AZ9718580002 [ECU bracket (WABCO)] |
ECU bracket (WABCO) |
| - |
|
AZ9718580003 [ECU bracket (KNORR)] |
ECU bracket (KNORR) |
| - |
|
AZ9719580002-1 [Control block right without relay] |
Control block right without relay |
| - |
|
F1-1 [Fuse for seat adjusting] |
Fuse for seat adjusting |
| - |
|
F1-2 [Fuse for start switch] |
Fuse for start switch |
| - |
|
F1-3 [Fuse for ABS of trailer] |
Fuse for ABS of trailer |
| - |
|
F1-4 [Fuse for cigar lighter left] |
Fuse for cigar lighter left |
| - |
|
F1-5 [Fuse for radio and cigar lighter right] |
Fuse for radio and cigar lighter right |
| - |
|
F2-1 [Fuse for ECAS] |
Fuse for ECAS |
| - |
|
F2-2 [Fuse for ABS (30#)] |
Fuse for ABS (30#) |
| - |
|
F2-3 [Fuse for ABS (30#)] |
Fuse for ABS (30#) |
| - |
|
F2-4 [Fuse for electrodinamic window left] |
Fuse for electrodinamic window left |
| - |
|
F2-5 [Fuse for electrodinamic window right] |
Fuse for electrodinamic window right |
| - |
|
F3-1 [Fuse for spare relay] |
Fuse for spare relay |
| - |
|
F3-2 [Fuse for spare relay] |
Fuse for spare relay |
| - |
|
F3-3 [Fuse for ABS (15#)] |
Fuse for ABS (15#) |
| - |
|
F3-4 [Fuse for ECAS (15#)] |
Fuse for ECAS (15#) |
| - |
|
F3-5 [Fuse for 15# electroline] |
Fuse for 15# electroline |
| - |
|
F4-1 [Fuse for steering lights] |
Fuse for steering lights |
| - |
|
F4-2 [Fuse for 30# electroline] |
Fuse for 30# electroline |
| - |
|
F4-3 [Fuse for electrothermal seat] |
Fuse for electrothermal seat |
| - |
|
F4-4 [Fuse for 15# electroline] |
Fuse for 15# electroline |
| - |
|
F4-5 [Fuse for air dryer] |
Fuse for air dryer |
| - |
|
F5-1 [Fuse for combination instrument and control block left] |
Fuse for combination instrument and control block left |
| - |
|
F5-2 [Fuse for wiper] |
Fuse for wiper |
| - |
|
F5-3 [Fuse for electroline of air conditioner] |
Fuse for electroline of air conditioner |
| - |
|
F5-4 [Fuse for low beam] |
Fuse for low beam |
| - |
|
F5-5 [Fuse for high beam] |
Fuse for high beam |
| - |
|
F6-1 [Fuse for position light] |
Fuse for position light |
| - |
|
F6-2 [Fuse for electroline D+] |
Fuse for electroline D+ |
| - |
|
F6-3 [Fuse for front fog lamp] |
Fuse for front fog lamp |
| - |
|
F6-4 [Spare fuse] |
Spare fuse |
| - |
|
F6-5 [Spare fuse] |
Spare fuse |
| - |
|
J1 [Relay for steering lamp right] |
Relay for steering lamp right |
| - |
|
J10 [Spare relay] |
Spare relay |
| - |
|
J11 [Spare relay] |
Spare relay |
| - |
|
J2 [Relay for air dryer and electrothermal seat] |
Relay for air dryer and electrothermal seat |
| - |
|
J3 [Relay for air conditioner] |
Relay for air conditioner |
| - |
|
J4 [Relay for high beam] |
Relay for high beam |
| - |
|
J5 [Relay for fog lamp front] |
Relay for fog lamp front |
| - |
|
J6 [Relay for steering lamp left] |
Relay for steering lamp left |
| - |
|
J7 [Relay for wiper intermission control] |
Relay for wiper intermission control |
| - |
|
J8 [Relay for low beam] |
Relay for low beam |
| - |
|
J9 [Relay for position light] |
Relay for position light |
| 1 |
|
AZ9719580002 [Control block right] |
Control block right |
| 2 |
|
WG9100583049 [Start relay (80A)] |
Start relay (80A) |
| 3 |
|
Q150B0516 [Screw] |
Screw |
| 4 |
|
Q40305 [Spring washer] |
Spring washer |
| 5 |
|
Q340B05 [Nut] |
Nut |
| 6 |
|
Q340B05 [Nut] |
Nut |
| 7 |
|
Q40405 [Spring washer] |
Spring washer |
| 8 |
|
189100770103 [Line connector (I)] |
Line connector (I) |
| 9 |
|
189100770104 [Line connector ( II)] |
Line connector ( II) |
| 10 |
|
Q150B0518 [Screw] |
Screw |
| 11 |
|
Q41205 [Toothed washer] |
Toothed washer |
| 12 |
|
Q340B05 [Nut] |
Nut |
| 13 |
|
AZ9719770040 [Bracket] |
Bracket |
| 14 |
|
WG9160580501 [ABS (4S/4M )electrical control unit (WABCO)] |
ABS (4S/4M )electrical control unit (WABCO) |
| 15 |
|
WG9718580001 [ABS (4S/4M) electrical control unit (KNORR)] |
ABS (4S/4M) electrical control unit (KNORR) |
