REPLACEMENT
PARTS

52

REPLACEMENT PARTS - Front body

REPLACEMENT PARTS

The following section illustrates replacement parts used in the repairs described in this manual. It is important that only
Hyundai replacement parts be used in making these repairs  to ensure the repairs are made with the highest possible
standards for fit, safety and corrosion protection.

For a more complete listing of service parts, refer to an authorized Hyundai dealership.

FRONT BODY

A

B

C

D

E

RADIATOR SUPPORT PANEL COMPLETE

FRONT SIDE MEMBER ASSEMBLY,

LH/RH

FENDER APRON PANEL ASSEMBLY, LH/RH

COWL COMPLETE PANEL ASSEMBLY

COWL CROSS BAR ASSEMBLY

PART NAME

C

B

CON-0090/CON-0091

A

D

E

53

REPLACEMENT PARTS - Side body

SIDE BODY

PART NAME

CON-0200

FRONT INNER LOWER PILLAR,

LH/RH

FRONT INNER UPPER PILLAR,

LH/RH

FRONT SIDE OUTER PANEL,

LH/RH

FRONT PILLAR OUTER REINFORCEMENT,

LH/RH

CENTER PILLAR OUTER REINFORCEMENT, LH/RH

ROOF SIDE INNTER RAIL,

LH/RH

CENTER INNER PILLAR,

LH/RH

REAR SIDE OUTER PANEL,

LH/RH

SIDE SILL OUTER REINFORCEMENT,

LH/RH

 SIDE SILL OUTER PANEL,

LH/RH

A

B

C

D

E

F

G

H

I

J

G

B

H

I

A

J

F

D

E

C

54

REPLACEMENT PARTS - Rear body

REAR BODY

A

B

C

D

E

REAR FLOOR PANEL

REAR FLOOR SIDE MEMBER ASSEMBLY,         LH/RH

REAR FLOOR  CENTER CORSS MEMBER ASSEMBLY

REAR FLOOR FRONT CROSS MEMBER

BACK PANEL ASSEMBLY

PART NAME

CON-1/CON-2/CON-BODY/CON-0861

D

A

E

B

C
