BT-4

BODY MODIFICATION TOOLS

ASSEMBLY  TOOLS

Vice pliers

Air bench

Quick bench

Flanging tool

Fix a panel or area to weld

Finish a hole for plug welding

Finish contact area of flange

Name

Used for

Figure

Finish contact area of  flange and finish

a hole for plug welding

MEASUREMENT  TOOLS

Centering gauge

Tracking gauge

Measure distortion of body and frame

Measure body and frame

Name

Used for

Figure

A3EB3512

A3EB3513

A3EB3514

A3EB3515

A3EB3516

A3EB3517

BODY MODIFICATION TOOLS

BT-5

Gas welding machine

Spot welding machine

Stud welding machine

Cut a panel

Weld a panel

Weld a panel

A3EB3518

A3EB3519

A3EB3520

A3EB3521

Name

Used for

Figure

WELDING MACHINE

Carbon arc welding

machine

Stretch a panel, weld a stud bolt to fix

front window mold clip

BT-6

BODY MODIFICATION TOOLS

Disk grinder

Disk sander

Belt sander

Small sized grinder

Double action sander

Orbital sander(short)

Buff

Buff

Buff paints

Buff paints or smooth finishing

BUFFING AND GRINDING  TOOLS

Name

Used for

Figure

Grind rough area of puttee assembled

area

A3EB3522

A3EB3523

A3EB3524

A3EB3525

A3EB3526

A3EB3527

Grind rough area of puttee assembled

area

BODY MODIFICATION TOOLS

BT-7

Orbital sander(long)

Flexible file

Surform tool

Hand file

Used for puttee grinding of wide area

Buff rough area of puttee area

Grind body puttee, pulley, finish puttee

Name

Used for

Figure

A3EB3528

A3EB3529

A3EB3506

A3EB3530

A3EB3531

Grind touch up area, uneven area of a

panel
