Honda Civic (2022 year). Manual in english - page 7





113

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

e

nt Pa

nel

Driver Information Interface

The driver information interface shows information such as the estimated travelable
distance and fuel economy of the vehicle. It also displays messages such as warnings
and other helpful information.
When a warning message displays, please check the message and contact a dealer
and have the vehicle inspected if necessary. Please refer to the pages below if the

Engine oil pressure low.

 or

Engine temperature too hot.

 message is displayed.

2

If the Low Oil Pressure Warning Appears

 P. 658

2

Overheating

 P. 656

Accessing contents in the display

Press the

 (home) button, then roll the left selector wheel to scroll to the content

you want to see. Press the left selector wheel to see detailed information.

Switching the Display

Models with A-type meter

1

Switching the Display

You can add or delete the meter contents.

2

Customize Display

 P. 124

114

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

e

nt Pa

nel

Customize
display

 P. 124

Left Selector
Wheel

 (home) Button

Roll the left
selector wheel.

No content

 P. 125

Speed & time

 P. 117

Warnings

 P. 125

Range & fuel

 P. 115

Settings

 P. 126

Driver
attention

 P. 119

Seat belts

 P. 122

Safety
Support

 P. 122

Maintenance

 P. 122

115

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

e

nt Pa

nel

Roll the left selector wheel to switch between trip meter A and trip meter B.

Range / Fuel / Trip Meter

Average Fuel Economy

Range

Trip Meter B

Instant Fuel Economy

Trip Meter A

uu

Gauges and Driver Information Interface

u

Driver Information Interface

116

In

strum

e

nt Pa

nel

Trip meter

Shows the total number of miles or kilometers driven since the last reset. Meters A
and B can be used to measure two separate trips.

Resetting a trip meter

To reset the trip meter, display it, press the left selector wheel and then select

Reset

u

The trip meter is reset to 0.0.

Average Fuel Economy

Shows the estimated average fuel economy of each trip meter in mpg or l/100 km.
The display is updated at set intervals. When a trip meter is reset, the average fuel
economy is also reset.

Instant Fuel Economy

Shows the instant fuel economy as a bar graph in mpg or l/100 km.

Range

Shows the estimated distance you can travel on the remaining fuel. This estimated
distance is based on the vehicle’s current fuel economy.

1

Average Fuel Economy

You can change when to reset the average fuel
economy.

2

Settings

 P. 126

1

Range

The driving range displayed is only an estimate and
may differ to the actual distance the vehicle can
travel.

117

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

e

nt Pa

nel

Roll the left selector wheel to switch between trip meter A and trip meter B.

Speed & Time

Trip Meter B

Average Speed

Trip Meter A

Elapsed Time

uu

Gauges and Driver Information Interface

u

Driver Information Interface

118

In

strum

e

nt Pa

nel

Trip meter

2

Trip meter

 P. 116

Elapsed time

Shows the time elapsed since Trip A or Trip B was reset.

Average speed

Shows the average speed in mph or km/h since Trip A or Trip B was reset.

1

Elapsed time

You can change when to reset the elapsed time.

2

Settings

 P. 126

1

Average speed

You can change when to reset the average speed.

2

Settings

 P. 126

Continued

119

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

e

nt Pa

nel

The Driver Attention Monitor analyzes steering inputs to determine if the vehicle is
being driven in a manner consistent with drowsy or inattentive driving. If it
determines that the vehicle is being driven in such a manner, it will display the
degree of the driver’s attention on the driver information interface.

When you select

Driver attention

 on the

driver information interface, bars on it light up
in white to indicate the degree of the driver’s
attention.

2

Accessing contents in the display

 P. 113

Driver Attention Monitor

1

Driver Attention Monitor

The Driver Attention Monitor cannot always detect if
the driver is tired or inattentive.
Regardless of the system’s feedback, if you are
feeling tired, stop in a safe location and rest for as
long as needed.

Driver Information
Interface

Left Selector
Wheel

 (home) Button

Level

120

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

e

nt Pa

nel

If two bars light up, the

Driver attention

level low

 message will appear.

If one bar lights up, the

Driver attention

level low. Time for a break.

 message will

appear, a beep will sound, and the steering
wheel will vibrate.
If this message appears, stop in a safe location
and rest for as long as needed.
The message will disappear when the left
selector wheel is pressed or when the system
has determined that the driver is driving
normally.
If the driver does not take a break and the
monitor continues to detect that the driver is
very tired, the message will appear again after
approximately 15 minutes, accompanied by a
beep and steering wheel vibrations.
The message does not appear when the
traveling time is 30 minutes or less.

Continued

121

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

e

nt Pa

nel

The Driver Attention Monitor resets when:

The engine is turned off.

The driver unfastens the seat belt and opens the door while the vehicle is stopped.

For the Driver Attention Monitor to function:

The vehicle must be traveling above 25 mph (40 km/h).

The electric power steering (EPS) system indicator must be off.

Depending on driving conditions or other factors, the Driver Attention
Monitor may not function in the following circumstances:

The steering assist function of the Lane Keeping Assist System (LKAS) is active.

2

Lane Keeping Assist System (LKAS)

 P. 516

The condition of the road is poor, e.g. the surface is unpaved or bumpy.

It is windy.

The driver is frequently operating the vehicle in an assertive manner such as
changing lanes or accelerating.

Customizing

You can change the Driver Attention Monitor settings. Select

Tactile and audible

alert

Tactile alert

 or

OFF.

2

Settings

 P. 126

1

For the Driver Attention Monitor to function:

The bars on the driver information interface remain
grayed out unless the Driver Attention Monitor is
functioning.

uu

Gauges and Driver Information Interface

u

Driver Information Interface

122

In

strum

e

nt Pa

nel

Appears when any of the seat belts are latched or unlatched.

Shows the remaining oil life and Maintenance Minder

TM

.

2

Maintenance Minder

TM

 P. 585

Indicates the state of the Road Departure Mitigation system, CMBS

TM

, and blind spot

information system

*

 such as On, Off, or Failure, by color and letters.

The following colors indicate the state of any of the above mentioned systems:

Green: The system is on.

Gray: The system is off.

Amber: There is a problem with the system.

Seat Belts

Maintenance

Safety Support

1

Safety Support

If a system is indicated by the color amber, have your
vehicle checked by a dealer immediately.

To turn on or off each system, first rotate the left
selector wheel to switch displays. From the next
display you can select which system to turn on or off.

2

Road Departure Mitigation system On and
Off

 P. 540

2

Blind Spot Information System On and Off



P. 471

2

CMBS

TM

 On and Off

 P. 480

You can also confirm the state of the each function
by the color of the safety support indicator.

2

Safety Support Indicator (Amber)

 P. 106

2

Safety Support Indicator (Green/Gray)



P. 108

* Not available on all models

123

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

e

nt Pa

nel

Area Info for
CMBS

TM

Area Info for
Road
Departure
Mitigation
System

Area Info for
Blind spot
information
system

*

Road
Departure
Mitigation
System Icon
and State Info

Blind spot
information
system Icon
and State
Info

*

CMBS

TM

 Icon

and State
Info

* Not available on all models

uu

Gauges and Driver Information Interface

u

Driver Information Interface

124

In

strum

e

nt Pa

nel

Change the settings to your liking.

Arrange content

You can choose which icons to display on the home screen.

1.

Roll the left selector wheel to scroll to select

Customize display

, then press the left

selector wheel.

2.

Roll the left selector wheel.

3.

Roll the left selector wheel to scroll
between icons, then press the left selector
wheel to check or uncheck them.

Customize Display

1

Customize Display

Icons that are gray cannot be removed from the
home screen.

When you customize settings, shift to

(

P

.

Continued

125

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

e

nt Pa

nel

Enables you to show another unit on the
driver information interface and set the
displayed measurements to read in either
miles and km, mph and km/h.

Press and hold the left selector wheel when
you select

No content

 on the driver

information interface. Each time you do this,
the unit will change from miles and mph to
km and km/h or vice versa. After this, a
confirmation screen will appear for a few
seconds.

You can check if there are any active warning messages.

Speed/Distance Units

Warnings

1

Warnings

If there are multiple warnings, you can roll the left
selector wheel to see other warnings.

uu

Gauges and Driver Information Interface

u

Driver Information Interface

126

In

strum

e

nt Pa

nel

Use the driver information interface to customize certain features.

How to customize

Press the

 (home) button, then select the

Settings

 screen by rolling the left

selector wheel while the power mode is in ON, the vehicle is at a complete stop, and
the shift position is in

(

P

. Then, press the left selector wheel.

Settings

1

Settings

To customize other features, roll the left selector
wheel.

2

List of customizable options

 P. 127

2

Example of customization settings

 P. 132

When you customize settings, shift to

(

P

.

Driver
Information
Interface

Left Selector Wheel

 (home) Button

127

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

e

nt Pa

nel

List of customizable options

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

TPMS
calibration

*

Calibrates the TPMS.

Cancel

/

Calibrate

Driver assist
system setup

Forward collision
warning distance

Changes the distance at which CMBS

TM

 alerts.

Long

/

Normal

*1

/

Short

ACC forward vehicle
detect beep

Causes the system to beep when the system detects a
vehicle, or when the vehicle goes out of ACC with Low
Speed Follow range.

ON

/

OFF

*1

Road departure
mitigation setting

Changes the setting for the Road Departure Mitigation
system.

Narrow

/

Normal

*1

/

Wide

/

Warning only

Lane keeping assist
suspend beep

Causes the system to beep when the LKAS is suspended.

ON

/

OFF

*1

Blind spot
information

*

Changes the setting for the blind spot information.

Audible and visual
alert

*1

/

Visual alert

* Not available on all models

128

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

e

nt Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Driver assist
system setup

Traffic sign
recognition system
display setting

Turns the traffic sign recognition system on and off.

ON

*1

/

OFF

Traffic sign
recognition system
exceeding speed
warning

Turns the traffic sign recognition system over speed
warning on and off.

ON

*1

/

OFF

Speed limit warning
threshold setting

Changes the setting speed the traffic sign recognition
system over speed warning is activated.

Speed limit

*1

/

Speed limit+3mph

/

Speed limit+5mph

/

Speed limit+10mph

(When mph is selected)

Speed limit

*1

/

Speed limit+5km/h

/

Speed limit+10km/h

/

Speed limit+15km/h

(When km/h is selected)

Driver attention
monitor

Changes the setting for the driver attention monitor.

Tactile and audible
alert

*1

Tactile alert

/

OFF















Content      ..     5      6      7      8     ..
