Hyundai Tiburon (2008 year). Instruction - part 10





DRIVING YOUR HYUNDAI
2
23
Vehicle capacity weight:
Towing capacity:
(3)Subtract the combined weight of the
700 lbs (317 kg)
Towing capacity is the maximum trailer
driver and passengers from XXX
Vehicle capacity weight is the maxi-
weight including its cargo weight, your
kilograms or XXX pounds.
mum combined weight of occupants
vehicle can tow. See the section "Trailer
(4)The resulting figure equals the avail-
and cargo. If your vehicle is equipped
or Vehicle Towing" for specifications
able amount of cargo and luggage
with a trailer, the combined weight in-
about the trailer weight.
load capacity. For example, if the
cludes the tongue load.
"XXX" amount equals 1400 lbs, and
Cargo capacity:
there will be five 150 lb. passengers
Seating capacity:
The cargo capacity of your vehicle will
in your vehicle, the amount of avail-
Total: 4 persons
increase or decrease depending on the
able cargo and luggage load capac-
(Front seat: 2 persons,
weight and the number of occupants
ity is 650 lbs. (1400-750 (5 x 150) =
Rear seat: 2 persons)
and the tongue load, if your vehicle is
650 lbs.)
Seating capacity is the maximum num-
equipped with a trailer.
(5)Determine the combined weight of
ber of occupants including a driver,
luggage and cargo being loaded on
your vehicle may carry.
Steps for Determining Correct Load
the vehicle. That weight may not
However the seating capacity may be
Limit
safely exceed the available cargo
reduced based upon the weight of all of
(1)Locate the statement "The combined
and luggage load capacity calcu-
the occupants, and the weight of the
weight of occupants and cargo should
lated in Step 4.
cargo being carried or towed. Do not
never exceed XXX kilograms or XXX
(6)If your vehicle will be towing a trailer,
overload the vehicle as there is a limit
pounds'' on your vehicle's placard.
load from your trailer will be trans-
to the total weight, or load limit including
(2)Determine the combined weight of
ferred to your vehicle. Consult this
occupants and cargo, the vehicle can
the driver and passengers that will be
manual to determine how this re-
carry.
riding in your vehicle.
duces the available cargo and lug-
gage load capacity of your vehicle.
2 DRIVING YOUR HYUNDAI
24
Example 1
Example 2
Example 3
A
B
C
A
B
C
A
B
C
C190F01JM
C190F02JM
C190F03JM
Item
Description
Total
Item
Description
Total
Item
Description
Total
1400 lbs
1400 lbs
1400 lbs
A
Vehicle Capacity Weight
A
Vehicle Capacity Weight
A
Vehicle Capacity Weight
(635 kg)
(635 kg)
(635 kg)
Subtract Occupant Weight
300 lbs
Subtract Occupant Weight
750 lbs
Subtract Occupant Weight
860 lbs
B
B
B
150 lbs (68 kg) × 2
(136 kg)
150 lbs (68 kg) x 5
(340 kg)
172 lbs (68 kg) x 5
(390 kg)
Available Cargo and
1100 lbs
Available Cargo and
650 lbs
540 lbs
C
C
C
Available Cargo Weight
Luggage weight
(498 kg)
Luggage Weight
(295 kg)
(245 kg)
DRIVING YOUR HYUNDAI
2
25
C190G03JM-AAT
Refer to your vehicle's tire and loading
This label also tells you the maximum
Compliance Label
information label for specific informa-
weights that can be supported by the
tion about your vehicle's capacity weight
front and rear axles, called Gross Axle
and seating positions. The combined
Weight Rating (GAWR). To find out the
weight of the driver, passengers and
actual loads on your front and rear
cargo should never exceed your
axles, you need to go to a weigh station
vehicle's capacity weight.
and weigh your vehicle. Your dealer can
help you with this. Be sure to spread out
your load equally on both sides of the
centerline.
C190G01A
!
The compliance label is located on the
WARNING:
driver's side of the center piller outer
o Never exceed the GVWR for your
panel.
vehicle, the GAWR for either the
front or rear axle and vehicle ca-
The label shows the maximum allow-
pacity weight. Exceeding these rat-
able weight of the fully loaded vehicle.
ings can cause an accident or
This is called the GVWR (Gross Ve-
vehicle damage. You can calcu-
hicle Weight Rating). The GVWR in-
late the weight of your load by
cludes the weight of the vehicle, all
weighing the items (or people)
occupants, fuel and cargo.
before putting them in the vehicle.
Be careful not to overload your
vehicle.
2 DRIVING YOUR HYUNDAI
26
NOTE:
o Overloading your vehicle may
!
!
WARNING:
WARNING:
cause damage. Repairs would not
o Do not load your vehicle any
o Overloading your vehicle can
be covered by your warranty. Do
heavier than the GVWR, either the
cause heat buildup in your
not overload your vehicle.
maximum front or rear GAWR and
vehicle's tires and possible tire
o Using heavier suspension com-
vehicle capacity weight. If you do,
failure that could lead to a crash.
ponents to get added durability
parts, including tires on your ve-
o Overloading your vehicle can
might not change your weight rat-
hicle can break, and it can change
cause increased stopping dis-
ings. Ask your dealer to help you
the way your vehicle handles and
tances that could lead to a crash.
load your vehicle the right way.
braking ability. This could cause
o A crash resulting from poor han-
you to lose control and crash.
dling vehicle damage, tire failure,
The label will help you decide how much
or increased stopping distances
Also, overloading can shorten the
cargo and installed equipment your
life of your vehicle.
could result in serious injury or
vehicle can carry.
death.
If you carry items inside your vehicle -
like suitcases, tools, packages, or any-
thing else - they more as fast as the
vehicle goes. If you have to stop or turn
quickly, or if there is a crash, the items
will keep going and can cause an injury
if they strikes the driver or a passenger.
DRIVING YOUR HYUNDAI
2
27
!
WARNING:
Items you carry inside your vehicle
can strike and injure people in a
sudden stop or turn, or in a crash.
o Put things in the cargo area of
your vehicle. Try to spread the
weight evenly.
o Never stack items, like suitcases,
inside the vehicle above the tops
of the seats.
o Do not leave an unsecured child
restraint in your vehicle.
o When you carry something inside
the vehicle, secure it.
o Do not drive with a seat folded
down unless necessary.
WHAT TO DO IN AN EMERGENCY
If the Engine will not Start
3-2
Jump Starting
3-3
If the Engine Overheats
3-4
Tire Pressure Monitoring System (TPMS)
3-5
Spare Tire
3-9
3
If You Have a Flat Tire
3-11
Changing a Flat Tire
3-11
If Your Vehicle Must be Towed
3-16
Emergency Towing
3-18
If You Lose Your Keys
3-18
3
WHAT TO DO IN AN EMERGENCY
3
IF THE ENGINE WILL NOT START
2
D010A01A-AAT
2. Check the battery connections to be sure
D010D01A-AAT
they are clean and tight.
If the Engine Stalls While Driving
3. Turn on the interior light. If the light dims or
!
1. Reduce your speed gradually, keeping a
WARNING:
goes out when you operate the starter, the
straight line. Move cautiously off the road to
If the engine will not start, do not push or
battery is discharged.
a safe place.
pull the car to start it. This could result in a
4. Check the starter connections to be sure
2. Turn on your emergency flashers.
collision or cause other damage. In addi-
they are securely tightened.
3. Try to start the engine again. If your vehicle
tion, push or pull starting may cause the
5. Do not push or pull the vehicle to start it. See
will not start, contact a Hyundai dealer or
catalytic converter to be overloaded and
instructions for "Jump Starting".
seek other qualified assistance.
create a fire hazard.
D010B03A-AAT
D010C02Y-AAT
If Engine Doesn’t Turn Over or Turns
If Engine Turns Over Normally but Does
Over Slowly
F020100AUN
Not Start
If the engine stalls at a crossroad or
1. Check fuel level.
crossing
2. With the key in the "OFF" position, check all
connectors at ignition, coils and spark plugs.
If the engine stalls at a crossroad or crossing,
Reconnect any that may be disconnected or
set the shift lever in the N (Neutral) position and
loose.
then push the vehicle to a safe place. If your
3. Check the fuel line in the engine compart-
vehicle has a manual transaxle not equipped
ment.
with the ignition lock switch, the vehicle can
4. If the engine still does not to start, call a
move forward by shifting to the 2(second) or
Hyundai dealer or seek other qualified assis-
3(third) gear and then turning the starter without
tance.
depressing the clutch pedal.
D010B01GK
1. If your car has an automatic transaxle, be
sure the gear selector lever is in "N" or "P"
and the parking brake is set.
WHAT TO DO IN AN EMERGENCY
3
JUMP STARTING
3
D020A03A-AAT
o
To jump start a car with a discharged battery,
2.0L
follow this procedure exactly:
!
WARNING:
1.
If the booster battery is installed in another
The gas produced by the battery during the
vehicle, be sure the two vehicles are not
Dis-
jump-start operation is highly explosive. If
touching.
charged
these instructions are not followed exactly,
2.
Turn off all unnecessary lights and acces-
battery
serious personal injury and damage to the
sories in both vehicles.
vehicle may occur! If you are not sure how
3.
Attach the clamps of the jumper cable in the
to follow this procedure, seek qualified
exact location shown on the previous page.
assistance. Automobile batteries contain
First, attach one clamp of the jumper cable
sulfuric acid. This is poisonous and highly
to the positive (+) post or cable of the dis-
corrosive. When jump starting, wear pro-
charged battery. Then attach the other end
tective glasses and be careful not to get
of the same cable to the positive (+) post or
Booster battery
acid on yourself, your clothing or on the car.
HGK4001
cable of the booster battery. Next, using the
other cable, attach one clamp to the negative
2.7L
Dis-
(-) post or cable of the booster battery. Then
charged
o If you should accidentally get acid on your
attach the other end of that cable to a solid
battery
skin or in your eyes, immediately remove
metal part of the engine of the vehicle with the
any contaminated clothing and flush the area
discharged battery away from the battery.
with clear water for at least 15 minutes. Then
Do not connect the cable to any moving part.
promptly obtain medical attention. If you
4.
Start the engine in the car with the booster
must be transported to an emergency facil-
battery and let it run for a few minutes. This
ity, continue to apply water to the affected
will help to assure that the booster battery is
area with a sponge or cloth.
fully charged. During the jumping operation,
o The gas produced by the battery during the
run the engine in this vehicle at about 2,000
jump-start operation is highly explosive. Do
rpm.
not smoke or allow a spark or an open flame
5.
Start the engine in the car with the dis-
Booster battery
in the vicinity.
charged battery using the normal starting
HGK4002
o The battery being used to provide the jump
procedure. After the engine starts, leave the
start must be 12-volt. If you cannot deter-
jumper cables connected and let the engine
mine that it is a 12-volt battery, do not attempt
run at fast idle or about 2000 rpm for several
to use it for the jump start.
minutes.
WHAT TO DO IN AN EMERGENCY
3
IF THE ENGINE OVERHEATS
4
6. Carefully remove the jumper cables in the
D030A02A-AAT
reverse order of attachment.
If your temperature gauge indicates overheat-
!
ing, you experience a loss of power, or hear loud
WARNING:
If you do not know why your battery became
pinging or knocking and the engine is probably
While the engine is running, keep hair,
too hot. If this happens and, you should:
discharged (because the lights were left on,
hands, and clothing away from moving
etc.), have the charging system checked by
parts such as the fan and drive belts to
your Hyundai dealer.
1.
Pull off the road and stop as soon as it is safe
prevent injury.
to do so.
2.
Place the gear selector lever in "P" (auto-
5. If the water pump drive belt is broken or
matic), or neutral (manual transaxle) and set
engine coolant is leaking out, stop the engine
the parking brake. If the air conditioning is on,
immediately and call the nearest Hyundai
turn it off.
dealer for assistance.
3.
If engine coolant is running out under the car
or steam is coming out from the hood, stop
the engine. Do not open the hood until the
engine coolant has stopped running or the
!
WARNING:
steaming has stopped. If there is no visible
Do not remove the radiator cap when the
loss of engine coolant and no steam, leave
engine is hot. This can allow coolant to be
the engine running and check to be sure the
blown out of the opening and cause seri-
engine cooling fan is operating. If the fan is
ous burns.
not running, turn the engine off.
4.
Check to see if the water pump drive belt is
missing. If it is not missing, check to see that
it is tight. If the drive belt seems to be
satisfactory, check for engine coolant leak-
ing from the radiator, hoses or under the car.
(If the air conditioning had been in use, it is
normal for cold water to be draining from it
when you stop).
WHAT TO DO IN AN EMERGENCY
3
TIRE PRESSURE MONITORING SYSTEM (TPMS)
5
6.
If you cannot find the cause of the overheat-
C320A01JM-AAT
As an added safety feature, your ve-
ing, wait until the engine temperature has
hicle has been equipped with a tire
returned to normal. Then, if the engine cool-
pressure monitoring system (TPMS)
ant has been lost, carefully add water to the
reservoir (Page 6-8) to bring the fluid level in
that illuminates a low tire pressure tell-
the reservoir up to the halfway mark.
tale when one or more of your tires is
7.
Proceed with caution, keeping alert for fur-
significantly under-inflated. Accord-
ther signs of overheating. If overheating
ingly, when the low tire pressure telltale
happens again, call a Hyundai dealer for
assistance.
illuminates, you should stop and check
your tires as soon as possible, and
inflate them to the proper pressure.
!
Driving on a significantly under-inflated
CAUTION:
tire causes the tire to overheat and can
Serious loss of engine coolant indicates
OGK036400N
there is a leak in the cooling system and this
lead to tire failure. Under-inflation also
➀ Low Tire Pressure Telltale
should be checked as soon as possible by
reduces fuel efficiency and tire tread
a Hyundai dealer.
➁ TPMS Malfunction Indicator
life, and may affect the vehicle’s han-
dling and stopping ability.
Each tire, including the spare (if pro-
vided), should be checked monthly when
Please note that the TPMS is not a
cold and inflated to the inflation pres-
substitute for proper tire maintenance,
sure recommended by the vehicle manu-
and it is the driver’s responsibility to
facturer on the vehicle placard or tire
maintain correct tire pressure, even if
inflation pressure label. (If your vehicle
under-inflation has not reached the level
has tires of a different size than the size
to trigger illumination of the TPMS low
indicated on the vehicle placard or tire
tire pressure telltale.
inflation pressure label, you should de-
termine the proper tire inflation pres-
sure for those tires.)
WHAT TO DO IN AN EMERGENCY
3
6
Your vehicle has also been equipped
Low tire pressure telltale
with a TPMS malfunction indicator to
!
CAUTION:
indicate when the system is not operat-
When the tire pressure monitoring sys-
In winter or cold weather, the low tire
ing properly. The TPMS malfunction
tem warning telltale is illuminated, one
pressure telltale may be illuminated
indicator is provided by a separate tell-
or more of your tires is significantly
if the tire pressure was adjusted to
tale, which displays the symbol "TPMS"
under-inflated.
the recommended tire inflation pres-
when illuminated. When the malfunc-
Immediately reduce your speed, avoid
sure in warm weather. It does not
tion indicator is illuminated, the system
hard cornering and anticipate increased
mean your TPMS is malfunctioning
may not be able to detect or signal low
stopping distances. You should stop
because the decreased temperature
tire pressure as intended. TPMS mal-
and check your tires as soon as pos-
leads to a proportional lowering of
functions may occur for a variety of
sible. Inflate the tires to the proper
tire pressure.
reasons, including the installation of
pressure as indicated on the vehicle’s
When you drive your vehicle from a
replacement or alternate tires or wheels
placard or tire inflation pressure label
warm area to a cold area or from a
on the vehicle that prevent the TPMS
located on the driver’s side center pillar
cold area to a warm area, or the
from functioning properly. Always check
outer panel. If you cannot reach a ser-
outside temperature is greatly higher
the TPMS malfunction telltale after re-
vice station or if the tire cannot hold the
or lower, you should check the tire
placing one or more tires or wheels on
newly added air, replace the low pres-
inflation pressure and adjust the tires
your vehicle to ensure that the replace-
sure tire with the temporary spare tire.
to the recommended tire inflation
ment or alternate tires and wheels allow
Then the TPMS malfunction indicator
pressure.
the TPMS to continue to function prop-
may turn on and the Low Tire Pressure
erly.
telltale may turn off after restarting and
about 20 minutes of continuous driving
before you have the low-pressure tire
repaired and replaced on the vehicle.
WHAT TO DO IN AN EMERGENCY
3
7
tale may turn on at the same time as the
o If there is a failed tire sensor, it is
TPMS malfunction indicator.
possible for the TPMS to tempo-
!
WARNING:
Have the system checked by an autho-
rarily learn a replacement sensor
Significantly low tire pressure makes
rized Hyundai dealer as soon as pos-
if closely driven to another vehicle
the vehicle unstable and can contrib-
sible to determine the cause of the
that is also equipped with TPMS.
ute to loss of vehicle control and
problem.
In rare cases, this may tempo-
increased braking distances.
rarily delay the TPMS malfunction
Continued driving on low pressure
NOTE:
indicator from turning on.
tires will cause the tires to overheat
o The TPMS malfunction indicator
and fail.
may be illuminated if the vehicle
Changing a tire with TPMS
is operated in areas close to elec-
If you have a flat tire, the Low Tire
tric power supply cables or radio
Pressure telltale will turn on. Have the
transmitters such as near police
TPMS (Tire pressure monitoring
flat tire repaired by an authorized Hyundai
stations, government and public
dealer as soon as possible or replace
system) malfunction telltale
offices, broadcasting stations,
the flat tire with the temporary spare
military installations, airports, or
The TPMS malfunction indicator turns
tire. NEVER use a puncture-repairing
transmitting towers, etc. which can
on and stays on when there is a problem
agent to repair and/or inflate a low
interfere with normal operation of
with the Tire Pressure Monitoring Sys-
pressure tire. If used, you will have to
the Tire Pressure Monitoring Sys-
tem. If the system is able to correctly
replace the tire pressure sensor.
tem (TPMS).
detect an under-inflation warning at the
Each wheel is equipped with a tire
o The TPMS malfunction indicator
same time as system failure then it will
pressure sensor mounted inside the tire
may be illuminated if snow chains
illuminate both the TPMS malfunction
behind the valve stem. You must use
some electronic devices, such as
and the low tire pressure telltale e.g. if
TPMS specific wheels. It is recom-
notebook computers, are used in
Front Left sensor fails, the TPMS mal-
mended that you always have your tires
the vehicle. This can interfere with
function indicator turns, but if Front
serviced by an authorized Hyundai dealer
normal operation of the Tire Pres-
Right, Rear Left, or Rear Right tire is
as soon as possible.
sure Monitoring System (TPMS).
under-inflated, the low tire pressure tell-
WHAT TO DO IN AN EMERGENCY
3
8
After you replace the low pressure tire
Always be sure the tire is cold before
with the spare tire, the TPMS malfunc-
inflating to the recommended pressure.
!
tion indicator or the Low Tire Pressure
A cold tire means the vehicle has been
WARNING - TPMS
telltale may illuminate after restarting
sitting for 3 hours and driven for less
o The TPMS cannot alert you to se-
and about 20 minutes of continuous
than 1 mile in that 3 hour period.
vere and sudden tire damage
driving.
caused by external factors.
Once the low pressure tire is re-inflated
NOTE:
o If you feel any vehicle instability,
to the recommended pressure and in-
o Do not use any tire sealant if your
immediately take your foot off the
stalled on the vehicle, the TPMS mal-
vehicle is equipped with a Tire
accelerator and slowly move to a
function indicator and the low tire pres-
Pressure Monitoring System. The
safe position off the road.
sure telltale will extinguish. If the low
liquid sealant can damage the tire
pressure and TPMS malfunction indi-
pressure sensors.
cators are not extinguished after about
o In order for the system to correctly
20 minutes of continuous driving, please
monitor tires for under-inflation,
!
visit an authorized Hyundai dealer.
there should be a total of exactly 4
WARNING:
You may not be able to identify a low tire
sensors fitted to each of the four
Tampering with, modifying, or dis-
by simply looking at it. Always use a
driven wheel positions. There
abling the Tire Pressure Monitoring
good quality tire pressure gauge to
should be no other sensors in the
System (TPMS) components may
measure the tire's inflation pressure.
vehicle include spare tire position
interfere with the system's ability to
Please note that a tire that is hot (from
since this could cause the system
warn the driver of low tire pressure
being driven) will have a higher pres-
to monitor the wrong sensors.
conditions and/or TPMS malfunc-
sure measurement than a tire that is
tions. Tampering with, modifying,
cold (from sitting stationary for at least
or disabling the Tire Pressure Moni-
3 hours and driven less than 1 mile
toring System (TPMS) components
during that 3 hour period). Allow the tire
may void the warranty for that por-
to cool before measuring the inflation
tion of the vehicle.
pressure.
WHAT TO DO IN AN EMERGENCY
3
SPARE TIRE
9
D040A03GK-AAT
This device complies with Part 15 of
4. As the temporary spare tire is spe-
Temporary Spare Tire
the FCC rules.
cifically designed for your car, it
Operation is subject to the following two
The following instructions for the tem-
should not be used on any other
conditions:
porary spare tire should be observed:
vehicle.
1. This device may not cause harmful
5. The temporary spare tire should not
interference, and
1. Check inflation pressure as soon as
be used on any other wheels, nor
2. This device must accept any inter-
practical after installing the spare
should standard tires, snow tires,
ference received, including interfer-
tire, and adjust to the specified pres-
wheel covers or trim rings be used
ence that may cause undesired op-
sure. The tire pressure should be
with the temporary spare wheel. If
eration.
periodically checked and maintained
such use is attempted, damage to
at the specified pressure while the
these items or other car components
tire is stored.
may occur.
!
WARNING:
6. The temporary spare tire pressure
Changes or modifications not ex-
Spare Tire Pressure
should be checked once a month
pressly approved by the party re-
Tire Size
T125/70 R16
while the tire is stored.
sponsible for compliance could void
Inflation Pressure
420 kPa(60 psi)
the user’s authority to operate the
equipment.
!
2. The spare tire should only be used
CAUTION:
temporarily and should be returned
o Do not use snow chains with your
to the luggage compartment as soon
temporary spare tire.
as the original tire can be repaired or
o Do not use more than one tempo-
replaced.
rary spare tire at a time.
3. Continuous use at speeds of over 50
o Do not tow a trailer while the tem-
mph (80 km/h) is not recommended.
porary spare tire is installed.
WHAT TO DO IN AN EMERGENCY
3
10
D040A01TG-AAT
D040B01A-AAT
Full Size Spare Tire (If Installed)
Handling the Spare Tire
!
WARNING:
The following instructions for the FULL
The temporary spare tire is for emer-
SIZE spare tire should be observed:
gency use only. Do not operate your
vehicle on this temporary spare at
Check inflation pressure as soon as
speeds over 50 mph (80 kmh). The
practical after installing the spare tire,
original tire should be repaired or
and adjust to the specified pressure.
replaced as soon as is possible to
The tire pressure should be periodically
avoid failure of the spare possibly
checked and maintained at the speci-
leading to personal injury or death.
fied pressure while the tire is stored.
HGK4010A
Spare Tire Pressure
Remove the installation bolt to remove
Tire Size
Full Size
the spare tire. To replace the spare tire
Inflation Pressure
240 kPa (35 psi)
in its storage compartment, tighten the
bolt firmly with your fingers until there is
no more play in the spare tire.
WHAT TO DO IN AN EMERGENCY
3
IF YOU HAVE A FLAT TIRE
CHANGING A FLAT TIRE
11
D050A01A-AAT
D060A02A-AAT
D060B02GK-AAT
1. Obtain Spare Tire and Tool
If a tire goes flat while you are driving:
1. Take your foot off the accelerator
pedal and let the car slow down while
driving straight ahead. Do not apply
the brakes immediately or attempt to
pull off the road as this may cause a
loss of control. When the car has
slowed to such a speed that it is safe
to do so, brake carefully and pull off
the road. Drive off the road as far as
OGK036060
possible and park on firm, level
HGK4008
The procedure described on the follow-
ground. If you are on a divided high-
ing pages can be used to rotate tires as
Remove the spare tire and remove the
way, do not park in the median area
well as to change a flat tire. When
jack and tool bag from the trunk.
between the two traffic lanes.
preparing to change a flat tire, check to
2. When the car is stopped, turn on your
be sure the gear selector lever is in "P"
emergency hazard flashers, set the
(automatic transaxle) or reverse gear
parking brake and put the transaxle
(manual transaxle) and that the parking
in "P" (automatic) or reverse (manual
brake is set, then:
transaxle).
3. Have all passengers get out of the car.
Be sure they all get out on the side of
the car that is away from traffic.
4. Change the tire following the instruc-
tions provided on the following pages.
WHAT TO DO IN AN EMERGENCY
3
12
D060C01A-AAT
D060D02A-AAT
2. Block the Wheel
3. Loosen Wheel Nuts
Flat tire
HGK4009
The jack is located behind the right side
HGK4011
HGK4013
luggage trim. Remove the jack cover by
Block the wheel that is diagonally oppo-
The wheel nuts should be loosened
unscrewing the bolts. Turn the jack end
site from the flat to keep the vehicle
slightly before raising the car. To loosen
counterclockwise to lower the jack
from rolling when the car is raised on the
the nuts, turn the wrench handle coun-
height by using a screw driver or wrench
jack.
terclockwise. When doing this, be sure
bar and remove it from the bracket.
that the socket is seated completely
over the nut so it cannot slip off. For
maximum leverage, position the wrench
so the handle is to the left as shown in
the drawing. Then, while holding the
wrench near the end of the handle, push
down on it with steady pressure. Do not
remove the nuts at this time. Just
loosen them about one-half turn.















Content   ..  8  9  10  11   ..
