47

BODY CONSTRUCTION  -  Roof panel

ROOF PANEL

1

4

3

2

5

NO

1
2
3
4
5

 PART NAME

Roof panel
Roof front rail
Roof center  rail
Tail gate hinge mounting reinforcement
Roof rear rail

CON-0320

48

SECTION B-B'

SECTION D-D'

SECTION C-C'

BODY CONSTRUCTION -  Door <Front door>

CON-0334

CON-0333

DOOR

1. FRONT DOOR

SECTION A-A'

CON-0331

   CON-0332

CON-0750

Front door outer
panel

Front door upper member

Front door latch
reinforcement

Front door outer panel

Front door inner panel

Front door upper member

Front door
outer panel

A

Ð

A'

Ð

<Cross-sectional Views>

C'

Í

Í

C

B

Í

Í

D'

B'

Ð

Front door outer panel

Brazing welding (17mm)

Brazing welding (10mm)

Bumper sealer
(Th: 1.5mm)

Mastic sealer
(16 places)

Mastic sealer

Front door inner
panel

Front door reinforcement
beam

Ð

D

Front door frame & channel assembly

Front door inner panel

49

SECTION B-B'

SECTION D-D'

SECTION C-C'

SECTION A-A'

BODY CONSTRUCTION -  Door<Rear door>

CON-0344

CON-0343

CON-0341

CON-0342

Rear door outer panel

Rear door inner panel

Rear door reinforcement
beam

Rear door latch reinforcement

Rear door outer panel

Rear door outer panel

Rear door outer
panel

Rear door inner panel

2. REAR DOOR

<Cross-sectional Views>

CON-0800

A

Ð

Ð

C'

Í

Í

C

B

D'

B'

D

Í

Í

A'

Ð

Ð

Bumper sealer
(Th: 1.5mm)

Mastic sealer
(14 places)

Rear door upper
member

Rear door inner
panel

Rear door reinforcement
beam

Rear door inner panel

Mastic sealer

50

BODY CONSTRUCTION -  Tail gate

 2

 1

NO

1
2
3

 PART TIME

Tail gate outer
Tail gate inner
Tail gate hinge

CON-0350/CON-0351/CON-0352

 3

TAIL GATE
