Tilting the sunroof
When the sunshade is opened
Closing the sunroof
When the sunshade is closed
If you push the sunroof control lever
upward, the sunroof glass will tilt.
To stop the sunroof movement at any
point, pull or push the sunroof control
lever momentarily.
3
OTL045030
OTL045029
To close the sunroof glass only
If you push the sunroof control lever
Push the sunroof control lever for-
upward, the sunshade will slide open
ward to the first detent position or
then the sunroof glass will tilt.
pull the lever downward.
To stop the sunroof movement at any
point, pull or push the sunroof control
To close the sunroof glass with
lever momentarily.
the sunshade
Push the sunroof control lever for-
ward to the second detent position.
The sunroof glass will close then the
sunshade will close automatically.
To stop the sunroof movement at any
point, pull or push the sunroof control
lever momentarily.
3-39
Convenient features of your vehicle
Automatic reversal
NOTICE
WARNING
• Periodically remove any dirt that
•
Make sure heads, other body
may accumulate on the sunroof
parts or other objects are safe-
guide rail or between the sun-
ly out of the way before closing
roof and roof panel, which can
the sunroof to avoid injuries or
make a noise.
vehicle damage.
• Do not try to open the sunroof
•
To avoid serious injury or
when the temperature is below
death, do not extend your
freezing or when the sunroof is
head, arms or body outside
covered with snow or ice, the
the sunroof while driving.
motor could be damaged. In
cold and wet climates, the sun-
•
A panorama sunroof is made
ODH043039
roof may not work properly.
of glass, therefore it may break
If an object or part of the body is
in an accident. If you do not
detected while the sunroof glass or
have your seat belt on, you
i
Information
sunshade is closing automatically, it
may stick out of the broken
After the vehicle is washed or in a
will reverse the direction, and then
glass and get injured or killed.
rainstorm, be sure to wipe off any
stop.
For all passengers safety, have
water that is on the sunroof before
an appropriate protection on
The auto reverse function does not
operating it.
work if a tiny obstacle is between the
(ex. seat belt, child restraint
system, etc.).
sliding glass or sunshade and the
sunroof sash. You should always
check that all passengers and
objects are away from the sunroof
before closing it.
3-40
Resetting the sunroof
3. Push the sunroof control lever for-
Sunroof open warning
ward in the direction of close
(if equipped)
(about 10 seconds) until the sun-
roof slightly moves. Then, release
the lever.
4. Push the sunroof control lever for-
ward in the direction of close until
the sunroof operates as follows:
3
Sunshade Open Glass Tilt Open
Glass Slide Open Glass Slide
Close Sunshade Close
OTL045031
Then, release the control lever.
OGB044103TU
Sunroof needs to be reset if (in the
followings)
•
If the driver turns off the engine when
When this is complete, the sunroof
- Battery is discharged or disconnect-
the sunroof is not fully closed, the
system is reset.
warning chime will sound for approx-
ed or the related fuse has been
replaced or disconnected
imately 3 seconds and sunroof open
For more details, contact an author-
warning will appear on the LCD dis-
- The one-touch sliding function of the
ized HYUNDAI dealer.
play.
sunroof does not normally operate
•
If the driver turns off the engine and
i
Information
opens the door when the sunroof is
1. Turn the engine on and close the
not fully closed, the open sunroof
If you do not reset the sunroof, it may
sunroof glass and sunshade com-
warning will appear on the LCD dis-
not work properly.
pletely.
play until the door is closed or the
2. Release the control lever.
sunroof is fully closed.
Close the sunroof securely when leav-
ing your vehicle.
3-41
Convenient features of your vehicle
EXTERIOR FEATURES
Hood
Opening the hood
OTLE045033
OTL045245
3. Go to the front of the vehicle, raise
4. Pull out the stay rod.
the hood slightly, push up the sec-
OTL045032
5. Hold the hood opened with the
ondary latch (1) inside of the hood
stay rod (1).
1. Park the vehicle and set the park-
center and lift the hood (2).
ing brake.
WARNING
2. Pull the release lever to unlatch
the hood. The hood should pop
• Grasp the stay rod in the area
open slightly.
wrapped in rubber. The rubber
will help prevent you from
being burned by hot metal
when the engine is hot.
• The stay rod must be inserted
completely into the hole provid-
ed whenever you inspect the
engine compartment. This will
prevent the hood from falling
and possibly injuring you.
3-42
Closing the hood
WARNING
WARNING
1. Before closing the hood, check the
following:
Always double check to be sure
•
Before closing the hood,
• All filler caps in engine compart-
that the hood is firmly latched
ensure that all obstructions
ment must be correctly installed.
before driving away. Check there
are removed from the hood
• Gloves, rags or any other com-
is no hood open warning light or
opening. Closing the hood
bustible material must be removed
message displayed on the instru-
with an obstruction present in
3
from the engine compartment.
ment cluster. If the hood is not
the hood opening may result
latched while the vehicle is mov-
in property damage or severe
2. Return the stay rod to its clip to
ing, the chime will sound to warn
personal injury.
prevent it from rattling.
the driver the hood is not fully
•
Do not leave gloves, rags or
3. Lower the hood halfway
(lifted
latched. Driving with the hood
any other combustible materi-
approximately 30cm from the closed
opened may cause a total loss of
al in the engine compartment.
position) and push down to securely
visibility, which might result in an
Doing so may cause a heat-
lock in place. Then double check to
accident.
induced fire.
be sure the hood is secure.
•
Do not move the vehicle with
the hood raised. The view will
be blocked and the hood could
fall or be damaged.
3-43
Convenient features of your vehicle
Fuel filler door
i
Information
Opening the fuel filler door
If the fuel filler door does not open
because ice has formed around it, tap
lightly or push on the door to break
the ice and release the door. Do not
pry on the door. If necessary, spray
around the door with an approved de-
icer fluid (do not use radiator anti-
freeze) or move the vehicle to a warm
place and allow the ice to melt.
OTL045035
2. Pull the fuel filler door (1) out to
fully open.
OTLE045031
3. To remove the fuel tank cap (2),
1. To open the fuel filler door, press
turn it counterclockwise. You may
the center edge of the fuel filler
hear a hissing noise as the pres-
door.
sure inside the tank equalizes.
4. Place the cap on the fuel filler door.
i
Information
The fuel filler door will open and close
only when all doors are unlocked.
3-44
Closing the fuel filler door
(Continued)
(Continued)
1. To install the fuel tank cap, turn it
•
Do not use cellular phones
•
When refueling, always move
clockwise until it “clicks” one time.
while refueling. Electric cur-
the shift lever to the P (Park)
2. To close the fuel filler door, press
rent and/or electronic interfer-
position (for automatic transaxle/
the edge of the fuel filler door.
ence from cellular phones can
dual clutch transmission) or first
Make sure it is securely closed.
potentially ignite fuel vapors
gear or R (Reverse, for manual
and cause a fire.
transaxle), set the parking brake,
3
and place the ignition switch to
WARNING
•
Do not get back into a vehicle
the LOCK/OFF position. Sparks
once you have begun refuel-
Gasoline is highly flammable
ing. You can generate a build-
produced by electrical compo-
and explosive. Failure to follow
up of static electricity by touch-
nents related to the engine can
these guidelines may result in
ing, rubbing or sliding against
ignite fuel vapors causing a fire.
SERIOUS INJURY or DEATH:
any item or fabric capable of
•
When using an approved
•
Read and follow all warnings
producing static electricity.
portable fuel container, be sure
posted at the gas station.
Static electricity discharge can
to place the container on the
ignite fuel vapors causing a
ground prior to refueling. Static
•
Before refueling, note the
fire. If you must re-enter the
electricity discharge from the
location of the Emergency
vehicle, you should once again
container can ignite fuel vapors
Gasoline Shut-Off, if available,
eliminate potentially danger-
causing a fire. Once refueling
at the gas station.
ous static electricity discharge
has begun, contact between
•
Before touching the fuel noz-
by touching a metal part of the
your bare hand and the vehicle
zle, you should eliminate the
vehicle, away from the fuel filler
should be maintained until the
potential build-up of static
neck, nozzle or other gasoline
filling is complete.
electricity by touching a metal
source, with your bare hand.
(Continued)
part of the vehicle, a safe dis-
(Continued)
tance away from the fuel filler
neck, nozzle, or other gas
source, with your bare hand.
(Continued)
3-45
Convenient features of your vehicle
(Continued)
(Continued)
i
Information
•
Use only approved portable
•
If pressurized fuel sprays out,
Make sure to refuel your vehicle
plastic fuel containers designed
it can cover your clothes or
according to the "Fuel Requirements"
to carry and store gasoline.
skin and thus subject you to
suggested in the Introduction chapter.
the risk of fire and burns.
•
Do not use matches or a
lighter and do not smoke or
Always remove the fuel cap
NOTICE
carefully and slowly. If the cap
leave a lit cigarette in your
is venting fuel or if you hear a
•
Do not spill fuel on the exterior
vehicle while at a gas station,
hissing sound, wait until the
surfaces of the vehicle. Any type
especially during refueling.
condition stops before com-
of fuel spilled on painted sur-
•
Do not over-fill or top-off your
pletely removing the cap.
faces may damage the paint.
vehicle tank, which can cause
•
Always check that the fuel cap
•
If the fuel filler cap requires
gasoline spillage.
is installed securely to pre-
replacement, use only a genuine
•
If a fire breaks out during refu-
vent fuel spillage in the event
HYUNDAI cap or the equivalent
eling, leave the vicinity of the
of an accident.
specified for your vehicle. An
vehicle, and immediately con-
incorrect fuel filler cap can
tact the manager of the gas
result in a serious malfunction
station and then contact the
of the fuel system or emission
local fire department. Follow
control system.
any safety instructions they
provide.
(Continued)
3-46
TAILGATE
Non-power tailgate (if equipped)
• Once the tailgate is opened and
WARNING
then closed, the tailgate locks
Opening the tailgate
automatically. (All doors must be
The tailgate swings upward.
locked.)
Make sure no objects or people
are near the rear of the vehicle
i
Information
when opening the tailgate.
In cold and wet climates, door lock
3
and door mechanisms may not work
properly due to freezing conditions.
CAUTION
Make certain that you close the
tailgate before driving your
vehicle. Possible damage may
OTL045036
occur to the tailgate lift cylin-
ders and attaching hardware if
•
The tailgate is locked or unlocked
the tailgate is not closed prior
when all doors are locked or
to driving.
unlocked with the key, transmitter,
smart key or central door
lock/unlock switch.
•
Only the tailgate is unlocked if the
tailgate unlock button on the remote
key or smart key is pressed for
approximately 1 second.
•
If unlocked, the tailgate can be
opened by pressing the handle and
pulling it up.
3-47
Convenient features of your vehicle
Closing the tailgate
CAUTION
WARNING
Make sure nothing is near the
Occupants should never ride in
tailgate latch and striker while
the rear cargo area where no
closing the tailgate. It may dam-
restraints are available. To avoid
age the tailgate's latch.
injury in the event of an accident
or sudden stops, occupants
should always be properly
WARNING
restrained.
If you drive with the tailgate
opened, you will draw danger-
OTL045037
ous exhaust fumes into your
vehicle which can cause seri-
Lower and push down the tailgate
ous injury or death to vehicle
firmly. Make sure that the tailgate is
occupants.
securely latched.
If you must drive with the tail-
gate opened, keep the air vents
WARNING
and all windows open so that
additional outside air comes
Make sure your hands, feet and
into the vehicle.
other parts of your body are
safely out of the way before clos-
Do not lean on tailgate lift cylin-
ing the tailgate.
ders, nor tie any rope or twine to
them to avoid bending and con-
In case of any malfunction we
sequent malfunction, vehicle
recommend to visit authorized
damage or injury in case bent lift
HYUNDAI dealer for inspection.
cylinder breaks the rear glass.
3-48
Emergency tailgate safety
Power tailgate (if equipped)
WARNING
release
Power tailgate button
•
For emergencies, be fully aware
of the location of the emer-
gency tailgate safety release
lever in the vehicle and how to
open the tailgate if you are acci-
3
dentally locked in the luggage
compartment.
•
No one should be allowed to
occupy the luggage compart-
ment of the vehicle at any time.
The luggage compartment is a
OTL045038
very dangerous location in the
OTL045039
event of a crash.
Your vehicle is equipped with the
The power tailgate operates when:
emergency tailgate safety release
•
Use the release lever for emer-
• The power tailgate button is pressed
lever located on the bottom of the
gencies only. Use with extreme
with the engine off.
tailgate. When someone is inadver-
caution, especially while the
• The power tailgate button is pressed
tently locked in the luggage compart-
vehicle is in motion.
when the ignition switch is in the ON
ment. The tailgate can be opened by
position with the shift lever in P
doing as follows:
(Park, for automatic transaxle/dual
1. Remove the cover.
clutch transmission vehicle) or the
shift lever in neutral
(for manual
2. Push the release lever to the right.
transaxle vehicle).
3. Push up the tailgate.
To activate or de-activate the power
tailgate, go to User Settings mode
and select the Power Tailgate on the
LCD display.
For more details, refer to “LCD
Display” in this chapter.
3-49
Convenient features of your vehicle
Opening the tailgate
WARNING
CAUTION
Never leave children or animals
Do not close or open the power
unattended in your vehicle.
tailgate manually. This may
cause damage to the power tail-
Children or animals might oper-
gate. If it is necessary to close
ate the power tailgate that could
or open the power tailgate man-
result in injury to themselves or
ually when the battery is dis-
others, or damage the vehicle.
charged or disconnected, do
not apply excessive force.
WARNING
Make sure there are no people
OTLE045030
or objects around the tailgate
The power tailgate will open automat-
before operating the power tail-
ically by doing one of the following:
gate. Wait until the tailgate is
• Press the tailgate unlock button on
opened fully and stopped before
the remote key or smart key for
loading or unloading cargo or
approximately one second.
passengers from the vehicle.
3-50
Closing the tailgate
3
OTL045039
OTL045040
• Press the power tailgate button for
• Press the tailgate handle switch
OTL045039
approximately one second.
carrying the smart key with you.
• Press the power tailgate button for
For emergency stop while operating,
approximately one second when
press the power tailgate button shortly.
the tailgate is opened.
The tailgate will close and lock
automatically.
For emergency stop while operating,
press the power tailgate button shortly.
3-51
Convenient features of your vehicle
Power tailgate non-opening
CAUTION
conditions
The tailgate does not open when the
Operating the power tailgate
vehicle is in motion.
more than 5 times continuously
could cause damages to the
WARNING
operating motor. In this case, the
system enters into a thermal pro-
The chime will sound if you
tection mode. In thermal protec-
drive with the tailgate opened.
tion mode, the power tailgate can
Stop your vehicle immediately
not operate and the chime will
at a safe place and check if your
sound for 3 times by any switch
OTL045041
tailgate is opened.
inputs. Leave your power tailgate
•
Press the power tailgate inner
system for rest about 1 minute
switch for approximately one sec-
and then operate.
ond when the tailgate is opened.
The tailgate will close and lock auto-
matically.
3-52
Automatic reversal
However, if the resistance is weak
i
Information
such as from an object that is thin or
•
The power tailgate can be operated
soft, or the tailgate is near the latched
when the engine is not running.
position, the automatic stop and rever-
However the power tailgate opera-
sal may not detect the resistance.
tion consumes large amounts of
If the automatic reversal feature
vehicle electric power. To prevent
operates continuously more than
the battery from being discharged,
twice during opening or closing oper-
3
do not operate it excessively. (e.g.:
ation, the power tailgate may stop at
more than approximately 10 times
that position. At this time, close the
repeatedly.)
tailgate manually and operate the
•
To prevent the battery from being
tailgate automatically again.
discharged, do not leave the power
tailgate in the open position for a
OTL045042
long time.
During power opening and closing if
•
Do not modify or repair any part of
the power tailgate is blocked by an
the power tailgate by yourself. We
object or part of the body, the power
recommend that you contact an
tailgate will detect the resistance.
authorized HYUNDAI dealer.
• If the resistance is detected while
•
When jacking up the vehicle to
opening the tailgate, it will stop and
change a tire or repair the vehicle,
move in the opposite direction.
do not operate the power tailgate.
• If the resistance is detected while
This could cause the power tailgate
closing the tailgate, it will stop and
to operate improperly.
move in the opposite direction.
•
In cold and wet climates, the power
tailgate may not work properly due
to freezing conditions.
3-53
Convenient features of your vehicle
How to reset the power tailgate
i
Information
WARNING
If the battery has been discharged or
If the power tailgate does not operate
disconnected, or if the related fuse has
Never intentionally place any
normally, check again if the gear posi-
been replaced or disconnected, for the
object or part of your body in
tion is in right position.
power tailgate to operate normally,
the path of the power tailgate to
reset the power tailgate as follow:
make sure the automatic rever-
sal operates.
1.Automatic transaxle/Dual clutch
transmission:
Put the shift lever in P (Park).
CAUTION
Manual transaxle:
Put the shift lever in neutral.
Do not put heavy stuffs on the
2.While Pressing the power tailgate
power tailgate before you oper-
inner switch, press the tailgate
ate the power tailgate.
handle switch for more than 3 sec-
Additional weight on tailgate
onds. (the chime will sound)
could cause damages to the
3.Close the tailgate manually.
system.
If the power tailgate does not work
properly after the above procedure,
we recommend that the system be
checked by an authorized HYUNDAI
dealer.
3-54
Power tailgate opening height
Emergency tailgate safety
WARNING
user setting
release
If you drive with the tailgate
opened, you will draw danger-
ous exhaust fumes into your
vehicle which can cause seri-
ous injury or death to vehicle
3
occupants.
If you must drive with the tail-
gate opened, keep the air vents
and all windows open so that
additional outside air comes
into the vehicle.
OTL045041
OTL045038
The driver may set the height of a
Your vehicle is equipped with the
fully opened tailgate by following the
WARNING
emergency tailgate safety release
below instruction.
lever located on the bottom of the
Occupants should never ride in
tailgate. When someone is inadver-
1. Position the tailgate manually to
the rear cargo area where no
tently locked in the luggage compart-
the height you prefer.
restraints are available. To avoid
ment, the tailgate can be opened by
2. Press the power tailgate inner
injury in the event of an acci-
doing as follows:
switch for more than 3 seconds.
dent or sudden stops, occu-
1. Remove the cover.
3. Close the tailgate manually after
pants should always be proper-
2. Push the release lever to the right.
hearing the buzzer sound.
ly restrained.
3. Push up the tailgate.
The tailgate will open to the height
the driver has set up.
3-55
