Hyundai Grand Santa Fe (2016 year). Instruction - part 16
Features of your vehicle
Air conditioning system operation tips
•
When using the air conditioning
Climate control air filter
system, you may notice clear water
•
If the vehicle has been parked in
direct sunlight during hot weather,
dripping (or even puddling) on the
Outside air
ground under the passenger side
open the windows for a short time
to let the hot air inside the vehicle
of the vehicle. This is a normal sys-
Recirculated
tem operation characteristic.
escape.
air
•
Use air conditioning to reduce
•
Operating the air conditioning sys-
tem in the recirculated air position
humidity and moisture inside the
vehicle on rainy or humid days.
provides maximum cooling, how-
ever, continual operation in this
•
During air conditioning system
mode may cause the air inside the
Blower
operation, you may occasionally
Heater core
vehicle to become stale.
Climate control
Evaporator
notice a slight change in engine
air filter
core
speed as the air conditioning com-
•
During cooling operation, you may
1LDA5047
occasionally notice a misty air flow
pressor cycles. This is a normal
The climate control air filter installed
system operation characteristic.
because of rapid cooling and
behind the glove box filters the dust
humid air intake. This is a normal
•
Use the air conditioning system
or other pollutants that come into the
system operation characteristic.
every month only for a few minutes
vehicle from the outside through the
to ensure maximum system per-
heating and air conditioning system.
If dust or other pollutants accumulate
formance.
in the filter over a period of time, the
air flow from the air vents may
decrease, resulting in moisture accu-
mulation on the inside of the wind-
shield even when the outside (fresh)
air position is selected. If this hap-
pens, we recommend that the cli-
mate control air filter be replaced by
an authorized HYUNDAI dealer.
4 171
Features of your vehicle
✽ NOTICE
Checking the amount of air
•
Replace the filter according to the
conditioner refrigerant and
WARNING - Vehicles
Maintenance Schedule.
compressor lubricant
equipped with R-1234yf*
If the car is being driven in severe
Because the refriger-
When the amount of refrigerant is
conditions such as dusty, rough
ant is mildly inflam-
low, the performance of the air condi-
roads, more frequent climate con-
mable and at very
tioning is reduced. Overfilling also
trol air filter inspections and
high pressure, the air
has a bad influence on the air condi-
changes are required.
conditioning system
tioning system.
•
When the air flow rate suddenly
should only be serv-
Therefore, if abnormal operation is
decreases, we recommend that the
iced by trained and
found, we recommend that the sys-
system be checked by an author-
certified technicians.
tem be inspected by an authorized
ized HYUNDAI dealer.
It is important that the correct
HYUNDAI dealer.
type and amount of oil and
refrigerant is used.
WARNING - Vehicles
Otherwise, it may cause damage
equipped with R-134a*
to the vehicle and personal injury.
Because the refriger-
ant is at very high
*: Your vehicle is filled with R-134a or
pressure, the air con-
R-1234yf according to the regula-
ditioning
system
tion in your country at the time of
should only be serv-
producing.
iced by trained and certified
technicians. It is important that
the correct type and amount of
oil and refrigerant is used.
Otherwise, it may cause damage
to the vehicle and personal injury.
4 172
Features of your vehicle
WINDSHIELD DEFROSTING AND DEFOGGING
•
For maximum defrosting, set the
Manual climate control system
WARNING - Windshield
temperature control to the extreme
To defog inside windshield
heating
right/hot position and the fan speed
control to the highest speed.
Do not use the
or
posi-
tion during cooling operation in
•
If warm air to the floor is desired
extremely humid weather. The
while defrosting or defogging, set
difference between the temper-
the mode to the floor-defrost posi-
ature of the outside air and the
tion.
windshield could cause the
•
Before driving, clear all snow and
outer surface of the windshield
ice from the windshield, rear win-
to fog up, causing loss of visi-
dow, outside rear view mirrors, and
bility. In this case, set the mode
all side windows.
selection to the
position
•
Clear all snow and ice from the
and fan speed control to the
hood and air inlet in the cowl grill to
ODM042298
lower speed.
improve heater and defroster effi-
1. Select desired temperature.
ciency and to reduce the probabili-
ty of fogging up the inside of the
2. Set the fan speed to the desired
windshield.
position.
3. Select the
or
position.
4. The outside
(fresh) air will be
selected automatically. If the
position is selected, air condition-
ing will also be selected automati-
cally.
If the air conditioning and/or outside
(fresh) air position are not selected
automatically, press the correspon-
ding button manually.
4 173
Features of your vehicle
To defrost outside windshield
Automatic climate control
If the air conditioning and outside
system
(fresh) air position are not selected
automatically, adjust the correspon-
To defog inside windshield
ding button manually. If the
posi-
tion is selected, lower fan speed is
adjusted to a higher fan speed.
ODM042299
1. Set the temperature to the
extreme hot position.
ODM042300
2. Set the fan speed to the highest
1. Select desired temperature.
position.
2. Set the fan speed to the desired
3. Select the
position.
position.
4. The outside (fresh) air and air con-
3. Press the defroster button (
).
ditioning will be selected automat-
4. The air conditioning will turn on
ically.
according to the detected ambient
temperature and outside
(fresh)
air position will be selected auto-
matically.
4 174
Features of your vehicle
To defrost outside windshield
Auto defogging system
This indicator illuminates
(if equipped)
when the auto defogging
system senses the mois-
ture of inside the wind-
shield and operates.
If more moisture is in the vehicle,
higher steps operate as follow.
Step 1 : Operating the air condition-
ing
Step 2 : Outside air position
ODM042301
Step 3 : Blowing air flow toward the
ODM042303
1. Set the temperature to the
windshield
extreme hot (HI) position.
Auto defogging reduces the possibil-
Step 4 : Increasing air flow toward
2. Set the fan speed to the•highest
ity of fogging up the inside of the
the windshield
position.
windshield by automatically sensing
the moisture of inside the windshield.
3. Press the defroster button (
).
The auto defogging system operates
4. The air conditioning will turn on
when the climate control system is on.
according to the detected ambient
temperature and outside
(fresh)
air position will be selected auto-
✽ NOTICE
matically.
The auto defogging system may not
operate normally, when the outside
temperature is below -10 °C.
4 175
Features of your vehicle
If your vehicle is equipped with the
✽ NOTICE
auto defogging system, it is automat-
If the A/C off is manually selected
ically activated when the conditions
while the auto defogging system is
are met. However, if you would like to
on, the auto defogging indicator will
cancel the auto defogging system,
blink 3 times to give notice that the
press the front defroster button
4
A/C off can not be selected.
times within 2 seconds while press-
ing the AUTO button. The indicator of
front defroster button will blink
3
CAUTION
times to notify you that the system is
Do not remove the sensor cover
cancelled. To use the auto defogging
located on the upper end of the
system again, follow the procedures
driver side windshield glass.
mentioned above.
Damage to the system parts
If the battery has been disconnected
could occur and may not be cov-
or discharged, it resets to the auto
ered by your vehicle warranty.
defogging status.
4 176
Features of your vehicle
STORAGE COMPARTMENT
Center console storage
Glove box
CAUTION
■ Type A
•
To avoid possible theft, do not
leave valuables in the storage
compartment.
•
Always keep the storage com-
partment covers closed while
driving. Do not attempt to
place so many items in the
storage compartment that the
storage compartment cover
can not close securely.
ODMECO2033
■ Type B
ODM042304
To open the center console storage,
WARNING - Flammable
push the lever and then lift up the
materials
cover.
Do not store cigarette lighters,
propane cylinders, or other
flammable/explosive materials
in the vehicle. These items may
catch fire and/or explode if the
vehicle is exposed to hot tem-
ODMECO2032
peratures for extended periods.
The glove box can be locked and
unlocked with a key. (1)
To open the glove box, push the but-
ton (2) and the glove box will auto-
matically open (3). Close the glove
box after use.
4 177
Features of your vehicle
Cool box (if equipped)
WARNING
WARNING
To reduce the risk of injury in an
Do not put perishable food in
accident or sudden stop, always
the cool box because it may not
keep the glove box door closed
maintain the necessary consis-
while driving.
tent temperature to keep the
food fresh.
CAUTION
Do not keep food in the glove
box for a long time.
ODM042306
You can keep beverage cans or other
items cool in the glove box.
1. Turn on the air conditioning.
2. Slide the open/close lever (1) of
the vent installed in the glove box
to the open position.
3. When the cool box is not used,
slide the lever
(1) to the closed
position.
✽ NOTICE
If some items in the cool box block
the vent, the cooling effectiveness of
the cool box is reduced.
4 178
Features of your vehicle
Multi box (if equipped)
Sunglass holder
WARNING
•
Do not keep objects except
sunglasses inside the sun-
glass holder. Such objects can
be thrown from the holder in
the event of a sudden stop or
an accident, possibly injuring
the passengers in the vehicle.
•
Do not open the sunglasses
holder while the vehicle is
moving. The rear view mirror
of the vehicle can be blocked
ODM042307
ODM042308
by an open sunglass holder.
To open the cover, push the lever (1)
To open the sunglass holder, press
•
Do not put the glasses
and the multi box will open automati-
the cover and the holder will slowly
forcibly into a sunglass holder
cally.
open. Place your sunglasses in the
to prevent breakage or defor-
compartment door with the lenses
It can be used for storing small items.
mation of glasses. It may
facing out. Push to close.
cause personal injury if you
CAUTION
try to open it forcibly when the
glasses are jammed in holder.
Do not drive with the multi box
open.
4 179
Features of your vehicle
Luggage tray
ONCNCO2024
You can place a first aid kit, a reflec-
tor triangle, tools, etc. in the box for
easy access.
Grasp the handle on the top of the
cover and lift it.
4 180
Features of your vehicle
INTERIOR FEATURES
Cigarette lighter (if equipped)
We recommend that you use parts
Ashtray (if equipped)
for replacement from an authorized
HYUNDAI dealer.
WARNING
• Holding the lighter in after it is
heated will cause it to over-
heat.
• If the lighter does not pop out
within 30 seconds, remove it
to prevent overheating.
ONCDCO3055
ODM042312
For the cigarette lighter to work, the
CAUTION
To use the ashtray, open the cover.
ignition switch must be in the ACC
The use of plug-in accessories
To clean or empty the ashtray, pull it
position or the ON position.
(shavers, hand-held vacuums,
out.
To use the cigarette lighter:
and coffee pots, for example)
1. Open the cover by pressing the
may damage the socket or
WARNING - Ashtray use
switch.
cause electrical failure.
• Do not use the vehicle’s ash-
2. Push the lighter all the way into the
tray as a waste receptacle.
socket.
• Putting lit cigarettes or match-
When the element has heated, the
es in an ashtray with other
lighter will pop out to the "ready"
combustible materials may
position.
cause a fire.
4 181
Features of your vehicle
Cup holder
■ Front
To use the center cup holder, pull
down the armrest and press the
Cups or small beverage cans may be
open button.
placed in the cup holders.
WARNING - Hot liquids
•
Do not place uncovered cups
of hot liquid in the cup holder
while the vehicle is in motion.
ODM042313
If the hot liquid spills, you may
■ Rear
burn yourself. Such a burn to
the driver could lead to loss of
control of the vehicle.
•
To reduce the risk of personal
injury in the event of sudden
stop or collision, do not place
uncovered or unsecured bot-
tles, glasses, cans, etc., in the
ONCNCO2026
cup holder while the vehicle is
■ Center
in motion.
WARNING
Keep cans and bottles out of
direct sunlight. Placing them in
a hot vehicle can cause them to
explode.
ODM042316
4 182
Features of your vehicle
Bottle holder
Sunvisor
WARNING
For your safety, do not block your
view when using the sunvisor.
ODMECO2036
OHG040168
Bottles may be placed in the holder.
Use the sunvisor to shield direct light
through the front or side windows.
To use the sunvisor, pull it downward.
✽ NOTICE
To use the sunvisor for the side win-
Only bottles should be place in the
dow, pull it downward, unsnap it from
holder as it is written in the vehicle
the bracket (1) and swing it to the
“BOTTLE ONLY”.
side (2).
To use the vanity mirror, pull down the
visor and slide the mirror cover (4).
The vanity mirror light comes on.
The ticket holder (5) is provided for
holding a tollgate ticket.
Adjust the sunvisor extension (3, if
equipped) forward and backward.
4 183
Features of your vehicle
Power outlet
CAUTION
■ Front
■ Center
· Type A
•
Use power outlet only when
the engine is running and
remove the accessory plug
after use. Using the accessory
plug for prolonged periods of
time with the engine off could
cause the battery to discharge.
•
Only use 12V electric acces-
sories which are less than 10A
ONCDCO3054
ODM042318
in electric capacity.
· Type B
■ Rear (if equipped)
•
Adjust the air-conditioner or
heater to the lowest operating
level when using the power
outlet.
•
Close the cover when not in
use.
•
Some electronic devices can
cause electronic interference
when plugged into a vehicle’s
ODMECO2037
ONCDCO3039
power outlet. These devices
may cause excessive audio
The power outlet is designed to provide power for mobile telephones or other
static and malfunctions in
devices designed to operate with vehicle electrical systems. The devices
other electronic systems or
should draw less than 10 amps with the engine running.
devices used in your vehicle.
4 184
Features of your vehicle
AC inverter (if equipped)
If you wish to use the AC inverter,
WARNING
press the AC inverter button while
Do not put a finger or a foreign
the engine is running. The light on
the AC inverter button will illuminate.
element (pin, etc.) into a power
outlet and do not touch with a
If you press the AC inverter button
wet hand. You may get electro-
again, the AC inverter will be deacti-
cuted or fire may occur.
vated and the light on the AC invert-
er button will turn off.
✽ NOTICE
When turning on the AC inverter,
ODM042320
the indicator on the AC inverter but-
ton illuminates late while the system
conducts a self-check.
ONCDCO3028
The AC inverter supplies 220V/200W
electric power to operate electric
accessories or equipments.
4 185
Features of your vehicle
WARNING
CAUTION
To reduce a risk of serious or
•
To prevent the battery from
fatal injuries:
being discharged, do not use
the AC inverter while the
•
Do not use a heated electric
engine is not running.
device such as a coffeepot,
toaster, heater, iron, etc.
•
When not using the AC invert-
er, make sure to turn off the AC
•
Do not insert foreign objects
inverter (the indicator on the
into the outlet and do not
button does not illuminate) and
touch the outlet as you may
close the AC inverter cover.
get shocked.
ODMECO2070
•
After using an electric acces-
•
Do not let children touch the
✽ NOTICE
sory or equipment, pull the
AC inverter.
plug out. Leaving the accesso-
• Rated voltage : AC 220V
ry or equipment plugged in for
• Maximum electric power : 200W
a long time may cause battery
• In order to avoid an electrical sys-
discharge.
tem failure, electric shock, etc., be
sure to read owner's manual
•
Do not use an electric acces-
before use.
sory or equipment the power
• Be sure to close the cover except
consumption of which is
the time of use.
greater than 200W(220V).
(Continued)
4 186
Features of your vehicle
Aux, USB and iPod®
✽ NOTICE
(Continued)
(if equipped)
When using a portable audio device
•
Some electric accessories or
connected to the power outlet, noise
equipments can cause elec-
may occur during playback. If this
tronic interference. It may
happens, use the power source of the
cause excessive audio noise
portable audio device.
and malfunctions in other
electric systems or devices in
❈ iPod® is a trademark of Apple Inc.
the vehicle.
•
Do not use broken electric
accessories or equipments,
which may damage the AC
inverter and electrical sys-
tems of the vehicle.
ONCDCO3053
•
Do not use two or more elec-
tric accessories or equip-
If your vehicle has an aux and/or
ments at the same time. It may
USB (universal serial bus) port, you
cause damage to the electrical
can use an aux port to connect audio
systems of the vehicle.
devices and an USB port to plug in
•
When the input voltage is
an USB and also in an iPod®.
under 11V, the outlet LED will
blink and the AC inverter will
turn off automatically. If the
input voltage goes up to nor-
mal, the AC inverter will turn
on again.
4 187
