467

uu

When Driving

u

Tire Pressure Monitoring System (TPMS) - Required Federal Explanation

Continued

Driving

Tire Pressure Monitoring System (TPMS) - Required
Federal Explanation

Each tire, including the spare (if provided), should be checked
monthly when cold and inflated to the inflation pressure
recommended by the vehicle manufacturer on the vehicle placard
or tire inflation pressure label.

(If your vehicle has tires of a different size than the size indicated
on the vehicle placard or tire inflation pressure label, you should
determine the proper tire inflation pressure for those tires.)

As an added safety feature, your vehicle has been equipped with
a tire pressure monitoring system (TPMS) that illuminates a low
tire pressure telltale

when one or more of your tires is significantly under-inflated.

Accordingly, when the low tire pressure telltale illuminates, you
should stop and check your tires as soon as possible, and inflate
them to the proper pressure.

Driving on a significantly under-inflated tire causes the tire to
overheat and can lead to tire failure. Under-inflation also reduces
fuel efficiency and tire tread life, and may affect the vehicle's
handling and stopping ability.

U.S. models

468

uu

When Driving

u

Tire Pressure Monitoring System (TPMS) - Required Federal Explanation

Driving

Please note that the TPMS is not a substitute for proper tire
maintenance, and it is the driver's responsibility to maintain
correct tire pressure, even if under-inflation has not reached the
level to trigger illumination of the TPMS low tire pressure telltale.

Your vehicle has also been equipped with a TPMS malfunction
indicator to indicate when the system is not operating properly.
The TPMS malfunction indicator is combined with the low tire
pressure telltale. When the system detects a malfunction, the
telltale will flash for approximately one minute and then remain
continuously illuminated. This sequence will continue upon
subsequent vehicle start-ups as long as the malfunction exists.

When the malfunction indicator is illuminated, the system may
not be able to detect or signal low tire pressure as intended.

TPMS malfunctions may occur for a variety of reasons, including
the installation of replacement or alternate tires or wheels on the
vehicle that prevent the TPMS from functioning properly.

Always check the TPMS malfunction telltale after replacing one or
more tires or wheels on your vehicle to ensure that the
replacement or alternate tires and wheels allow the TPMS to
continue to function properly.

469

uu

When Driving

u

Blind Spot Information System

*

Continued

Driving

Blind Spot Information System

*

When the system detects vehicles approaching from behind in adjacent lanes, the
appropriate indicator comes on, providing assistance when you change lanes.

The system activates when your vehicle is moving forward at about 20 mph (32 km/h)
or above.

Alert zone range
A: Approx. 1.6 ~ 10 feet (0.5 ~ 3 meters) from vehicle side.
B: Approx. 10 feet (3 meters) from rear bumper.
C: Approx. 10 ~ 82 feet (3 ~ 25 meters) behind from rear bumper. (The faster the
approaching vehicle, the further away it will be detected.)

The initially set alert zone is alert zone 1. Over time, after the vehicle has been driven
on straight roads with traffic and roadside objects, the system will adapt and expand
the alert zone (alert zone 1 and 2).

How the System works

1

Blind Spot Information System

*

Important Safety Reminder

Like all assistance systems, the blind spot information
system has limitations. Always look in your mirrors, to
either side of your vehicle, and behind you for other
vehicles before changing lanes. Overreliance on the
blind spot information system may result in a
collision.

Have your vehicle checked by a dealer in the
following situations:

The rear bumper or area around the radar sensors
is strongly impacted.

The indicator does not come on even if a vehicle in
the alert zone should have been detected.

The rear bumper or any system components need
to be repaired.

If the rear bumper or any system components are
repaired, the system will revert to alert zone 1 only
until it is able to adapt and expand to alert zone 1
and 2.

Radar Sensors : underneath
the rear bumper corners

: Alert zone 1

A

B

C

: Alert zone 2

* Not available on all models

uu

When Driving

u

Blind Spot Information System

*

470

Driving

When the system detects a vehicle

Blind spot information system alert indicator:
Located on the outside rearview mirror on
both sides.

Comes on when:

A vehicle approaches you from behind to
overtake you at a speed difference of no
more than about 31 mph (50 km/h).

You pass a vehicle at a speed difference of
no more than about 12 mph (20 km/h).

Blinks and a beeper sounds when:

You use the turn signal lever to signal a turn in
the direction of the detected vehicle while the
blind spot information system alert indicator is
on.

u

The beeper sounds three times.

1

Blind Spot Information System

*

For proper blind spot information system operation:

Always keep the rear bumper and area around the
radar sensors clean.

Do not cover the rear bumper corner area with
labels or stickers of any kind.

The system is for your convenience only. Even if an
object is within the alert zone, the following
situations may occur:

The blind spot information system alert indicator
does not come on and the message

Blind spot

information system not available

 appears on

the driver information interface.

The blind spot information system alert indicator
may come on even with the message displayed.

Comes On

Blinks

* Not available on all models

Continued

471

uu

When Driving

u

Blind Spot Information System

*

Driving

When you turn the blind spot information
system on and off, do the following.

1.

Press the safety support switch.

2.

Roll the left selector wheel to the

 symbol

and push it.

2.

Roll the right selector wheel to the



symbol and push it.

u

A message appears on the driver
information interface when the system
turns on or off.

u

A check mark appears in the box and the
color of the

 symbol changes to green

when the system is on. The check mark
disappears and the color of the



symbol changes to gray when the system
is off.

The blind spot information system will stay on
the previously selected on (checked) or off
(unchecked) setting each time you start the
engine.

Blind Spot Information System On and Off

1

Blind Spot Information System

*

You can also select safety support content from the
driver information interface.

2

Driver Information Interface

 P. 113

2

Driver Information Interface (Right Side
Area)

 P. 138

You can change the settings for the blind spot
information system.

2

Settings

 P. 126

2

Customized Features

 P. 363

Models with A-type meter

Left Selector
Wheel

Safety Support Switch

Models with A-type meter

Models with B-type meter

Right Selector
Wheel

Safety Support Switch

Models with B-type meter

* Not available on all models

472

uu

When Driving

u

Blind Spot Information System

*

Driving

The blind spot information system alert indicator may not come on under the
following conditions:

There is a large speed difference between your vehicle and the vehicle in the
adjacent lane.

A vehicle is parked in a side lane.

An object not detected by the radar sensors approaches or passes your vehicle.

The vehicle driving in the adjacent lane is a motorcycle or other small vehicle.

The blind spot information system may not operate correctly under the following
conditions:

Making a turn at an intersection.

Objects (guard rails, poles, trees, etc.) are detected.

An object that does not reflect radio waves well or a motorcycle, is in the alert
zone.

Driving on a curved road.

A vehicle is moving from a far lane to the adjacent lane.

The system picks up signal interference such as other radar sensors from another
vehicle or strong radio wave transmitted from a facility nearby.

The rear bumper or the area around the radar sensors is covered by dirt, mud,
snow, ice, etc.

The rear bumper or the area around the radar sensors has been damaged or
deformed.

In bad weather (heavy rain, snow, and fog).

Making a short turn or driving on a bumpy road that slightly tilts the vehicle.

Blind Spot Information System Conditions and Limitations

473

Continued

Driving

Honda Sensing

®

Honda Sensing

®

 is a driver support system which employs the use of two distinctly

different kinds of sensors: the sonar sensors located in the front and rear bumper
and a front wide view camera mounted to the interior side of the windshield, behind
the rearview mirror.

Honda Sensing

®

 is a driver support system which employs the use of a front wide

view camera mounted to the interior side of the windshield, behind the rearview
mirror.

Honda Sensing

®

 has following functions.

The functions which do not require switch operations to activate

Collision Mitigation Braking System

TM

 (CMBS

TM

2

 P. 476

Low Speed Braking Control

*



2

 P. 488

Road Departure Mitigation System

2

 P. 537

Traffic Sign Recognition System

2

 P. 545

The functions which require switch operations to activate

Adaptive Cruise Control (ACC) with Low Speed Follow

2

 P. 494

Lane Keeping Assist System (LKAS)

2

 P. 516

Traffic Jam Assist

2

 P. 528

Models without Low Speed Braking Control

Models without Low Speed Braking Control

* Not available on all models

474

uu

Honda Sensing

®

u

Driving

 Button

Press to activate standby mode for ACC with
Low Speed Follow. Or press to cancel the
system.

LKAS Button

Press to activate standby mode for LKAS and
Traffic Jam Assist. Or press to cancel these
systems.

RES/+/SET/− Switch

Press the

RES/+

/

SET/−

 switch up to resume

the ACC with Low Speed Follow or increase
the vehicle speed.
Press the

RES/+

/

SET/−

 switch down to set the

ACC with Low Speed Follow or decrease the
vehicle speed.

Interval Button

Press to change the ACC with Low Speed
Follow following-interval.

CANCEL Button

Press to cancel ACC with Low Speed Follow.

Operation Switches for the Adaptive Cruise Control (ACC)

with Low Speed Follow/Lane Keeping Assist System (LKAS)/
Traffic Jam Assist

Interval Button

 Button

LKAS Button

CANCEL

 Button

RES/+

/

SET/−

 Switch

475

uu

Honda Sensing

®

u

Driving

You can see the current state of Adaptive
Cruise Control (ACC) with Low Speed Follow,
Lane Keeping Assist System (LKAS) and Traffic
Jam Assist.

a

Indicates that ACC with Low Speed Follow
is ready to be activated.

Green: The system is on.

White: The system is standby.

Amber: There is a problem with the system.

b

Indicates that LKAS or Traffic Jam Assist is
ready to be activated.

Green: The system is on.

White: The system is standby.

Amber: There is a problem with the system.

c

Indicates that LKAS or Traffic Jam Assist is
activated and whether or not traffic lane
lines are detected.

Green lines: The system is on.

White lines: Traffic lane lines are detected.

Amber line: Lane departure is detected.

d

Indicates whether or not a vehicle is
detected ahead.

Control target vehicle: White and outlined
in green

Outside of control target vehicle: Gray

e

Indicates that ACC with Low Speed Follow
shows the set vehicle speed.

f

Indicates that ACC with Low Speed Follow
shows the set vehicle interval.

Gauge Content

6

Models with A-type meter

6

Models with B-type meter

Models with B-type meter

476

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

Collision Mitigation Braking System

TM

 (CMBS

TM

)

The system can assist you when it determines there is a possibility of your vehicle
colliding with a vehicle ahead from behind, an oncoming vehicle in front, a
pedestrian, or someone riding a bicycle (moving bicycle).
The CMBS

TM

 is designed to alert you when the potential for a collision is determined,

as well as assist in reducing speed, avoiding collisions, and reducing collision
severity.

1

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Important Safety Reminder

The CMBS

TM

 is designed to reduce the severity of an

unavoidable collision. It does not prevent collisions
nor stop the vehicle automatically. It is still your
responsibility to operate the brake pedal and steering
wheel appropriately according to the driving
conditions.

The CMBS

TM

 may not activate or may not detect a

vehicle in front of your vehicle under certain
conditions:

2

CMBS

TM

 Conditions and Limitations

 P. 481

You can read about handling information for the
camera equipped with this system.

2

Front Wide View Camera

 P. 551

When the CMBS

TM

 is activated, it will continue to

operate even if the accelerator pedal is partially
depressed. However, it will be canceled if the
accelerator pedal is fully depressed.

Continued

477

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

How the system works

The CMBS

TM

 will be canceled when your vehicle stops or the system determines

there no longer is the potential for a collision.
The CMBS

TM

 may also be canceled when a driver operates the steering wheel and

the brake or accelerator pedal to avoid a collision.

1

How the system works

The camera in the CMBS

TM

 is also designed to detect

pedestrians.
However, this pedestrian detection feature may not
activate or may not detect a pedestrian in front of
your vehicle under certain conditions.
Refer to the ones indicating the pedestrian detection
limitations from the list.

2

CMBS

TM

 Conditions and Limitations

 P. 481

A front wide view camera is located
behind the rearview mirror.

The system starts monitoring the roadway ahead when your vehicle speed is about
3 mph (5 km/h) and will search for a vehicle, pedestrian, or moving bicycle in front
of you.

The CMBS

TM

 activates when:

The speed difference between your vehicle and a vehicle, pedestrian, or moving
bicycle detected in front of you becomes about 3 mph (5 km/h) and over with a
chance of a collision.

Your vehicle drives at about 18 mph (30 km/h) or less and there is a chance of in
frontal collision with a detected oncoming vehicle when you turn left at an
intersection.

Your vehicle speed is about 62 mph (100 km/h) or less and the system determines
there is a chance of a collision with:

- An oncoming or stationary vehicle detected in front of you.
- A pedestrian or moving bicycle detected in front of you.

When to use

478

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

When the system activates

You can change the distance (

Long

/

Normal

/

Short

) between vehicles at which the

system’s earliest collision alert will come on through the driver information
interface

*

 or audio/information screen

*

 setting options.

2

Settings

 P. 126

2

Customized Features

 P. 363

The system provides visual and audible alerts of a possible collision, and stops if the
collision is avoided.

u

Take appropriate action to prevent a collision (apply the brakes, change
lanes, etc.)

Visual Alerts

Beep

Audible Alert

* Not available on all models

479

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Continued

Driving

The system has three alert stages for a possible collision. However, depending on circumstances, the CMBS

TM

 may not go through all of

the stages before initiating the last stage.

Collision Alert Stages

Distance between vehicles

CMBS

TM

The sensors detect a vehicle

Audible & Visual WARNINGS

Braking

Stage

one

There is a risk of a collision with the
vehicle ahead of you.

When in

Long

, visual and audible

alerts come on at a longer distance
from a vehicle ahead than in

Normal



setting, and in

Short

, at a shorter

distance than in

Normal

.

Stage

two

The risk of a collision has increased,
time to respond is reduced.

Visual and audible alerts.

Lightly applied

Stage

three

The CMBS

TM

 determines that a collision

is unavoidable.

Forcefully applied

Your Vehicle

Vehicle
Ahead

Normal

Short

Long

Your
Vehicle

Vehicle
Ahead

Your
Vehicle

Vehicle
Ahead

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

480

Driving

When you turn the CMBS

TM

 on and off, do the

following.

1.

Press the safety support switch.

2.

Roll the left selector wheel to the



symbol and push it.

2.

Roll the right selector wheel to the



symbol and push it.

u

A message appears on the driver
information interface when the system
turns on or off.

u

A check mark appears in the box and the
color of the

 symbol changes to green

when the system is on. The check mark
disappears and the color of the



symbol changes to gray when the system
is off.

The CMBS

TM

 is turned on every time you start

the engine, even if you turned it off the last
time you drove the vehicle.

CMBS

TM

 On and Off

1

Collision Mitigation Braking System

TM

 (CMBS

TM

)

You cannot turn the CMBS

TM

 off while driving.

The CMBS

TM

 may automatically shut off, and the

safety support indicator (amber) will come and stay
on under certain conditions:

2

CMBS

TM

 Conditions and Limitations

 P. 481

The CMBS

TM

 is not activated for about 15 seconds

after the engine starts.

You can also select safety support content from the
driver information interface.

2

Driver Information Interface

 P. 113

2

Driver Information Interface (Right Side
Area)

 P. 138

The Vehicle Stability Assist

TM

 (VSA

®

) system, Vehicle

Stability Assist

TM

 (VSA

®

OFF

, Adaptive Cruise Control

(ACC) with Low Speed Follow, low tire pressure/
TPMS

*

 and safety support indicators may come on in

amber along with a message in the gauge when you
set the power mode to ON after reconnecting the
battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

Safety Support Switch

Left Selector
Wheel

Models with A-type meter

Models with A-type meter

Models with B-type meter

Right
Selector
Wheel

Safety Support
Switch

Models with B-type meter

* Not available on all models

Continued

481

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

The system may automatically shut off and the safety support indicator (amber) will
come on under certain conditions. Some examples of these conditions are listed
below. Other conditions may reduce some of the CMBS

TM

 functions.

2

Front Wide View Camera

 P. 551

Environmental conditions

Driving in bad weather (rain, fog, snow, etc.).

Sudden changes between light and dark, such as the entrance or exit of a tunnel
or the shadows of trees, buildings, etc.

Driving into low sunlight (e.g., at dawn or dusk).

Strong light is reflected onto vehicles, pedestrians, moving bicycles, or road
surfaces.

Water is sprayed by or snow blown from a vehicle ahead.

Driving at night or in a dark place such as a tunnel (due to low-light conditions,
vehicles, pedestrians, or moving bicycles may not be illuminated).

Roadway conditions

Driving on curvy, winding, undulating, or sloping roads.

There is a film of water or puddles on the road surface.

Driving on rutted roads (snowy or unpaved roads, etc.).

Your vehicle is strongly shaken on uneven road surfaces.

CMBS

TM

 Conditions and Limitations

1

CMBS

TM

 Conditions and Limitations

Have your vehicle checked by a dealer if you find any
unusual behavior of the system (e.g., the warning
message appears too frequently).

482

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

Vehicle conditions

The vehicle is tilted due to heavy load in the trunk or rear seats.

Tire chains are installed.

Driving at night or in a dark place (e.g., a tunnel) with the headlights off.

The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals,
accessories, stickers, or film on the windshield.

There is residue on the windshield from the windshield wipers.

When lighting is weak due to dirt covering the headlight lenses, or there is poor
visibility in a dark place due to the headlights being improperly adjusted.

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

The suspension has been modified.















Content      ..     27      28      29      30     ..
