WG9130580100-1 [Center control distribution box] |
Center control distribution box |
1 |
|
15A Fuse [Air-condition Fuse] |
Air-condition Fuse |
2 |
|
7.5A Fuse [Warning alarm Fuse] |
Warning alarm Fuse |
3 |
|
5A Fuse [Reserve Fuse] |
Reserve Fuse |
4 |
|
7.5A Fuse [Reserve Fuse] |
Reserve Fuse |
5 |
|
7.5A Fuse [Left rear lamp and high lamp Fuse] |
Left rear lamp and high lamp Fuse |
6 |
|
7.5A Fuse [Right rear lamp and high lamp Fuse] |
Right rear lamp and high lamp Fuse |
7 |
|
10A Fuse [Rear sidelight Fuse] |
Rear sidelight Fuse |
8 |
|
7.5A Fuse [Left low beam Fuse] |
Left low beam Fuse |
9 |
|
7.5A Fuse [Right low beam Fuse] |
Right low beam Fuse |
10 |
|
7.5A Fuse [Left high beam Fuse] |
Left high beam Fuse |
11 |
|
7.5A Fuse [Right high beam Fuse] |
Right high beam Fuse |
12 |
|
10A Fuse [Assistant high beam Fuse] |
Assistant high beam Fuse |
13 |
|
7.5A Fuse [Rear fog lamp Fuse] |
Rear fog lamp Fuse |
14 |
|
10A Fuse [Front fog lamp Fuse] |
Front fog lamp Fuse |
15 |
|
15A Fuse [Coldstart Fuse] |
Coldstart Fuse |
16 |
|
10A Fuse [ABS (30) Fuse] |
ABS (30) Fuse |
17 |
|
7.5A Fuse [Cigar lighter Fuse] |
Cigar lighter Fuse |
18 |
|
15A Fuse [Roof lamp and radio Fuse] |
Roof lamp and radio Fuse |
19 |
|
7.5A Fuse [Indicator light Fuse] |
Indicator light Fuse |
20 |
|
7.5A Fuse [Combination instrument II Fuse] |
Combination instrument II Fuse |
21 |
|
7.5A Fuse [Air drier Fuse] |
Air drier Fuse |
22 |
|
5A Fuse [Reserve Fuse] |
Reserve Fuse |
23 |
|
5A Fuse [ABS (15) Fuse] |
ABS (15) Fuse |
24 |
|
7.5A Fuse [Reversing light Fuse] |
Reversing light Fuse |
25 |
|
7.5A Fuse [Combination instrument I Fuse] |
Combination instrument I Fuse |
26 |
|
7.5A Fuse [Warning indicator Fuse] |
Warning indicator Fuse |
27 |
|
7.5A Fuse [Mirror beating, diff and power take off Fuse] |
Mirror beating, diff and power take off Fuse |
28 |
|
7.5A Fuse [Wiper, buzzer and working lamp Fuse] |
Wiper, buzzer and working lamp Fuse |
29 |
|
7.5A Fuse [Electric horn Fuse] |
Electric horn Fuse |
30 |
|
7.5A Fuse [Stop lamp Fuse] |
Stop lamp Fuse |
31 |
|
JD2910B [Relay] |
Relay |
32 |
|
JD2910C [Relay] |
Relay |
33 |
|
WG9130580100 [Center control distribution device] |
Center control distribution device |
34 |
|
7081D-6.3-11 [Connector] |
Connector |
35 |
|
7013-9.5-11 [Connector] |
Connector |
36 |
|
7.13-9.5-21 [Connector] |
Connector |
