Honda Insight (2022 year). Manual in english - page 31





493

Main

tenan

ce

Maintenance Minder

TM

If the engine oil life is less than 15%, you will see the Maintenance Minder messages
appear on the driver information interface every time you set the power mode to
ON. The messages notify you when to change the engine oil, or when to bring your
vehicle to a dealer for indicated maintenance services.

494

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Main

tenan

ce

To Use Maintenance Minder

TM

Maintenance items, which should be serviced at the same time that you replace the
engine oil, appear on the driver information interface.
You can view them on the engine oil life screen at any time.

1.

Set the power mode to ON.

2.

Press the

 (home) button.

3.

Roll the left selector wheel until

 is displayed.

4.

Press the left selector wheel to go to the

Maintenance

 screen. The engine oil life

appears on the driver information interface along with maintenance items due
soon.

Displaying the Maintenance Minder Information

1

Displaying the Maintenance Minder Information

Based on the engine operating conditions, the
remaining engine oil life is calculated and displayed
as a percentage.

There is a list of maintenance main and sub items you
can view on the driver information interface.

2

Maintenance Service Items

 P. 497

Displayed Engine Oil

Life (%)

Calculated Engine Oil

Life (%)

100

100 to 91

90

90 to 81

80

80 to 71

70

70 to 61

60

60 to 51

50

50 to 41

40

40 to 31

30

30 to 21

20

20 to 16

15

15 to 11

10

10 to 6

5

5 to 1

0

0

 (home) Button

Engine Oil Life

Main Item

Sub Item

Left Selector Wheel

495

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Continued

Main

tenan

ce

Maintenance Minder Messages on the Driver Information

Interface

Maintenance Message

Oil Life Display

Explanation

Information

When you select the Maintenance
screen, it displays codes for
maintenance items due at the next
engine oil change, along with the
percentage of engine oil life
remaining.

Maintenance Due Soon

15 %

The engine oil life indicator starts to
appear along with other due-soon
maintenance item codes when the
remaining oil life drops to 15
percent.

The engine oil is approaching the end
of its service life.

496

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Main

tenan

ce

The system message indicator (

) comes on along with the Maintenance Minder

message.

Maintenance Due Now

5 %

The remaining engine oil life is 5 to 1

percent. Press the

 (home)

button to switch to another display.

The engine oil has almost reached the
end of its service life, and the
maintenance items should be inspected
and serviced as soon as possible.

Maintenance Past Due

Negative Distance

The engine oil has passed its service
life, and a negative distance appears
after driving over 10 miles. The
negative distance on the display
blinks.

The engine oil life has passed.
The maintenance items must be
inspected and serviced immediately.

Maintenance Message

Oil Life Display

Explanation

Information

5 %

497

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Continued

Main

tenan

ce

Maintenance Service Items

1

Maintenance Service Items

Adjust the valves during services A, B, 1, 2, or 3 if
they are noisy.

Maintenance Minder Message

System Message

Indicator

Sub Items

Main Item

*1: If a Maintenance Minder message does not appear more than 12 months after the display is reset,

change the engine oil every year.

# : See information on maintenance and emissions warranty in the first column on page

594

.

*2: If you drive in dusty conditions, replace the air cleaner element every 15,000 miles (24,000 km).

CODE

Maintenance Main Items

A

Replace engine oil

*1

B

Replace engine oil

*1

 and oil filter

Inspect front and rear brakes

Check expiry date for tire repair kit bottle

Inspect tie rod ends, steering gearbox, and boots

Inspect suspension components

Inspect driveshaft boots

Inspect brake hoses and lines (Including ABS/VSA

®

)

Inspect all fluid levels and condition of fluids

Inspect exhaust system

#

Inspect fuel lines and connections

#

*3: If you drive primarily in urban areas that have high concentrations of soot in the air from industry and

from diesel-powered vehicles, replace the dust and pollen filter every 15,000 miles (24,000 km).

*4: Driving in mountainous areas at very low vehicle speeds results in higher transmission temperatures.

This requires transmission fluid changes more frequently than recommended by the Maintenance
Minder. If you regularly drive your vehicle under these conditions, have the transmission fluid changed
every 47,500 miles or 3 years (76,000 km or 3 years).

*5: If a Maintenance Minder message does not appear more than 36 months after the display for item 7 is

reset, change the brake fluid every 3 years.

CODE

Maintenance Sub Items

1

Rotate tires

2

Replace air cleaner element

*2

Replace dust and pollen filter

*3

3

Replace transmission fluid

*4

4

Replace spark plugs

Inspect valve clearance

5

Replace engine coolant

7

Replace brake fluid

*5

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

498

Main

tenan

ce

Reset the maintenance minder information display if you have performed the
maintenance service.

1.

Set the power mode to ON.

2.

Press the

 (home) button.

3.

Roll the left selector wheel until

 is displayed.

4.

Press the left selector wheel to go to the

Maintenance

 screen.

5.

Press the left selector wheel to enter the reset mode.

6.

Roll the left selector wheel to select a maintenance item to reset, or to select

All

Due Items

 (You can also select

Cancel

 to end the process).

7.

Press the left selector wheel to reset the selected item.

8.

Repeat from step 5 for other items you wish to reset.

Resetting the Display

1

Resetting the Display

NOTICE

Failure to reset the Maintenance Minder

TM

 display

after a maintenance service results in the system
showing incorrect maintenance intervals, which can
lead to serious mechanical problems.

The dealer will reset the Maintenance Minder

TM



display after completing the required maintenance
service. If someone other than a dealer performs
maintenance service, reset the Maintenance
Minder

TM

 display yourself.

You can also reset the Maintenance Minder

TM

 display

using the audio/information screen.

2

Customized Features

 P. 326

Left Selector Wheel

 (home) Button

499

Main

tenan

ce

Maintenance Under the Hood

Maintenance Items Under the Hood

Brake Fluid

(Black Cap)

Engine Coolant

Reserve Tank

Radiator Cap

Washer Fluid

(Blue Cap)

Engine Oil Dipstick

(Orange)

Engine Oil Fill Cap

12-Volt Battery

(In the Center

Console)

Inverter Coolant

Filler Tank

500

uu

Maintenance Under the Hood

u

Opening the Hood

Main

tenan

ce

Opening the Hood

1.

Park the vehicle on a level surface, and set
the parking brake.

2.

Pull the hood release handle under the
driver’s side lower corner of the dashboard.

u

The hood will pop up slightly.

3.

Push the hood latch lever (located under
the front edge of the hood to the center) to
the side and raise the hood. Once you have
raised the hood slightly, you can release the
lever.

4.

Remove the support rod from the clamp
using the grip. Mount the support rod in
the hood.

When closing, remove the support rod, and
stow it in the clamp, then gently lower the
hood. Remove your hand at a height of
approximately 12 inches (30 cm) and let the
hood close.

1

Opening the Hood

NOTICE

Do not open the hood when the wiper arms are
raised. The hood will strike the wipers, resulting in
possible damage to the hood and/or the wipers.

When closing the hood, check that the hood is
securely latched.

If the hood latch lever moves stiffly, or if you can
open the hood without lifting the lever, the latch
mechanism should be cleaned and lubricated.

Hood Release Handle

Pull

Lever

Support Rod

Grip

Clamp

501

uu

Maintenance Under the Hood

u

Recommended Engine Oil

Main

tenan

ce

Recommended Engine Oil

Use a genuine engine oil or another commercial engine oil of suitable type and
viscosity (for the ambient temperature) as shown in the image that follows.

Oil is a major contributor to your engine’s performance and longevity. If you drive
the vehicle with insufficient or deteriorated oil, the engine may fail or be damaged.

*1:Formulated to improve fuel economy.

Synthetic oil

You may also use synthetic motor oil if it is labeled with the API Certification Seal
and is the specified viscosity grade.

Genuine Engine Oil

Commercial Engine Oil

Honda Genuine Motor Oil

Premium-grade 0W-20 detergent oil
with an API Certification Seal on the
container.

1

Recommended Engine Oil

Engine Oil Additives
Your vehicle does not require oil additives. In fact,
they may adversely affect the engine performance
and durability.

The following seal indicates the oil is energy
conserving and that it meets the American Petroleum
Institute’s latest requirements.

Ambient Temperature

Ambient Temperature

502

uu

Maintenance Under the Hood

u

Oil Check

Main

tenan

ce

Oil Check

We recommend that you check the engine oil level every time you refuel.
Park the vehicle on level ground.

Turn off the power system. You can check the oil level without the engine having
run beforehand. If the engine has been running, wait approximately three minutes
before you check the oil.

1.

Remove the dipstick (orange).

2.

Wipe the dipstick with a clean cloth or
paper towel.

3.

Insert the dipstick back all the way into its
hole.

4.

Remove the dipstick again, and check the
level. It should be between the upper and
lower marks. Add oil if necessary.

1

Oil Check

If the oil level is near or below the lower mark, slowly
add oil, being careful not to overfill.

Upper Mark
Lower Mark

503

uu

Maintenance Under the Hood

u

Adding Engine Oil

Main

tenan

ce

Adding Engine Oil

1.

Unscrew and remove the engine oil fill cap.

2.

Add oil slowly.

3.

Reinstall the engine oil fill cap, and tighten
it securely.

4.

Wait for three minutes and recheck the
engine oil dipstick.

1

Adding Engine Oil

NOTICE

Do not fill the engine oil above the upper mark.
Overfilling the engine oil may result in leaks and
engine damage.

If any oil spills, wipe it away immediately. Spilled oil
may damage the engine compartment components.

Engine Oil Fill Cap

504

uu

Maintenance Under the Hood

u

Changing the Engine Oil and Oil Filter

Main

tenan

ce

Changing the Engine Oil and Oil Filter

You must change the engine oil and oil filter regularly in order to maintain the
engine’s lubrication. The engine may be damaged if they are not changed regularly.

Turning the power system on automatically starts the engine if the High Voltage
battery charge level gauge shows two segments or less.

2

High Voltage Battery Charge Level Gauge

 P. 130

Change the oil and filter in accordance with the maintenance message on the driver
information interface.

1.

Run the engine until it reaches normal
operating temperature, and then turn the
engine off.

2.

Open the hood and remove the engine oil
fill cap.

3.

Remove the Phillips-head screws and
slotted head screws by turning 90°
counterclockwise on the undercarriage
and remove the under cover.

4.

Remove the drain bolt and washer from
the bottom of the engine, and drain the
oil into a suitable container.

1

Changing the Engine Oil and Oil Filter

NOTICE

You may damage the environment if you do not
dispose of the oil in a suitable way. If you are
changing the oil by yourself, appropriately dispose of
the used oil. Put the oil in a sealed container and take
it to a recycling center. Do not throw the oil away
into a garbage can or onto the ground.

Under Cover

Screw

Drain Bolt

Washer

505

uu

Maintenance Under the Hood

u

Changing the Engine Oil and Oil Filter

Main

tenan

ce

5.

Remove the oil filter and dispose of the
remaining oil.

6.

Check that the filter gasket is not stuck to
the engine contact surface.

u

If it is stuck, you must detach it.

7.

Wipe away dirt and dust adhering to the
contact surface of the engine block, and
install a new oil filter.

u

Apply a light coat of new engine oil to
the filter gasket.

8.

Put a new washer on the drain bolt, then
reinstall the drain bolt.

u

Tightening torque:
30 lbf∙ft (40 N∙m, 4.0 kgf∙m)

9.

Pour the recommended engine oil into the
engine.

u

Engine oil change capacity (including
filter):
3.5 US qt (3.3 L)

10.

Reinstall the engine oil fill cap securely and
start the engine.

11.

Run the engine for a few minutes, and
then check that there is no leak from the
drain bolt or oil filter.

12.

Stop the engine, wait for three minutes,
and then check the oil level on the
dipstick.

u

If necessary, add more engine oil.

1

Changing the Engine Oil and Oil Filter

You will need a special wrench to replace the oil
filter. You can buy this wrench from a dealer.

When installing the new oil filter, follow the
instructions supplied with the oil filter.

Reinstall the engine oil fill cap. Start the engine. The
low oil pressure indicator should go off within five
seconds. If it does not, turn off the engine, and check
your work.

Oil Filter

506

uu

Maintenance Under the Hood

u

Cooling System

Main

tenan

ce

Cooling System

This coolant is premixed with 50% antifreeze and 50% water. Do not add any
straight antifreeze or water.

We recommend you check the engine coolant level every time you refuel. Check the
reserve tank first. If it is completely empty, also check the coolant level in the
radiator. Add the engine coolant accordingly.

1. Make sure the engine and radiator are

cool.

2.

Check the amount of coolant in the reserve
tank.

u

If the coolant level is below the

MIN



mark, add the specified coolant until it
reaches the

MAX

 mark.

3.

Inspect the cooling system for leaks.

Specified coolant: Honda Long Life Antifreeze/Coolant Type 2

Reserve Tank

1

Cooling System

NOTICE

Genuine Honda engine coolant is a 50/50 mixture of
antifreeze and water that can withstand freezing at
temperatures as low as about -31°F (-35°C). If your
vehicle is consistently subjected to temperatures
below this, the concentration of antifreeze in the
coolant should be increased. Consult a dealer for
details.

If Honda antifreeze/coolant is not available, you may
use another major brand of non-silicate coolant as a
temporary replacement. Check that it is a high quality
coolant recommended for aluminum engines.
Continued use of any non-Honda coolant can result
in corrosion, causing the cooling system to
malfunction or fail. Have the cooling system flushed
and refilled with Honda antifreeze/coolant as soon as
possible.

Do not add rust inhibitors or other additives to your
vehicle’s cooling system. They may not be compatible
with the coolant or with the engine components.

3

WARNING

Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.

Always let the engine and radiator cool
down before removing the radiator cap.

Reserve Tank

MAX

MIN

507

uu

Maintenance Under the Hood

u

Cooling System

Main

tenan

ce

1. Make sure the engine and radiator are

cool.

2.

Turn the radiator cap 1/8 turn counter-
clockwise and relieve any pressure in the
cooling system.

3.

Push down and turn the radiator cap
counterclockwise to remove it.

4.

The coolant level should be up to the base
of the filler neck. Add coolant if it is low.

5.

Put the radiator cap back on, and tighten it
fully.

Radiator

1

Radiator

NOTICE

Pour the fluid slowly and carefully so you do not spill
any. Clean up any spills immediately; they can
damage components in the engine compartment.

Radiator Cap

508

uu

Maintenance Under the Hood

u

Inverter Coolant

Main

tenan

ce

Inverter Coolant

This coolant is premixed with 50% antifreeze and 50% water. Do not add any
straight antifreeze or water.

We recommend you check the inverter coolant level every time you refuel.

Have a dealer replace the inverter coolant.

1.

Check the fluid level in the tank.

2.

If the coolant level has dropped below the

MIN

 level, have your vehicle serviced at a

dealer.

u

Only a properly trained technician can
refill the coolant and check the system
for leaks.

Specified coolant: Honda Long Life Antifreeze/Coolant Type 2

Checking the Coolant

1

Inverter Coolant

NOTICE

Genuine Honda engine coolant is a 50/50 mixture of
antifreeze and water that can withstand freezing at
temperatures as low as about –31°F (–35°C). If your
vehicle is consistently subjected to temperatures
below this, the concentration of antifreeze in the
coolant should be increased. Consult a dealer for
details.

If Honda antifreeze/coolant is not available, you may
use another major brand of non-silicate coolant as a
temporary replacement. Check that it is a high quality
coolant recommended for aluminum engines.
Continued use of any non-Honda coolant can result
in corrosion, causing the cooling system to
malfunction or fail. Have the cooling system flushed
and refilled with Honda antifreeze/coolant as soon as
possible.

Do not add rust inhibitors or other additives to your
vehicle’s coolant system. They may not be compatible
with the coolant or with the motor components.

MAX

MIN

Filler Tank















Content      ..     29      30      31      32     ..
