Hyundai H350 (2016 year). Instruction

Maintenance

NOTICE

CAUTION

Basically equipped battery is

•

When replacing the battery,

maintenance free type. If your

we recommend that you use

vehicle is equipped with the bat-

parts replacement from an

tery marked with LOWER and

authorized HYUNDAI dealer.

UPPER on the side, you can check

•

There is a vent hose for

the electrolyte level. The elec-

trolyte level should be between

degasing. You must check the

connection for venting when

LOWER and UPPER. If the elec-

trolyte level is low, it needs to add

you change the battery.

distilled

(demineralized) water

OEU074025

(Never add sulfuric acid or other

Battery sensor

Auxiliary battery (VAN/Truck)

electrolyte). When refill, be careful

The auxiliary battery is located in

not to splash the battery and adja-

engine room. (if equipped)

cent components. And do not

overfill the battery cells. It can

• Keep the battery securely mount-

cause corrosion on other parts.

ed.

After then ensure that tighten the

• Keep the battery top clean and dry.

Vent hose

cell caps. We recommend that you

• Keep the terminals and connec-

contact an authorized HYUNDAI

tions clean, tight, and coated with

dealer.

OEU075075

petroleum jelly or terminal grease.

• Rinse any spilled electrolyte from

WARNING

the battery immediately with a

solution of water and baking soda.

Do not open the AGM battery.

7-38

WARNING

(Continued)

If any electrolyte gets

• When lifting a plastic-cased

Battery dangers

into your eyes, flush

battery, excessive pressure

your eyes with clean

on the case may cause battery

Always read the follow-

water for at least 15 min-

acid to leak, resulting in per-

ing instructions carefully

utes and get immediate

sonal injury. Lift with a battery

when handling a battery.

medical attention.

carrier or with your hands on

Keep lighted cigarettes

opposite corners.

If electrolyte gets on

and all other flames or

your skin, thoroughly

• Never attempt to recharge the

sparks away from the

wash the contacted

battery when the battery

battery.

area. If you feel a pain or

cables are connected.

Hydrogen, a highly com-

a burning sensation, get

• The electrical ignition system

bustible gas, is always

medical attention imme-

works with high voltage.

present in battery cells

diately.

Never touch these compo-

and may explode if ignit-

Wear eye protection

nents with the engine running

ed.

when charging or work-

or the ignition switched on.

Keep batteries out of the

ing near a battery.

Failure to follow the above

reach

children

Always provide ventila-

warnings can result in serious

because batteries con-

tion when working in an

bodily injury or death.

tain highly corrosive

enclosed space.

SULFURIC ACID. Do not

An inappropriately dis-

allow battery acid to

posed battery can be

contact your skin, eyes,

CAUTION

harmful to the environ-

clothing or paint finish.

ment and human health.

If you connect unauthorized

(Continued)

Dispose the battery

electronic devices to the bat-

according to your local

tery, the battery may be dis-

law(s) or regulation.

charged. Never use unautho-

(Continued)

rized devices.

7-39

Maintenance

Battery capacity label

Battery recharging

CAUTION

■ Example

Your vehicle has a maintenance-free,

calcium-based battery.

For the vehicle equipped with

•

If the battery becomes discharged

ISG system (AGM battery), be

in a short time (because, for exam-

careful not to damage the bat-

ple, the headlights or interior lights

tery sensor when the battery is

were left on while the vehicle was

replaced or recharged.

not in use), recharge it by slow

1) When replacing the battery, it

charging (trickle) for 10 hours.

should be same one (type,

•

If the battery gradually discharges

capacity and brand) that is

because of high electric load while

originally installed on your

the vehicle is being used, recharge

vehicle. If a battery of a dif-

OEU074074

it at 20-30A for two hours.

ferent type is replaced, bat-

tery sensor may recognize

❈ The actual battery label in the vehicle

the battery to be abnormal.

may differ from the illustration.

2) When installing the ground

cable on the negative post of

1. CMF100L-DIN

: The HYUNDAI

battery, tighten the clamp

model name of battery

with specified torque of 4.0 ~

2.12V : The nominal voltage

6.0 N.m (0.4 ~ 0.6 kgf.m, 3.0 ~

3.100Ah(20HR) : The

nominal

4.41 lb-ft). An excessive tight-

capacity

(in

ening torque can damage the

Ampere hours)

PCB internal circuit.

4.190RC : The nominal reserve

3) When recharging the battery,

capacity (in min.)

ground the negative terminal

5.780CCA (SAE) : The cold-test cur-

of the booster battery to the

rent in amperes by SAE

vehicle body.

6.625A (EN) : The cold-test current

in amperes by EN

7-40

WARNING

(Continued)

WARNING

• Disconnect the battery charg-

Recharging battery

er in the following order.

• Before performing mainte-

nance or recharging the bat-

When recharging the battery,

1. Turn off the battery charger

tery, turn off all accessories

observe the following precau-

main switch.

and stop the engine.

tions:

2. Unhook the negative clamp

• The negative battery cable

•

The battery must be removed

from the negative battery ter-

must be removed first and

from the vehicle and placed in

minal.

installed last when the battery

an area with good ventilation.

3. Unhook the positive clamp

is disconnected.

•

Do not allow cigarettes,

from the positive battery ter-

• Do not open the AGM battery.

sparks, or flame near the bat-

minal.

tery.

4. After recharging, park the

•

Watch the battery during

vehicle for about 5 hours with

Reset items

charging, and stop or reduce

the hood and all doors

the charging rate if the battery

closed. During this period,

Items should be reset after the bat-

cells begin gassing (boiling)

the dark current must be

tery has been discharged or the bat-

violently or if the temperature

under

100mA.(AGM battery

tery has been disconnected.

of the electrolyte of any cell

only)

• Auto up/down window

exceeds 49°C (120°F).

(See section 3)

•

Do not charge the AGM bat-

• Trip computer (See section 3)

tery with over 14.5V. No quick-

• Climate control system

charging routines

(See section 3)

•

Wear eye protection when

• Clock (See section 3)

checking the battery during

• Audio (See section 4)

charging.

(Continued)

7-41

Maintenance

TIRES AND WHEELS

Tire care

WARNING

(Continued)

For proper maintenance, safety, and

And it can lead to deformation

maximum fuel economy, you must

•

Overinflation or underinfla-

or abnormal wear of wheel,

always maintain recommended tire

tion can reduce tire life,

severe heat build-up, causing

inflation pressures and stay within

adversely affect vehicle han-

blowouts, tread separation

the load limits and weight distribution

dling, and lead to sudden tire

and other tire failures that can

recommended for your vehicle.

failure. You must always main-

result in the loss of vehicle

tain recommended tire pres-

control leading to severe

Recommended cold tire infla-

sures.

injury or death. This risk is

tion pressures

much higher on hot days and

Warm tires normally exceed

recommended cold tire pres-

when driving for long periods

All tire pressures

(including the

at high speeds.

sures by 28 to 41 kPa (4 to 6

spare) should be checked when the

psi). Do not release air from

If the problem is not solved (a

tires are cold. “Cold Tires” means the

warm tires to adjust the pres-

tire frequently needs refilling),

vehicle has not been driven for at

sure or the tires will be under-

we recommend that the sys-

least three hours or driven less than

inflated.

tem be checked by an author-

1.6 km (1 mile).

•

Tire underinflation

ized HYUNDAI dealer.

Recommended pressures must be

•

Tire overinflation

maintained for the best ride, top vehi-

If the tire pressure drops

cle handling, and minimum tire wear.

repeatedly, the wheel, valve or

Tires with excessively high

tire may be damaged.

pressure can burst because

For recommended inflation pressure

they are damaged more easily

refer to “Tire and wheels” in section

Underinflation results in

reducing fitness of tire and

by road debris, potholes etc.

wheel, excessive wear, poor

In addition, they also produce

handling and reduced fuel

a harsh ride, excessive wear

economy.

at the center of the tire tread,

(Continued)

and a greater possibility of

damage from road hazards.

7-42

Checking tire inflation pres-

CAUTION

sure

•

Warm tires normally exceed

Tire pressure

Check your tires once a month or

more.

recommended cold tire pres-

Always observe the following:

sures by 28 to 41 kPa (4 to 6

Also, check the tire pressure of the

•

Check tire pressure when the

psi). Do not release air from

spare tire.

warm tires to adjust the pres-

tires are cold. (After vehicle

has been parked for at least

sure or the tires will be under-

How to check

inflated.

three hours or hasn't been

driven more than 1.6 km (1

Use a good quality gage to check tire

•

Be sure to reinstall the tire

mile) since startup.)

pressure. You can not tell if your tires

inflation valve caps. Without

are properly inflated simply by look-

•

Check the pressure of your

the valve cap, dirt or moisture

ing at them. Radial tires may look

could get into the valve core

spare tire each time you check

properly inflated even when they're

the pressure of other tires.

and cause air leakage. If a

underinflated.

valve cap is missing, install a

•

Never overload your vehicle.

Check the tire's inflation pressure

new one as soon as possible.

Be careful not to overload a

when the tires are cold.

- "Cold"

vehicle luggage rack if your

means your vehicle has been sitting

vehicle is equipped with one.

for at least three hours or driven no

WARNING

•

Worn, old tires can cause

more than 1.6 km (1 mile).

accidents. If your tread is

Tire inflation

badly worn, or if your tires

have been damaged, replace

Overinflation or underinflation

them.

can reduce tire life, adversely

affect vehicle handling, and

lead to sudden tire failure. This

could result in loss of vehicle

control and potential injury.

7-43

Maintenance

Remove the valve cap from the tire

Tire rotation

WARNING

valve stem. Press the tire gage firm-

To equalize tread wear, it is recom-

ly onto the valve to get a pressure

mended that the tires be rotated

•

Inspect your tires frequently

measurement. If the cold tire inflation

every 12,000 km (7,500 miles) or

pressure matches the recommended

for proper inflation as well as

sooner if irregular wear develops.

wear and damage. Always use

pressure on the tire and loading

information label, no further adjust-

a tire pressure gauge.

During rotation, check the tires for

correct balance.

ment is necessary. If the pressure is

•

Tires with too much or too lit-

low, add air until you reach the rec-

tle pressure wear unevenly

When rotating tires, check for uneven

ommended amount.

causing poor handling, loss of

wear and damage. Abnormal wear is

If you overfill the tire, release air by

vehicle control, and sudden

usually caused by incorrect tire pres-

tire failure leading to acci-

sure, improper wheel alignment, out-

pushing on the metal stem in the

center of the tire valve. Recheck the

dents, injuries, and even

of-balance wheels, severe braking or

death. The recommended cold

severe cornering. Look for bumps or

tire pressure with the tire gage. Be

sure to put the valve caps back on

tire pressure for your vehicle

bulges in the tread or side of tire.

can be found in this manual

Replace the tire if you find either of

the valve stems. They help prevent

leaks by keeping out dirt and mois-

and on the tire label located

these conditions. Replace the tire if

on the driver's side center pil-

fabric or cord is visible. After rotation,

ture.

lar.

be sure to bring the front and rear tire

pressures to specification and check

•

Worn tires can cause acci-

lug nut tightness.

dents. Replace tires that are

worn, show uneven wear, or

Refer to “Tire and wheels” in section

are damaged.

•

Remember to check the pres-

sure of your spare tire.

HYUNDAI recommends that

you check the spare every

time you check the pressure

of the other tires on your vehi-

cle.

7-44

With a full-size spare tire (if equipped)

Disc brake pads should be inspected

Wheel alignment and tire bal-

for wear whenever tires are rotated.

ance

The wheels on your vehicle were

NOTICE

aligned and balanced carefully at the

factory to give you the longest tire life

Rotate radial tires that have an

and best overall performance.

asymmetric tread pattern only

from front to rear and not from

In most cases, you will not need to

right to left.

have your wheels aligned again.

S2BLA790

However, if you notice unusual tire

Without a spare tire

wear or your vehicle pulling one way

WARNING

or the other, the alignment may need

to be reset.

• Do not use the compact spare

tire for tire rotation.

If you notice your vehicle vibrating

when driving on a smooth road, your

• Do not mix bias ply and radial

wheels may need to be rebalanced.

ply tires under any circum-

stances. This may cause

unusual handling characteris-

CAUTION

S2BLA790A

tics that could result in death,

Directional tires (if equipped)

severe injury, or property

Improper wheel weights can

damage.

damage your vehicle's alu-

minum wheels. Use only

approved wheel weights.

CBGQ0707A

7-45

Maintenance

Tire replacement

CAUTION

WARNING

Tread wear indicator

When replacing the tires,

Replacing tires

recheck and tighten the wheel

•

Driving on worn-out tires is

nuts after driving about 1,000

very hazardous and will

km (620miles). If the steering

reduce braking effectiveness,

wheel shakes or the vehicle

steering accuracy, and trac-

vibrates while driving, the tire is

tion.

out of balance. Align the tire

balance. If the problem is not

•

Your vehicle is equipped with

solved, we recommend that you

tires designed to provide for

contact an authorized HYUNDAI

safe ride and handling capa-

dealer.

bility. Do not use a size and

OEN076053

type of tire and wheel that is

If the tire is worn evenly, a tread wear

different from the one that is

indicator will appear as a solid band

originally installed on your

across the tread. This shows there is

vehicle. It can affect the safety

less than 1.6 mm (1/16 in.) of tread

and performance of your vehi-

left on the tire. Replace the tire when

cle, which could lead to han-

this happens.

dling failure or rollover and

Do not wait for the band to appear

serious injury. When replacing

the tires, be sure to equip all

across the entire tread before replac-

ing the tire.

four tires with the tire and

wheel of the same size, type,

tread, brand and load-carrying

capacity.

(Continued)

7-46

Wheel replacement

Tire traction

(Continued)

When replacing the metal wheels for

Tire traction can be reduced if you

•

The use of any other tire size

any reason, make sure the new

drive on worn tires, tires that are

or type may seriously affect

wheels are equivalent to the original

improperly inflated or on slippery

ride, handling, ground clear-

factory units in diameter, rim width

road surfaces. Tires should be

ance, stopping distance, body

and offset.

replaced when tread wear indicators

to tire clearance, snow tire

appear. To reduce the possibility of

clearance, and speedometer

losing control, slow down whenever

reliability.

WARNING

there is rain, snow or ice on the road.

•

It is best to replace all four

tires at the same time. If that

A wheel that is not the correct

is not possible, or necessary,

size may adversely affect wheel

Tire maintenance

then replace the two front or

and bearing life, braking and

In addition to proper inflation, correct

stopping abilities, handling

two rear tires as a pair.

wheel alignment helps to decrease

characteristics, ground clear-

Replacing just one tire can

tire wear. If you find a tire is worn

ance, body-to-tire clearance,

seriously affect your vehicle’s

unevenly, have your dealer or other

handling.

snow

chain

clearance,

repair shops that use qualified tech-

speedometer and odometer cal-

•

The ABS works by comparing

nicians check the wheel alignment.

ibration, headlight aim and

the speed of the wheels. Tire

When you have new tires installed,

bumper height.

size can affect wheel speed.

make sure they are balanced. This

When replacing tires, all

will increase vehicle ride comfort and

tires must use the same size

tire life. Additionally, a tire should

originally supplied with the

always be rebalanced if it is removed

vehicle. Using tires of a differ-

from the wheel.

ent size can cause the ABS

(Anti-lock Brake System) and

ESP

(Electronic Stability

Program)

(if equipped) to

work irregularly.

7-47

Maintenance

Tire sidewall labeling

2. Tire size designation

113 - Load Index, a numerical code

associated with the maximum

A tire’s sidewall is marked with a tire

load the tire can carry. (Dual

size designation. You will need this

Trie)

information when selecting replace-

ment tires for your vehicle. The fol-

115 - Load Index, a numerical code

lowing explains what the letters and

associated with the maximum

numbers in the tire size designation

load the tire can carry. (Single

mean.

Tire)

Example tire size designation:

R - Speed Rating Symbol. See the

speed rating chart in this section

(These numbers are provided as an

for additional information.

example only; your tire size designa-

tor could vary depending on your

OEU064042

vehicle.)

Wheel size designation

This information identifies and

235/65R16 115/113R

Wheels are also marked with impor-

describes the fundamental charac-

tant information that you need if you

teristics of the tire and also provides

ever have to replace one. The follow-

235 - Tire width in millimeters.

the tire identification number

(TIN)

ing explains what the letters and

65 - Aspect ratio. The tire’s section

for safety standard certification. The

numbers in the wheel size designa-

height as a percentage of its

TIN can be used to identify the tire in

tion mean.

width.

case of a recall.

R - Tire construction code (Radial).

Example wheel size designation:

16 - Rim diameter in inches.

1. Manufacturer or brand name

16X6.5J

Manufacturer or Brand name is

shown.

16 - Rim diameter in inches.

6.5 - Rim width in inches.

J - Rim contour designation.

7-48

Tire speed ratings

3. Checking tire life

WARNING

The chart below lists many of the dif-

(TIN : Tire Identification

ferent speed ratings currently being

Number)

Tire age

used for passenger vehicles. The

Any tires that are over 6 years, based

speed rating is part of the tire size

on the manufacturing date, tire

Tires degrade over time, even

designation on the sidewall of the

strength and performance, decline

when they are not being used.

tire. This symbol corresponds to that

with age naturally

(even unused

Regardless of the remaining

tire's designed maximum safe oper-

spare tires). Therefore, the tires

tread, it is recommended that

ating speed.

(including the spare tire) should be

tires generally be replaced after

replaced by new ones. You can find

six (6) years of normal service.

Speed Rating

Heat caused by hot climates or

Maximum Speed

the manufacturing date on the tire

Symbol

frequent high loading condi-

sidewall (possibly on the inside of the

160 km/h (99 mph)

wheel), displaying the DOT Code.

tions can accelerate the aging

The DOT Code is a series of num-

process. Failure to follow this

170

km/h (106 mph)

bers on a tire consisting of numbers

Warning can result in sudden

180

km/h (112 mph)

tire failure, which could lead to

and English letters. The manufactur-

190

km/h (118 mph)

ing date is designated by the last four

a loss of control and an acci-

digits (characters) of the DOT code.

dent involving serious injury or

200

km/h (124 mph)

death.

DOT : XXXX XXXX OOOO

The front part of the DOT means a

plant code number, tire size and

tread pattern and the last four num-

bers indicate week and year manu-

factured.

For example:

DOT XXXX XXXX 1615 represents

that the tire was produced in the 16th

week of 2015.

7-49

Maintenance

FUSES

4. Tire ply composition and

6. Maximum load rating

material

This number indicates the maximum

The number of layers or plies of rub-

load in kilograms and pounds that

ber-coated fabric are in the tire. Tire

can be carried by the tire. When

Normal

Blown

manufacturers also must indicate the

replacing the tires on the vehicle,

materials in the tire, which include

always use a tire that has the same

steel, nylon, polyester, and others.

load rating as the factory installed

The letter "R" means radial ply con-

tire.

struction; the letter "D" means diago-

nal or bias ply construction; and the

Normal

Blown

letter "B" means belted-bias ply con-

struction.

5. Maximum permissible infla-

tion pressure

Normal

Blown

1VQA4037

This number is the greatest amount

of air pressure that should be put in

A vehicle’s electrical system is pro-

the tire. Do not exceed the maximum

tected from electrical overload dam-

permissible inflation pressure. Refer

age by fuses.

to the Tire and Loading Information

This vehicle has 3 fuse panels, one

label for recommended inflation

located in the driver’s side panel bol-

pressure.

ster, the other in the engine compart-

ment near the battery.

If any of your vehicle’s lights, acces-

sories, or controls do not work, check

the appropriate circuit fuse. If a fuse

has blown, the element inside the

fuse will be melted.

7-50

If the electrical system does not

WARNING

CAUTION

work, first check the driver’s side

fuse panel.

Fuse replacement

•

When replacing a blown fuse

Before replacing a blown fuse, dis-

or relay with a new one, make

connect the negative battery cable.

•

Never replace a fuse with any-

sure the new fuse or relay fits

thing but another fuse of the

Always replace a blown fuse with

tightly into the clips. The

same rating.

one of the same rating.

incomplete fastening fuse or

•

A higher capacity fuse could

If the replacement fuse blows, this

relay may cause the vehicle

indicates an electrical problem. Avoid

cause damage and possibly a

wiring and electric systems

fire.

using the system involved and we

damage and a possible fire.

recommend that you consult an

•

Never install a wire or alu-

•

Do not remove fuses, relays

authorized HYUNDAI dealer.

minum foil instead of the

and terminals fastened with

Three kinds of fuses are used: blade

proper fuse - even as a tem-

bolts or nuts. The fuses,

porary repair. It may cause

type for lower amperage rating, car-

relays and terminals may be

tridge type, and fusible link for higher

extensive wiring damage and

fastened incompletely, and it

a possible fire.

amperage ratings.

may cause a possible fire. If

fuses, relays and terminals

fastened with bolts or nuts are

CAUTION

blown, consult with an author-

ized HYUNDAI dealer.

Do not use a screwdriver or any

•

Do not input any other objects

other metal object to remove

except fuses or relays into

fuses because it may cause a

fuse/relay terminals such as a

short circuit and damage the

driver or wiring. It may cause

system.

contact failure and system

malfunction.

NOTICE

The actual fuse/relay panel label

may differ from equipped items.

7-51

Maintenance

Inner panel fuse replacement

1.Turn the ignition switch and all

other switches off.

■ Driver’s side panel

2.Open the fuse panel cover.

OEU074027

■ Driver’s seat side

OEU074029

3.Pull the suspected fuse straight

out. Use the removal tool provided

in the engine compartment fuse

panel.

4.Check the removed fuse; replace it

if it is blown.

5.Push in a new fuse of the same rat-

OEU074026

ing, and make sure it fits tightly in

■ Main battery

the clips.

If it fits loosely, we recommend that

you consult an authorized HYUNDAI

dealer.

If you do not have a spare, use a

fuse of the same rating from a circuit

you may not need for operating the

vehicle, such as the cigar lighter

OEU074028

fuse.

7-52

If the headlights or other electrical

Engine compartment panel fuse

CAUTION

components do not work and the

replacement

fuses are OK, check the fuse block in

After checking the fuse box in

the engine compartment. If a fuse is

the engine compartment,

blown, it must be replaced.

securely install the fuse box

cover. If not, electrical failures

may occur from water leaking

in.

OEU074029

1.Turn the ignition switch and all

other switches off.

2.Remove the fuse box cover by

pressing the tap and pulling up.

3.Check the removed fuse; replace it

if it is blown. To remove or insert

the fuse, use the fuse puller in the

engine compartment fuse panel.

4.Push in a new fuse of the same rat-

ing, and make sure it fits tightly in

the clips.

If it fits loosely, we recommend that

you consult an authorized

HYUNDAI dealer.

7-53

Maintenance

Alternator fuse

Multi fuse

NOTICE

If the main fuse is blown, we rec-

ommend that you consult an

authorized HYUNDAI dealer.

OEU074036

OEU074037

If the main fuse is blown, it must be

If the multi fuse is blown, it must be

removed as follows:

1.Turn off the engine.

2.Disconnect the negative battery

cable.

3.Remove the nuts shown in the pic-

3.Remove the fuse panel on the right

ture above.

side in the engine compartment.

4.Replace the fuse with a new one of

4.Remove the nuts shown in the pic-

the same rating.

ture above.

5.Reinstall in the reverse order of

5.Replace the fuse with a new one of

removal.

the same rating.

6.Reinstall in the reverse order of

removal.

7-54

Hyundai H350 (2016 year). Instruction - part 24
