Honda e (2021 year). Manual in english - page 27





418

uu

When Driving

u

Vehicle Stability Assist (VSA) System

Driving

Vehicle Stability Assist (VSA) System

VSA helps to stabilise the vehicle during cornering if the vehicle turns more or less
than what was intended. It also assists in maintaining traction on slippery surfaces.
It does so by regulating motor output and selectively applying the brakes.

When VSA activates, you may notice that the
motor does not respond to the accelerator.
You may also notice some noise from the
hydraulic system. You will also see the
indicator blink.

VSA Operation

1

Vehicle Stability Assist (VSA) System

The VSA may not function properly if tyre type and
size are mixed. Make sure to use the same size and
type of tyre, and the air pressures as specified.

When the VSA system indicator comes on and stays
on while driving, there may be a problem with the
system. While this may not interfere with normal
driving, have your vehicle checked by a dealer
immediately.

VSA cannot enhance stability in all driving situations
and does not control the entire braking system. You
still need to drive and corner at speeds appropriate
for the conditions and always leave a sufficient
margin of safety.

The main function of the VSA system is generally
known as Electronic Stability Control (ESC). The
system also includes a traction control function.

a

VSA System Indicator

419

uu

When Driving

u

Vehicle Stability Assist (VSA) System

Driving

The

(VSA

OFF

) icon is in the safety config

of the audio/information screen.
To partially disable VSA functionality/features,
press the

 (VSA

OFF

) icon (green).

2

Driver Assist System On and Off

 P. 326

Your vehicle will have normal braking and
cornering ability, but traction control function
will be less effective.

To restore VSA functionality/features, press
the

(VSA

OFF

) icon (amber).

VSA is turned on every time you turn the
power system on, even if you turned it off the
last time you drove the vehicle.

VSA On and Off

1

Vehicle Stability Assist (VSA) System

In certain unusual conditions when your vehicle gets
stuck in shallow mud or fresh snow, it may be easier
to free it with the VSA temporarily switched off.

When the VSA system is off, the traction control
function becomes less effective. This allows for the
wheels to spin more freely at low speed. You should
only attempt to free your vehicle with the VSA off if
you are not able to free it when the VSA is on.

Immediately after freeing your vehicle, be sure to
switch VSA on again. We do not recommend driving
your vehicle with the VSA system switched off.

You may hear a motor sound coming from under the
bonnet while system checks are being performed
immediately after turn the power system on or while
driving. This is normal.

a

VSA

OFF

 Indicator

b

 (VSA

OFF

) Icon

420

uu

When Driving

u

Deflation Warning System

Driving

Deflation Warning System

Instead of directly measuring the pressure in each tyre, the deflation warning system
on this vehicle monitors and compares the rolling radius and rotational
characteristics of each wheel and tyre while you are driving to determine if one or
more tyres are significantly under-inflated.

This will cause the low tyre pressure/deflation
warning system indicator to come on and a
message to appear on the driver information
interface.

1

Deflation Warning System

The system does not monitor the tyres when driving
at low speed.

Conditions such as low ambient temperature and
altitude change directly affect tyre pressure and can
trigger the low tyre pressure/deflation warning
system indicator to come on.

Tyre pressure checked and inflated in:

Warm weather can become under-inflated in
colder weather.

Cold weather can become over-inflated in warmer
weather.

The Low Tyre Pressure/Deflation Warning System
indicator will not come on as a result of over inflation.

The deflation warning system may not function
properly if tyre type and size are mixed.
Make sure to use the same size and type of tyre.

2

Checking and Maintaining Tyres

 P. 609

The low tyre pressure/deflation warning system
indicator may come on with a delay or may not come
on at all when:

You rapidly accelerate, decelerate, or turn the
steering wheel.

You drive on snowy or slippery roads.

Tyre chains are used.

a

Low Tyre Pressure/Deflation
Warning System Indicator

Continued

421

uu

When Driving

u

Deflation Warning System

Driving

You must start deflation warning system calibration every time you:

Adjust the pressure in one or more tyres.

Rotate the tyres.

Replace one or more tyres.

Before calibrating the deflation warning system:

Set the cold tyre pressure in all four tyres.

2

Checking Tyres

 P. 609

Make sure:

The vehicle is at a complete stop.

The transmission is in

(

P

.

The power mode is in ON.

Deflation Warning System Calibration

1

Deflation Warning System

The low tyre pressure/deflation warning system
indicator may come on under the following
conditions:

Tyre chains are used.

1

Deflation Warning System Calibration

The calibration process requires approximately
30 minutes of cumulative driving at speeds between
40-100 km/h (25 - 62 mph).
During this period, if the power system is turned on
and the vehicle is not moved within 45 seconds, you
may notice the low tyre pressure indicator comes on
briefly. This is normal and indicates that the
calibration process is not yet complete.

If the tyre chains are installed, remove them before
calibration the deflation warning system.

If the low tyre pressure/deflation warning system
indicator comes on even when the properly inflated
specified regular tyres are installed, have your vehicle
checked by a dealer.

We recommend that the tyres be replaced with the
same brand, model, and size as the originals. Ask a
dealer for details.

422

uu

When Driving

u

Deflation Warning System

Driving

You can calibrate the system from the
customized feature on the audio/information
screen.

1.

Set the power mode to ON.

2.

Select

All Apps

.

3.

Select

Vehicle Settings

.

4.

Select

Deflation Warning System

.

5.

Select

Cancel

 or

Calibrate

.

If the

Calibration Failed to Start.

 message

appears, repeat step 5.

The calibration process finishes
automatically.

423

uu

When Driving

u

Blind spot information System

*

Continued

Driving

Blind spot information System

*

Is designed to detect vehicles in specified alert zones adjacent to your vehicle,
particularly in harder to see areas commonly known as “blind spots.”

When the system detects vehicles approaching from behind in adjacent lanes, the
appropriate indicator comes on for a few seconds, providing assistance when you
change lanes.

1

Blind spot information System

*

Important Safety Reminder

Like all assistance systems, blind spot information
system has limitations. Over reliance on blind spot
information system may result in a collision.

3

WARNING

Failure to visually confirm that it is safe to
change lanes before doing so may result in
a crash and serious injury or death.
Do not rely only on the blind spot
information system when changing lanes.

Always look in your mirrors, to either side
of your vehicle, and behind you for other
vehicles before changing lanes.

* Not available on all models

uu

When Driving

u

Blind spot information System

*

424

Driving

How the system works

Radar sensors detect a vehicle in the alert
zone when your vehicle is moving forward
at 20 km/h (12 mph) or faster.

Radar Sensors: underneath the rear bumper
corners

1

Blind spot information System

*

The system is for your convenience only. Even if an
object is within the alert zone, the following
situations may occur.

The blind spot information system alert indicator
may not come on due to obstruction (splashes,

etc.) even without the

 driver information

interface appearing.

The blind spot information system alert indicator

may come on even with the

 message

appearing.

The blind spot information system alert indicator may
not come on under the following conditions:

A vehicle does not stay in the alert zone for more
than two seconds.

A vehicle is parked in a side lane.

The speed difference between your vehicle and the
vehicle you are passing is greater than 10 km/h
(6 mph).

An object not detected by the radar sensors
approaches or passes your vehicle.

A vehicle running in the adjacent lane is a
motorcycle or other small vehicle.

You can turn off the audible alert, or all the blind spot
information system alert using the audio/information
screen.

2

Customized Features

 P. 327

a

Alert zone

b

Approx. 0.5 m (1.6 ft.)

c

Approx. 3 m (10 ft.)

d

Approx. 3 m (10 ft.)

* Not available on all models

Continued

425

uu

When Driving

u

Blind spot information System

*

Driving

When the system detects a vehicle

Blind spot information System Alert Indicator:
Located under the side camera mirror system
display.
Comes on when:

A vehicle enters the alert zone from behind
to overtake you with a speed difference of
no more than 50 km/h (31 mph) from your
vehicle.

You pass a vehicle with a speed difference
of no more than 20 km/h (12 mph).

Blinks and a beeper sounds when:

You move the turn signal lever in the direction
of the detected vehicle. The beeper sounds
three times.

1

Blind spot information System

*

Blind spot information system may be adversely
affected when:

Objects (guard rails, poles, trees, etc,.) are
detected.

An object that does not reflect radio waves well,
such as a motorcycle, is in the alert zone.

Driving on a curved road.

A vehicle is moving from a far lane to the adjacent
lane.

The system picks up external electrical interference.

The rear bumper or the sensors have been
improperly repaired or the rear bumper has been
deformed.

The orientation of the sensors has been changed.

In bad weather (rain, snow, and fog).

Making a turn at an intersection.

Driving on a bumpy road.

Making a short turn that slightly tilts the vehicle.

For a proper blind spot information system operation:

Always keep the rear bumper corner area clean.

Do not cover the rear bumper corner area with
labels or stickers of any kind.

Take your vehicle to a dealer if you need the rear
bumper corner area or the radar sensors to be
repaired, or the rear bumper corner area is strongly
impacted.

a

Comes On

b

Blinks

* Not available on all models

426

uu

When Driving

u

Blind spot information System

*

Driving

Blind spot information On and Off

You can switch the system on and off from the audio/information screen.

2

Driver Assist System On and Off

 P. 326

You can also turn the system on and off by the
following procedure:

1.

Press the

 button on the steering wheel.

2.

Roll the left selector wheel and select

Safety Support

, then press the left

selector wheel.

3.

Roll the left selector wheel and select

Blind

Spot Information System

, then press the

left selector wheel.

u

The message appears on the driver
information interface when the system
becomes on or off.

u

A tick appears in the box and the colour
of the

 symbol changes green when

the system is on. The tick disappear and
the colour of the

 symbol changes

gray when the system is off.

427

Continued

Driving

Honda Sensing

Honda Sensing is a driver support system which employs the use of three distinctly
different kinds of sensors:
A radar sensor located in the front grille, a front sensor camera mounted to the
interior side of the windscreen, behind the rearview mirror, the sonar sensors
located in the front and rear bumper.

Honda Sensing has following functions.

The functions which do not require switch operations to activate

Collision Mitigation Braking System (CMBS)

2

 P. 430

Low Speed Braking Control

2

 P. 441

Road Departure Mitigation System

2

 P. 478

Lead Car Departure Notification System

2

 P. 484

Traffic Sign Recognition System

2

 P. 488

The functions which require switch operations to activate

Adaptive Cruise Control (ACC) with Low Speed Follow

2

 P. 447

Lane Keeping Assist System (LKAS)

2

 P. 467

428

uu

Honda Sensing

u

Driving

 Button

Press to activate standby mode for ACC with
Low Speed Follow. Or press to cancel this
system.

LKAS Button

Press to activate standby mode for LKAS. Or
press to cancel this system.

RES/+/SET/− Button

Press

RES/+

 to resume the ACC with Low

Speed Follow or increase the vehicle speed.
Press

SET/−

 to set the ACC with Low Speed

Follow or decrease the vehicle speed.

Interval Button

Press to change the ACC with Low Speed
Follow following-interval.

CANCEL Button

Press to cancel ACC with Low Speed Follow.

Operation Switches for the ACC with Low Speed Follow/LKAS

a

CANCEL

 Button

b

Interval Button

c

LKAS Button

d

 Button

e

RES/+

 Button

f

SET/−

 Button

429

uu

Honda Sensing

u

Driving

You can see the current state of ACC with
Low Speed Follow and LKAS.

a

Indicates that ACC with Low Speed Follow
is ready to be activated.

Green: The system is on.

White: The system is standby.

Amber: There is a problem with the system.

b

Indicates that LKAS, is ready to be
activated.

Green: The system is on or standby.

Amber: There is a problem with the system.

c

Indicates that LKAS is activated.

d

Indicates whether or not ACC with Low
Speed Follow detected the vehicle ahead.

e

Indicates that ACC with Low Speed Follow
shows the set vehicle speed.

f

Indicates that ACC with Low Speed Follow
shows the set vehicle interval.

g

Indicates that ACC with Low Speed Follow
shows the setting status.

Green: The system is on.

Gray: The system is not activated.

Driver Information Interface Content

430

uu

Honda Sensing

u

Collision Mitigation Braking System (CMBS)

Driving

Collision Mitigation Braking System (CMBS)

Can assist you when there is a possibility of your vehicle colliding with a vehicle,
pedestrian on foot or riding a bicycle (moving bicycle) detected in front of yours. The
CMBS is designed to alert you when a potential collision is determined, as well as
assist in reducing speed, avoiding collisions, and reducing collision severity.

1

Collision Mitigation Braking System (CMBS)

For directions on the proper handling of the radar
sensor, refer to the following page.

2

Radar Sensor

 P. 496

You can read about handling information for the
camera equipped with this system.

2

Front Sensor Camera

 P. 494

Important Safety Reminder

The CMBS is designed to reduce the severity of an
unavoidable collision. It does not prevent collision nor
stop the vehicle automatically. It is still your
responsibility to operate the brake pedal and steering
wheel appropriately according to the driving
conditions.

The CMBS may not activate or may not detect a
vehicle in front of your vehicle under certain
conditions:

2

CMBS Conditions and Limitations

 P. 435

Continued

431

uu

Honda Sensing

u

Collision Mitigation Braking System (CMBS)

Driving

How the system works

The system starts monitoring the roadway ahead when your vehicle speed is about
5 km/h (3 mph) and there is a vehicle, pedestrian or moving bicycle in front of you.

1

Collision Mitigation Braking System (CMBS)

When the CMBS activates, it may automatically apply
the brake. It will be cancelled when your vehicle stops
or a potential collision is not determined.

a

The camera is located behind the rearview mirror.

b

The radar sensor is located in the front grille.

When to use

uu

Honda Sensing

u

Collision Mitigation Braking System (CMBS)

432

Driving

The CMBS activates when:

The speed difference between your vehicle and a vehicle, pedestrian or moving
bicycle detected in front of you becomes about 5 km/h (3 mph) and over with a
chance of a collision.

Your vehicle speed is about 100 km/h (62mph) or less and the system determines
there is a chance of a collision with:

-

An oncoming or stationary vehicle detected in front of you.

-

A pedestrian or moving bicycle detected in front of you.

Your vehicle speed is above 100 km/h (62 mph), and the system determines there
is a chance of a collision with a vehicle detected in front of you travelling in your
same direction.

The CMBS will be canceled when your vehicle stops or a potential collision is not
determined.

When the system activates

The system provides visual and audible alerts
of a possible collision, and stops if the collision
is avoided.

u

Take appropriate action to prevent a
collision (apply the brakes, change lanes,
etc.)

At system’s earliest collision alert stage, you
can change the distance (

Far

/

Normal

/

Near

between vehicles at which alerts will come on
through audio/information screen setting
options.

2

Customized Features

 P. 327

1

When the system activates

The camera in the CMBS is also designed to detect
pedestrians.
However, this pedestrian detection feature may not
activate or may not detect a pedestrian in front of
your vehicle under certain conditions.
Refer to the ones indicating the pedestrian detection
limitations from the list.

2

CMBS Conditions and Limitations

 P. 435

a

Visual Alerts

b

Audible Alert

433

uu

Honda Sensing

u

Collision Mitigation Braking System (CMBS)

Continued

Driving

The system has three alert stages for a possible collision. However, depending on circumstances, the CMBS may not go through all of the
stages before initiating the last stage.

Collision Alert Stages

Distance between vehicles

CMBS

The radar sensor detects a

vehicle

Audible & Visual WARNINGS

Braking

Stage

one

There is a risk of a collision with
the vehicle ahead of you.

When in

Far

, visual and audible alerts come

on at a longer distance from a vehicle
ahead than in

Normal

 setting, and in

Near

, at a shorter distance than in

Normal

.

Stage

two

The risk of a collision has
increased, time to respond is
reduced.

Visual and audible alerts.

Lightly applied

Stage

three

The CMBS determines that a
collision is unavoidable.

Forcefully applied

a

Your Vehicle

b

Vehicle Ahead

c

Far

d

Normal

e

Near















Content      ..     25      26      27      28     ..
