Honda Civic (2022 year). Manual in english - page 30





Continued

483

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

Examples of limitations on the correct detection of the camera due to the
condition of the vehicle ahead of you, oncoming vehicles, pedestrians, or
moving bicycles

The distance between your vehicle and the vehicle ahead of you, oncoming
vehicle, pedestrian, or moving bicycle ahead of you is too short.

The vehicle ahead of you, oncoming vehicle, pedestrian, or moving bicycle
suddenly cuts in front of or jumps out in front of you.

The bicycle is stopped.

The oncoming vehicle or vehicle ahead of you is sideways.

When the vehicle ahead of you, oncoming vehicle, pedestrian, or moving bicycle
blends in with the background, preventing the system from recognizing them.

When several pedestrians or bicycles are moving ahead of you in a group.

When a pedestrian or moving bicycle crosses the road too quickly.

A pedestrian or moving bicycle approaches from the opposite direction.

The headlights of the vehicle ahead of you or oncoming vehicle are lit on one side
or not lit on either side in a dark place.

When part of a pedestrian (heads, limbs, etc.) is hidden by load.

When a pedestrian is bent over or squatting, when their hands are raised, or they
are running.

When the pedestrian is shorter than about 3.3 feet (1 meter) or taller than about
6.6 feet (2 meters) in height.

When the pedestrian is pushing a stroller or bicycle.

1

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Make sure that all the tires are of the same specified
size, type and brand, and that they are evenly worn.
If you use tires of different sizes, types, brands, or
degree of wear, the system may not work properly.

Do not modify the suspension. Altering the height of
the vehicle may prevent the system from working
properly.

484

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

Examples of other limitations on detection or system operation

When the vehicle ahead of you is a motorcycle, wheelchair, or other specially-
shaped vehicle.

When a vehicle is lower in the rear than the front such as trucks that are not
carrying a load, or a narrow vehicle.

When the vehicle ahead of you, oncoming vehicle, pedestrian or moving bicycle
is not in front of the vehicle.

The speed difference between your vehicle and the vehicle ahead of you,
oncoming vehicle, pedestrian or moving bicycle is significantly large.

When the vehicle or moving bicycle in front of you slows suddenly.

When the driver operates the brake pedal and steering wheel to avoid a collision.

When you approach the vehicle ahead of you, oncoming vehicle, pedestrians or
moving bicycles while accelerating rapidly or operating the steering wheel (except
when turning left at an intersection etc.)

*1

When the moving bicycle is a child-sized bicycle, folding bicycle, three-wheeler or
other bicycle with small tires, or a long bicycle like a tandem bicycle.

When the camera cannot correctly identify the shape of the vehicle ahead of you,
oncoming vehicle, pedestrian, or moving bicycle.

When the minimum ground clearance of a vehicle ahead of you is extremely high.

*1 : When there is a possibility of a frontal collision with the oncoming vehicle while turning left, the CMBS

TM



is activated. However, it may not be activated if you suddenly turn the steering wheel.

485

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Continued

Driving

Automatic shutoff

The CMBS

TM

 may automatically shut itself off and the safety support indicator

(amber) comes and stays on when:

You drive off-road or on a mountain road, or curved and winding road for an
extended period.

Driving in bad weather (rain, fog, snow, etc.).

Driving with the parking brake applied.

The camera temperature gets too high.

The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals,
accessories, stickers, or film on the windshield.

An abnormal tire condition is detected (incorrect tire size, flat tire, etc.).

Once the conditions that caused the CMBS

TM

 to shut off improve or are addressed

(e.g., cleaning), the system comes back on.

486

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

Even if there is little chance of a collision, the CMBS

TM

 may activate under the

following conditions:

Your vehicle approaches or passes another vehicle that is making a left or right
turn.

Your vehicle approaches another vehicle ahead of you and you change lanes to
pass.

Your vehicle approaches another vehicle at an intersection, etc.

With Little Chance of a Collision

487

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

When passing through a low or narrow gate at a speed well over the speed limit.

When there are traffic signs or structures such as guard rails are beside the road
along a curve.

When driving through curves, your vehicle comes to a point where the oncoming
vehicle is right in front of you.

When approaching stationary vehicles or walls, such as when parking.

488

uu

Honda Sensing

®

u

Low Speed Braking Control

*

Driving

Low Speed Braking Control

*

Using sonar sensors located on the front and rear bumpers, this system detects if
there is danger of a potential collision with a wall or other obstacle during normal
driving or when the accelerator pedal is depressed with too much force. The system
then assists in avoiding collisions and reducing damage from impact through
assistive braking and/or assistive driving power suppression.

1

Low Speed Braking Control

*

If the Low Speed Braking Control activates in a
situation where you do not want automatic brake
application (such as when the vehicle is between two
railroad crossing gates), simply press the brake pedal
to deactivate the system and then continue to drive
as intended.

3

WARNING

The Low Speed Braking Control System
cannot avoid all collisions and may not
reduce damage in each situation where the
accelerator is mistakenly or aggressively
pressed. Overreliance on the system may
result in a collision with serious injury or
death. Always check your surroundings,
your shift position, and your pedal use.
Driver remains responsible for safely
operating the vehicle.

* Not available on all models

Continued

489

uu

Honda Sensing

®

u

Low Speed Braking Control

*

Driving

Assistive braking

Assistive braking provides a visual and audible alert when the vehicle is moving
between approximately 1 and 6 mph (2 and 10 km/h) and there is the possibility of
a collision with a detected wall or other obstacles, as well as providing assistance
with braking.

If the only rear sensors are turned off using the parking sensor system, the assistive
braking is not working when reversing.

2

Turning off All Rear Sensors

 P. 568

How the System Works

1

Low Speed Braking Control

*

For directions on the proper handling of the sonar
sensors, please refer to the following page.

2

Sonar Sensors

*

 P. 553

The vehicle will release the brake and start moving a
few seconds after the system is activated. To keep the
vehicle stopped, keep the brake pedal depressed or
put the transmission into

(

P

.

In order to prevent the system from activating when
not needed, always turn it off during vehicle
maintenance, when loading on ships, trucks, and so
on, or when using a chassis dynamometer, free
rollers for inspection or when washing the car in
conveyor type car wash machine.

Audible Alert

Beep

Beep

The vehicle
applies brake

Driver
depresses
brake pedal

Remove
brake after
maintaining
stationary
position

Stop

* Not available on all models

490

uu

Honda Sensing

®

u

Low Speed Braking Control

*

Driving

Assistive driving power suppression

When the vehicle is stopped or moving at less than 6 mph (10 km/h) and there is an
obstacle such as a wall detected near the front of or back of the vehicle, if the
accelerator pedal is depressed more than necessary, the system will inform you with
a visual and audible alert. At the same time, the system will prevent sudden forward
or backwards movement by limiting the output of the engine, then assistive braking
will activate nearby the obstacle.

Assistive driving power suppression will not activate in the following situations.
When moving forward:
When on a steep slope or the shift position is in

(

P

(

R

, or

(

N

.

When reversing:
When on a steep slope or the shift position is in a position other than

(

R

.

If the only rear sensors are turned off using the parking sensor system, the assistive
driving power suppression is not working when reversing.

2

Turning off All Rear Sensors

 P. 568

Audible Alert

Beep

Beep

Accidental depression of
the accelerator/Limiting
the output of the engine

Continued

491

uu

Honda Sensing

®

u

Low Speed Braking Control

*

Driving

When you turn the system on and off, do the
following.

1.

Press the safety support switch.

2.

Roll the right selector wheel to the



symbol and push it.

u

A message appears on the driver
information interface when the system
turns on or off.

u

A check mark appears in the box and the
color of the

 symbol changes to green

when the system is on. The check mark
disappears and the color of the



symbol changes to gray when the system
is off.

The system is turned on every time you start
the engine, even if you turned it off the last
time you drove the vehicle.

System On and Off

1

System On and Off

You can also select safety support content from the
driver information interface.

2

Driver Information Interface

 P. 113

2

Driver Information Interface (Right Side
Area)

 P. 138

The system may temporarily turn off after
reconnecting the battery.
The system will automatically turn ON after the
vehicle has been moving at over 12 mph (20 km/h)
for some time.
If the system does not turn on, have your vehicle
checked by a dealer.

Right
Selector
Wheel

Safety Support Switch

uu

Honda Sensing

®

u

Low Speed Braking Control

*

492

Driving

Conditions for assistive driving power suppression.

When the accelerator is no longer depressed.

When the accelerator is depressed for approximately four seconds.

When the brake pedal is depressed.

When the steering wheel is turned and a collision avoided.

Conditions for assistive braking cancellation.

A certain amount of time has passed since activation.

The system may not operate correctly in the following conditions:

Examples of obstacles the sonar sensor cannot detect

Obstacles that do not reflect sound waves well, such as people, snow, cloth,
sponges, etc.

Thin obstacles such as fences, bicycles, sign posts, etc.

Short or small obstacles.

Obstacles immediately in front of the bumper.

Moving objects or obstacles that suddenly enter the road.

Obstacles that are not perpendicular to the ground.

Conditions for Cancellation

Low Speed Braking Control System Conditions and Limitations

1

Conditions for Cancellation

After Low Speed Braking Control has activated once,
it will not activate again for the same obstacle.
They can be activated again after driving for a certain
distance after last activation.

Low Speed Braking Control activates separately when
moving forward and reversing. (For example, if it
activates when moving forward, it can be activated
again immediately if reversing.)
However, if assistive braking has been activated, in
order to activate assistive driving power suppression
again, it is necessary to drive for a certain distance to
reset the system.

493

uu

Honda Sensing

®

u

Low Speed Braking Control

*

Driving

Examples of situations where the sonar sensor cannot detect obstacles

The sonar sensor is dirty (covered by snow, water, mud, etc.).

The vehicle is too hot or cold.

The steering wheel is turned sharply when approaching the obstacle at an angle.

Examples of other cases where the system may not work correctly

The vehicle is tilted due to heavy load or suspension modifications.

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

Bad weather conditions such as heavy rain, fog, snow, sandstorms, etc.

The ambient temperature/humidity is too high or low.

When going down a very steep slope.

When close to other vehicles with sonar sensors or other objects that emit
ultrasonic waves.

Situations where the system may activate even without risk of a collision

When passing through short or narrow gates.

When driving on uneven surfaces, grassy areas, or places with steps.

When a sloped pillar or wall is protruding from a high position.

When there are obstacles next to the road.

When driving toward flags, curtains, tree branches, railroad crossing bars, etc.

When driving on flooded roads.

494

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

Adaptive Cruise Control (ACC) with Low Speed Follow

Helps maintain a constant vehicle speed and a set following-interval behind a vehicle
detected ahead of yours and, if the detected vehicle comes to a stop, can decelerate
and stop your vehicle, without you having to keep your foot on the brake or the
accelerator.
When ACC with Low Speed Follow slows your vehicle by applying the brakes, your
vehicle’s brake lights will illuminate.

1

Adaptive Cruise Control (ACC) with Low Speed Follow

Important Reminder

As with any system, there are limits to ACC with Low
Speed Follow. Use the brake pedal whenever
necessary, and always keep a safe interval between
your vehicle and other vehicles.

3

WARNING

Improper use of ACC with Low Speed
Follow can lead to a crash.

Use ACC with Low Speed Follow only
when driving on expressways or freeways
and in good road and weather conditions.

3

WARNING

ACC with Low Speed Follow has limited
braking capability and may not stop your
vehicle in time to avoid a collision with a
vehicle that quickly stops in front of you.

Always be prepared to apply the brake
pedal if the conditions require.

When to use

Vehicle speed for ACC with Low Speed Follow:

A vehicle is detected ahead

within ACC with Low Speed Follow range

 – ACC with Low Speed Follow

operates at speeds up to 90 mph (145 km/h).

No vehicle is detected within ACC with Low Speed Follow range

 – ACC with

Low Speed Follow operates at the speed of 25 mph (40 km/h) or above.

Shift position for ACC with Low Speed Follow: In

(

D

 or

(

S

*

.

A front wide view camera is
located behind the rearview
mirror.

* Not available on all models

Continued

495

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

How to activate the system

1

Adaptive Cruise Control (ACC) with Low Speed Follow

You can read about handling information for the
camera equipped with this system.

2

Front Wide View Camera

 P. 551

ACC with Low Speed Follow may not work properly
under certain conditions.

2

ACC with Low Speed Follow Conditions
and Limitations

 P. 504

When not using ACC with Low Speed Follow: Turn
off adaptive cruise by pressing the

 button.

Do not use ACC with Low Speed Follow under the
following conditions:

Driving in continuous stop and go traffic.

On roads with sharp turns.

On roads with toll collection facilities or other
objects between lanes of traffic, or in parking
areas, or facilities with drive through access.

On roads with bad weather (rain, fog, snow, etc.).
It prevents the system from detecting the distance
between your vehicle and vehicle ahead of you
properly.

On roads with slippery or icy surfaces. The wheels
may spin out and your vehicle may lose the control
on the condition.

On roads with steep uphill or steep downhill slopes.

On roads with undulating slopes.

How to use

Press the

 button on the

steering wheel.

 (white) is on in the gauge

ACC with Low Speed Follow is ready to use.

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

496

Driving

When driving at about 25 mph (40 km/h) or above:

Take your foot off the

pedal and press the

RES/+

/

SET/−

 switch up or down when you reach the desired

speed. The moment you release the switch, the set speed is fixed, and ACC with Low
Speed Follow begins.

When driving slower than about 25 mph (40 km/h):

If the vehicle is moving

and the brake pedal is not depressed, pressing the switch fixes the set speed to
about 25 mph (40 km/h) regardless of current vehicle speed. If your vehicle is
stationary, you can set the vehicle speed even with the brake pedal depressed.

*1 : Models with A-type meter
*2 : Models with B-type meter

To Set the Vehicle Speed

1

To Set the Vehicle Speed

The Vehicle Stability Assist

TM

 (VSA

®

) system, Vehicle

Stability Assist

TM

 (VSA

®

OFF

, Adaptive Cruise Control

(ACC) with Low Speed Follow, low tire pressure/
TPMS

*

 and safety support indicators may come on in

amber along with a message in the gauge when you
set the power mode to ON after reconnecting the
battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

You can switch the displayed set speed
measurements on the driver information interface or
audio/information screen

*

 between mph and km/h.

2

Settings

 P. 126

2

Speed/Distance Units

 P. 125, 150

2

Customized Features

 P. 363

On when ACC with Low Speed Follow begins

Up or down

RES/+

/

SET/−

 Switch

 (green)

*1

*2

* Not available on all models

497

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

When ACC with Low Speed Follow starts
operating, the vehicle icon, interval bars and
set speed appear on the gauge.

When you use ACC with Low Speed Follow,
Straight Driving Assist (a feature of the Electric
Power Steering system) is activated.
By enabling the steering system to
automatically compensate for natural steering
pull, Straight Driving Assist makes it easier for
you to keep your vehicle in a straight line.

Set Vehicle Speed

Set Vehicle Interval

Models with A-type meter

 (green)

Set Vehicle Speed

Set Vehicle Interval

Models with B-type meter

 (green)

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

498

Driving

There is a vehicle ahead

ACC with Low Speed Follow monitors if a
vehicle ahead of you enters the ACC with Low
Speed Follow range. If a vehicle is detected
doing so, the ACC with Low Speed Follow
system maintains or decelerates your vehicle’s
set speed in order to keep the vehicle’s set
following-interval from the vehicle ahead.

2

To Set or Change Following-interval



P. 509

When in Operation

1

When in Operation

If the vehicle ahead of you slows down abruptly, or if
another vehicle cuts in front of you, a beeper sounds,
a message appears on the driver information
interface.

Depress the brake pedal, and keep an appropriate
interval from the vehicle ahead.

Beep

Outside of control target vehicle

Control target vehicle

Models with B-type meter

Control target vehicle: White
and outlined in green
Outside of control target vehicle:
Gray

ACC with Low Speed Follow Range: 394 ft. (120 m)















Content      ..     28      29      30      31     ..
