Safety features of your vehicle
SRS Care
WARNING
The SRS is virtually maintenance-
free and so there are no parts you can
Modification to SRS compo-
nents or wiring, including the
safely service by yourself. If the SRS
air bag warning light " " does not
addition of any kind of badges
to the pad covers or modifica-
illuminate, when you turn the ignition
on, or continuously remains on, or
tions to the body structure,
can adversely affect SRS per-
continuously blinks have your vehicle
immediately inspected by an author-
formance and lead to possible
injury.
ized HYUNDAI dealer.
Not only the modification of
1VQA2092
the parts where the SRS sen-
Any work on the SRS system, such
Air bags may not inflate if the vehi-
sors are but also the modifica-
as removing, installing, repairing, or
cle collides with objects such as
tion of other parts of the vehi-
any work on the steering wheel, the
utility poles or trees.
cle may affect the SRS per-
front passenger's panel, front seats
formance and lead to possible
and roof rails must be performed by
injury.
an authorized HYUNDAI dealer.
No objects should be placed
Improper handling of the SRS system
may result in serious personal injury.
over or near the air bag mod-
ules on the steering wheel,
instrument panel, and the
To clean the air bag pad covers, use
front passenger's panel above
only a soft, dry cloth or one which has
the glove box, because any
been moistened with plain water.
such object could cause harm
Solvents or cleaners could adversely
if the vehicle is in a crash
affect the air bag covers and proper
severe enough to cause the
deployment of the system.
air bags to inflate.
(Continued)
3 79
Safety features of your vehicle
If components of the air bag system
Additional safety precautions
(Continued)
must be discarded, or if the vehicle
Never let passengers ride in the
If the air bags inflate, they
must be scrapped, certain safety
cargo area or on top of a folded-
must be replaced by an
precautions must be observed. An
down back seat. All occupants
authorized HYUNDAI dealer.
authorized HYUNDAI dealer knows
should sit upright, fully back in their
Do not tamper with or discon-
these precautions and can give you
seats with their seat belts on and
nect SRS wiring, or other
the necessary information. Failure to
their feet on the floor.
components of the SRS sys-
follow these precautions and proce-
Passengers should not move
tem. Doing so could result in
dures could increase the risk of per-
out of or change seats while the
injury, due to accidental infla-
sonal injury.
vehicle is moving. A passenger
tion of the air bags or by ren-
who is not wearing a seat belt dur-
dering the SRS inoperative.
ing a crash or emergency stop can
If your car was flooded and
be thrown against the inside of the
has soaked carpeting or water
vehicle, against other occupants,
on the flooring, you shouldn't
or out of the vehicle.
try to start the engine; have
Each seat belt is designed to
the car towed to an authorized
restrain one occupant. If more
HYUNDAI dealer.
than one person uses the same
seat belt, they could be seriously
injured or killed in a collision.
Do not use any accessories on
seat belts. Devices claiming to
improve occupant comfort or repo-
sition the seat belt can reduce the
protection provided by the seat belt
and increase the chance of serious
injury in a crash.
3 80
Safety features of your vehicle
Passengers should not place
Do not place items under the
(Continued)
hard or sharp objects between
front seats. Placing items under
themselves and the air bags.
the front seats could interfere with
Always sit upright with the
Carrying hard or sharp objects on
the operation of the supplemental
seatback in an upright posi-
your lap or in your mouth can result
restraint system sensing compo-
tion, centered on the seat
in injuries if an air bag inflates.
nents and wiring harnesses.
cushion with your seat belt
on, legs comfortably extended
Keep occupants away from the
Never hold an infant or child on
and your feet on the floor.
air bag covers. All occupants
your lap. The infant or child could
should sit upright, fully back in their
be seriously injured or killed in the
Always have the ignition OFF
seats with their seat belts on and
event of a crash. All infants and
when the vehicle is being
their feet on the floor. If occupants
children should be properly
towed or where it may other-
are too close to the air bag covers,
restrained in appropriate child
wise be tilted, since the side
they could be injured if the air bags
safety seats or seat belts in the
and/or curtain air bags may
inflate.
rear seat.
inflate if the sensors interpret
those tilt angles as a potential
Do not attach or place objects
rollover.
on or near the air bag covers.
WARNING
Any object attached to or placed
Be careful not to cause impact
• Sitting improperly or out of
to the doors when the ignition
on the front or side air bag covers
could interfere with the proper
position can cause occupants
is ON. The air bags may
to be shifted too close to a
inflate.
operation of the air bags.
deploying air bag, strike the
Do not modify the front seats.
interior structure or be thrown
Modification of the front seats
from the vehicle resulting in
could interfere with the operation of
serious injury or death.
the supplemental restraint system
sensing components or side air
(Continued)
bags.
3 81
Safety features of your vehicle
Adding equipment to or modi-
Air bag warning label
fying your air bag-equipped
vehicle
If you modify your vehicle by chang-
ing your vehicle's frame, bumper sys-
tem, front end or side sheet metal or
ride height, this may affect the oper-
ation of your vehicle's air bag sys-
tem.
OANNSA2006
ODM032057
Air bag warning labels, some
required by the U.S. National
Highway Traffic Safety Administration
(NHTSA), are attached to alert the
driver and passengers of potential
risks of the air bag system.
3 82
Features of your vehicle
Folding key
4-4
• Smart Liftgate (Smart Tailgate)
4-34
• Record your key number
4-4
• Emergency liftgate (tailgate) safety release
4-38
• Key operations
4-4
Windows
4-39
• Transmitter precautions
4-6
• Power windows
4-40
• Battery replacement
4-7
Hood
4-44
• Immobilizer system
4-8
• Opening the hood
4-44
Smart key
4-10
• Closing the hood
4-45
• Record your key number
4-10
Fuel filler lid
4-46
• Smart key function
4-10
• Opening the fuel filler lid
4-46
• Loss of the smart key
4-13
• Closing the fuel filler lid
4-46
• Smart key precautions
4-14
• Emergency fuel filler door release
4-49
4
• Smart key immobilizer system
4-14
Panoramic sunroof
4-50
• Battery replacement
4-16
• Sunroof open warning
4-51
Theft-alarm system
4-17
• Sunshade
4-52
• Armed stage
4-17
• Sliding the sunroof
4-52
• Theft-alarm stage
4-19
• Tilting the sunroof
4-53
• Disarmed stage
4-19
• Closing the sunroof
4-53
Door locks
4-21
• Resetting the sunroof
4-55
• Operating door locks from outside the vehicle
4-21
Steering wheel
4-56
• Operating door locks from inside the vehicle
4-23
• Electric power steering (EPS)
4-56
• Impact sensing door unlock system
4-25
• Tilt & telescopic steering
4-57
• Child-protector rear door lock
4-25
• Heated steering wheel
4-58
Liftgate (Tailgate)
4-26
• Horn
4-59
• Non-Powered liftgate (tailgate)
4-26
• Power liftgate (Power tailgate)
4-28
Mirrors
4-60
Warning and indicator lights
4-100
• Inside rearview mirror
4-60
• Warning lights
4-100
• Side view mirrors
4-68
• Indicator Lights
4-108
• Blind spot mirror
4-71
Driver assist system
4-113
Instrument cluster
4-72
• Rear parking assist system
4-113
• Instrument cluster control
4-73
• Rear View Camera
4-117
• Gauges
4-73
• Multi-view Camera System
4-118
• Transaxle Shift Indicator
4-76
Hazard warning flasher
4-119
LCD display
4-77
Lighting
4-120
• LCD Display Control
4-77
• Battery saver function
4-120
4
• LCD Modes
4-77
• Headlamp delay
4-120
• Trip Computer Mode
4-78
• Lighting control
4-121
• Turn By Turn (TBT) Mode
4-78
• Smart High Beam
4-126
• Advanced Smart Cruise Control/Lane Departure
• Adaptive Front Lighting System (AFLS)
4-129
Warning System (SCC/LDWS) Mode
4-78
Wipers and washers
4-130
• A/V Mode
4-79
• Windshield wipers
4-130
• Service Mode
4-79
• Windshield washers
4-131
• User Settings Mode
4-80
• Rear window wiper and washer switch
4-132
• Warning Messages
4-86
Interior light
4-133
Trip computer
4-95
• Automatic turn off function
4-133
• Overview
4-95
• Map lamp
4-133
• Fuel Economy
4-96
• Room lamp
4-134
• Trip A/B
4-97
• Luggage room lamp
4-135
• Digital Speedometer
4-98
• Vanity mirror lamp
4-135
• Glove box lamp
4-135
Welcome system
4-136
• Multi box
4-163
• Headlamp welcome
4-136
• Sunglass holder
4-163
• Interior light
4-136
• Luggage tray
4-164
• Pocket lamp
4-136
Interior features
4-165
Defroster
4-137
• Cigarette lighter
4-165
• Rear window defroster
4-137
• Cup holder
4-165
• Front wiper deicer
4-138
• Sunvisor
4-166
Manual climate control system
4-139
• Power outlet
4-167
• Heating and air conditioning
4-140
• AC inverter
4-168
• 3rd row climate control
4-145
• Clothes hanger
4-170
• System operation
4-145
• Floor mat anchor(s)
4-171
4
• Climate control air filter
4-147
• Aux, USB and iPod® port
4-172
• Checking the amount of air conditioner
• USB Charger
4-172
refrigerant and compressor lubricant
4-148
• Luggage net (holder)
4-173
• Air Conditioning refrigerant label
4-148
• Cargo security screen
4-173
• Side curtain
4-175
Automatic climate control system
4-149
• Automatic heating and air conditioning
4-151
Exterior features
4-176
• Manual heating and air conditioning
4-152
• Roof rack
4-176
• 3rd row climate control
4-158
Audio system
4-177
Windshield defrosting and defogging
4-159
• Antenna
4-177
• Manual climate control system
4-159
• Steering wheel audio control
4-177
• Automatic climate control system
4-160
• Audio / Video / Navigation system (AVN)
4-178
• How vehicle audio works
4-179
Storage compartments
4-162
• Caring for CDs
4-181
• Center console storage
4-162
• Glove box
4-162
Features of your vehicle
FOLDING KEY
Record your key number
Key operations
CAUTION
The key code num-
Do not fold the key without
ber is stamped or
pressing the release button.
printed on the key
This may damage the key.
code tag attached to
the key set. Should
you lose your keys,
this number will enable an author-
WARNING
ized HYUNDAI dealer to duplicate
Use only HYUNDAI original
the keys easily. Remove the key
parts for the ignition key in your
code tag and store it in a safe place.
vehicle. If an aftermarket key is
Also, record the key code number
used, the ignition switch may
and keep it in a safe and handy
ODM046800
not return to ON after START. If
place, but not in the vehicle.
this happens, the starter will
Used to start the engine.
continue to operate causing
Used to lock and unlock the doors.
damage to the starter motor
and possible fire due to exces-
Used to lock and unlock the glove
sive current in the wiring.
box.
To unfold the key, press the release
button then the key will unfold auto-
matically. To fold the key, fold the
key manually while pressing the
release button.
4 4
Features of your vehicle
Door Lock (1)
Door Unlock (2)
WARNING - Ignition key
1. Press the unlock button (2).
Leaving children unattended in
2. The driver's door will unlock. The
a vehicle with the ignition key
hazard warning lights will blink two
is dangerous even if the key is
times.
not in the ignition switch is ACC
3. Press the unlock button (2) twice
or ON position. Children copy
within 4 seconds and all doors and
adults and they could place the
liftgate
(tailgate) will unlock. The
key in the ignition switch.
hazard warning lights will blink two
The ignition key would enable
times.
children to operate power win-
dows or other controls, or even
make the vehicle move, which
NOTICE
OVF041003
could result in serious bodily
You can activate or deactivate the
1. Close all doors, engine hood and
injury or even death. Never
Two Turn Unlock and Horn
leave the keys in your vehicle
liftgate (tailgate).
Feedback function. Refer to "User
with unsupervised children,
2. Press the lock button(1).
settings" in this section.
when the engine is running.
3. All doors and liftgate (tailgate) will
lock. The hazard warning lights
will blink once.
4. If the lock button is pressed once
more within 4 seconds, the hazard
warning lights will blink and the
horn will sound once
(Horn
Feedback function).
5. Make sure that doors are locked
by checking the door lock button
inside or pulling the outside door
handle.
4 5
Features of your vehicle
Liftgate (Tailgate) unlock (3)
Transmitter precautions
(Continued)
• If the transmitter is in close prox-
The liftgate (tailgate) is unlocked if
NOTICE
the button is pressed for more than 1
imity to your mobile phone, the
The transmitter will not work if any
signal could be blocked by your
second.
of following occur:
mobile phones normal operational
Also, once the liftgate
(tailgate) is
• The ignition key is in the ignition
signals. This is especially impor-
opened and then closed, the liftgate
switch.
tant when the phone is active such
(tailgate) will be locked automatically.
• You exceed the operating distance
as making and receiving calls, text
limit (about 90 feet [30 m]).
messaging, and/or sending/receiv-
Panic (4)
• The battery in the transmitter is
ing emails. Avoid placing the
weak.
transmitter and your mobile
The horn sounds and hazard warn-
• Other vehicles or objects may be
phone in the same pants or jacket
ing lights flash for about 30 seconds
blocking the signal.
pocket and always try to maintain
if this button is pressed for more than
• The weather is extremely cold.
an adequate distance between the
1 second. To stop the horn and lights,
• The transmitter is close to a radio
two devices.
press any button on the transmitter.
transmitter such as a radio substa-
tion or an airport which can inter-
CAUTION
fere with normal operation of the
transmitter.
Keep the transmither away from
When the transmitter does not work
water or any liquid and fire.
correctly, open and close the door
If the inside of the transmitter
with the ignition key. If you have a
gets damp (due to drinks or
problem with the transmitter, con-
moisture), or is heated, internal
tact an authorized HYUNDAI deal-
circuit may malfunction.
er.
(Continued)
4 6
Features of your vehicle
Battery replacement
For replacement transmitters, see an
authorized HYUNDAI dealer for
CAUTION - Transmitter
transmitter reprogramming.
damage
The transmitter is designed to give
Do not drop, wet or expose the
you years of trouble-free use, how-
keyless entry system transmit-
ever it can malfunction if exposed to
ter to heat or sunlight.
moisture or static electricity. If you
are unsure how to use your trans-
mitter or replace the battery, contact
an authorized HYUNDAI dealer.
Using the wrong battery can cause
the transmitter to malfunction. Be
sure to use the correct battery.
OLM042302
To avoid damaging the transmitter,
The transmitter uses a 3 volt lithium
don't drop it, get it wet, or expose it
battery which will normally last for
to heat or sunlight.
several years. When replacement is
An inappropriately dis-
necessary, use the following proce-
posed battery can be harm-
dure.
ful to the environment and
1. Insert a slim tool into the slot and
may cause human health.
gently pry open the transmitter
Dispose the battery accord-
center cover.
ing to your local law(s) or
2. Replace the battery with a new
regulation.
battery (CR2032). When replacing
the battery, make sure the battery
position.
3. Install the battery in the reverse
order of removal.
4 7
Features of your vehicle
Immobilizer system
To activate the immobilizer sys-
NOTICE
(if equipped)
tem:
When starting the engine, do not use
Your vehicle is equipped with an
Turn the ignition key to the OFF posi-
the key with other immobilizer keys
electronic engine immobilizer system
tion. The immobilizer system acti-
around. Otherwise the engine may
to reduce the risk of unauthorized
vates automatically. Without a valid
not start or may stop soon after it
vehicle use.
ignition key for your vehicle, the
starts. Keep each key separate in
engine will not start.
order to avoid a starting malfunction.
Your immobilizer system is com-
prised of a small transponder in the
ignition key and electronic devices
To deactivate the immobilizer
CAUTION
inside the vehicle.
system:
Do not put metal accessories
With the immobilizer system, when-
Insert the ignition key into the key
near the ignition switch.
ever you insert your ignition key into
cylinder and turn it to the ON position.
Metal accessories may interrupt
the ignition switch and turn it to ON,
the transponder signal and may
it checks and determines and verifies
prevent the engine from being
if the ignition key is valid.
WARNING
started.
If the key is determined to be valid,
In order to prevent theft of your
the engine will start.
vehicle, do not leave spare keys
anywhere in your vehicle. Your
If the key is determined to be invalid,
NOTICE
Immobilizer password is a cus-
the engine will not start.
If you need additional keys or lose
tomer unique password and
your keys, contact an authorized
should be kept confidential. Do
HYUNDAI dealer.
not leave this number anywhere
in your vehicle.
4 8
Features of your vehicle
This device complies with Part 15
CAUTION
of the FCC rules.
The transponder in your ignition
Operation is subject to the following
key is an important part of the
two conditions:
immobilizer system. It is
1. This device may not cause harm-
designed to give years of trou-
ful interference, and
ble-free service, however you
2. This device must accept any inter-
should avoid exposure to mois-
ference received, including inter-
ture, static electricity and rough
ference that may cause undesired
handling. Immobilizer system
operation.
malfunction could occur.
CAUTION
CAUTION
Changes or modifications not
Do not change, alter or adjust
expressly approved by the party
the immobilizer system because
responsible for compliance
it could cause the immobilizer
could void the user's authority
system to malfunction and
to operate the equipment. If the
should only be serviced by an
keyless entry system is inopera-
authorized HYUNDAI dealer.
tive due to changes or modifica-
tions not approved by the party
Malfunctions caused by improp-
responsible for compliance, it
er alterations, adjustments or
will not be covered by your man-
modifications to the immobilizer
ufacturer's vehicle warranty.
system are not covered by your
vehicle manufacturer warranty.
4 9
Features of your vehicle
SMART KEY
Record your key number
Smart key function
With a smart key, you can lock or
unlock a door (and Liftgate (Tailgate))
The key code num-
and start the engine.
ber is stamped or
printed on the key
Refer to the following for more details.
code tag attached to
the key set. Should
WARNING - Smart key
you lose your keys,
Leaving children unattended in
this number will enable an author-
a vehicle with the smart key is
ized HYUNDAI dealer to duplicate
dangerous even if the Engine
the keys easily. Remove the key
Start/Stop Button is in the ACC
code tag and store it in a safe place.
or ON position. Children copy
Also, record the key code number
adults and they could press the
and keep it in a safe and handy
ODM042002
Engine Start/Stop Button.
place, but not in the vehicle.
The smart key would enable
To remove the mechanical key, press
children to operate power win-
and hold the release button (1) and
dows or other controls, or even
remove the mechanical key (2).
make the vehicle move, which
To reinstall the mechanical key, put
could result in serious bodily
the key into the hole and push it until
injury or even death. Never
a click sound is heard.
leave the keys in your vehicle
with unsupervised children,
when the Engine is running.
4 10
Features of your vehicle
Door Lock
3. Press the button of the outside
Using the button on the smart key
door handle.
1. Close all doors, engine hood and
4. The hazard warning lights will
liftgate (tailgate).
blink and the chime will sound
2. Press the lock button(1).
once.
3. The hazard warning lights will
5. Make sure that doors are locked
blink and the chime will sound
by pulling the outside door handle.
once.
4. Make sure that doors are locked
NOTICE
by pulling the outside door handle.
The door handle button will only
OVF041004
operate when the smart key is
within 28~40in. (0.7~1m) from the
outside door handle.
Even though you press the outside
door handle button, the doors will
not lock and the chime will sound
for 3 seconds if any of following
occur:
- The smart key is in the vehicle.
- The engine start/stop button is in
ACC or ON position.
ODM042006
- Any door is open.
Using the door handle button
1. Carry the smart key.
2. Close all doors, engine hood and
liftgate (tailgate).
4 11
Features of your vehicle
Unlocking
NOTICE
Using the button on the smart key
Using the door handle button
The door handle button will only
1. Press the unlock button (2) of the
1. Carry the smart key.
operate when the smart key is
smart key.
within 28~40in. (0.7~1m) from the
2. The driver’s door will unlock. The
2. Press the button of the driver's
outside door handle.
hazard warning lights will blink
outside door handle.
When the smart key is recognized
and the chime will sound two
3. The driver’s door will unlock. The
in the area of 28~40in. (0.7~1m)
times.
hazard warning lights will blink
from the front outside door han-
3. Press the unlock button (2) twice
and the chime will sound two
dle, other people can also unlock
within 4 seconds and all doors and
times.
the doors by pressing the button of
the liftgate
(tailgate) will unlock.
4. Press the button twice within
4
the front outside door handle.
The hazard warning lights will
seconds and all doors and the lift-
After unlocking the driver's door
blink and the chime will sound two
gate (tailgate) will unlock and the
or all doors, the door(s) will lock
times.
hazard warning lights will blink
automatically unless the door is
and the chime will sound two
opened.
times.
NOTICE
After pressing the button, the doors
❈ If you press the button of the front
will lock automatically unless any
passenger’s outside door handle
door is opened within 30 seconds.
while carrying the smart key, all
doors will unlock.
NOTICE
You can activate or deactivate the
Two Turn Unlock function. Refer to
"User settings" in this section.
4 12
Features of your vehicle
Liftgate (Tailgate) unlocking
Panic
Loss of the smart key
Using the liftgate
(tailgate) handle
1. Press the panic button
(4) for
A maximum of 2 smart keys can be
button
more than 1 second.
registered to a single vehicle.
1. Carry the smart key.
2. The horn sounds and hazard
If you happen to lose your smart key,
2. Press the liftgate (tailgate) handle
warning light flash for about
30
you will not be able to start the
button.
seconds.
engine. You should immediately take
3. When all doors are locked, the
the vehicle and remaining key to your
hazard warning lights will blink two
authorized HYUNDAI dealer (tow the
NOTICE
times.
vehicle, if necessary) to protect it
To stop the horn and lights, press
Once the liftgate
(tailgate) is
from potential theft.
opened and then closed, the lift-
any button on the smart key.
gate (tailgate) will lock automati-
cally.
Start-up
You can start the engine without
NOTICE
inserting the key. For detailed infor-
mation refer to the "Engine start/stop
The button will only operate when
button" in section 5.
the smart key is within
28~40in.
(0.7~1m) from the liftgate (tailgate)
handle.
NOTICE
Always have the smart key with you
Using the button on the smart key
when leaving the vehicle. If the
1. Press the liftgate (tailgate) unlock
smart key is left near the vehicle, the
button (3) for more than 1 second.
vehicle battery may be discharged.
2. When all doors are locked, the
hazard warning lights will blink two
times.
4 13















Content   ..  4  5  6  7   ..
