Hyundai Azera (2017 year). Instruction - part 7

Features of your vehicle

When the sunshade is opened

If you pull the sunroof control lever

rearward, the sunroof glass will slide

all the way open. To stop the sunroof

movement at any point, pull or push

the sunroof control lever momentarily.

✽ NOTICE

Only the front glass of the panora-

ma sunroof opens and closes.

OHG045032

OHG045509

Tilting the sunroof

Closing the sunroof

When the sunshade is closed

Press the sunshade CLOSE button.

If you push the sunroof control lever

The sunroof glass will close then the

upward, the sunshade will slide all

sunshade will close. To stop the sun-

the way open then the sunroof glass

roof movement at any point, press

will tilt.

the sunshade control switch momen-

To stop the sunroof movement at any

tarily.

point, pull or push the sunroof control

If you want to close the sunroof glass

lever momentarily.

only, push the sunroof control lever.

Push the sunroof control lever again

to close the sunshade. To stop the

When the sunshade is opened

sunroof movement at any point, pull

If you push the sunroof control lever

or push the sunroof control lever

upward, the sunroof glass will tilt.

momentarily.

To stop the sunroof movement at any

point, pull or push the sunroof control

lever momentarily.

4 37

Features of your vehicle

Do not extend the face, neck, arms

or body outside the sunroof while

CAUTION - Sunroof motor

driving.

damage

Periodically remove any dirt that may

•

If you try to open the sunroof

accumulate on the guide rail.

when the temperature is

below freezing or when the

sunroof is covered with snow

or ice, the glass or the motor

could be damaged.

•

If the sunshade or sunroof is

completely closed or opened,

OYF049215

stop pressing the control

switch. Pressing the control

Automatic reversal

switch longer than necessary

If an object or part of the body is

may damage the motor.

detected while the sunroof glass or

sunshade is closing automatically, it

will reverse the direction, and then

stop.

CAUTION

The auto reverse function does not

If you drive with the sunroof

work if a tiny obstacle is between the

opened right after a car wash or

sliding glass or sunshade and the

rain, water may get inside the

sunroof sash. You should always

vehicle.

check that all passengers and

objects are away from the sunroof

before closing it.

4 38

Features of your vehicle

3. Push the sunroof control lever for-

WARNING

ward in the direction of close

A panoramic sunroof is made of

(about 10 seconds) until the sun-

glass, therefore it may break in

roof is moved a little. Then,

an accident. If you do not have

release the lever.

your seat belt on, you may go

4. Push the sunroof control lever for-

through the broken glass and

ward in the direction of close until

get injured or killed. For all pas-

the sunroof operates as follows;

sengers safety, have the appro-

priate protection on

(ex. seat

SUNSHADE OPEN → TILT OPEN

belt, child restraint seat, etc.).

→ SLIDE OPEN

→ SLIDE

OHG045197

CLOSE → SUNSHADE CLOSE

Resetting the sunroof

Then, release the control lever.

Sunroof needs to be reset if (in the

followings)

When this is complete, the sun-

- Battery is discharged or discon-

roof system is reset.

nected or the related fuse has been

replaced or disconnected

For more detailed information, con-

- The one-touch sliding function of

tact an authorized HYUNDAI dealer.

the sunroof does not normally oper-

ate

✽ NOTICE

If you do not reset the sunroof, it

1. Turn the engine on and close the

may not work properly.

sunroof glass and sunshade com-

pletely.

2. Release the control lever.

4 39

Features of your vehicle

DRIVER POSITION MEMORY SYSTEM (IF EQUIPPED)

Storing positions into memory

WARNING

using the buttons on the door

•

Never attempt to operate the

Storing driver’s seat positions

driver position memory system

1. Move the shift lever into P while

while the vehicle is moving.

the Engine Start/Stop button is in

This could result in loss of

the ON position.

control, and an accident caus-

2. Adjust the driver’s seat, outside

ing death, serious injury, or

mirrors, steering wheel position

property damage.

and instrument panel illumination.

•

Do not adjust the seat while

3. Press the SET button on the con-

wearing seat belts. Moving the

trol panel. The system will beep

OHG040033

seat cushion forward may

once.

cause strong pressure on the

The driver position memory system

4. Press one of the memory buttons

abdomen.

stores and recalls the driver's seat,

(1 or

2) within

5 seconds after

outside mirror, and steering wheel

pressing the SET button. The sys-

positions, as well as the instrument

tem will beep twice when memory

panel illumination intensity. By saving

has been successfully stored.

the desired positions, different driv-

ers can recall different settings

according to their preference. If the

battery is disconnected, the memory

will be erased.

4 40

Features of your vehicle

5.

Recalling positions from memory

Adjusting the control switch for the

1. Move the shift lever into P while

driver’s seat, side view mirrors, steer-

the Engine Start/Stop button is in

ing wheel and the instrument panel

the ON position.

illumination while the system is

recalling the stored position will

2. To recall the position in memory,

cause the movement to stop and

press the desired memory button

move in the direction that the control

(1 or

2). The system will beep

switch is moved.

once, then the driver’s seat, out-

side mirrors, steering wheel and

OHG045521L/OHG045522L

the instrument panel illumination

"Driver

1(or

2) settings saved" will

will automatically adjust to the

appear on the instrument cluster

stored positions.

LCD display.

3.

OHG045523N/OHG045524N

"Driver 1 (or 2) settings is applied"

will appear on the instrument cluster

LCD display.

4 41

Features of your vehicle

STEERING WHEEL

Electronic power steering (EPS)

✽ NOTICE

(Continued)

• When the vehicle is stationary, if

The power steering uses a motor to

The following symptoms may occur

you turn the steering wheel all the

assist you in steering the vehicle. If

during normal vehicle operation:

way to the left or right continuous-

the engine is off or if the power steer-

•

The steering effort is high immedi-

ly, the steering wheel effort

ing system becomes inoperative, the

ately after the engine starts. This

increases. This is not a system mal-

vehicle may still be steered, but it will

happens as the system performs

function. As time passes, the steer-

require increased steering effort.

the EPS system diagnostics. When

ing wheel effort will return to its

The motor driven power steering is

the diagnostics is completed, the

normal condition.

controlled by a power steering con-

steering wheel will return to its

trol unit which senses the steering

normal condition.

If the Electronic Power Steering

wheel torque and vehicle speed to

•

A click noise may be heard from

System does not operate normally,

command the motor.

the EPS relay after the ignition

the warning light (

) will illuminate

The steering becomes heavier as

switch is changed to the ON or

on the instrument cluster. The steer-

the vehicle’s speed increases and

OFF position.

ing wheel may become difficult to

becomes lighter as the vehicle’s

•

Motor noise may be heard when

control or operate abnormally. Take

speed decreases for optimum steer-

the vehicle is at a stop or at a low

your vehicle to an authorized

ing control.

driving speed.

HYUNDAI dealer and have the

•

When you operate the steering

Should you notice any change in the

vehicle checked as soon as possible.

wheel in low temperature, abnor-

effort required to steer during normal

mal noise could occur. If tempera-

vehicle operation, have the power

ture rises, the noise will disappear.

steering checked by an authorized

This is a normal condition.

HYUNDAI dealer.

(Continued)

4 43

Features of your vehicle

Tilt and telescopic steering

Tilt and telescopic steering allows

you to adjust the steering wheel

before you drive. You can also raise it

to give your legs more room when

you exit and enter the vehicle.

The steering wheel should be posi-

tioned so that it is comfortable for

you to drive, while permitting you to

see the instrument panel warning

OHG040189L

OHG040035

lights and gauges.

Manual type

Electric type

To change the steering wheel angle

To change the steering wheel angle

WARNING - Steering

and height:

and height:

wheel adjustment

1. Pull down the lock-release lever

• Move the switch (1) up and down

Never adjust the angle and

(1).

to adjust the angle (2).

height of the steering wheel

2. Adjust the steering wheel to the

• Move the switch forward or rear-

while driving. You may lose

desired angle (2) and height (3).

ward to adjust the height (3).

steering control and cause seri-

3. Pull up the lock-release lever to

ous personal injury, death, or

lock the steering wheel in place.

accidents.

4 44

Features of your vehicle

OHG040038

Horn

To sound the horn, press the area

indicated by the horn symbol on your

steering wheel (see illustration). The

horn will operate only when this area

is pressed.

Check the horn regularly to be sure it

operates properly.

4 45

Features of your vehicle

MIRRORS

Inside rearview mirror

Electric chromic mirror (ECM)

with HomeLink® system and

Adjust the rearview mirror so that the

compass

center view through the rear window

is seen. Make this adjustment before

Your vehicle may be equipped with a

you start driving.

Gentex Automatic-Dimming Mirror

with a Z-Nav™ Electronic Compass

Do not place objects in the rear seat

Display

and an Integrated

or cargo area which would interfere

HomeLink® Wireless

Control

with your vision through the rear win-

System. During nighttime driving,

dow.

this feature will automatically detect

and reduce rearview mirror glare

while the compass indicates the

OYF042250N

direction the vehicle is pointed. The

(1) Telematics button

HomeLink® Universal Transceiver

(2) Telematics button

allows you to activate your garage

door(s), electric gate, home lighting,

(3) Telematics button

etc.

(4) Compass control button &

Dimming ON/OFF button

(5) Status indicator LED

(6) Channel 1 button

(7) Channel 2 button

(8) Channel 3 button

(9) Compass display

(10) Rear light sensor

4 46

Features of your vehicle

Automatic-Dimming Night Vision

Automatic-dimming function

Z-Nav™ Compass Display

Safety™ (NVS®) Mirror

Your mirror will automatically dim

The NVS™ Mirror in your vehicle is

The NVS® Mirror in your vehicle is

upon detecting glare from the vehi-

also equipped with a Z-Nav™

the most advanced way to reduce

cles traveling behind you. The auto-

Compass that shows the vehicle

annoying glare in the rearview mirror

dimming function can be controlled

Compass heading in the Display

during any driving situation. For more

by the Dimming ON/OFF button:

Window using the 8 basic cardinal

information regarding NVS® mirrors

headings (N, NE, E, SE, etc.).

and other applications, please refer

1. Pressing and holding the button

to the Gentex website:

for 3 seconds turns the autodim-

www.gentex.com

ming function OFF which is indi-

cated by the green Status

✽ NOTICE

Indicator LED turning off.

The NVS® Mirror automatically

2. Pressing and holding the button

reduces glare during driving condi-

for

3 seconds again turns the

tions based upon light levels moni-

auto-dimming function ON which

tored in front of the vehicle and

is indicated by the green Status

from the rear of the vehicle. These

Indicator LED turning on.

light sensors are visible through

The mirror defaults to the ON posi-

openings in the front and rear of the

tion each time the vehicle is started.

mirror case. Any object that

obstructs either light sensor will

degrade the automatic dimming

control feature.

4 47

Features of your vehicle

Compass function

The Compass can be turned ON and

OFF and will remember the last state

when the ignition is cycled. To turn

the display feature ON/OFF:

1. Press and release the

button

within 1 second to turn the display

feature OFF.

2. Press and release the

button

again within 1 second to turn the

display back ON.

Additional options can be set with

press and hold sequences of the

button and are detailed below.

There is a difference between mag-

netic north and true north. The com-

pass in the mirror can compensate

for this difference when it knows the

Magnetic Zone in which it is operat-

ing. This is set either by the dealer or

by the user. The operating Zone

Numbers for North America are

shown in the figure on the following

section.

B520C05NF

4 48

Features of your vehicle

To adjust the Zone setting:

There are some conditions that can

Integrated HomeLink® Wireless

1. Determine the desired Zone

cause changes to the vehicle mag-

Control System

Number based upon your current

nets, such as installing a ski rack or

The HomeLink® Wireless Control

location on the Zone Map.

a CB antenna. Body repair work on

System provides a convenient way to

2. Press and hold the button for 6

the vehicle can also cause changes

replace up to three hand-held radio-

to the vehicle's magnetic field. In

frequency (RF) transmitters with a

seconds, the current Zone

Number will appear on the display.

these situations, the compass will

single built-in device. This innovative

need to be re-calibrated to quickly

feature will learn the radio frequency

3. Pressing and holding the button

correct these changes. To re-cali-

codes of most current transmitters to

again will cause the numbers to

brate the compass:

operate devices such as gate opera-

increment (Note: they will repeat

tors, garage door openers, entry

…13, 14, 15, 1, 2, …). Releasing

the button when the desired Zone

1. Press and hold the

button for

door locks, security systems, even

more than 9 seconds. When the

home lighting. Both standard and

Number appears on the display

will set the new Zone.

compass memory is cleared a "C"

rolling code-equipped transmitters

will appear in the display.

can be programmed by following the

4. Within about 5 seconds the com-

outlined procedures. Additional

pass will start displaying a com-

2. To calibrate the compass, drive

HomeLink® information can be found

pass heading again.

the vehicle in 2 complete circles at

at: www.homelink.com or by calling

less than 5 mph (8 km/h).

1-800-355-3515.

4 49

Features of your vehicle

Retain the original transmitter of the

✽ NOTICE - Programming

WARNING

RF device you are programming for

HomeLink®

Before programming HomeLink®

use in other vehicles as well as for

•

When programming a garage

to a garage door opener or gate

future HomeLink® programming. It is

door opener, it is advised to park

operator, make sure that people

also suggested that upon the sale of

the vehicle outside of the garage.

and objects are out of the way of

the vehicle, the programmed

•

It is recommended that a new bat-

the device to prevent potential

HomeLink® buttons be erased for

tery be placed in the hand-held

harm or damage. Do not use

security purposes.

transmitter of the device being pro-

HomeLink® with any garage

grammed to HomeLink® for quick-

door opener that lacks the safe-

er training and accurate transmis-

ty stop and reverse features

sion of the radio-frequency signal.

required by U.S. federal safety

•

Some vehicles may require the

standards

(this includes any

ignition switch to be turned to the

garage door opener model man-

second (or "accessories") position

ufactured before April 1, 1982). A

for programming and/or opera-

garage door that cannot detect

tion of HomeLink®.

an object - signaling the door to

•

In the event that there are still pro-

stop and reverse - does not meet

gramming difficulties or questions

current U.S. federal safety stan-

after following the programming

dards. Using a garage door

steps

listed

below, contact

opener without these features

HomeLink®homelwww.homelink.com

increases the risk of serious

or 1-800-355-3515.

injury or death.

4 50

Features of your vehicle

Programming

✽ NOTICE

Flashing

To train most devices, follow these

Some devices may require you to

instructions:

replace this Programming step

3

with procedures noted in the "Gate

Flashing

Operator/Canadian Programming"

section. If the HomeLink® indicator

light does not change to a rapidly

blinking light after performing these

steps, contact HomeLink®

at

www.homelink.com.

OYF042251N

2. Position the end of your hand-held

transmitter

1-3 inches

(2-8 cm)

away from the HomeLink® button

OYF042252N

you wish to program while keeping

1. For first-time programming, press

the indicator light in view.

and hold the two outside buttons

3. Simultaneously press and hold

(

,

), HomeLink® Channel

1

both the HomeLink® and hand-

and Channel 3, until the indicator

held transmitter buttons until the

light begins to flash (after 10 sec-

HomeLink® indicator light changes

onds). Release both buttons. Do

from a slow to a rapid blinking light.

not hold the buttons for longer

Now you may release both the

than 20 seconds.

HomeLink® and hand-held trans-

mitter buttons.

4 51

Features of your vehicle

Reprogramming a single

Erasing HomeLink® buttons

FCC ID: NZLTLMHL4

HomeLink® button

Individual buttons cannot be erased.

IC: 4112A-TLMHL4

To program a device to HomeLink®

However, to erase all three pro-

using a HomeLink® button previously

grammed buttons:

This device complies with Part 15

trained, follow these steps:

1. Press and hold the two outer

of the FCC Rules.

1. Press and hold the desired

HomeLink® buttons until the indi-

Operation is subject to the following

HomeLink® button. DO NOT

cator light begins to flash after 10

two conditions:

release the button.

seconds.

1. This device may not cause harm-

2. The indicator light will begin to

2. Release both buttons. Do not hold

ful interference, and

flash after

20 seconds. Without

for longer than 20 seconds.

2. This device must accept any inter-

releasing the HomeLink® button,

The Integrated HomeLink® Wireless

ference received, including inter-

proceed with "Programming" step

Control System is now in the training

ference that may cause undesired

2.

(learn) mode and can be pro-

operation.

grammed at any time following the

For questions or comments, contact

appropriate steps in the Programming

WARNING

HomeLink®omelwww.homelink.com or

sections above.

The transceiver has been tested

1-800-355-3515.

and complies with FCC and

Industry Canada rules. Changes

or modifications not expressly

approved by the party responsi-

ble for compliance could void

the user's authority to operate

the device.

4 53

Content   ..  5  6  7  8   ..
