emission.
Driving with the Malfunction Indicator
there may be a problem in the
In this case, we recommend that
Lamp (MIL) on may cause damage to
electrical charging system.
you have the engine control sys-
the emission control systems which
In this case, we recommend that
tem inspected by an authorized
could affect drivability and/or fuel
you have the vehicle inspected by
HYUNDAI dealer.
economy.
an authorized HYUNDAI dealer as
soon as possible.
3-55
Convenient features of your vehicle
Engine Oil Pressure
NOTICE
Low Fuel Level
Warning Light
Warning Light
•
If the engine does not stop
immediately after the Engine Oil
Pressure Warning Light is illumi-
This warning light illuminates:
nated, severe damage could
This warning light illuminates:
• When the engine oil pressure is low.
result.
• When the fuel tank is nearly empty.
•
If the warning light stays on
Add fuel as soon as possible.
while the engine is running, it
If the engine oil pressure is low:
indicates that there may be seri-
NOTICE
1. Drive carefully to the nearest safe
ous engine damage or malfunc-
location and stop your vehicle.
tion. In this case,
Driving with the Low Fuel Level
2. Turn the engine off and check the
warning light on or with the fuel
1. Stop the vehicle as soon as it
engine oil level (For more details,
level below
“0” can cause the
is safe to do so.
refer to “Engine Oil” in chapter 7).
engine to misfire and damage the
2. Turn off the engine and check
If the level is low, add oil as required.
catalytic converter (if equipped).
the oil level. If the oil level is
If the warning light remains on
low, fill the engine oil to the
after adding oil or if oil is not avail-
proper level.
able, we recommend that you
3. Start the engine again. If the
have the vehicle inspected by an
warning light stays on after the
authorized HYUNDAI dealer as
engine is started, turn the
soon as possible.
engine off immediately. In this
case, we recommend that you
have the vehicle inspected by
an authorized HYUNDAI dealer.
3-56
Master Warning Light
Low Tire Pressure
This warning light remains on after
Warning Light
blinking for approximately 60 sec-
(if equipped)
onds or repeats blinking and off at
the intervals of approximately 3
seconds:
This indicator light illuminates:
This warning light illuminates:
• When there is a malfunction with
•
When there is a malfunction in the
• When you set the ignition switch or
the TPMS.
below systems.
Engine Start/Stop button to the ON
In this case, we recommend that
3
position.
- Low washer fluid (if equipped)
you have the vehicle inspected by
- Smart high beam malfunction
- It illuminates for approximately 3
an authorized HYUNDAI dealer as
seconds and then goes off.
(if equipped)
soon as possible.
• When one or more of your tires are
- Blind Spot Detection (BSD) mal-
significantly underinflated
(The
For more details, refer to
function (if equipped)
location of the underinflated tires
“Tire Pressure Monitoring System
- Autonomous Emergency Braking
are displayed on the LCD display).
(TPMS)” in chapter 6.
(AEB) malfunction (if equipped)
- Speed Limit Information Function
For more details, refer to
WARNING
(SLIF) malfunction (if equipped)
“Tire Pressure Monitoring System
(TPMS)” in chapter 6.
- Advanced Smart Cruise Control
Safe Stopping
malfunction (if equipped)
• The TPMS cannot alert you to
- Tire Pressure Monitoring System
severe and sudden tire damage
(TPMS, if equipped)
caused by external factors.
To identify the details of the warn-
• If you notice any vehicle insta-
ing, look at the LCD display.
bility, immediately take your
foot off the accelerator pedal,
apply the brakes gradually with
light force, and slowly move to
a safe position off the road.
3-57
Convenient features of your vehicle
Fuel Filter Warning
Exhaust System (DPF)
Glow Indicator Light
Light (Diesel Engine)
Warning Light (Diesel
(Diesel Engine)
Engine)
This warning light illuminates:
This warning light illuminates:
• When there is a malfunction with
This indicator light illuminates:
• When water has accumulated
Diesel Particulate Filter (DPF) sys-
• When the engine is being preheat-
inside the fuel filter.
tem.
ed with the ignition switch or
In this case, remove the water from
When this warning light illumi-
Engine Start/Stop Button in the ON
the fuel filter.
nates, it may turn off after driving
position.
the vehicle:
- The engine can be started after
For more details, refer to "Fuel
the glow indicator light goes off.
- at more than 60 km/h (37 mph), or
Filter" in chapter 7.
- at more than 2nd gear with 1500
- The illumination time varies with
~ 2500 engine rpm for a certain
the engine coolant temperature,
time (for about 25 minutes).
air temperature, and battery con-
NOTICE
dition.
If this warning light blinks in spite of
• When the Fuel Filter Warning
the procedure
(at this time LCD
Light illuminates, engine power
warning message will be displayed),
If the indicator light remains on or
(vehicle speed & idle speed) may
we recommend that you have the
blinks after the engine has warmed
decrease.
DPF system checked by an author-
up or while driving, there may a mal-
• If you keep driving with the warn-
ized HYUNDAI dealer.
function with the engine preheating
ing light on, engine parts (injec-
system.
tor, common rail, high pressure
NOTICE
In this case, we recommend that you
fuel pump) may be damaged. If
this occurs, we recommend that
If you continue to drive with the
have the vehicle inspected by an
authorized HYUNDAI dealer.
you have the vehicle inspected
DPF warning light blinking for a
by an authorized HYUNDAI deal-
long time, the DPF system can be
er as soon as possible.
damaged and fuel consumption
can worsen.
3-58
Electronic Stability
Electronic Stability
i
Information
Control (ESC) Indicator
Control (ESC) OFF
If the engine does not start within 10
Light (if equipped)
Indicator Light
seconds after the preheating is com-
(if equipped)
pleted, set the ignition switch or
Engine Start/Stop Button to the
LOCK or OFF position for 10 seconds
This indicator light illuminates:
This indicator light illuminates:
and then to the ON position in order
• When you set the ignition switch or
• When you set the ignition switch or
3
to preheat the engine again.
the Engine Start/Stop button to the
the Engine Start/Stop button to the
ON position.
ON position.
- It illuminates for approximately 3
- It illuminates for approximately
seconds and then goes off.
3 seconds and then goes off.
• When there is a malfunction with
• When you deactivate the ESC sys-
the ESC system.
tem by pressing the ESC OFF but-
ton.
In this case, we recommend that
you have the vehicle inspected by
For more details, refer to “Electronic
an authorized HYUNDAI dealer.
Stability Control (ESC)” in chapter 5.
This indicator light blinks:
• While the ESC is operating.
For more details, refer to “Electronic
Stability Control (ESC)” in chapter 5.
3-59
Convenient features of your vehicle
AUTO STOP Indicator
Immobilizer Indicator
Immobilizer Indicator
Light (if equipped)
Light (without smart key)
Light (With Smart Key)
(if equipped)
(if equipped)
This indicator light illuminates:
This indicator light illuminates:
This indicator light illuminates for
up to 30 seconds:
• When the engine enters the Idle
• When the vehicle detects the
Stop mode of the ISG (Idle Stop and
immobilizer in the key with the igni-
• When the vehicle detects the
Go) system.
tion switch in the ON position.
smart key in the vehicle with the
- At this time, you can start the
Engine Start/Stop button in the
ACC or ON position.
engine.
This indicator light blinks:
- The indicator light goes off after
- At this time, you can start the
• When the automatic starting occurs,
starting the engine.
engine.
the AUTO STOP indicator on the
- The indicator light goes off after
cluster will blink for 5 seconds.
starting the engine.
This indicator light blinks:
For more details, refer to the “ISG
• When there is a malfunction with
(Idle Stop and Go) system” in chap-
the immobilizer system.
This indicator light blinks for a few
ter 5.
seconds:
In this case, we recommend that
• When the smart key is not in the
you have the vehicle inspected by
i
Information
an authorized HYUNDAI dealer.
vehicle.
When the engine automatically starts
- At this time, you cannot start the
by the ISG system, some warning
engine.
lights(ABS, ESC, ESC OFF, EPS or
Parking brake warning light) may
turn on for a few seconds.
This happens because of low battery
voltage. It does not mean the system
has malfunctioned.
3-60
This indicator light illuminates for
Turn Signal Indicator
Low Beam Indicator
2 seconds and goes off:
Light
Light (if equipped)
• If the smart key is in the vehicle
and the Engine Start/Stop button is
ON, but the vehicle cannot detect
This indicator light blinks:
This indicator light illuminates:
the smart key.
• When you turn the turn signal light
• When the headlights are on.
In this case, we recommend that
on.
you have the vehicle inspected by
3
an authorized HYUNDAI dealer.
High Beam Indicator
If any of the following occurs, there
Light
may be a malfunction with the turn
This indicator light blinks:
signal system.
• When the battery voltage of the
- The turn signal indicator light illumi-
smart key is low.
This indicator light illuminates:
nates but does not blink
- At this time, you cannot start the
• When the headlights are on and in
- The turn signal indicator light blinks
engine. However, you can start
the high beam position
rapidly
the engine if you press the
• When the turn signal lever is pulled
- The turn signal indicator light does
Engine Start/Stop button with the
into the Flash-to-Pass position.
not illuminate at all
smart key.
(For more details,
refer to "Starting the Engine"
If either of these conditions occur, we
in chapter 5).
recommend you to have your vehicle
inspected by an authorized HYUNDAI
• When there is a malfunction with
dealer.
the immobilizer system.
In this case, we recommend that
you have the vehicle inspected by
an authorized HYUNDAI dealer.
3-61
Convenient features of your vehicle
Smart High Beam
Front Fog Indicator
• When there is a malfunction with
Indicator Light
Light (if equipped)
the LED headlamp.
(if equipped)
In this case, we recommend that you
have the vehicle inspected by an an
authorized HYUNDAI dealer.
This warning light illuminates:
This indicator light illuminates:
• When the high-beam is on with the
• When the front fog lights are on.
This warning light blinks:
light switch in the AUTO light posi-
When there is a malfunction with a
tion.
LED headlamp related part.
Rear Fog Indicator
• If your vehicle detects oncoming or
Light
In this case, we recommend that you
preceding vehicles, the Smart High
have the vehicle inspected by an an
Beam system will switch the high
authorized HYUNDAI dealer.
beam to low beam automatically.
This indicator light illuminates:
NOTICE
For more details, refer to "Smart
• When the rear fog lights are on.
High Beam" in this chapter.
Continuous driving with the LED
Headlamp Warning Light on or
LED Headlamp Warning
blinking can reduce LED head-
Light ON Indicator
Light (if equipped)
lamp life.
Light
Cruise Indicator Light
This warning light illuminates:
(if equipped)
This indicator light illuminates:
• When you turn the ignition switch
• When the tail lights or headlights
or the Engine Start/Stop button to
are on.
the ON position.
This indicator light illuminates:
• When the cruise control system is
enabled.
For more details, refer to "Cruise
Control System" in chapter 5.
3-62
Cruise SET Indicator
SPORT Mode Indicator
Autonomous
Light (if equipped)
Light (if equipped)
Emergency Braking
(AEB) Warning light
(if equipped)
This indicator light illuminates:
This indicator light illuminates
This indicator light illuminates:
• When the cruise control speed is
• When you set the ignition switch or
• When you select "SPORT" mode
set.
as drive mode.
Engine Start/Stop button to the ON
3
position.
For more details, refer to "Cruise
For more details, refer to "Drive
- It illuminates for approximately 3
Control System" in chapter 5.
Mode Integrated Control System"
seconds and then goes off.
in chapter 5.
• When there is a malfunction with
Speed Limiter Indicator
the AEB.
Light (if equipped)
ECO Mode Indicator
In this case, we recommend that you
Light (if equipped)
have the vehicle inspected by an
authorized HYUNDAI dealer.
This indicator light illuminates
when:
For more information, refer to
This indicator light illuminates
"Autonomous Emergency Braking
• When the speed limiter is enabled.
• When you select "ECO" mode as
(AEB)" in chapter 5.
For more details, refer to "Speed
drive mode.
Limit Control System" in chapter
For more details, refer to "Drive
5.
Mode Integrated Control System"
in chapter 5.
3-63
Convenient features of your vehicle
Lane Departure Warning
Lane Keeping Assist
Icy Road Warning Light
System (LDWS)
System (LKAS)
(if equipped)
Indicator Light
Indicator Light
(if equipped)
(if equipped)
This indicator light illuminates:
This indicator light illuminates:
This warning light is to warn the driver
•
[Green] When you activate the lane
•
[Green] When the system operat-
the road may be icy.
departure warning system.
ing conditions are satisfied.
When the temperature on the out-
•
[White] When system operating
•
[White] The system operating con-
side temperature gauge is approxi-
conditions are not satisfied.
ditions are not satisfied.
mately below
4°C (40°F), the Icy
•
[Yellow] When there is a malfunc-
•
[Yellow] When there is a malfunc-
Road Warning Light and Outside
tion with the lane departure warn-
tion with the lane keeping assist
Temperature Gauge blinks and then
ing system.
system.
illuminates. Also, the warning chime
In this case, we recommend you to
sounds 1 time.
In this case, we recommend that
you have the vehicle inspected by
have your vehicle inspected by an
an authorized HYUNDAI dealer.
authorized HYUNDAI dealer.
i
Information
For more details, refer to "Lane
If the icy road warning light appears
For more details, refer to "Lane
while driving, you should drive more
Departure Warning System (LDWS)"
Keeping Assist System (LKAS)" in
chapter 5.
attentively and safely refraining from
in chapter 5.
over-speeding, rapid acceleration, sud-
den braking or sharp turning, etc.
3-64
