INSTRUMENTS AND CONTROLS
(LEFT-HAND DRIVE)
B250A02HR-GAT
OHR018001
F8
1. Brake Fluid Reservoir
12.Hood Release Lever
2. Multi-Function Light Switch
13.Headlight Leveling Switch (If Installed)
3. Instrument Cluster
14.Fuse Box
4. Horn
15.Steering Wheel Tilt Lever (If Installed)
5. Front Fog Light Switch (If Installed)
16.Cigarette Lighter
6. Windshield Wiper/Washer Switch
17.Engine Idie RPM Adjustment Knob (If Installed)
7. Rear Fog Light Switch (If Installed)
18.Ashtray
8. Hazard Warning Light Switch
19.Shift Lever
9. Rear Window Defroster Switch (If Installed)
20.Driver's Drink Holder
10.Audio System (If Installed)
21.Glove Box
11.Heating/Air Conditioning Control Panel (If Installed)
!
CAUTION:
When installing a container of liquid air freshener inside the vehicle, do not place it near the
instrument cluster nor on the instrument panel pad surface. If there is any leakage from the
air freshener onto these areas (Instrument cluster, instrument panel pad or air ventilator), it
may damage these parts. If the liquid from air freshener does leak onto these areas, wash them
with water immediately.
F9
INSTRUMENTS AND CONTROLS
(RIGHT-HAND DRIVE)
B250B02HR-GAT
OHR018001R
F10
1. Heating/Air Conditioning Control Panel (If Installed)
11.Brake Fluid Reservoir
2. Audio System (If Installed)
12.Glove Box
3. Front Fog Light Switch (If Installed)
13.Driver's Drink Holder
4. Rear Fog Light Switch (If Installed)
14.Shift Lever
5. Hazard Warning Light Switch
15.Ashtray
6. Windshield Wiper/Washer Switch
16.Engine Idie RPM Adjustment Knob (If Installed)
7. Ticket Holder
17.Cigarette Lighter
8. Horn
18.Steering Wheel Tilt Lever (If Installed)
9. Instrument Cluster
19.Fuse Box
10.Multi-Function Light Switch
20.Hood Release Lever
!
CAUTION:
When installing a container of liquid air freshener inside the vehicle, do not place it near the
instrument cluster nor on the instrument panel pad surface. If there is any leakage from the
air freshener onto these areas (Instrument cluster, instrument panel pad or air ventilator), it
may damage these parts. If the liquid from air freshener does leak onto these areas, wash them
with water immediately.
F11
YOUR VEHICLE AT A GLANCE
B255A01HR-GAT
INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER
Turn Signal Indicator Lights
Low Fuel Level Warning Light
High Beam Indicator Light
Malfunction Indicator Light (If Installed)
Low Oil Pressure Warning Light
Seat Belt Warning Light (If Installed)
Parking Brake/Low Brake Fluid Level
Diesel Pre-heat Indicator Light
Warning Light
Charging System Warning Light
Fuel Filter Warning Light
Door Ajar Warning Light
* More detailed explanations of these items will be found begining on page 1-26.
F12
FEATURES OF YOUR HYUNDAI
Fuel Recommendations
1-2
Breaking In Your New Hyundai
1-3
Key
1-4
1
Door Locks
1-5
Window Glass
1-7
Seat
1-8
To Access the Engine
1-12
Seat Belt
1-14
Child Restraint System
1-18
Instrument Cluster and Indicator Lights
1-22
Warning Light and Indicator Lights
1-26
Odometer/Trip Odometer
1-31
Multi-function Light Switch
1-32
Windshield Wiper/Washer Switch
1-35
Digital Clock
1-39
1
Glove Box
1-43
Center Seatback Console Compartment
1-44
Mirror
1-45
Hood Release
1-47
Fuel Tank Cap
1-48
Rear Gate
1-49
Side Gate
1-50
Heating and Cooling Control
1-53
Stereo Sound System
1-64
Audio System
1-66
1 FEATURES OF YOUR HYUNDAI
FUEL RECOMMENDATIONS
2
B010A04HR-GAT
Diesel fuel of above cetane 51 is used
Biodiesel
Use Diesel
in Hyundai vehicle. If two types of
Commercially supplied Diesel blends
diesel fuel are available, use summer or
of no more than 7% biodiesel, com-
winter fuel properly according to the
monly known as "B7 Diesel" may be
following temperature conditions.
used in your vehicle if Biodiesel meets
EN 14214 or equivalent specifications.
o Above -5°C (23°F) ... Summer type
(EN stands for "European Norm"). The
diesel fuel.
use of biofuels exceeding 7% made
o Below -5°C (23°F) ... Winter type
from rapeseed methyl ester (RME),
diesel fuel.
fatty acid methyl ester (FAME), veg-
etable oil methyl ester (VME) etc. or
Watch the fuel level in the tank very
mixing diesel exceeding
7% with
carefully : If the engine stops through
biodiesel will cause increased wear or
B010A01HR
fuel failure, the circuits must be com-
damage to the engine and fuel system.
Diesel fuel
pletely purged to permit restarting.
Repair or replacement of worn or dam-
aged components due to the use of non
Diesel engine must be operated only on
approved fuels will not be covered by
commercially available diesel fuel that
the manufactures warranty.
complies with EN 590 or comparable
!
CAUTION:
standard. (EN stands for "European
Biodiesel (for New Zealand)
Do not let any gasoline or water enter
Norm"). Do not use marine diesel fuel,
the tank. This would make it neces-
Commercially supplied Diesel blends
heating oils, or non-approved fuel addi-
sary to drain it out and to bleed the
of no more than 7% biodiesel, com-
tives, as this will increase wear and
lines to avoid jamming the injection
monly known as "B7 Diesel" may be
cause damage to the engine and fuel
pump and damaging the engine.
used in your vehicle if Biodiesel meets
system. The use of non-approved fuels
EN 14214 or equivalent specifications.
and / or fuel additives will result in a
(EN stands for "European Norm"). The
limitation of your warranty rights.
use of biofuels exceeding 7%, made
from rapeseed methyl ester (RME),
vegetable oil methyl ester (VME) etc. or
mixing diesel exceeding
7% with
biodiesel will cause increased wear or
damage to the engine and fuel system.
FEATURES OF YOUR HYUNDAI
1
BREAKING IN YOUR NEW
3
HYUNDAI
Repair or replacement of worn or dam-
B020B01HR-GAT
o Whether going fast or slow, vary your
aged components due to the use of non
During the First 1,000 Km
speed from time to time.
approved fuels will not be covered by
(600 Miles)
o Don't let the engine idle longer than 3
the manufactures warranty.
minutes at one time.
No formal "break-in" procedure is re-
o Don't tow a trailer during the first
quired with your new Hyundai. How-
1,000 km (600 miles) of operation.
ever, you can contribute to the eco-
!
o Do not exceed loading limits.
CAUTION:
nomical operation and durability of your
o Never use any fuel, whether diesel
Hyundai by observing the following
or B7 biodiesel or otherwise, that
recommendations during the first 1,000
B030A01P-GAT
fails to meet the latest petroleum
km (600 miles).
Before Operation
industry specification.
o Never use any fuel additives or
o While driving, keep your engine
Precautions for New Vehicle
treatments that are not recom-
speed (rpm, or revolutions per
The performance and life of a vehicle
mended or approved by the ve-
minute) between 2,000 rpm and 4,000
depend largely on how the vehicle is
hicle manufacturer.
rpm.
handled when new.
o While driving, keep under three quar-
To maintain the parts smoothly and
ters of maximum speed.
sustain high performance for a long
o Use moderate acceleration. Don't
B010F01A-AAT
time to come, be sure to observe the
start, depress the accelerator pedal
Operation in Foreign Countries
following points.
fully.
If you are going to drive your Hyundai
o For the first 300 km (200 miles), try
Make sure that your vehicle does not
in another country, be sure to:
to avoid hard stops.
miss the first 5,000 km inspections.
o Don't lug the engine (in other words,
o Observe all regulations regarding
don't drive so slowly in too-high a
After the first 5,000 km of driving, take
registration and insurance.
gear that the engine "bucks": shift to
your vehicle to your nearest service
o Determine that acceptable fuel is
a lower gear).
shop for inspection.
available.
1 FEATURES OF YOUR HYUNDAI
KEYS
4
B055A02P-GAT
B030A01A-AAT
B030B01A-AAT
LOADING YOUR VEHICLE
Record Your Key Number
Type A
Never load the luggage and people to
exceed GVWR (MLW) and GAWR of
your vehicle.
You can find the GVWR(MLW) and
GAWR -maximum loading capacities-
on the VIN plate (See page 8-2).
The GVWR (Gross Vehicle Weight Rat-
ing) or MLW (Maximum Loaded Weight)
means total weight of the vehicle, all
occupants, fuel and cargo. And GAWR
OUN026060
means the maximum weights that the
OUN046100L
For greater convenience, the same key
front and rear axles can endure the
Type B
operates all the locks in your Hyundai.
weights including vehicle itself weight.
However, because the doors can be
locked without a key, carrying a spare
!
key is recommended in case you acci-
WARNING:
dentally lock one key inside the car.
Improperly loading your car can se-
rious affect its steering and braking
performance causing a crash in
which you may be seriously injured
or killed.
B030B01HR
NOTE:
A code number is stamped on the
Your warranty does not cover parts
number plate that came with the keys
or components that fail because of
to your Hyundai.
overloading.
FEATURES OF YOUR HYUNDAI
1
DOOR LOCKS
5
This key number plate should not be left
B040A01A-AAT
B040B01HR-GAT
with the keys but kept in a safe place,
Locking and Unlocking Front
not in the vehicle. The key number
Doors With a Key
!
should also be recorded in a place
WARNING:
where it can be found in an emergency.
o Unlocked doors can be danger-
ous. Before you drive away (es-
LOCK
If you need additional keys, or if you
pecially if there are children in
should lose your keys, your authorized
UNLOCK
the car), be sure that all the doors
Hyundai dealer can make new keys if
are securely closed and locked
you can supply the key number.
so that the doors cannot be inad-
vertently opened from the inside.
B030D01HR-GAT
This helps ensure that the doors
Use of key
will not be opened accidentally.
Also, when combined with the
3
HHR2023
proper use of seat belts, locking
the doors helps keep occupants
o
The door can be locked or unlocked
from being ejected from the car in
with a key.
1
case of an accident.
o
Lock the door by turning the key
o Before opening the door, always
toward the rear of the vehicle and
look for and avoid oncoming traf-
unlock it by turning the key toward
fic.
the front.
o If you don’t close the door se-
curely, the door may open again.
4
o Be careful that someone’s body
2
B030D01HR
and hands are not trapped when
1. Ignition Switch
closing the door.
2. Front Door (Driver's Door)
3. Front Door (Passenger's Door)
(if installed)
4. Fuel Tank Cap
1 FEATURES OF YOUR HYUNDAI
6
B040C01S-AAT
B040D01FC-GAT
B040G02HR-GAT
Locking From the Outside
Locking From the Inside
Central Door Lock (If Installed)
LOCK
UNLOCK
UNLOCK
UNLOCK
LOCK
LOCK
B040C01HR
HHR2023A
B040C01HR
The doors can be locked without a key.
To lock the doors from the inside, sim-
The central door locking is operated by
To lock the doors, first push the inside
ply close the door and push the lock
pushing the driver's door lock switch
lock switch to the "LOCK" position so
switch to the "LOCK" position. When
toward the front or rear of the vehicle.
that the red mark on the switch is not
this is done, neither the outside nor the
If the passenger or rear doors are open
visible, then close the door.
inside door handle can be used.
when the switch is pushed, the door will
remain locked when closed.
NOTE:
NOTE:
o When locking the door this way,
When the door is locked, the red
NOTE:
be careful not to lock the door with
mark on the switch is not visible and
o When pushing the switch toward
the ignition key left in the vehicle.
the character "LOCK" on the switch
the rear, all doors will unlock.
o To protect against theft, always
is visible.
When pushing the switch toward
remove the ignition key, close all
the front, all doors will lock.
windows, and lock all doors when
o When the door is unlocked, the
leaving your vehicle unattended.
red mark on the switch is visible
and the character "LOCK" on the
switch is not visible.
FEATURES OF YOUR HYUNDAI
1
WINDOW GLASS
7
o The central door locking is oper-
B050A01A-AAT
B060A01HR-GAT
ated by turning the key (driver's
POWER WINDOWS (If Installed)
door only) toward the front or rear
OPEN
of the vehicle.
CLOSE
OPEN
CLOSE
!
CAUTION:
If the door is locked/unlocked mul-
tiple times in rapid succession with
either the vehicle key or door lock
switch, the system may stop operat-
B050A01HR
ing temporarily in order to protect
(1)
B060A01HR
To raise or lower the window, turn the
the circuit and prevent damage to
window regulator handle clockwise or
The power windows operate when the
system components.
counterclockwise.
ignition key is in the "ON" position. The
main switches are located on the
driver's armrest and control the front
!
windows on both sides of the vehicle.
WARNING:
The windows may be opened by de-
When opening or closing the win-
pressing the appropriate window switch
dows, make sure your passenger's
and closed by pulling up the switch. To
arms, hands and body are safely
open the window on the driver's side,
out of the way.
press the switch(1) down. The window
moves as long as the switch is oper-
ated.
1 FEATURES OF YOUR HYUNDAI
ADJUSTABLE SEATS
8
B080A01FC-GAT
B080B01HR-GAT
Auto-Down Window
FRONT SEATS
(Driver's Side) (If Installed)
Adjusting Seat Forward and
!
The Auto-Down window is moved to its
WARNING:
Rearward (Driver's Seat Only)
fully open position by pushing the
Never attempt to adjust the seat while
switch. To stop at the desired position
the vehicle is moving. This could
push the switch again.
result in loss of control or an acci-
dent which may cause death, seri-
ous injury, or property damage.
!
WARNING:
1) Be careful that someone's head,
!
hands and body are not trapped
WARNING:
by a closing window.
o Do not adjust the seat while wear-
2) Never try to operate the main
ing seat belts. Moving the seat
switch on the driver's door and the
cushion forward may cause strong
HHR2043
passenger's door window switch
pressure on the abdomen.
To move the seat toward the front or
in opposing directions at the same
o Use extreme caution so that hands
rear, pull the lock release lever up-
time. If this is done, the window
or other objects are not caught in
ward. This will release the seat on its
will stop and cannot be opened or
the seat mechanisms while the
track so you can move it forward or
closed.
seat is moving.
rearward to the desired position. When
3) Do not leave children alone in the
o Do not put a cigarette lighter on
you find the position you want, release
car. Always remove the ignition
the floor or seat. When you oper-
the lever and slide the seat forward or
key for their safety.
ate the seat, gas may gush out of
rearward on its track until it locks into
the lighter and cause fire.
the desired position and cannot be
moved further.
FEATURES OF YOUR HYUNDAI
1
9
B080C01HR-GAT
Adjusting Seatback Angle
!
!
WARNING:
(Driver's Seat Only)
WARNING:
To ensure the seat is locked se-
(If Installed)
To minimize risk of severe injury in
curely, attempt to move the seat for-
the event of a collision or a sudden
ward or rearward without using the
stop, both the driver and passen-
lock release lever.
ger seatbacks should always be in
an upright position while the ve-
hicle is in motion. The protection
provided by the seat belts in a frontal
collision may be reduced signifi-
cantly when the seatbacks are re-
clined. There is greater risk that the
driver and passenger will slide un-
der the seat belt which may result in
HHR2044
serious injury if a crash occurs when
the seatbacks are reclined. The seat
To recline the seatback, lean forward to
belt cannot provide full protection to
take your weight off it, then pull up on
an occupant if the seatback is re-
the recliner control lever at the outside
clined.
edge of the seat. Now lean back until
the desired seatback angle is achieved.
To lock the seatback into position,
release the recliner control lever.
1 FEATURES OF YOUR HYUNDAI
10
B080D02JM-GAT
B080E02O-AAT
Adjustable Headrests
Lumbar Support Control
!
WARNING:
(Driver's Seat Only) (If Installed)
Lock Knob
1
2
B080D01HR
Headrests are designed to help reduce
B080D01JM
HHR2045
the risk of neck injuries.
o For maximum effectiveness in case
To adjust the lumbar support, turn the
To raise the headrest, pull it up. To
of an accident the headrest should be
handle on the inboard side of the seat.
lower it, push it down while pressing the
adjusted so the middle of the head-
To increase the amount of lumbar sup-
lock knob. To remove the headrest,
rest is at the same height as the top of
port, pull the lever forward. To decrease
raise it as far as it can go then press the
the occupant's eyes. For this reason,
it, push the lever toward the rear.
lock knob while pulling upward.
the use of a cushion that holds the
body away from the seatback should
1. Minimum support
not be recommended.
2. Maximum support
o Do not operate vehicle with the
headrests removed as injury to the
occupants may occur in the event
of an accident. Headrests may pro-
vide protection against neck inju-
ries when properly adjusted.
o Do not adjust the headrest height
while the vehicle is in motion.
FEATURES OF YOUR HYUNDAI
1
11
B080G01HR-GAT
B110B02HR-GAT
Center Seat (With Seatback Con-
REAR SEAT (If Installed)
sole Compartment) (If Installed)
Rear Seat Cushion Under Box
Lever
HHR2052
To use the rear seat cushion under box,
pull up the clamp levers on the both
HHR2048
B110B01HR
sides of the cushion and unhook the
o To use the console compartment,
There is mutipurpose receipt space
clamp from the seat cushion's hook.
push down the lever and tilt the
under the rear seat cushion.
And then, pull the strap on the seat
seatback forward.
cushion.
o To use the center seat, lift up the
seatback until it locks into position.
!
WARNING:
!
When you return the seat cushion to
CAUTION:
its original position, make sure the
When lifting up the seatback, do not
seat belts are in position to be acces-
place any object on the console com-
sible and to function properly.
partment.
|
|
|
