Child-protector rear door locks

To lock the child safety lock, insert a

key (or screwdriver) (1) into the hole

and turn it to the lock position.

To allow a rear door to be opened

from inside the vehicle, unlock the

child safety lock.

3

WARNING

If children accidently open the

rear doors while the vehicle is

in motion, they could fall out of

the vehicle. The rear door safety

OPDE046009

locks should always be used

The child safety lock is provided to

whenever children are in the

help prevent children seated in the

vehicle.

rear from accidentally opening the

rear doors. The rear door safety locks

should be used whenever children

are in the vehicle.

The child safety lock is located on

the edge of each rear door. When the

child safety lock is in the lock posi-

tion, the rear door will not open if the

inner door handle is pulled.

3-15

Convenient features of your vehicle

THEFT-ALARM SYSTEM

This system helps to protect your

Once the security system is set, open-

vehicle and valuables. The horn will

ing any door, the tailgate, or the hood

sound and the hazard warning lights

without using the remote key or smart

will blink continuously if any of the

key will cause the alarm to activate.

following occurs:

The Theft Alarm System will not set if

- A door is opened without using the

the hood, the tailgate, or any door is

remote key or smart key.

not fully closed. If the system will not

set, check the hood, the tailgate, or

- The tailgate is opened without

the doors are fully closed.

using the remote key or smart key.

- The engine hood is opened.

Do not attempt to alter this system or

add other devices to it.

The alarm continues for 30 seconds,

OJC040170

then the system resets. To turn off

the alarm, unlock the doors with the

i

Information

i

Information

remote key or smart key.

•

Do not lock the doors until all pas-

Vehicles equipped with a theft alarm

The Theft Alarm System automati-

sengers have left the vehicle. If the

system will have a label attached to

cally sets 30 seconds after you lock

remaining passenger leaves the

the vehicle with the following words:

the doors and the tailgate. For the

vehicle when the system is armed,

1. WARNING

system to activate, you must lock the

the alarm will be activated.

2. SECURITY SYSTEM

doors and the tailgate from outside

•

If the vehicle is not disarmed with

the vehicle with the remote key or

the remote key or smart key, open

smart key or by pressing the button

the doors by using the mechanical

on the outside of the door handles

key and place the ignition switch in

with the smart key in your posses-

the ON position (for remote key) or

sion.

start the engine (for smart key) and

The hazard warning lights will blink

wait for 30 seconds.

and the chime will sound once to

•

When the system is disarmed but a

indicate the system is armed.

door or tailgate is not opened within

30 seconds, the system will be

rearmed.

3-16

DRIVER POSITION MEMORY SYSTEM (IF EQUIPPED)

Recalling memory positions

i

Information

1. Move the shift lever into P (Park)

• If the battery is disconnected, the

while the ignition switch or the

memory settings will be erased.

Engine Start/Stop button is in the

• If the Driver Position Memory

ON position.

System does not operate normally,

2. Press the desired memory button

we recommend that you have the

(1 or

2). The system will beep

system checked by an authorized

3

once, then the driver’s seat posi-

HYUNDAI dealer.

tion, outside rearview mirror and

instrument panel illumination will

Storing memory positions

automatically adjust to the stored

OPDE046010

position (if equipped).

1. Move the shift lever into P (Park)

The Driver Position Memory System

while the ignition switch or the

3. "Driver 1(or 2) settings is applied"

is provided to store and recall the fol-

Engine Start/Stop button is in the

will appear on the LCD display.

lowing memory settings with a sim-

ON position.

ple button operation.

2. Adjust the driver's seat position,

- Driver's seat position

outside rearview mirror position

- Outside rearview mirror position

and instrument panel illumination

- Instrument panel illumination intensity

intensity to the desired position.

3. Press the SET button. The system

will beep once and notify you

WARNING

"Press button to save settings"on

the LCD display.

Never attempt to operate the driv-

er position memory system while

4. Press one of the memory buttons

the vehicle is moving.

(1 or 2) within 4 seconds. The sys-

This could result in loss of con-

tem will beep twice when the mem-

trol, and an accident causing

ory has been successfully stored.

death, serious injury, or property

5. "Driver 1 (or 2) settings saved" will

damage.

appear on the LCD display.

3-17

Convenient features of your vehicle

Easy access function

i

Information

CAUTION

(if equipped)

•

While recalling the "1" memory

position, pressing the SET or 1 but-

The system will move the driver's

Driver should be cautious when

ton temporarily stops the adjust-

seat automatically as follows:

using this function to assure no

ment of the recalled memory posi-

The shift lever is in P (Park)

injury to passenger or child on

tion. Pressing the 2 button recalls

the back seat. In case of emer-

• Without smart key system

the "2" memory position.

gency the driver has to stop

- It will move the driver’s seat rear-

movement of front seat (when

•

While recalling the "2" memory

ward when the ignition key is

easy access feature is activat-

position, pressing the SET or 2 but-

removed and the driver’s door is

ed) by pressing SET button or

ton temporarily stops the adjust-

opened.

any of the driver seat control

ment of the recalled memory posi-

- It will move the driver’s seat forward

switches.

tion. Pressing the 1 button recalls

when the ignition key is inserted.

the "1" memory position.

• With smart key system

•

While recalling the stored positions,

- It will move the driver’s seat rear-

pressing one of the control buttons

for the driver's seat, outside

ward when the Engine Start/Stop

button is in the OFF position and

rearview mirror, or instrument

panel illumination will cause the

the driver’s door is opened.

movement of that component to stop

- It will move the driver’s seat for-

and move in the direction that the

ward when the vehicle is turned

control button is pressed.

ON or the driver’s door is closed

with the smart key with you.

You can activate or deactivate the

Easy Access Function from the User

Settings mode on the LCD display.

For more details, refer to "LCD

Display" in this chapter.

3-18

STEERING WHEEL

Electric power steering (EPS)

i

Information

NOTICE

The system assists you with steering

The following symptoms may occur

the vehicle. If the engine is off or if

•

If the Electric Power Steering

during normal vehicle operation:

System does not operate nor-

the power steering system becomes

mally, the warning light (

) will

•

The steering effort may be high

inoperative, the vehicle may still be

illuminate or blink on the instru-

immediately after placing the igni-

steered, but it will require increased

ment cluster. The steering wheel

tion switch button in the ON posi-

steering effort.

may become difficult to control

tion.

3

Also, the steering effort becomes

or operate. Take your vehicle to

This happens as the system per-

heavier as the vehicle’s speed

an authorized HYUNDAI dealer

forms the EPS system diagnostics.

increases and becomes lighter as

and have the system checked as

When the diagnostics is completed,

the vehicle’s speed decreases for

soon as possible.

the steering wheel will return to its

better control of the steering wheel.

•

When abnormality is detected in

normal condition.

Should you notice any change in the

the electric power steering sys-

•

A click noise may be heard from the

effort required to steer during normal

tem, to prevent a deadly acci-

EPS relay after the ignition switch is

vehicle operation, we recommend

dent, the steering assist function

placed to the ON or LOCK/OFF

that the system be checked by an

will stop. At this time, the warn-

position.

authorized HYUNDAI dealer.

ing light turns on or blinks on

•

Motor noise may be heard when the

the cluster. The steering wheel

vehicle is at a stop or at a low driv-

may become difficult to control

ing speed.

or operate. Have your vehicle

•

When you operate the steering

checked immediately, after mov-

wheel in low temperature, abnormal

ing the vehicle to a safe zone.

noise may occur. If temperature

rises, the noise will disappear. This

is a normal condition.

(Continued)

3-19

Convenient features of your vehicle

(Continued)

Tilt steering / Telescope steering

• When the vehicle is stationary, if

you turn the steering wheel all the

WARNING

way to the left or right continuously,

the steering wheel effort increases.

Never adjust the steering wheel

This is not a system malfunction. As

while driving. You may lose

time passes, the steering wheel

steering control and cause

effort will return to its normal con-

severe personal injury, death or

dition.

accidents.

i

Information

OPD046012

After adjustment, sometimes the lock-

Pull down the lock-release lever (1) on

release lever may not lock the steering

the steering wheel column and adjust

wheel.

the steering wheel angle (2) and posi-

tion (3). Move the steering wheel, so it

It is not a malfunction. This occurs

points toward your chest, not toward

when two gears are not engaged cor-

your face.

rectly. In this case, adjust the steering

wheel again and then lock the steering

Make sure you can see the instrument

wheel.

panel warning lights and gauges.

After adjusting, pull up the lock-

release lever (1) to lock the steering

wheel in place. Push the steering

wheel both up and down to be cer-

tain it is locked in position. Always

adjust the position of the steering

wheel before driving.

3-20

Heated steering wheel

Horn

i

Information

(if equipped)

The heated steering wheel will turn off

automatically approximately 30 min-

utes after the heated steering wheel is

turned on.

When the engine is turned off during

the engine and the heated steering

3

wheel is on, the timer function of heat-

ed steering wheel will be reset.

To reuse heated steering wheel, press

button again.

OPD046014

NOTICE

OPDE046013

To sound the horn, press the area

Do not install any cover or acces-

When the ignition switch is in the ON

indicated by the horn symbol on your

sory on the steering wheel. This

position or when the engine is running,

steering wheel. The horn will operate

cover or accessory could cause

press the heated steering wheel but-

only when this area is pressed.

damage to the heated steering

ton to warm the steering wheel. The

wheel system.

indicator on the button will illuminate.

NOTICE

To turn the heated steering wheel off,

Do not strike the horn severely to

press the button again. The indicator

operate it, or hit it with your fist.

on the button will turn off.

Do not press on the horn with a

sharp-pointed object.

3-21

Convenient features of your vehicle

MIRRORS

Inside rearview mirror

Day/night rearview mirror

WARNING

(if equipped)

Before you start driving, adjust the

rearview mirror to the center on the

NEVER adjust the mirror while

view through the rear window.

driving. This may cause loss of

vehicle control resulting in an

accident.

WARNING

Night

Make sure your line of sight is

NOTICE

not obstructed. Do not place

objects in the rear seat, cargo

When cleaning the mirror, use a

paper towel or similar material

area, or behind the rear head-

rests which could interfere with

dampened with glass cleaner. Do

not spray glass cleaner directly on

your vision through the rear

Day

window.

the mirror as that may cause the

OAE046010

liquid cleaner to enter the mirror

Make this adjustment before you

housing.

start driving and while the day/night

WARNING

lever is in the day position.

Pull the day/night lever toward you to

To prevent serious injury during

reduce glare from the headlights of

an accident or deployment of

the vehicles behind you during night

the air bag, do not modify the

driving.

rearview mirror and do not

install a wide mirror.

Remember that you lose some

rearview clarity in the night position.

3-22

Electric Chromic Mirror (ECM)

Outside rearview mirror

(if equipped)

The electric rearview mirror automati-

cally controls the glare from the head-

lamp of the car behind you in night-

time or low light driving conditions.

When the engine is running, the

Indicator

glare is automatically controlled by

3

the sensor mounted in the rearview

mirror. The sensor detects the light

level around the vehicle, and auto-

OAD045010

matically adjusts to control the head-

lamp glare from vehicles behind you.

To operate the electric rearview

OPD046016

Whenever the shift lever is placed in

mirror:

Be sure to adjust mirror angles

R (Reverse), the mirror will automat-

• Press the ON/OFF button (1) to

before driving.

ically go to the brightest setting in

turn the automatic dimming func-

order to improve the drivers view

tion off. The mirror indicator light

Your vehicle is equipped with both

behind the vehicle.

will turn off.

left-hand and right-hand outside

rearview mirrors.

Press the ON/OFF button (1) to

turn the automatic dimming func-

The mirror can be adjusted remotely

tion on. The mirror indicator light

with the remote switch.

will illuminate.

The mirror heads can be folded to

• The mirror defaults to the ON posi-

prevent damage during an automatic

tion whenever the ignition switch is

car wash or when passing through a

in the ON position.

narrow street.

3-23

Convenient features of your vehicle

NOTICE

Adjusting the rearview mirrors

WARNING

•

Do not scrape ice off the mirror

•

The right outside rearview mir-

face; this may damage the sur-

ror is convex. In some coun-

face of the glass.

tries, the left outside rearview

•

If the mirror is jammed with ice,

mirror is also convex. Objects

do not adjust the mirror by

seen in the mirror are closer

force. Use an approved spray

than they appear.

de-icer (not radiator antifreeze)

•

Use your interior rearview

spray, or a sponge or soft cloth

mirror or turn your head and

with very warm water, or move

look to determine the actual

the vehicle to a warm place and

distance of following vehicles

allow the ice to melt.

when changing lanes.

OPDE046017

1. Press either the L (left side) or R

(right side) button (1) to select the

rearview mirror you would like to

WARNING

adjust.

Do not adjust or fold the outside

2. Use the mirror adjustment control

rearview mirrors while driving.

(2) to position the selected mirror

This may cause loss of vehicle

up, down, left or right.

control resulting in an accident.

3. After adjustment, put the button

into neutral

(center) position to

prevent inadvertent adjustment.

3-24

NOTICE

Folding the outside rearview

mirror

•

The mirrors stop moving when

they reach the maximum adjust-

ing angles, but the motor contin-

ues to operate while the switch

is pressed. Do not press the

switch longer than necessary,

3

the motor may be damaged.

•

Do not attempt to adjust the out-

side rearview mirror by hand or

the motor may be damaged.

OPDE046019

Electric type

Left : The mirror will unfold.

OPD046018

Right : The mirror will fold.

Manual type

Center (AUTO) : The mirror will fold

To fold the outside rearview mirror,

or unfold automatically as follows:

grasp the housing of the mirror and

then fold it toward the rear of the

• Without smart key system

vehicle.

- The mirror will fold or unfold when

the door is locked or unlocked by

the remote key.

• With smart key system

- The mirror will fold or unfold when

the door is locked or unlocked by

the smart key.

- The mirror will fold or unfold when

the door is locked or unlocked by

the button on the outside door

handle.

3-25

Convenient features of your vehicle

NOTICE

Reverse parking aid function

The position of the outside rearview

(if equipped)

mirror switch (1) determines whether

The electric type outside rearview

or not the mirrors will move:

mirror operates even though the

Left/Right : When either the L (Left) or

ignition switch is in the OFF posi-

R (Right) switch is select-

tion. However, to prevent unnec-

ed, both outside rearview

essary battery discharge, do not

mirrors will move.

adjust the mirrors longer than

necessary while the engine is not

Neutral : When neither switch is select-

ed, the outside rearview mir-

running.

rors will not move.

NOTICE

The outside rearview mirrors will

automatically revert to their original

Do not fold the electric type out-

positions if any of the following occur:

side rearview mirror by hand. It

OPDE046423

• The ignition switch is placed to

could cause motor failure.

either the LOCK/OFF position or

When you move the shift lever to the

the ACC position.

R (Reverse) position, the outside

• The shift lever is moved to any

rearview mirror(s) will rotate down-

position except R (Reverse).

wards to aid with driving in reverse.

• The outside rearview mirror switch

is not selected.

3-26

WINDOWS

Power windows (if equipped)

(1) Driver’s door power window

switch

(2) Front passenger’s door power

window switch

(3) Rear door (left) power window

switch*

3

(4) Rear door (right) power window

switch*

(5) Window opening and closing

(6) Automatic power window*

(7) Power window lock switch

* : if equipped

OPDE046021

3-27

Convenient features of your vehicle

The ignition switch must be in the ON

Window opening and closing

i

Information

position to be able to raise or lower

the windows. Each door has a Power

•

In cold and wet climates, power win-

Window switch to control that door's

dows may not work properly due to

window. The driver has a Power

freezing conditions.

Window Lock switch which can block

•

While driving with the rear win-

the operation of passenger windows.

dows down or with the sunroof (if

The power windows will operate for

equipped) opened

(or partially

approximately 30 seconds after the

opened), your vehicle may demon-

ignition switch is placed in the ACC

strate a wind buffeting or pulsation

or OFF position. However, if the front

noise. This noise is normal and can

doors are opened, the Power

be reduced or eliminated by taking

Windows cannot be operated even

the following actions. If the noise

within the 30 second period.

occurs with one or both of the rear

OAE046020

windows down, partially lower both

To open:

front windows approximately one

WARNING

Press the window switch down to the

inch. If you experience the noise

first detent position (5). Release the

with the sunroof open, slightly close

To avoid serious injury or death,

switch when you want the window to

the sunroof.

do not extend your head, arms

stop.

or body outside the windows

while driving.

To close:

Pull the window switch up to the first

detent position (5). Release the win-

dow switch when you want the win-

dow to stop.

3-28

Auto down window (if equipped)

To reset the power windows

Automatic reversal (if equipped)

Pressing the power window switch

If the power windows do not operate

momentarily to the second detent

normally, the automatic power win-

position

(6) completely lowers the

dow system must be reset as follows:

window even when the switch is

1. Place the ignition switch to the ON

released. To stop the window at the

position.

desired position while the window is

2. Close the window and continue

in operation, pull up or press down

3

pulling up on the power window

and release the switch.

switch for at least one second.

If the power windows do not operate

Auto up/down window

properly after resetting, it is recom-

(if equipped)

mended that the system be checked

Pressing or pulling up the power win-

by an authorized HYUNDAI dealer.

OLF044032

dow switch momentarily to the sec-

If a window senses any obstacle

ond detent position

(6) completely

while it is closing automatically, it will

lowers or lifts the window even when

stop and lower approximately 30 cm

the switch is released. To stop the

(12 inches) to allow the object to be

window at the desired position while

cleared.

the window is in operation, pull up or

If the window detects the resistance

press down and release the switch.

while the power window switch is

pulled up continuously, the window

will stop upward movement then

lower approximately 2.5 cm (1 inch).

If the power window switch is pulled

up continuously again within 5 sec-

onds after the window is lowered by

the automatic window reversal fea-

ture, the automatic window reversal

will not operate.

3-29

Convenient features of your vehicle

Power window lock switch

i

Information

WARNING

The automatic reverse feature is only

active when the “Auto Up” feature is

Do not allow children to play

used by fully pulling up the switch to

with the power windows. Keep

the second detent.

the driver’s door power window

lock switch in the LOCK posi-

tion. Serious injury or death can

WARNING

result from unintentional win-

dow operation by a child.

Make sure body parts or other

objects are safely out of the way

before closing the windows to

NOTICE

avoid injuries or vehicle damage.

OPDE046023

•

To prevent possible damage to

Objects less than 4 mm (0.16

the power window system, do

inch) in diameter caught between

The driver can disable the power

not open or close two windows

the window glass and the upper

window switches on the rear passen-

or more at the same time. This

window channel may not be

gers' doors by pressing the power

will also ensure the longevity of

detected by the automatic reverse

window lock switch.

the fuse.

window and the window will not

When the power window lock switch

stop and reverse direction.

•

Never try to operate the main

is pressed:

switch on the driver's door and

• The driver's master control can

the individual door window

operate all the power windows.

switch in opposite directions at

• The front passenger's control can

the same time. If this is done, the

operate the front passenger's

window will stop and cannot be

power window.

opened or closed.

• The rear passenger's control can-

not operate the rear passengers'

power window.

3-30

Content   ..  4  5  6  7   ..
