Hyundai Santa Fe XL (2019 year). Instruction - part 10

Features of your vehicle

Programming

✽ NOTICE

Flashing

Some devices may require you to

Flashing

replace this Programming step

3

with procedures noted in the "Gate

Operator/Canadian Programming"

section. If the HomeLink® indicator

light does not change to a rapidly

blinking light after performing these

steps, contact HomeLink®

at

www.homelink.com.

ONC048630N

2. Position the end of your hand-held

ONC048629N

transmitter

1-3 inches

(2-8 cm)

To train most devices, follow these

away from the HomeLink® button

instructions:

you wish to program while keeping

1. For first-time programming, press

the indicator light in view.

and hold the two outside buttons

3. Simultaneously press and hold

(

,

), HomeLink® Channel

1

both the HomeLink® and hand-

and Channel 3, until the indicator

held transmitter buttons until the

light begins to flash (after 10 sec-

HomeLink®

indicator

light

onds). Release both buttons. Do

changes from a slow to a rapid

not hold the buttons for longer

blinking light. Now you may

than 20 seconds.

release both the HomeLink® and

hand-held transmitter buttons.

4 65

Features of your vehicle

Reprogramming a single

Erasing HomeLink® buttons

FCC ID: NZLTLMHL4

HomeLink® button

Individual buttons cannot be erased.

IC: 4112A-TLMHL4

To program a device to HomeLink®

However, to erase all three pro-

using a HomeLink® button previously

grammed buttons:

This device complies with Part 15

trained, follow these steps:

1. Press and hold the two outer

of the FCC Rules.

1. Press and hold the desired

HomeLink® buttons until the indi-

Operation is subject to the following

HomeLink® button. DO NOT

cator light begins to flash after 10

two conditions:

release the button.

seconds.

1. This device may not cause harm-

2. The indicator light will begin to

2. Release both buttons. Do not hold

ful interference, and

flash after

20 seconds. Without

for longer than 20 seconds.

2. This device must accept any inter-

releasing the HomeLink® button,

The Integrated HomeLink® Wireless

ference received, including inter-

proceed with "Programming" step

Control System is now in the training

ference that may cause undesired

2.

(learn) mode and can be pro-

operation.

grammed at any time following the

appropriate

steps

in

the

For questions or comments, contact

CAUTION

Programming sections above.

HomeLink®omelwww.homelink.com or

The transceiver has been tested

1-800-355-3515.

and complies with FCC and

Industry Canada rules. Changes

or modifications not expressly

approved by the party responsi-

ble for compliance could void

the user's authority to operate

the device.

4 67

Features of your vehicle

NVS® is a registered trademark and

Blue Link® center

Side view mirrors

Z-Nav™ is a trademark of the

■ Type A

Be sure to adjust mirror angles

Gentex Corporation, Zeeland,

before driving.

Michigan. HomeLink® is a registered

Your vehicle is equipped with both

trademark owned by Johnson

left-hand and right-hand side view

Controls, Incorporated, Milwaukee,

mirrors. The mirrors can be adjusted

Wisconsin.

remotely with the remote switch. The

mirror heads can be folded back to

prevent damage during an automatic

car wash or when passing in a nar-

row street.

ONCNCO2009

■ Type B

CAUTION - Side view

mirrors

•

The right side view mirrors is

convex. Objects seen in the

mirror are closer than they

appear.

•

Use your interior rearview mir-

ror or direct observation to

determine the actual distance

ONC048628N

of following vehicles when

For the details, refer to the Blue

changing lanes.

Link® Owner’s Guide, navigation

manual or audio manual. The audio

manual is in this section.

4 68

Features of your vehicle

Remote control

To adjust the position of the mirrors:

CAUTION

1. Place the ignition switch in the ON

Do not scrape ice off the mirror

position.

face; this may damage the sur-

2. Move the lever(1) to R (right) or L

face of the glass. If ice should

(left) to select the right side mirror

restrict movement of the mirror,

or the left side mirror.

do not force the mirror for

3. Press a corresponding point on

adjustment. To remove ice, use

the mirror adjustment control to

a deicer spray, or a sponge or

position the selected mirror up,

soft cloth with warm water.

down, left or right.

4. After the adjustment, position the

lever in the center to prevent inad-

CAUTION

OANNCO2076

vertent movement.

If the mirror is jammed with ice,

The electric remote control mirror

do not adjust the mirror by force.

switch allows you to adjust the posi-

Use an approved spray de-icer

CAUTION

tion of the left and right side view mir-

(not radiator antifreeze) to

•

The mirrors stop moving when

rors.

release the frozen mechanism or

they reach the maximum

move the vehicle to a warm

adjusting angles, but the

place and allow the ice to melt.

motor continues to operate

while the switch is pressed.

Do not press the switch longer

WARNING

than necessary, the motor

may be damaged.

Do not adjust or fold the side

view mirrors while the vehicle is

•

Do not attempt to adjust the

moving. This could result in

side view mirrors by hand.

loss of control, and an accident

Doing so may damage the mir-

which could cause death, seri-

ror.

ous injury or property damage.

4 69

Features of your vehicle

Reverse parking aid function

According to the position of the side

Folding the side view mirrors

(if equipped)

view mirrors control switch (1), the

side view mirror(s) will operate as fol-

lows:

Left or Right : When the side view

mirrors control switch

is in the L (Left) or R

(Right) position, both

side view mirrors will

move downward.

Neutral : When the side view mirrors

control switch is in the neu-

tral

(center) position, the

ONCEMC3214

side view mirrors will not

ODM044035N

To fold side view mirrors, grasp the

operate.

housing of mirror and then fold it

When you shift the shift lever to the R

toward the rear of the vehicle.

(Reverse) position, the side view mir-

✽ NOTICE

ror(s) will move downward to aid

The side view mirrors will automat-

reverse parking.

ically revert to their original posi-

tions under the following conditions:

• When the ignition switch or engine

start/stop button is set to the ACC

or OFF position.

• When the shift lever is moved to

any position except the R

(Reverse) position.

4 70

Features of your vehicle

Blind spot mirror (if equipped)

WARNING

• Always check the road condi-

tion while driving for unex-

pected situations

even

though the vehicle is

equipped with a blind spot

mirror.

• The blind spot mirror is a

device made for convenience.

Do not solely rely on the mir-

OFS043249

ror but always pay attention to

traffic around you.

CAUTION

Do not clean the mirror with

harsh abrasives, fuel or other

petroleum based cleaning prod-

ucts.

OFS053068

The Blind Spot Mirror (BSM) is a

supplemental mirror that minimizes

the driver's blind spot zone by

expanding the field of view on the

rear side of the vehicle. The blind

spot mirror is equipped on the dri-

ver's left side view mirror.

4 71

Features of your vehicle

INSTRUMENT CLUSTER

■ Type A

1. Tachometer

2. Speedometer

3. Engine coolant temperature gauge

4. Fuel gauge

5. LCD display

6. Warning and indicator lights (if equipped)

■ Type B

7. Turn signal indicator lights

❈ The actual cluster in the vehicle may differ

from the illustration.

For more details, refer to the "Gauges" in

this chapter.

ONC047117N/ONC047084N

4 72

Features of your vehicle

Instrument Cluster Control

■ Type A

■ Type B

Gauges

Adjusting Instrument Cluster

Speedometer

Illumination

ODM046621L/ODM046620L

• The brightness has 20 levels : 1

(MIN) ~ 20 (MAX)

ODM046057N

ODM042056

• If you hold the illumination control

knob on the right end (+) or left end

The speedometer indicates the

The brightness of the instrument

(-), the brightness will be changed

speed of the vehicle and is calibrated

panel illumination is changed by

continuously.

in miles per hour (mph) and/or kilo-

moving the illumination control knob

meters per hour (km/h).

• If the brightness reaches to the

right or left when the ignition switch

maximum or minimum level, an

or Engine Start/Stop button is ON, or

alarm will sound.

the tail lights are turned on.

4 73

Features of your vehicle

Tachometer

Engine Coolant Temperature

Gauge

CAUTION

If the gauge pointer moves

beyond the normal range area

toward the "H" position, it indi-

cates overheating that may

damage the engine.

Do not continue driving with an

overheated engine. If your vehi-

cle overheats, refer to "If the

Engine Overheats" in chapter 6.

ODM046733

ODM046734

WARNING

The tachometer indicates the

approximate number of engine revo-

Never remove the radiator cap

This gauge indicates the tempera-

lutions per minute (rpm).

when the engine is hot. The

ture of the engine coolant when the

engine coolant is under pres-

Use the tachometer to select the cor-

ignition switch or Engine Start/Stop

sure and could severely burn.

rect shift points and to prevent lug-

button is ON.

Wait until the engine is cool

ging and/or over-revving the engine.

before adding coolant to the

reservoir.

CAUTION

Do not operate the engine with-

in the tachometer's RED ZONE.

This may cause severe engine

damage.

4 74

Features of your vehicle

Fuel Gauge

Odometer

WARNING - Fuel Gauge

■ Type A

■ Type B

Running out of fuel can expose

vehicle occupants to danger.

You must stop and obtain addi-

tional fuel as soon as possible

after the warning light comes

on or when the gauge indicator

comes close to the "E (Empty)"

level.

ODM046735

CAUTION

OTLE045140/OTLE045141

This gauge indicates the approxi-

Avoid driving with a extremely

The odometer Indicates the total dis-

low fuel level. Running out of

mate amount of fuel remaining in the

tance that the vehicle has been driv-

fuel tank.

fuel could cause the engine to

en and should be used to determine

misfire damaging the catalytic

when periodic maintenance should

✽ NOTICE

converter.

be performed.

• The fuel tank capacity is given in

chapter 8.

• The fuel gauge is supplemented by

a low fuel warning light, which

will illuminate when the fuel tank

is nearly empty.

• On inclines or curves, the fuel

gauge pointer may fluctuate or the

low fuel warning light may come

on earlier than usual due to the

movement of fuel in the tank.

4 75

Features of your vehicle

Outside Temperature Gauge

Transaxle Shift Indicator

Shift indicator pop-up

(if equipped)

■ Type A

■ Type B

Automatic Transaxle Shift

Indicator

■ Type A

■ Type B

■ Type A

■ Type B

OTLA045130/OTLA045131

This gauge indicates the current out-

OTL045134/ONC046099

side air temperatures by 1°F (1°C).

ODM046615/ODM046614

The pop-up displays the current gear

- Temperature range : -40°F ~ 140°F

This indicator displays which auto-

position selected for

2 seconds

(-40°C ~ 60°C)

(P/R/N/D).

matic transaxle shift lever is select-

The outside temperature on the dis-

ed.

play may not change immediately

like a general thermometer to pre-

• Park : P

vent the driver from being distracted.

• Reverse : R

The temperature unit (from °F to °C

or from °C to °F) can be changed by

• Neutral : N

using the "User Settings" mode of

• Drive : D

the LCD display.

• Manual Shift mode : 1, 2, 3, 4, 5, 6

4 76

Features of your vehicle

LCD DISPLAY

LCD Display Control

LCD Modes

Modes

Symbol

Explanation

This mode displays driving information like the tripmeter,

Trip

fuel economy, and so on.

Computer

For more details, refer to "Trip Computer" in this chapter.

Turn By Turn

This mode displays the state of the navigation.

(if equipped)

This mode displays the state of the Advanced Smart

Cruise Control system (SCC) and Lane Departure Warning

SCC/LDWS

System (LDWS). For more details, refer to "Advanced

(if equipped)

Smart Cruise Control system (SCC)" or "Lane Departure

ODM042224

Warning System (LDWS)" in chapter 5.

The LCD display modes can be

A/V

changed by using the control buttons

This mode displays the state of the A/V system.

on the steering wheel.

(if equipped)

This mode informs of service interval and pressure sta-

(1)

: MODE button for changing

tus of each tire.

modes

This mode informs of warning messages related to

(2)

: MOVE button for changing

Service

washer fluid or malfunction of Blind Spot Detection

items

system (BSD) and so on.

(3)

: SELECT/RESET button for

When the any door is not closed securely, this symbol is

setting or resetting the

illuminated.

selected item

In this mode, you can change settings of the doors,

User Settings

lamps and so on.

4 77

Features of your vehicle

Trip Computer Mode

Turn By Turn (TBT) Mode

SCC/LDWS Mode (if equipped)

(if equipped)

■ Type A

■ Type B

■ Type A

■ Type B

■ Type A

■ Type B

OTLA045187/OTLA045188

OTLA045175/OTLA045176

ODM046611/ODM046610

The trip computer mode displays

This mode displays the state of the

information related to vehicle driving

This mode displays the state of the

Advanced Smart Cruise Control sys-

parameters including range, fuel

navigation.

tem

(SCC) or Lane Departure

economy, trip meter information and

Warning System (LDWS).

vehicle speed.

For more information, refer to

For more information, refer to "Trip

"Advanced Smart Cruise Control

Computer" in this chapter.

system (SCC)" or "Lane Departure

Warning System (LDWS)" in chapter

5.

4 78

Features of your vehicle

A/V Mode

Service Mode

■ Type A

■ Type B

■ Type A

■ Type B

Service Interval

■ Type A

■ Type B

ODM046128N/ODM046166N

Service required

ODM046613/ODM046612

OTLA045181/OTLA045182

If you do not have your vehicle serv-

This mode displays the state of the

iced according to the pre-selected

A/V system.

Service in

service interval, "Service required"

It calculates and displays when you

message is displayed for several

need a scheduled maintenance

seconds each time you set the igni-

service (mileage or days).

tion switch or Engine Start/Stop

Button to the ON position

(The

If the remaining mileage or time

mileage and time changes to "---").

reaches 900 mi. (1,500 km) or 30

days, "Service in" message is dis-

To reset the service interval to the

played for several seconds each time

mileage and days you inputted before:

you set the ignition switch or Engine

- Press the SELECT/RESET button

Start/Stop Button to the ON position.

for more than 1 second.

4 79

Features of your vehicle

■ Type A

■ Type B

Master Warning Mode

User Settings Mode

(if equipped)

Description

• This warning light informs the driv-

er the following situations:

- Low washer fluid (if equipped).

- Blind Spot Detection (BSD) mal-

function (if equipped).

- Lane Departure warning system

(LDWS) malfunction (if equipped).

ODM046607N/ODM046608N

- Smart cruise control system

Service in OFF

(SCC) malfunction (if equipped).

If the service interval is not set,

- Service reminder and so on.

ODM046178L

"Service in OFF" message is dis-

The Master Warning Light illumi-

played on the LCD display.

On this mode, you can change set-

nates when more than one of the

ting of the doors, lamps, and so on.

above warning situations occur. At

✽ NOTICE

this time, the LCD Modes Icon will

change from (

) to (

).

If any of the following conditions

occur, the mileage and days may be

If the warning situation is solved, the

incorrect.

master warning light will be turned

- The battery cable is disconnected.

off and the LCD Modes Icon will be

- The fuse switch is turned off.

changed back to its previous icon

- The battery is discharged.

(

). (ex : refill the washer fluid)

4 80

Features of your vehicle

Driving Assist (if equipped)

Items

Explanation

Smart Cruise Control

Choose the sensitivity of the smart cruise control.

Response (if equipped)

For more details, refer to "Advanced Smart Cruise Control System" in chapter 5.

Rear Cross Traffic Alert

If this item is checked, the rear cross traffic alert function will be activated.

(RCTA) (if equipped)

For more details, refer to "Blind Spot Detection System" in chapter 5.

Automatic Emergency

To activate or deactivate the AEB system.

Braking (AEB) (if equipped)

For more details, refer to "Automatic Emergency Braking (AEB)" in chapter 5.

4 81

Content   ..  8  9  10  11   ..
