Engine Overheat
Air bag Warning Light
Low Fuel Level
Warning Light
(if equipped)
Warning Light
This indicates a coolant temperature.
This warning light illuminates:
This warning light illuminates:
When a temperature is above the
•
Once you set the ignition switch to
When the fuel tank is nearly empty.
normal range, the engine overheat
the ON position.
3
warning light illuminates.
- It illuminates for approximately 6
This warning light blinks:
When there is a telecommunication
seconds and then goes off.
When the fuel sensor is disconnect-
error, the engine overheat warning
•
When there is a malfunction with
ed.
light blinks.
the SRS.
In this case, we recommend that
If the fuel tank is nearly empty:
WARNING
you have the vehicle inspected by
an authorized HYUNDAI dealer.
Add fuel as soon as possible.
The illumination of the engine
overheat warning light indicates
NOTICE
- Low Fuel Level
that the engine is over-heated.
Driving with the Low Fuel Level
Refer to the chapter 6, "What to
warning light on or with the fuel
Do in an Emergency."
level below “0 or E” can cause the
engine to misfire and damage the
catalytic converter (if equipped).
3-67
Convenient features of your vehicle
Immobilizer Indicator
Turn Signal Indicator
Low Beam Indicator
Light (if equipped)
Light
Light (if equipped)
This indicator light illuminates:
This indicator light blinks:
This indicator light illuminates:
When the vehicle detects the immo-
• When you turn the turn signal light
• When the headlights are on.
bilizer in your key properly while the
on.
ignition switch is ON.
- At this time, you can start the engine.
If any of the following occurs, there
High Beam Indicator
- The indicator light goes off after
may a malfunction with the turn signal
Light
starting the engine.
system. In this case, we recommend
that you have the vehicle inspected by
an authorized HYUNDAI dealer.
This indicator light blinks:
This indicator light illuminates:
- The indicator light does not blink
When there is a malfunction with the
• When the headlights are on and in
but illuminates.
immobilizer system.
the high beam position
- The indicator light blinks more
In this case, we recommend that you
• When the turn signal lever is pulled
rapidly.
have the vehicle inspected by an
into the Flash-to-Pass position.
- The indicator light does not illumi-
authorized HYUNDAI dealer.
nate at all.
WARNING
Do not use high beam when
there are other vehicles. Using
high beam could obstruct the
other driver's vision.
3-68
Light ON indicator light
Parking brake warning
Low brake fluid level
light
warning light
This indicator illuminates when the
The parking brake warning light
WARNING
tail lights or headlights are on or
should come on when the parking
when the lights switch is turned to
brake is applied and the ignition
If you suspect brake trouble, we
3
“AUTO” position.
switch is turned to "ON" or "START".
recommend that the system be
After the engine is started, the light
checked by an authorized
should go out when the parking
HYUNDAI dealer. Driving your
brake is released.
Front Fog Indicator
vehicle with a problem in either
Light (if equipped)
If the parking brake is not applied,
the brake electrical system or
the warning light should come on
brake hydraulic system is dan-
and warning buzzer sounds when
gerous, and could result in a
the ignition switch is turned to "ON"
serious injury or death.
This indicator light illuminates:
or "START" with specified speed,
• When the front fog lights are on.
then go out when the engine starts. If
the light comes on at any other time,
you should slow the vehicle and
bring it to a complete stop in a safe
Rear Fog Indicator
location off the roadway.
Light (if equipped)
If you drive while parking brake is
applied, the parking brake warning
This indicator light illuminates:
light comes on and warning buzzer
• When the rear fog lights are on.
sounds simultaneously.
3-69
Convenient features of your vehicle
Warning light operation
Anti-lock Brake System
Electronic Brake force
The brake fluid level warning light
(ABS) Warning Light
Distribution (EBD)
indicates that the brake fluid level in
System Warning Light
the brake master cylinder is low and
hydraulic brake fluid conforming to
This warning light illuminates:
SAE J1703 specifications should be
• Once you set the ignition switch to
added. After adding fluid, if no other
the ON position.
These two warning lights illuminate
trouble is found, we recommend that
- It illuminates for approximately 3
at the same time while driving:
the system be inspected by an
seconds and then goes off.
• When the ABS and regular brake
authorized HYUNDAI dealer. If fur-
ther trouble is experience, we recom-
• When there is a malfunction with
system may not work normally.
mend that you contact an authorized
the ABS (The normal braking sys-
In this case, we recommend that
HYUNDAI dealer.
tem will still be operational without
you have the vehicle inspected by
the assistance of the anti-lock
an authorized HYUNDAI dealer.
brake system).
In this case, we recommend that
you have the vehicle inspected by
an authorized HYUNDAI dealer.
3-70
Vehicle Dynamic
i
Information - Electronic
WARNING
Control (VDC) Indicator
Brake force Distribution (EBD)
Light
System Warning Light
Electronic Brake force
Distribution (EBD) System
When the ABS Warning Light is on or
Warning Light
both ABS and EBD are on, the
This indicator light illuminates:
speedometer, odometer, or tripmeter
• Once you set the ignition switch to
When both ABS and EBD are
may not work.
the ON position.
on, the brake system will not
3
work normally and you may
In this case, we recommend you have
- It illuminates for approximately 3
experience an unexpected and
the vehicle inspected by an authorized
seconds and then goes off.
dangerous situation during
HYUNDAI dealer as soon as possible.
• When there is a malfunction with
sudden braking.
the VDC system.
In this case, avoid high speed
In this case, we recommend that
driving and abrupt braking.
you have the vehicle inspected by
We recommend you have the
an authorized HYUNDAI dealer.
vehicle inspected by an author-
ized HYUNDAI dealer as soon
This indicator light blinks:
as possible.
While the VDC is operating.
For more details, refer to “Vehicle
Dynamic Control (VDC)” in chapter
5.
3-71
Convenient features of your vehicle
Vehicle Dynamic
ECO Mode Indicator
Cruise Indicator Light
Control (VDC) OFF
Light (if equipped)
ECO
(if equipped)
Indicator Light
This indicator light illuminates:
This indicator light illuminates:
This indicator light illuminates:
Once you set the ignition switch to
• When you select “ECO” mode as
• When the cruise control system is
drive mode.
enabled.
the ON position.
- It illuminates for approximately
3 seconds and then goes off.
WARNING
For more details, refer to “Cruise
Control System” in chapter 5.
For more details, refer to “Vehicle
Do not watch the ECO indicator
Dynamic Control (VDC)” in chapter
light while driving. This will dis-
5.
tract you and may cause an
Cruise SET Indicator
accident that results in severe
Light (if equipped)
SET
personal injury.
This indicator light illuminates:
• When the cruise control speed is
set.
For more details, refer to “Cruise
Control System” in chapter 5.
3-72
Auto stop indicator
Engine Oil Pressure
Malfunction indicator
(if equipped)
Warning Light
lamp (MIL)
(check engine light)
This indicator will illuminate when the
This warning light illuminates:
This indicator light is part of the
engine enters the Idle Stop mode of
Engine Control System which moni-
• Once you set the ignition switch to
the ISG (Idle Stop and Go) system.
tors various emission control system
the ON position.
components. If this light illuminates
3
When the automatic starting occurs,
- It remains on until the engine is
while driving, it indicates that a
the auto stop indicator on the cluster
started.
potential problem has been detected
will blink for few seconds.
• When the engine oil pressure is low.
somewhere in the emission control
system.
For more details, refer to the ISG
If the engine oil pressure is low:
This light will also illuminate when
(Idle Stop and Go) system in the
the ignition switch is turned to the
chapter 5.
1. Drive carefully to the nearest safe
ON position, and will go out in a few
location and stop your vehicle.
seconds after the engine is started. If
i
Information
2. Turn the engine off and check the
it illuminates while driving, or does
engine oil level (For more details,
When the engine automatically starts
not illuminate when the ignition key is
refer to “Engine Oil” in chapter 7).
by the ISG system, some warning
turned to the ON position, we recom-
If the level is low, add oil as required.
lights
(ABS/EBD/VDC/VDC OFF)
mend that the system be checked by
If the warning light remains on
an authorized HYUNDAI dealer.
may turn on for a few seconds.
after adding oil or if oil is not avail-
This happens because of the low bat-
Generally, your vehicle will continue
able, we recommend that you
tery voltage. It does not mean the sys-
to be drivable, but we recommend
have the vehicle inspected by an
tem is malfunctioning.
that the system be checked by an
authorized HYUNDAI dealer as
authorized HYUNDAI dealer.
soon as possible.
3-73
Convenient features of your vehicle
NOTICE
Charging System
If there is a malfunction with either
Warning Light
the alternator or electrical charging
Prolonged driving with the
system:
Emission
Control
System
1. Drive carefully to the nearest safe
Malfunction Indicator Light illumi-
This warning light illuminates:
location and stop your vehicle.
nated may cause damage to the
emission control systems which
•
Once you set the ignition switch to
2. Turn the engine off and check the
could effect drivability and/or fuel
the ON position.
alternator drive belt for looseness
economy.
or breakage.
- It remains on until the engine is
started.
If the belt is adjusted properly,
NOTICE
there may be a problem in the
•
When there is a malfunction with
electrical charging system.
Diesel engine
either the alternator or electrical
charging system.
In this case, we recommend that
If the Emission Control System
you have the vehicle inspected by
Malfunction Indicator Light blinks,
an authorized HYUNDAI dealer as
some error related to the injection
soon as possible.
quantity adjustment occurs which
could result in loss of engine
power, combustion noise and
poor emission. We recommend
that the system be inspected by
an authorized HYUNDAI dealer.
3-74
Lane departure warn-
Tachograh
Master Warning Light
ing system (LDWS)
(if equipped)
T
(if equipped)
The warning light illuminates, if
The warning light illuminates, if an
The Master Warning Light illumi-
LDWS cannot identify any lane
error in a tachograph is detected.
nates, when one of the following sys-
departure due to a system malfunc-
Have your vehicle inspected by an
tem malfunctions occurs. More
details about a malfunction will be
3
tion, snow, or dirt.
HYUNDAI authorized dealer.
displayed on the LCD display.
❈
In case of a communications fail-
ure, the warning light flashes in
The Master Warning Light illumi-
nates, when there is a malfunction
the amber color.
with one of the followings:
- Lamp disconnection
WARNING
- DPF check-up
•
There will be a warning sound
- Service alarm
if you change the lane without
Situations, where the Master
turning ON the turn signal
Warning Light illuminates, may be
switch.
various. When a warning situation is
•
Change the lane after turning
settled, the Master Warning Light
ON the turn signal switch,
turns OFF.
when required.
In addition, for a malfunction with the
major units, such as CM and SJB,
the Master Warning Light also illumi-
nates.
❈ DPF : Diesel Particular Filter
❈ CM : Central Module
❈ SJB : Smart Junction Box
3-75
Convenient features of your vehicle
Door ajar warning light
Fuel filter warning light
Diesel preheat indica-
tor light
This warning light illuminates when a
This warning light illuminates for 3
The indicator light illuminates amber
door and the electrical step (for bus)
seconds after the ignition switch is
when the ignition switch is placed at
are not closed securely with the igni-
set to the ON position and then it will
the "ON" position. The engine can be
tion in any position.
go out. If it lights up while the engine
started after the preheat indicator
is running, it indicates that water has
light goes off. The illuminating time
WARNING
accumulated inside the fuel filter. If
varies with the water temperature, air
this happens, remove the water from
temperature and battery condition.
•
Before driving, make sure that
the fuel filter. For more information,
all doors and the electrical
refer to “Fuel filter” in section 7.
NOTICE
step are securely closed, and
If the engine were not started
that all warning lights are
CAUTION
turned OFF.
within 10 seconds after the pre-
heating is completed, turn the
•
While any warning light illumi-
When the fuel filter warning
ignition key once more to the
nates, turning OFF the engine
light is illuminated, engine
"LOCK" position, and then to the
may discharge the battery and
power (vehicle speed & idle
"ON" position, in order to preheat
fail the engine starting.
speed) may decrease. If you
again.
•
Before leaving the vehicle,
keep driving with the warning
light on, you can damage your
securely close all doors and
lock them.
vehicle's engine parts and
injection system. If this occurs,
we recommend that the system
be checked by an authorized
HYUNDAI dealer.
3-76
DPF (Diesel Particulate
If the DPF warning indicator(
)
Urea Level Warning
Filter) Warning
continues to blink or "check emission
lamp
Indicator
system" message comes on in the
cluster in spite of the above proce-
dure, we recommend that the system
The Diesel Particulate Filter (DPF)
The urea level warning lamp illumi-
be checked by an authorized
system removes the soot emitted
nates, when the urea solution vol-
HYUNDAI dealer.
from the vehicle.
ume falls below 12% or less of the
If you continue to drive with the indi-
tank. Without adding the urea solu-
3
Unlike a disposable air filter, the DPF
cator light blinking for a long time, the
tion, when the urea solution volume
system automatically burns
(oxi-
DPF system can be damaged and
drops to 6%, urea level warning lamp
dizes) and removes the accumulated
fuel consumption can be worsen.
will start blinking. When the urea
soot while driving.
solution volume drops 4% or under,
However, if the vehicle continues to
both urea level warning lamp and
be driven in short distance repeated-
urea system warning lamp will simul-
ly or at low speed for a long time, the
taneously blink with limited torque.
accumulated soot may not be auto-
matically removed because of low
When the urea volume falls below
1%, both lamps will stay blinking sta-
exhaust gas temperature. In this par-
ticular case, if the amount of soot is
tus with limited vehicle speed.
out of detection limit, the DPF warn-
When the urea level warning lamp
ing indicator (
) will illuminate. In
illuminates, the urea solution must
order to start the DPF regeneration
be added.
and to stop the DPF warning lamp
The urea level warning lamp will still
illuminating, drive the vehicle in a
illuminate with the remaining driving
safety driving circumstance with
distance after replenishment, and
more than 60km/h (37 mph) vehicle
then the lamp will go out after sever-
speed or with more than second
al minutes driving or after several
gear engaged and
1500
~ 2000
minutes ignition on status.
engine rpm for a certain time (for
about 25 minutes).
3-77
Convenient features of your vehicle
Urea system warning
Engine oil level warn-
i
Information
lamp
ing light (if equipped)
• If you travel approximately 50~100
km after the engine warms up, after
adding the engine oil, the warning
When the vehicle has critical prob-
The engine oil level warning light illu-
light will go off.
lems such as incorrect urea replen-
minates when the engine oil level
• Cycle the ignition from OFF to ON 3
ishment, urea consumption devia-
should be checked.
times within 10 seconds, the warn-
tion, urea dosing interruption or
If the warning light comes on, check
ing light will go off immediately.
EGR(exhaust gas recirculation) sys-
the engine oil level as soon as possi-
However, when you turn off the
tem malfunction, the urea system
ble and add engine oil as required.
warning light without adding the
warning lamp will start blink with lim-
Slowly pour the recommended oil lit-
engine oil, the light will come on
ited engine torque or vehicle speed.
tle by little into a funnel.
again after traveling approximately
Use only the specified engine oil.
50~100 km after the engine warms
up.
(Refer to "Recommended lubricants
and capacities" in section 8.)
Do not overfill the engine oil to
NOTICE
ensure the oil level is not above F
If the light comes on continuously
mark on the dipstick.
after adding the engine oil and
traveling approximately
50~100
km after the engine warms up, we
recommend that the system be
checked by an authorized
HYUNDAI dealer.
Even if this light doesn't come on
after the engine has started, the
engine oil should be checked and
supplied periodically.
3-78
PTO (Power take off)
Lining wear warning
Hill-start assist system
indicator light
light
indicator (if equipped)
(If equipped)
(if equipped)
The PTO indicator light will be illumi-
The main intend is to prevent the
If the wheel brake are(is) worn, the
nated when the PTO switch is on.
vehicle from rolling backwards while
light will come on. If the sensor of
wheel brake is defective, the light will
driving off uphill on an inclined sur-
face. The braking pressure is
3
blink.
CAUTION
reduced as soon as the system
detects the driver's intention to drive
Be sure not to operate the
CAUTION
off.
switch while driving as this may
cause damage to each power
We recommend that the system
train parts.
be inspected by an authorized
HYUNDAI dealer. Replace right
Mirror heater indicator
and left pads with new ones
light (If equipped)
simultaneously when replacing
brake pads.
The mirror heater indicator will be
illuminated when mirror heater
switch is turned “ON”.
3-79
Convenient features of your vehicle
DIGITAL TACHOGRAPH (IF EQUIPPED)
Warning sound
■ Type A
(a) Symbol " " for ADR variant*
Overspeed warning
(ADR=European Agreement con-
(if equipped)
120
cerning the international carriage of
km/h
dangerous goods by road)
The DTCO 1381 can be remotely
controlled by the corresponding
Overspeed warning light
accessories.
If you drive with the speed of
120km/h or more, the overspeed
warning light will blink. This is to pre-
vent from driving your vehicle with
overspeed.
OEU044072
Overspeed warning chime
(1) Display
If you drive with the speed of
120km/h or more, the overspeed
(2) Driver 1 keypad
warning chime will sound for about 5
(3) Card slot 1
seconds. This is to prevent you from
(4) Download interface
driving your vehicle with overspeed.
(5) Driver 2 keypad
(6) Card slot 2
(7) Unlock button printer drawer
(8) Cutting edge
(9) Menu buttons
3-80
Description
Driver 2 keypad (5)
Menu buttons (9)
(
2
) activity button for driver 2
Use the following buttons to enter,
Display (1)
(
) ejection button for card slot 2
display, or print out data.
Depending on the vehicle's opera-
(
2
2
) Use the paging function to
tional condition, different displays will
/
select the desired function or
appear or data can be displayed.
Card slot 2 (6)
selection.(This is possible by
Driver 2, who is not driving the vehi-
pressing and holding down
Driver 1 keypad (2)
cle at this moment in time, inserts his
the auto-repeat function key.)
3
(
1
) activity button for driver 1
driver card into slot 2 (crew opera-
(
OK
) Confirm or acknowledge desired
tion).
(
) ejection button for card slot 1
function/selection.
(
OK
) Press and hold, repeatedly until
Unlock button (7)
the last entry field.
Card slot 1 (3)
Use this button to unlock the printer
(
) Back to the last entry field, abort
Driver 1, who will drive the vehicle at
drawer, for example when inserting a
the entry of a country, or leave
this moment in time, inserts his driv-
roll of paper.
the menu one step at a time.
er card into slot 1.
Cutting edge (8)
Download interface (4)
You can use the cutting edge to tear
The download interface is located
off a printout generated by integrated
under the cover. The access rights of
printer.
this interface are regulated according
to the inserted tachograp card.
3-81
Convenient features of your vehicle
ADR variant*(a)
■ Type B
3. VDC
-
Some functions, such as insertion
Name and function (If equipped)
- This button is used to escape the
or removal of the tachograph
moving and move to the previous
cards, printing or display of data
menu.
are possible only while the ignition
- This button is used to escape
is switched on.
USB Download & Printing and
-
The download interface dap on the
move to the previous menu.
DTCO 1381 must be closed during
4.SEL
loading and unloading of haz-
Select the menu and move to the
ardous materials.
next menu.
5.Direction key
❈ For more detail information,
- This key is used for moving
refer to operating instructions
between Menus.
(book or CD) from the manufac-
OEG028021
turing company.
- It is also used to enter and modi-
1. MENU
fy the info in the setting menu.
- This button is used to move from
6.USB
initial screen to Menus.
Travel Info can be saved in a USB
2. PRINT
device using this key .
- This button is used to move from
initial screen to Choose Printing
Date.
3-82
LCD Display
Search travel information
CAUTION
• Do not use the USB devices
not qualified
certificate
because of compatibility.
• The product records informa-
tion while the vehicle is run-
3
ning. No key or menu will be
working.
OCY28401M
1.It displays the current date infor-
mation.
2.It displays the current time.
3.It displays the current driving con-
dition.
-
❚
IGN ON for vehicle stop
-
Vehicle Driving
-
❙❙
Vehicle IDLE
OCY28402M
4.It displays the time from Key On to
1.Initial screen
now.
It displays Date, Time, Driving con-
5.It displays the distance from Key
dition, Travel hour, Travel distance.
On to the current location.
2.Search travel info
3-83
