97

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Low Tire Pressure/
TPMS Indicator

May come on briefly if the power mode is
set to ON and the vehicle is not moved
within 45 seconds, to indicate the
calibration process is not yet complete.

Comes on and stays on when:

-

One or more tires’ pressures are
determined to be significantly low.

-

The system has not been calibrated.

Comes on while driving

- Stop in a safe place,

check tire pressures, and inflate the tire(s) if
necessary.

Stays on after the tires are inflated to the
recommended pressures

- The system needs to

be calibrated.

2

TPMS Calibration

 P. 463

Blinks for about one minute, and then stays
on if there is a problem with the TPMS, or
when a compact spare tire is temporarily
installed.

Blinks and remains on

- Have your vehicle

checked by a dealer. If the vehicle is fitted with a
compact spare tire, get your regular tire repaired or
replaced and put back on your vehicle as soon as
you can.

Comes on if the TPMS is deactivated
temporarily after the battery has been
disconnected, then re-connected.

Drive a short distance at more than 12 mph (20 km/h).
The indicator should go off. If it does not, have your
vehicle checked by a dealer.

U.S.
models

98

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Turn Signal and
Hazard Warning
Indicators

Blinks when you operate the turn signal
lever.

Blink along with all turn signals when you
press the hazard warning button.

Does not blink or blinks rapidly

2

Replacing Light Bulbs

 P. 610, 611

High Beam
Indicator

Comes on when the high beam headlights
are on.

Lights On Indicator

Comes on when the parking, tail, and
other external lights are on.

2

Light Switches

 P. 183

Fog Light
Indicator

*

Comes on when the fog lights are on.

2

Fog Lights

*

 P. 186

Auto High-Beam
Indicator

Comes on when all the operating
conditions of the auto high-beam are met.

2

Auto High-Beam

 P. 187

* Not available on all models

99

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

System Message
Indicator

Comes on along with a beep when a
problem is detected. A system message on
the driver information interface appears at
the same time.

Refer to the Indicators information in this chapter
when a system message appears on the driver
information interface. Take the appropriate action
for the message.

While the indicator is on, press the

 (home)

button, and select

Warnings

 to see the message

again.

2

Accessing contents in the display

 P. 113

The driver information interface will not return to
the normal screen unless the warning is canceled,
or the

 (home) button is pressed.

While the indicator is on, roll the right selector
wheel to see the message again.

2

Switching the Display

 P. 139

The driver information interface will not return to
the normal screen unless the warning is canceled,
or the right selector wheel is rolled.

Models with A-type meter

Models with B-type meter

100

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models without drive mode switch
*2:Models with drive mode switch

Indicator

Name

On/Blinking

Explanation

ECON

 Mode

Indicator

Comes on when the ECON mode is on.

Comes on when you set the drive mode to

ECON

.

2

ECON Button

*

 P. 449

2

Drive Mode Switch

*

 P. 450

NORMAL

 Mode

Indicator

*

Comes on when you set the drive mode to

NORMAL

.

2

Drive Mode Switch

*

 P. 450

SPORT

 Mode

Indicator

*

Comes on when you set the drive mode to

SPORT

.

The ambient meter remains lit up in red as long as

SPORT

 mode is selected.

The ambient meter goes off and gauges in the
instrument panel lit up in red as long as

SPORT



mode is selected.

2

Drive Mode Switch

*

 P. 450

Low Temperature
Indicator

*

Comes on when the engine coolant
temperature is low.

If the indicator stays on after the engine has
reached normal operating temperature, there may
be a problem with the temperature sensors. Have
your vehicle inspected by a dealer.

*1

*2

Models without drive mode switch

Models with drive mode switch

Models with A-type meter

Models with B-type meter

* Not available on all models

101

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Immobilizer System
Indicator

Blinks if the immobilizer system cannot
recognize the key information.

Blinks

 - You cannot start the engine. Set the

power mode to VEHICLE OFF, then select the ON
mode again.

Depress and hold the brake pedal before setting
the power mode to ON.

Repeatedly blinks

- The system may be

malfunctioning. Have your vehicle checked by a
dealer.

Do not attempt to alter this system or add other
devices to it. Electrical problems can occur.

Security System
Alarm Indicator

Blinks when the security system alarm has
been set.

2

Security System Alarm

 P. 173

Indicator

Models with
A-type meter

Indicator

Models with
B-type meter

Canadian models

Indicator

Models with
A-type meter

Indicator

Models with
B-type meter

102

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Auto Idle Stop

OFF



Indicator

Comes on when the Auto Idle Stop system
has been turned off by the Auto Idle Stop

OFF

 button.

2

Auto Idle Stop System ON/OFF

 P. 454

Auto Idle Stop
System Indicator
(Amber)

Blinks if there is a problem with the Auto
Idle Stop system.

Blinks

- Have your vehicle checked by a dealer.

Auto Idle Stop
Indicator (Green)

Comes on when Auto Idle Stop is in
operation. The engine automatically shuts
off.

2

Auto Idle Stop

 P. 453

103

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Auto Idle Stop
Suspend Indicator

Comes on while Auto Idle Stop is
temporarily suspended in the following
situations.

-

Brake pedal is not fully pressed

Depress the brake pedal firmly.

-

The transmission is in a position other than

(

D

2

Auto Idle Stop

 P. 453

-

System charging is prioritized

-

Climate control system is prioritized

-

Engine coolant temperature is not in
operating range

-

SPORT

 mode

*

 is selected.

2

Auto Idle Stop

 P. 453

2

Drive Mode Switch

*

 P. 450

-

Auto Idle Stop does not activate for some
reason.

If you press and hold the Auto Idle Stop

OFF



button, you can select whether to display the status
messages or not.

* Not available on all models

104

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Adaptive Cruise
Control (ACC) with
Low Speed Follow
Indicator (Amber)

Comes on if there is a problem with ACC
with Low Speed Follow.

Comes on while driving

- Have your vehicle

checked by a dealer.

Comes on if the ACC with Low Speed
Follow is deactivated temporarily after the
battery has been disconnected, then re-
connected.

Drive a short distance at more than 12 mph (20 km/h).
The indicator should go off. If it does not, have your
vehicle checked by a dealer.

Indicator may come on temporarily when
the Maximum Load Limit is exceeded.

ACC with Low Speed Follow has been
automatically canceled.

Make sure the total load is within the Maximum
Load Limit.

2

Maximum Load Limit

 P. 433

Stays on constantly

- Have your vehicle checked

by a dealer.

Adaptive Cruise
Control (ACC) with
Low Speed Follow
Indicator
(White/Green)

Lights up in white when you press the



button.

Lights up in green when you press the up
or down the

RES/+

/

SET/−

 switch.

2

Adaptive Cruise Control (ACC) with Low
Speed Follow

 P. 494

105

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Lane Keeping
Assist System
(LKAS) Indicator
(Amber)

Comes on if there is a problem with the
LKAS.

Stays on constantly

- Have your vehicle checked

by a dealer.

Indicator may come on temporarily when
the Maximum Load Limit is exceeded.

Make sure the total load is within the Maximum
Load Limit.

2

Maximum Load Limit

 P. 433

Stays on constantly

 - Have your vehicle checked

by a dealer.

Lane Keeping
Assist System
(LKAS) Indicator
(White/Green)

Lights up in white when you press the LKAS
button.

Lights up in green when the LKAS is in
operation.

2

Lane Keeping Assist System (LKAS)

 P. 516

Cruise Mode
Indicator
(White/Green)

Lights up in white when you change to
cruise mode.

Lights up in green when you have set a
speed for cruise control.

2

To Switch ACC with Low Speed Follow to
Cruise Control

 P. 513

Adaptive Cruise
Control (ACC) with
Low Speed Follow
Interval Indicator

*

Comes on when Adaptive Cruise Control
(ACC) with Low Speed Follow indicator
comes on.

Each time you press the Interval button, the
following interval (the interval behind a vehicle
detected ahead of you) setting cycles through extra
long, long, middle, and short following intervals.

2

To Set or Change Following-interval

 P. 509

* Not available on all models

106

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

Comes on if there is a problem with Road
Departure Mitigation system, CMBS

TM

, Low

Speed Braking Control

*

 or blind spot

information system

*

.

Stays on constantly

 - Have your vehicle checked

by a dealer.

Indicator may come on temporarily when
the Maximum Load Limit is exceeded.

Make sure the total load is within the Maximum
Load Limit.

2

Maximum Load Limit

 P. 433

Stays on constantly

 - Have your vehicle checked

by a dealer.

Comes on if the Road Departure Mitigation
system, CMBS

TM

 and Low Speed Braking

Control

*

 are deactivated temporarily after

the battery has been disconnected and
then re-connected.

Drive a short distance at more than 12 mph (20
km/h). The indicator should go off. If it does not,
have your vehicle checked by a dealer.

* Not available on all models

107

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

Comes on when the Road Departure
Mitigation system and/or CMBS

TM

 shuts

itself off.

Stays on

 - The temperature inside the camera is

too high.
Use the climate control system to cool down the
camera.
The system activates when the temperature inside
the camera cools down.

2

Front Wide View Camera

 P. 551

Stays on

 - The area around the camera is blocked

by dirt, mud, etc. Stop your vehicle in a safe place
and wipe the debris off with a soft cloth.

Have your vehicle checked by a dealer if the
indicator and message are still displayed even after
you have cleaned the area around the camera.

2

Front Wide View Camera

 P. 551

It may come on when the ambient conditions are
dark, such as when driving in a tunnel, or at night,
dawn, or dusk.

108

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

Comes on when mud, snow, or ice
accumulates in the vicinity of the sonar
sensor.

Remove the obstacle in the vicinity of the sonar
sensor.

2

Low Speed Braking Control

*

 P. 488

Comes on when mud, snow, or ice
accumulates in the vicinity of the blind spot
information system sensor.

Comes on when the temperature of the
blind spot information system sensor is
high.

Comes on while driving

 - Something may be

interfering with the blind spot information system
sensor. Check the vicinity of the blind spot
information system sensor and remove any
obstacles.

The system will return to normal when the
temperature cools down.

2

Blind Spot Information System

*

 P. 469

Safety Support
Indicator (Green/
Gray)

Lights up in green when Road Departure
Mitigation system, CMBS

TM

, Low Speed

Braking Control

*

 and blind spot

information system

*

 are on.

Lights up in green and gray when Road
Departure Mitigation system, CMBS

TM

, Low

Speed Braking Control

*

, blind spot

information system

*

 or any two or three of

these systems are off.

Lights up in gray when Road Departure
Mitigation system, CMBS

TM

, Low Speed

Braking Control

*

 and blind spot

information system

*

 are off.

2

Road Departure Mitigation system On and Off



P. 540

2

CMBS

TM

 On and Off

 P. 480

2

Blind Spot Information System On and Off



P. 471

2

System On and Off

 P. 491

Models with Low Speed Braking Control

Models with blind spot information system

* Not available on all models

109

Continued

In

strum

e

nt Pa

nel

Gauges and Driver Information Interface

Gauges

Gauges include the speedometer, fuel gauge, and other related indicators.
They are displayed when the power mode is in ON.

Displays your driving speed in mph or km/h.

Shows the number of engine revolutions per minute.

Speedometer

Tachometer

1

Speedometer

You can set the speedometer and the displayed
measurements to read in either km/h and mph.

2

Speed/Distance Units

 P. 125, 150

2

Settings

 P. 126

2

Customized Features

 P. 363

If you change the unit from miles and mph to km and
km/h, the current vehicle speed in mph appears next
to the digital speedometer.

U.S. models with B-type meter

Vehicle Speed in mph

1

Tachometer

You can turn on or off the tachometer display.

2

Settings

 P. 126

Models with A-type meter

uu

Gauges and Driver Information Interface

u

Gauges

110

In

strum

e

nt Pa

nel

Displays the amount of fuel left in the fuel tank.

Displays the temperature of the engine coolant.

Shows the total number of miles or kilometers that your vehicle has accumulated.

Fuel Gauge

Temperature Gauge

Odometer

1

Fuel Gauge

NOTICE

You should refuel when the reading approaches

.

Running out of fuel can cause the engine to misfire,
damaging the catalytic converter.

The actual amount of remaining fuel may differ from
the fuel gauge reading.

E

Models with B-type meter

1

Temperature Gauge

NOTICE

Driving with the temperature gauge pointer in the
upper zone can cause serious engine damage. Pull
safely to the side of the road and allow engine
temperature to return to normal.

2

Overheating

 P. 656

Continued

111

uu

Gauges and Driver Information Interface

u

Gauges

In

strum

e

nt Pa

nel

Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).

Adjusting the outside temperature display

Adjust the temperature reading by up to ±5°F or ±3°C if the temperature reading
seems incorrect.

Shows traffic signs while driving.
The indicator blinks when the maximum speed of the traffic sign detected by the
Traffic Sign Recognition System is exceeded.

2

Traffic Sign Recognition System

 P. 545

Outside Temperature

Traffic Sign Recognition System

1

Outside Temperature

The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

You can adjust the temperature reading.

2

Settings

 P. 126

2

Customized Features

 P. 363

Models with A-type meter

Models with B-type meter

uu

Gauges and Driver Information Interface

u

Gauges

112

In

strum

e

nt Pa

nel

Shows the current mode for ACC with Low Speed Follow, LKAS, and traffic jam assist.

2

Adaptive Cruise Control (ACC) with Low Speed Follow

 P. 494

2

Lane Keeping Assist System (LKAS)

 P. 516

2

Traffic Jam Assist

 P. 528

Shows the clock.
You can adjust the time manually or change the clock display to show the 12 hour
clock or 24 hour clock by using the audio/information screen.

2

Clock

 P. 154

Current Mode for ACC with Low Speed Follow, the LKAS, and
Traffic Jam Assist

Clock

1

Current Mode for ACC with Low Speed Follow, the LKAS, and
Traffic Jam Assist

When you set speed for ACC with Low Speed Follow
or cruise control, a set speed mark will be displayed
on the speedometer.

Models with B-type meter

Set
Speed

Models with A-type meter















Content      ..     4      5      6      7     ..
