Honda e (2021 year). Manual in english - page 29





450

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

When driving at about 30 km/h (18 mph) or above:

Take your foot off the

pedal and press the

SET/−

 button when you reach the desired speed. The moment

you release the button, the set speed is fixed, and ACC with Low Speed Follow
begins.

To Set the Vehicle Speed

a

RES/+

 Button

b

SET/−

 Button

c

 (green)

d

Set Vehicle Interval

e

Set Vehicle Speed

f

Setting Status (green)

451

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

When driving slower than about 30 km/h (18 mph):

If the vehicle is moving and the brake pedal is not depressed, pressing the button
fixes the set speed to
30 km/h (18 mph) regardless of current vehicle speed. If your vehicle is stationary,
you can set the vehicle speed even with the brake pedal depressed.

When ACC with Low Speed Follow starts
operating, set speed appear (green) on the
gauge.

a

Set Vehicle Speed (white)

b

Setting Status (green)

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

452

Driving

There is a vehicle ahead

ACC with Low Speed Follow monitors if a vehicle ahead of you enters the ACC with
Low Speed Follow range. If a vehicle is detected doing so, the ACC with Low Speed
Follow system maintains or decelerates your vehicle’s set speed in order to keep the
vehicle’s set following interval from the vehicle ahead.

2

To Set or Change Following-interval

 P. 459

When a vehicle whose speed is slower than
your set speed comes in or cuts in front of you
and is detected by the radar and the camera,
your vehicle starts to slow down.

When in Operation

1

When in Operation

If the vehicle ahead of you slows down abruptly, or if
another vehicle cuts in front of you, the beeper
sounds, a message appears on the driver information
interface.

Depress the brake pedal, and keep an appropriate
interval from the vehicle ahead.

a

Audible Alert

a

ACC with Low Speed Follow Range: 120 m (394 ft.)

a

A vehicle icon appears on the
gauge

Continued

453

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

There is no vehicle ahead

Your vehicle maintains the set speed without
having to keep your foot on the brake or
accelerator pedal.
If there previously was a vehicle detected
ahead that kept your vehicle from travelling at
the set speed, ACC with Low Speed Follow
accelerates your vehicle to the set speed, and
then maintains it.

When you depress the accelerator pedal

You can temporarily increase the vehicle speed. In this case, there is no audible or
visual alert even if a vehicle is in the ACC with Low Speed Follow range.
ACC with Low Speed Follow stays on unless you cancel it. Once you release the
accelerator pedal, the system resumes an appropriate speed for keeping the
following interval while a vehicle ahead is within the ACC with Low Speed Follow
range.

1

When in Operation

Even if the interval between your vehicle and the
vehicle detected ahead is short, ACC with Low Speed
Follow may start accelerating your vehicle under the
following circumstances:

The vehicle ahead of you is going at almost the
same speed as, or faster than, your vehicle.

A vehicle that cuts in front of you is going faster
than your vehicle, gradually increasing the interval
between the vehicles.

You can also set the system to beep when a vehicle
detected in front of you comes in and goes out of the
ACC with Low Speed Follow detecting range.
Change the

ACC Vehicle Ahead Detected Beep



setting.

2

Customized Features

 P. 327

Limitations

You may need to use the brake to maintain a safe
interval when using ACC with Low Speed Follow.
Additionally, ACC with Low Speed Follow may not
work properly under certain conditions.

2

ACC with Low Speed Follow Conditions
and Limitations

 P. 455

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

454

Driving

A vehicle detected ahead is within ACC with Low Speed Follow range and
slows to a stop

Your vehicle also stops automatically. The

 message appears on the gauge.

When the vehicle ahead of you starts again,
the vehicle icon on the gauge blinks. If you
press the

RES/+

 or

SET/−

 button, or depress

the accelerator pedal, ACC with Low Speed
Follow operates again within the previously
set speed.

If no vehicle is ahead of you before you
resume driving, depress the accelerator pedal
and ACC with Low Speed Follow will operate
again within the prior set speed.

1

When in Operation

3

WARNING

Exiting a vehicle that has been stopped
while the ACC with Low Speed Follow
system is operating can result in the
vehicle moving without operator
control.

A vehicle that moves without operator
control can cause a crash, resulting in
serious injury or death.

Never exit a vehicle when the vehicle is
stopped by ACC with Low Speed Follow.

a

Adaptive Cruise Control (ACC)
with Low Speed Follow
Indicator (green)

b

Setting Status (green)

a

Adaptive Cruise Control (ACC)
with Low Speed Follow
Indicator (green)

b

Setting Status (green)

Continued

455

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

The system may automatically shut off and the Adaptive Cruise Control (ACC) with
Low Speed Follow Indicator (amber) will come on under certain conditions. Some
examples of these conditions are listed below. Other conditions may reduce some of
the ACC functions.

2

Front Sensor Camera

 P. 494

2

Radar Sensor

 P. 496

Environmental conditions

Driving in bad weather (rain, fog, snow, etc.).

Roadway conditions

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,
reflected lights, road spray, high contrast).

Vehicle conditions

The outside of the windscreen is blocked by dirt, mud, leaves, wet snow, etc.

An abnormal tyre or wheel condition (Wrong sized, varied size or construction,
improperly inflated, etc.).

The camera temperature gets too high.

The electric parking brake is applied.

When the front grille is dirty.

The vehicle is tilted due to a heavy load or suspension modifications.

When tyre chains are installed.

ACC with Low Speed Follow Conditions and Limitations

1

ACC with Low Speed Follow Conditions and Limitations

The radar sensor for ACC with Low Speed Follow is
shared with the collision mitigation braking system
(CMBS).

2

Collision Mitigation Braking System
(CMBS)

 P. 430

Always keep the radar sensor cover clean.

Never use chemical solvents or polishing powder for
cleaning the sensor cover. Clean it with water or a
mild detergent.

Do not put a sticker on the radar sensor cover or
replace the radar sensor cover.

If you need the radar sensor to be repaired, or
removed, or the radar sensor cover is strongly
impacted, turn off the system by pressing the



button and take your vehicle to a dealer.

Have your vehicle checked by a dealer if you find any
unusual behaviour of the system (e.g., the warning
message appears too frequently).

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

456

Driving

Detection limitations

A vehicle suddenly crosses in front of you.

The interval between your vehicle and the vehicle ahead of you is too short.

A vehicle cuts in front of you at a slow speed, and it brakes suddenly.

When you accelerate rapidly and approach the vehicle ahead of you at high
speed.

The vehicle ahead of you is a motorcycle, bicycle, mobility scooter, or other small
vehicle.

When there are animals in front of your vehicle.

When you drive on a curved or winding or undulating road that makes it difficult
for the sensor to properly detect a vehicle in front of you.

The speed difference between your vehicle and a vehicle in front of you is
significantly large.

An oncoming vehicle suddenly comes in front of you.

Your vehicle abruptly crosses over in front of an oncoming vehicle.

1

ACC with Low Speed Follow Conditions and Limitations

If the front of the vehicle is impacted in any of the
following situations, the radar sensor may not work
properly. Have your vehicle checked by a dealer:

The vehicle impacted a bump, curb, chock,
embankment, etc.

You drive the vehicle where the water is deep.

Your vehicle has a frontal collision.

457

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

When driving through a narrow iron bridge.

When the vehicle ahead of you brakes suddenly.

When the vehicle ahead of you has a unique shape.

When your vehicle or the vehicle ahead of you is driving on one edge of the lane.

a

Radar detects upper section of an empty carrier lorry.

b

Panel lorry, tanker lorry, etc.

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

458

Driving

Increase or decrease the vehicle speed using the

RES/+

 or

SET/−

 button on the

steering wheel.

Each time you press the

RES/+

 or

SET/−

 button, the vehicle speed is increased or

decreased by about 1 km/h or 1 mph accordingly.

If you keep pressing the

RES/+

 or

SET/−

 button, the vehicle speed increases or

decreases by about 10 km/h or 10 mph accordingly.

To Adjust the Vehicle Speed

1

To Adjust the Vehicle Speed

If a vehicle detected ahead is going at a speed slower
than your increased set speed, ACC with Low Speed
Follow may not accelerate your vehicle. This is to
maintain the set interval between your vehicle and
the vehicle ahead.

When you depress the accelerator pedal and then
push and release the

SET/−

 button, the current

speed of the vehicle is set.

a

To increase speed

b

To decrease speed

459

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

Press the interval button to change the ACC
with Low Speed Follow following interval.
Each time you press the button, the following-
interval (the interval behind a vehicle detected
ahead of you) setting cycles through extra
long, long, middle, and short following-
intervals.

Determine the most appropriate following-
interval setting based on your specific driving
conditions. Be sure to adhere to any
following-interval requirements set by local
regulation.

To Set or Change Following-interval

a

Interval Button

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

460

Driving

The higher your vehicle’s following-speed is, the longer the short, middle, long or
extra long following-interval becomes. See the following examples for your
reference.

When your vehicle stops automatically because a vehicle detected ahead of you has
stopped, the interval between the two vehicles will vary based on the ACC with Low
Speed Follow interval setting.

Following-interval

When the Set Speed is:

80 km/h (50 mph)

104 km/h (65 mph)

Short

24.2 metres

79.4 feet

1.1 sec

33.0 metres

108.2 feet

1.1 sec

Middle

33.0 metres

108.2 feet

1.5 sec

43.0 metres

141.0 feet

1.5 sec

Long

44.0 metres

144.3 feet

2.0 sec

57.5 metres

188.5 feet

2.0 sec

Extra
Long

63.5 metres

208.3 feet

2.9 sec

83.4 metres

273.6 feet

2.9 sec

1

To Set or Change Following-interval

The driver must in all circumstances preserve a
sufficient braking interval from the vehicle which
precedes it and be aware that minimum intervals or
times of spacing can be provided by the provisions of
the Motorway Code locally applicable and that it is
the driver’s responsibility to respect those laws.

Continued

461

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

To cancel ACC with Low Speed Follow, do any
of the following:

Press the

CANCEL

 button.

u

The

 indicator (green) on the gauge

change to the

 indicator (white.)

Press the

 button.

u

 indicator (green) goes off.

Press the

LIM

 button.

Depress the brake pedal while the vehicle is
moving forward.

u

The

 indicator (green) on the gauge

change to the

 indicator (white.)

To Cancel

1

To Cancel

The set speed cannot be set or resumed when ACC
with Low Speed Follow has been turned off using the

 button. Press the

 button to activate the

system, then set the desired speed.

Resuming the prior set speed: After you have
cancelled ACC with Low Speed Follow, you can
activate the ACC with Low Speed Follow with the
prior set speed displayed on the meter (in gray) by
pressing the

RES/+

 button even if the vehicle is

stopped.
When you turn the ACC with Low Speed Follow off
by pressing the

CANCEL

 button or depressing the

brake pedal, the prior set speed is displayed on the
meter in gray.
When pressing the

RES/+

 button, the ACC with Low

Speed Follow is activated with displayed speed.
Then, when the

 white indicator is displayed and

you press the

RES/+

 button during the prior set

speed (in gray) is not displayed, the current vehicle
speed is set as same as the condition of operating the

SET/-

 button.

a

LIM

 Button

b

CANCEL

 Button

c

 Button

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

462

Driving

Automatic cancellation

The beeper sounds and a message appears on the gauge when ACC with Low
Speed Follow is automatically cancelled. Any of these conditions may cause the ACC
with Low Speed Follow to automatically cancel:

Bad weather (rain, fog, snow, etc.)

When the radar sensor in the front grille gets dirty.

The vehicle ahead of you cannot be detected.

An abnormal tyre condition is detected, or the tyres are skidding.

Driving on a mountainous road, or driving off road for extended periods.

Abrupt steering wheel movement.

When the ABS, VSA or CMBS is activated.

When the ABS or VSA system indicator comes on.

When the vehicle is stopped on a very steep slope.

When you manually apply the electric parking brake.

When the detected vehicle within the ACC with Low Speed Follow range is too
close to your vehicle.

The camera behind the rearview mirror, or the area around the camera, including
the windscreen, gets dirty.

When the Maximum Load Limit is exceeded.

When passing through an enclosed space, such as tunnel.

The ACC with Low Speed Follow automatic cancellation can be also triggered by the
following causes. In these cases, the electric parking brake will be automatically
applied.

The driver’s seat belt is unfastened when the vehicle is stationary.

The vehicle stops for more than 10 minutes.

The power system is turned off.

1

To Cancel

a

 (white)

b

Setting Status (gray)

c

Prior Set Speed (gray)

1

Automatic cancellation

Even though ACC with Low Speed Follow has been
automatically cancelled, you can still resume the prior
set speed. Wait until the condition that caused ACC
with Low Speed Follow to cancel improves, then
press the

RES/+

 or

SET/−

 button.

463

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

In the following cases, a buzzer sounds, ACC is deactivated, and the

 message

appears in the driver information interface.

The vehicle has repeatedly applied the brakes to maintain the set speed (for
example, you are descending a long slope).

464

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

Provides an early prediction for a cut-in situation. The system detects that a vehicle
running in the adjacent slower lane has an intention to cut in front of you and
adjusts the speed of your vehicle in advance while ACC with Low Speed Follow is
activated.

Intelligent Adaptive Cruise Control Function

465

uu

Honda Sensing

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

How the system works

The radar sensor in the front grille detects
vehicles ahead of you including those in the
adjacent lane, and the camera behind the
rearview mirror detects the lane markings.

This system improves ACC with Low Speed
Follow's following/tracking property; it adjusts
your vehicle speed in advance predicting a
situation that a vehicle running in the adjacent
slower lane catches up with a slower vehicle
ahead of it and changes the lane to cut in
front of you early.
When such a cut-in situation is predicted, your
vehicle speed decreases a little. When
detected, your vehicle speed decreases
according to the vehicle cutting in front of
you.

As the speed is adjusted by the system, the cut
in vehicle icon appears on the gauge to
indicate that the system is activated.

Left-hand drive type is shown.

a

Slow Vehicle

b

Cut-in Vehicle

c

Your Vehicle















Content      ..     27      28      29      30     ..
