uu

Cleaning

u

Interior Care

626

Main

tenan

ce

Wipe using a glass cleaner.

Super UV Cut/IR Cut Glass

The front side windows are laminated with UV-cut and IR-cut film. When cleaning
the interior side of the windows, make sure to use a soft damp cloth.

The front floor mat hooks over the floor anchors, which keep the mat from sliding
forward. When reinstalling the mat after cleaning, position it properly.

Do not put additional floor mats on top of the anchored mat.

Cleaning the Window

Floor Mats

*

1

Cleaning the Window

Wires are mounted to the inside of the rear window.
Wipe along the same direction as the wires with a
soft cloth so as not to damage them.

Be careful not to spill fluids, such as water or glass
cleaner, on or around the cover of both the front
sensor camera and the rainfall/light sensor

*

1

Super UV Cut/IR Cut Glass

To ensure the longevity of the UV-cut and IR-cut film,
avoid:

Opening and closing the windows when they are
covered with dirt and other debris.

Using a glass cleaner containing polishing
compounds, wax, or detergents.

1

Floor Mats

*

If you use any floor mats that were not originally
provided with your vehicle, make sure they are
designed for your specific vehicle, fit correctly, and
are securely anchored by the floor anchors.
Position the rear seat floor mats properly. If they are
not properly positioned, the floor mats can interfere
with the front seat functions.

* Not available on all models

627

uu

Cleaning

u

Interior Care

Main

tenan

ce

To properly clean leather:

1.

Use a vacuum or soft dry cloth first to remove any dirt or dust.

2.

Clean the leather with a soft cloth dampened with a solution comprised of 90%
water and 10% neutral soap.

3.

Wipe away any soap residue with a clean damp cloth.

4.

Wipe away residual water and allow leather to air dry in the shade.

Maintaining Genuine Leather

1

Maintaining Genuine Leather

It is important to clean or wipe away dirt or dust as
soon as possible. Spills can soak into leather resulting
in stains. Dirt or dust can cause abrasions in the
leather. In addition, please note that some dark
coloured clothing can rub onto the leather seats
resulting in discolouration or stains.

628

uu

Cleaning

u

Exterior Care

Main

tenan

ce

Exterior Care

Dust off the vehicle body after you drive. Regularly inspect your vehicle for scratches
on painted surfaces. A scratch on a painted surface can result in body rust. If you
find a scratch, promptly repair it.

Wash the vehicle regularly. Wash more frequently when driving in the following
conditions:

If driving on roads with road salt.

If driving in coastal areas.

If tar, soot, bird droppings, insects, or tree sap are stuck to painted surfaces.

Make sure to follow the instructions indicated on the automated car wash.

Turn off the automatic intermittent wipers.

Washing the Vehicle

Using an Automated Car Wash

1

Washing the Vehicle

Do not spray water into the air intake vents. It can
cause a malfunction.

If you need to lift the wiper arms away from the
windscreen, first set the wiper arms to the
maintenance position.

2

Changing the Front Wiper Blade Rubber



P. 604

a

Air Intake Vents

1

Using an Automated Car Wash

When using an automated car wash that pulls the
vehicle through with a conveyor, make sure vehicle is
in car wash mode.

2

If you want to keep the transmission in

(

N



position (car wash mode)

 P. 391

Continued

629

uu

Cleaning

u

Exterior Care

Main

tenan

ce

Keep sufficient distance between the cleaning nozzle and the vehicle body.

Take particular care around the windows. Standing too close may cause water to
enter the vehicle interior.

Do not spray water under the bonnet where the high voltage system components
are located. It could cause a malfunction.

Do not spray water directly at the charging port.

A good coat of automotive body wax helps to protect your vehicle’s paint from the
elements. Wax will wear off over time and expose your vehicle’s paint to the
elements, so reapply as necessary.

If you get coolant or battery fluid on resin coated parts, they may be stained or the
coating may peel. Promptly wipe it away using a soft cloth and clean water.

Wipe using a glass cleaner.

Using High Pressure Cleaners

Applying Wax

Maintaining the Bumpers and Other Resin Coated Parts

Cleaning the Window

1

Applying Wax

NOTICE

Chemical solvents and strong cleaners can damage
the paint, metal, and plastic on your vehicle. Wipe
away spills immediately.

1

Maintaining the Bumpers and Other Resin Coated Parts

Ask a dealer about the correct coating material when
you want to repair the painted surface of the parts
made of resin.

630

uu

Cleaning

u

Exterior Care

Main

tenan

ce

Aluminium is susceptible to deterioration caused by salt and other road
contaminants. When necessary, as early as possible use a sponge and mild detergent
to wipe away these contaminants. Do not use a stiff brush or harsh chemicals
(including some commercial wheel cleaners). These can damage the protective finish
on aluminium alloy wheels, resulting in corrosion. Depending on the type of finish,
the wheels also may lose their lustre or appear burnished. To avoid water stains,
wipe the wheels dry with a cloth while they are still wet.

The inside lenses of exterior lights (headlights, brake lights, etc.) may fog temporarily
if you have driven in the rain, or after the vehicle has been run through a car wash.
Dew condensation also may build up inside the lenses when there is a significant
enough difference between the ambient and inside lens temperatures (similar to
vehicle windows fogging up in rainy conditions). These conditions are natural
processes, not structural design problems in the exterior lights.
Lens design characteristics may result in moisture developing on the light lens frame
surfaces. This also is not a malfunction.
However, if you see large amounts of water accumulation, or large water drops
building up inside the lenses, have your vehicle inspected by a dealer.

Maintaining Aluminium Wheels

Fogged Exterior Light Lenses

631

Main

tenan

ce

Accessories and Modifications

Accessories

When installing accessories, check the following:

Do not install accessories on the windscreen. They can obstruct your view and
delay your reaction to driving conditions.

Do not install any accessories over areas marked SRS Airbag, on the sides or backs
of the front seats, on front or side pillars, or near the side windows.
Accessories installed in these areas may interfere with proper operation of the
vehicle’s airbags or may be propelled into you or another occupant if the airbags
deploy.

Be sure electronic accessories do not overload electrical circuits or interfere with
proper operation of your vehicle.

2

Fuses

 P. 662

Before installing any electronic accessory, have the installer contact a dealer for
assistance. If possible, have a dealer inspect the final installation.

1

Accessories and Modifications

3

WARNING

Improper accessories or modifications can
affect your vehicle’s handling, stability, and
performance, and cause a crash in which
you can be seriously hurt or killed.

Follow all instructions in this owner’s
manual regarding accessories and
modifications.

3

WARNING

Use of improperly designed, engineered or
manufactured high-voltage battery
assemblies could cause a fire in your
vehicle.

A vehicle fire could result in a crash or
injury.

Only use a genuine Honda high-voltage
battery assembly, or its equivalent, in your
vehicle.

632

uu

Accessories and Modifications

u

Modifications

Main

tenan

ce

Modifications

Do not modify your vehicle in a manner that may affect its handling, stability, or
reliability, or install non-genuine Honda parts or accessories that may have a similar
effect.

Even minor modifications to vehicle systems can affect overall vehicle performance.
Always make sure all equipment is properly installed and maintained, and do not
make any modification to your vehicle or its systems that might cause your vehicle
to no longer meet your country’s and local regulations.

The on-board diagnostic port (OBD-II/SAE J1962 connector) installed on this vehicle
is intended to be used with automobile system diagnostic devices or with other
devices that Honda has approved. Use of any other type of device may adversely
affect the vehicle’s electronic systems or allow them to be compromised, possibly
resulting in a system malfunction, drained battery, or other unexpected problems.

Do not modify or attempt to repair your vehicle’s high-voltage power system or
otherwise modify vehicle electrical systems. Disassembling or modifying electrical
equipment can result in a crash or a fire.

If you ever need to replace your vehicle’s high-voltage battery assembly outside of
warranty coverage, we highly recommend that you only use a genuine Honda high-
voltage battery assembly. Genuine Honda high-voltage battery assemblies are
designed to work with your vehicle’s power system and have been designed,
engineered and manufactured to avoid overcharging situations. Non-genuine high-
voltage battery assemblies may not have been similarly designed, engineered and
manufactured, and installation of such assemblies could result in overcharging, fires,
loss of power, or other conditions that may increase the likelihood of a crash or
injury.

1

Accessories and Modifications

When properly installed, mobile phones, alarms, two-
way radios, radio antennas, and low-powered audio
systems should not interfere with your vehicle’s
computer controlled systems, such as your airbags
and anti-lock brakes.

Honda Genuine accessories are recommended to
ensure proper operation on your vehicle.

633

Handling the Unexpected

This chapter explains how to handle unexpected troubles.

If a Tyre Goes Flat

Temporarily Repairing a Flat Tyre...... 634

Handling of the Jack

......................... 647

Power System Won’t Start

Checking the Procedure ................... 648

If the Keyless Remote Battery is Weak .. 649

Emergency Power System Off........... 650

If the 12-Volt Battery Is Dead

.......... 651

Overheating

How to Handle Overheating............. 654

Indicator, Coming On/Blinking

If the 12-Volt Battery Charging System

Indicator Comes On ....................... 655

If the Brake System Indicator (Red) Comes

On or Blinks ................................... 656

If the Electric Power Steering (EPS) System

Indicator Comes On ....................... 657

If the Brake System Indicator (Red) Comes On

or Blinks at the Same Time When the Brake
System Indicator (Amber) Comes On .. 658

If the Low Tyre Pressure/Deflation Warning

System Indicator Comes On or Blinks ... 659

If the Transmission System Indicator Blinks

along with the Warning Message... 660

If the Power System Indicator Comes On... 661

Fuses

Fuse Locations ................................. 662
Inspecting and Changing Fuses........ 669

Emergency Towing

........................... 671

If You Cannot Open the Charge Lid

.....672

If You Cannot Disengage the Charging

Connector

........................................ 673

If You Cannot Open the Tailgate

.... 674

634

Han

d

lin
g the U

n

expected

If a Tyre Goes Flat

Temporarily Repairing a Flat Tyre

If the tyre has a large cut or is otherwise severely damaged, you will need to have
the vehicle towed. If the tyre only has a small puncture, from a nail for instance, you
can use the temporary tyre repair kit so that you can drive to the nearest service
station for a more permanent repair.

If a tyre goes flat while driving, grasp the steering wheel firmly, and brake gradually
to reduce speed. Then stop in a safe place.

1.

Park the vehicle on firm, level, and non-slippery ground and apply the parking
brake.

2.

Put the transmission into

(

P

.

3.

Turn on the hazard warning lights and set the power mode to VEHICLE OFF
(LOCK).

1

Temporarily Repairing a Flat Tyre

The kit should not be used in the following situations.
Instead, contact a dealer or a roadside assistant to
have the vehicle towed.

The tyre sealant has expired.

More than one tyre is punctured.

The puncture or cut is larger than 4 mm (3/16 inch).

The tyre side wall is damaged or the puncture is
outside the contact area.

Damage has been caused by driving with the tyres
extremely under inflated.

The tyre bead is no longer seated.

The rim is damaged.

Do not remove a nail or screw that punctured the
tyre. If you remove it from the tyre, you may not be
able to repair the puncture using the kit.

When the puncture is:

Kit Use

Smaller than 4 mm (3/16 inch)

Yes

Larger than 4 mm (3/16 inch)

No

a

Contact Area

Continued

635

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

Han

d

lin
g the U

n

expected

Getting Ready to Temporarily Repair the Flat Tyre

1

Getting Ready to Temporarily Repair the Flat Tyre

Speed restriction label are applied to the side of
temporary tyre repair kit.

When making a temporary repair, carefully read the
instruction manual provided with the kit.

a

Air Compressor

b

Wheel Label

c

Sealant Bottle

d

Speed Restriction Label

e

Expiration Date

f

Handling Manual

636

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

Han

d

lin
g the U

n

expected

1.

Remove the floor lid from the luggage area,
then take the kit out of the tool box.

2.

Place the kit, face up, on flat ground near
the flat tyre, away from traffic. Do not place
the kit on its side.

a

Floor Lid

a

Tyre Repair Kit

Continued

637

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

Han

d

lin
g the U

n

expected

1.

Take the air compressor hose and plug
cord out of the back of the air compressor.

2.

Remove the cap from the air compressor.

Injecting Sealant and Air

1

Injecting Sealant and Air

Keep the sealant bottle out of the reach of children.

In cold temperatures, the sealant may not flow easily.
In this situation, warm it by keeping the bottle in the
passenger compartment before using.

The sealant can permanently stain clothing and other
materials. Be careful during handling and wipe away
any spills immediately.

3

WARNING

Tyre sealant contains substances that are
harmful and can be fatal if swallowed.

If accidentally swallowed, do not induce
vomiting. Drink plenty of water and get
medical attention immediately.

For skin or eye contact, flush with cool
water and get medical attention if
necessary.

a

Plug Cord

b

Air Compressor Hose

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

638

Han

d

lin
g the U

n

expected

3.

Shake the bottle well.

4.

Remove the bottle cap.

u

Do not remove the sealed cover.

1

Injecting Sealant and Air

Do not remove the empty bottle after injecting the
sealant.

See a Honda dealer for a replacement of sealant
bottle and proper disposal of the empty bottle.

a

Bottle Cap

b

Not Removed

639

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

Continued

Han

d

lin
g the U

n

expected

5.

Screw the sealed bottle onto the air
compressor.

u

Screw the bottle tightly so that it does
not become loose.

6.

Unscrew the valve cap.

a

Valve Cap

b

Valve

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

640

Han

d

lin
g the U

n

expected

7.

Screw the air compressor hose onto the
tyre valve.

u

Make sure the air valve is closed and the
air compressor is turned off.

8.

Plug in the compressor to the accessory
power socket.

2

Accessory Power Socket

 P. 243

9.

Turn on the vehicle's power system.

1

Injecting Sealant and Air

Turn the air compressor off when connecting the air
compressor hose.

You hear a motor sound coming from the activated
air compressor. This is normal.

If the specified air pressure is not reached within 10
minutes, the tyre may be too severely damaged for
the kit to provide the necessary seal and your vehicle
will need to be towed.

If you want to measure the air pressure using a
gauge, turn the air compressor off first.

a

Air Valve

b

Air Compressor Hose

c

Valve

a

Plug

b

Accessory Power Socket

Continued

641

uu

If a Tyre Goes Flat

u

Temporarily Repairing a Flat Tyre

Han

d

lin
g the U

n

expected

10.

Turn on the air compressor and inflate the
tyre to the specified air pressure.

u

The compressor starts injecting sealant
and air into the tyre.

u

Refer to the driver’s doorjamb label for
the specified pressure.

11.

After the air pressure reaches to specified
pressure, turn off the compressor.

u

Check the air pressure gauge on the air
compressor.

u

If overinflated, release the air by turning
the air valve. Be careful not to spill any
sealant.

12.

Unplug the plug from the accessory power
socket.

13.

Unscrew the air compressor hose from the
tyre valve. Install the hose cap.

u

Be careful not to spill any sealant when
the hose is disconnected. Wipe away
any spills.

1

Injecting Sealant and Air

Inform the use of tyre sealant when you ask a Honda
dealer or the road assistant service for replacing or
repairing the flat tyre.

This air compressor is designed for the automotive
tyre. Check the following:

The power supply of the air compressor is limited to
your vehicle’s 12-volt DC accessory power socket.

Do not operate the temporary tyre repair kit
compressor for more than 15 minutes. The
compressor can overheat and become permanently
damaged.
Make it cool down when using the compressor
continuously.

a

Air Valve

b

Switch

c

OFF

d

ON















Content      ..     38      39      40      41     ..
