Honda e (2021 year). Manual in english - page 16





uu

Interior Convenience Items

u

Storage Items

242

Co
ntrols

The luggage area cover may be removed to give you more luggage room.

To remove the luggage area cover

1.

Open the tailgate.

2.

Remove the strap on each side of the
tailgate.

3.

Disengage the support rods, then remove
the luggage area cover.

Reverse this procedure to install the luggage
area cover.

After reinstalling the luggage area cover,
make sure it is latched securely.

Luggage Area Cover

1

Luggage Area Cover

Do not place items on the luggage area cover, or
stack objects higher than the top of the back seat.
They could block your view and be thrown around
the vehicle during a crush or sudden stop.

Do not apply excessive pressure to the cover, such as
leaning on it to retrieve an item.

a

Support Rod

243

uu

Interior Convenience Items

u

Other Interior Convenience Items

Continued

Co
ntrols

Other Interior Convenience Items

The accessory power socket can be used when the power mode must be in
ACCESSORY or ON.

Console panel

Open the cover to use it.

Accessory Power Socket

1

Accessory Power Socket

NOTICE

Do not insert an automotive type cigarette lighter
element. This can overheat the power socket.

The accessory power socket is designed to supply
power for 12-volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent 12-volt battery drain, only use the power
socket with the power system on.

When the power socket is not in use, close the cover
to prevent any small foreign objects from getting into
the power socket.

uu

Interior Convenience Items

u

Other Interior Convenience Items

244

Co
ntrols

The AC power outlet can be used when the power mode is in ON.

Open the cover to use it. Plug in the appliance,
then push the

AC 230V

 button.

AC Power Outlet

*

1

AC Power Outlet

*

NOTICE

Do not use the AC power outlet for electric
appliances that require high initial peak wattage such
as refrigerators, electric pumps, etc. It is not suitable
for devices that process precise data, such as medical
equipment, and that require an extremely stable
power supply, such as microcomputer-controlled
electric blankets, touch sensor lamps, etc.

The AC power outlet is designed to supply power for
up to 230 volt appliances that are rated 1500 watts
or less.
Continued use of any electric appliance/device
exceeding these ratings may result in damage to the
appliance/device.

When the AC power outlet is not in use, close the
cover to prevent any small foreign objects from
getting into the AC power outlet.

Refrain from using heat-generating electrical
equipment or cooking utensils that cannot be
secured while driving.

You may hear static on the radio depending on the
electrical equipment in use.

* Not available on all models

Continued

245

uu

Interior Convenience Items

u

Other Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
heated steering wheel.

Press the button on the right side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you turn the power system on, even if
you turned it on the last time you drove the
vehicle.

Heated Steering Wheel

*

1

Heated Steering Wheel

*

Do not use the heated steering wheel continuously
when the power system is off. Under such conditions,
the 12-volt battery may be weakened, making it
difficult to turn the power system on.

When the remote climate pre-conditioning is on, the
heated steering wheel may turn on automatically,
depending on the ambient temperature.

* Not available on all models

uu

Interior Convenience Items

u

Other Interior Convenience Items

246

Co
ntrols

The power mode must be in ON to use the
seat heaters.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

When the power mode is in ON after it is
turned off, the previous setting of seat heaters
is maintained.

Front Seat Heaters

1

Front Seat Heaters

Do not use the seat heaters even in LO when the
power system is off. Under such conditions, the 12-
volt battery may be weakened, making it difficult to
turn the power system on.

After a certain period of time, the strength setting for
the seat heater will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

When the remote climate pre-conditioning is on, the
front seat heaters may turn on automatically,
depending on the ambient temperature.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

247

Continued

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the power system is on.

1.

Press the

AUTO

 button.

2.

Adjust the interior temperature using the temperature control dial.

3.

Press the

 (ON/OFF) button to cancel.

*1: Left-hand drive types are shown. For the right-hand drive types, these buttons are located
at the symmetrically opposite to the left-hand drive type.

1

Using Automatic Climate Control

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.

The

AUTO

 indicator will go off, but functions

unrelated to the button that were pressed will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the

AUTO



button is pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit,

Lo

 or

Hi

 is displayed.

Pressing the

 button switches the climate control

system between on and off. When turned on, the
system returns to your last selection.

When the

 or

 mode is active, depending on

conditions like the temperature and the humidity, the
heater inside the front windscreen may turn on
automatically.

Models with centre camera mirror system

a

AUTO

 Button

*1

g

MODE Control Button

 Air flows from dashboard vents

 Air flows from dashboard and

floor vents

 Air flows from floor vents

 Air flows from floor and

windscreen demister vents

b

Temperature Control Dial

*1

c

Fan Control Dial

*1

d

ON/OFF

 Button

*1

e

Recirculation Button

*1

f

A/C

(Air Conditioning) Button

*1

uu

Climate Control System

u

Using Automatic Climate Control

248

Co
ntrols

Switching between the recirculation and fresh air modes

Press the

 (recirculation) button and switch the mode depending on

environmental conditions.
Recirculation mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh air mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

1

Using Automatic Climate Control

The High Voltage battery level being low may reduce
the climate control system performance.

Continued

249

uu

Climate Control System

u

Using Automatic Climate Control

Co
ntrols

Pressing the

 (windscreen demister) button

turns the air conditioning system on and
automatically switches the system to fresh air
mode.

Press the

 button again to turn off, the

system returns to the previous settings.

To rapidly defrost the windows

1.

Press the

 button (indicator on).

2.

Press the

 button (indicator on).

Defrosting the Windscreen and Windows

1

Defrosting the Windscreen and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windscreen, the outside of the
windscreen may fog up.

When you press the

 button, the heater inside the

front windscreen will also turn on.

Models with centre camera mirror system

1

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode. If you keep the system in recirculation mode,
the windows may fog up from humidity. This
impedes visibility.

uu

Climate Control System

u

Using Automatic Climate Control

250

Co
ntrols

You can operate the climate control system from outside the vehicle.

To turn on the system

1.

Press the lock button.

u

Some exterior lights flash.

2.

Within about five seconds, press and hold
the climate button.

u

Some exterior lights flash.

u

After a few seconds, some exterior lights
flash six times and the climate control
system is turned on.

To turn off the system

Press and hold the climate button.

u

Some exterior lights flash and the climate
control system is turned off.

Remote Climate Pre-Conditioning

1

Remote Climate Pre-Conditioning

The climate control system does not operate when
any of the following conditions are met.

A door or the bonnet is not closed.

The power mode is set to ON.

The High Voltage battery level is low.

The climate control system automatically turned off
when any of the following conditions are met.

The system has been operated for more than time
your set.

The High Voltage battery level becomes low.

A bonnet is opened.

The power mode is set to ON.

3

WARNING

Make sure that no one is inside the vehicle
when you use the remote climate control
system. After a certain period of time has
elapsed, the system shuts off temporarily.
During this time, the interior of the vehicle
may heat up or cool down depending on
ambient temperatures. If a child is left
inside the vehicle, extreme temperature
exposure can result in death or serious
injury of the child.

a

Lock Button

b

Climate Button

251

uu

Climate Control System

u

Using Automatic Climate Control

Co
ntrols

1

Remote Climate Pre-Conditioning

The following functions also operate according to the
temperature:
When it is warm outside:

The air conditioning is activated in recirculation
mode.

When it is cold outside:

The heater inside the front screen

*

 is activated as

necessary.

The rear demister is activated.

The seat heater and heated steering wheel* are
activated.

2

Heated Steering Wheel

*

 P. 245

2

Front Seat Heaters

 P. 246

Depending on the charging environment, the charge
amount of High Voltage battery may be reduce even
if the charging connector is plugged in.

You can adjust the pre-conditioning temperature,
change the operation time, and turn off the
automatic defroster by using the audio/information
screen.

2

EV Menu

 P. 321

You can customize the settings of the climate control
system schedule.

2

EV Menu

 P. 321

* Not available on all models

252

uu

Climate Control System

u

Automatic Climate Control Sensors

Co
ntrols

Automatic Climate Control Sensors

The automatic climate control system is
equipped with sensors. Do not cover or spill
any liquid on them.

a

Sensor

a

Sensor

253

Features

This chapter describes how to operate technology features.

Audio System

About Your Audio System................ 254
Audio System Theft Protection ......... 255

Display Audio

.................................... 256

Start Up ........................................... 256
Basic Operation................................ 257
On-Board Owner’s Manual .............. 263
Honda Personal Assistant ................. 264
Voice Control Operation*

1

............... 265

Audio/Information Screen ................ 268
Clock Setup ..................................... 274
Adjusting the Sound ........................ 277

Display Setup ................................... 278
System Updates ............................... 279
Playing FM Radio ............................. 284

Playing DAB (Digital Audio

Broadcasting) ............................. 289

Playing an iPod ................................ 292
Playing Aha

TM

................................... 295

Playing a USB Flash Drive ................. 296
Playing

Bluetooth

®

 Audio................. 300

Playing a Video Using the HDMI

TM

.... 303

On Board Apps ................................ 305
Wi-Fi Connection ............................. 307

Apple CarPlay .................................. 309
Android Auto .................................. 313
Power Flow...................................... 317
EV Menu ......................................... 321
Driver Assist System On and Off....... 326
Customized Features ....................... 327
Defaulting All the Settings ............... 343
Hands-Free Telephone System ......... 344

Audio Error Messages

...................... 362

General Information on the Audio

System

............................................. 363

Emergency Call (eCall)

...................... 369

254

Features

Audio System

About Your Audio System

The audio system features FM radio and Digital Audio Broadcasting (DAB) service. It
can also play USB flash drives, iPod, iPhone,

Bluetooth

®

 devices, smartphone, and

HDMI

TM

 devices.

You can operate the audio system from the buttons and volume knob on the panel,
the remote controls on the steering wheel or the icons on the touchscreen interface.

1

About Your Audio System

iPod, iPhone and iTunes are trademarks of Apple Inc.

Key Off Operation

After you set the power mode to VEHICLE OFF
(LOCK), you can use the audio system for up to 30
minutes per driving cycle. However, whether you can
continue using the audio system depends on the
battery condition. Repeatedly using this feature may
drain the battery.

a

Remote Controls

b

HDMI

TM

c

iPod

d

USB Flash Drive

255

uu

Audio System

u

Audio System Theft Protection

Features

Audio System Theft Protection

The audio system is disabled when it is disconnected from the power source, such as
when the 12-volt battery is disconnected or goes dead. In certain conditions, the
system may display a code entry screen. If this occurs, reactivate the audio system.

Reactivating the audio system

1.

Set the power mode to ON.

2.

Turn on the audio system.

3.

Press and hold the audio system power button for more than two seconds.

u

The audio system is reactivated when the audio control unit establishes a
connection with the vehicle control unit. If the control unit fails to recognise
the audio unit, you must go to a dealer and have the audio unit checked.

256

Features

Display Audio

Start Up

The Display Audio starts automatically when you set the power mode to
ACCESSORY or ON. At start-up, the following screen about the data upload will be
displayed.

Select

Start

.

u

If you want to change the settings for
data upload, select

Settings

, then select

the ON/OFF settings on the

Location

and vehicle data sharing

 screen.

u

 If you do not select

Start

, the system will

automatically be switched the audio/
information screen after a certain period
of time.

u

If there is no registered device, select

Start

 and the

Bluetooth

®

 pairing screen

will be displayed.

u

If you check the box with

Do not show

this again

, this screen will not be

displayed.

To pair a mobile phone (when there is
no phone paired to the system)

1.

Make sure your phone is in search or
discoverable mode.

2.

Select

Honda HFT

 from your phone.

u

If you want to pair a phone from this
Display Audio, select

Search for

Devices

, and then select your phone

when it appears on the list.

1

Start Up

Location and vehicle data sharing
ON

: Available the data communication.

OFF

: Not available the data communication.

257

uu

Display Audio

u

Basic Operation

Continued

Features

Basic Operation

To use the audio system function, the power mode must be in ACCESSORY or ON.

Audio System Function

1

Audio System Function

This screen is shown for the left-hand drive models.
For the right-hand drive models, these are located at
the symmetrically opposite to the left-hand drive
model.

You can use the audio system for 30 minutes when
the power mode is in VEHICLE OFF, the system will
then turn off automatically.
If you want to keep using it, we recommend that you
set the power mode to ACCESSORY or ON.

Key Off Operation

2

Key Off Operation

 P. 254

a

 (Screen Switch) Icon

g

 (Power/Audio) Button

b

 (Recent) Icon

h

 (Brightness) Button

c

 (Back) Icon

i

 (Home) Button

d

Status Icons

j



All Apps

e



Search Station

k

Safety Config

f

VOL

 Knob

l

Shortcut Icon















Content      ..     14      15      16      17     ..
