uu

Adjustment of Each Type of Mirror

u

Side Camera Mirror System

226

Co
ntrols

When the temperature is too extreme or there
is a problem with the system, the indicator will
come on.

When the temperature inside the vehicle
is too hot or too cold:

This icon

 will be displayed on the image.

The

 indicator will also be displayed on the

instrument panel. When the temperature
inside the vehicle returns to a temperature at
which the system can operate the

 indicator

will turn off.

When there is a system problem:

The video will no longer display. This indicator

 will also be displayed on the instrument

panel. Have the side camera mirror system
promptly repaired by a dealer.

Indicator

1

Indicator

If the temperature inside the vehicle is high, the
image may darken, and if the temperature becomes
too high, the image may not show. If the
temperature inside the vehicle is low, there may be
afterimages on the display.

If the temperature in the vehicle is too hot or cold,
you can use the climate control system to regulate
the temperature.

a

Indicator

227

Continued

Co
ntrols

Seats

Front Seats

Adjust the driver’s seat as far back as possible
while allowing you to maintain full control of
the vehicle. You should be able to sit upright,
well back in the seat and be able to
adequately press the pedals without leaning
forward, and grip the steering wheel
comfortably. The passenger’s seat should be
adjusted in a similar manner, so that it is as far
back from the front airbag in the dashboard
as possible.

1

Seats

In addition to the seat adjustment, you can adjust the
steering wheel up and down, in and out. Allow at
least 25 cm (10 inches) between the centre of the
steering wheel and the chest.

Always make seat adjustments before driving.

3

WARNING

Sitting too close to a front airbag can result
in serious injury or death if the front
airbags inflate.

Always sit as far back from the front
airbags as possible while maintaining
control of the vehicle.

Move back to allow sufficient
space.

uu

Seats

u

Front Seats

228

Co
ntrols

Adjusting the front manual seat

Adjusting the Seat Positions

1

Adjusting the front manual seat

Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.

a

Horizontal Position Adjustment

Pull up on the bar to move the seat, then release the bar.

b

Seat-back Angle Adjustment

Pull up the lever to change the angle.

c

Height Adjustment

(Driver side only)

Pull up or push down the lever to raise or lower the seat.

229

uu

Seats

u

Front Seats

Co
ntrols

Adjust the driver's seat-back to a comfortable,
upright position, leaving ample space
between your chest and the airbag cover in
the centre of the steering wheel.

The front seat passenger should also adjust
their seat-back to a comfortable, upright
position.

Reclining a seat-back so that the shoulder part of the belt no longer rests against the
occupant's chest reduces the protective capability of the belt. It also increases the
chance of sliding under the belt in a crash and being seriously injured. The farther a
seat-back is reclined, the greater the risk of injury.

Adjusting the Seat-Backs

1

Adjusting the Seat-Backs

Do not put a cushion, or other object, between the
seat-back and your back.

Doing so may interfere with proper seat belt or airbag
operation.

If you cannot get far enough away from the steering
wheel and still reach the controls, we recommend
that you investigate whether some type of adaptive
equipment may help.

3

WARNING

Reclining the seat-back too far can result in
serious injury or death in a crash.

Adjust the seat-back to an upright position,
and sit well back in the seat.

230

uu

Seats

u

Rear Seats

Co
ntrols

Rear Seats

1.

Lower the rear seat head restraint to its
lowest position.

2.

Pull the release lever and fold down the
seat.

This feature alerts you to passengers or items possibly forgotten in the rear seat. It
activates when the rear doors are opened, and will alert you by display and sound
before exiting the vehicle.

Folding Down the Rear Seats

1

Folding Down the Rear Seats

The rear seat-backs can be folded down to
accommodate bulkier items in the luggage area.

When returning the seat-back to its original position,
push it firmly back. Also, make sure all rear shoulder
belts are positioned in front of the seat-back.

Make sure all items in the luggage area or items
extending through the opening into the rear
seats are properly secured. Loose items can fly
forward if you have to brake hard.

3

WARNING

Make sure the seat-backs are latched
securely before driving.

a

Release Lever

Rear Seat Reminder

1

Rear Seat Reminder

When the power mode is set to OFF, the reminder
will go off and the function will terminate.

The reminder will also go off when the shift position
is set to

(

P

 and the driver’s seat belt is unfastened

before setting the power mode to OFF.

The reminder will not work if the power mode has
not been set to ON within 10 minutes of operating
the rear doors.

231

uu

Seats

u

Maintain a Proper Sitting Position

Co
ntrols

Maintain a Proper Sitting Position

After all occupants have adjusted their seats and head restraints, and put on their
seat belts, it is very important that they continue to sit upright, well back in their
seats, with their feet on the floor, until the vehicle is safely parked and the power
mode is off.

Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is greatly
increased.

In addition, an occupant who is out of position in the front seat can be seriously or
fatally injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

1

Rear Seat Reminder

The system does not detect passengers in the rear
seat(s).
Instead, it can detect when a rear door is opened and
closed, indicating that there may be something in the
rear seat(s).

You can turn off the notification setting.

2

How to Customize the Vehicle Settings

 P. 336

1

Maintain a Proper Sitting Position

3

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

232

uu

Seats

u

Head Restraints

Co
ntrols

Head Restraints

Your vehicle is equipped with head restraints in all seating positions.

Head restraints are most effective for
protection against whiplash and other rear-
impact crash injuries when the centre of the
back of the occupant's head rests against the
centre of the restraint. The tops of the
occupant's ears should be level with the
centre height of the restraint.

To raise the head restraint:

 Pull it upward.

To lower the head restraint:

 Push it down

while pressing the release button.

Adjusting the Front Head Restraints

1

Adjusting the Front Head Restraints

In order for the head restraint system to work
properly:

Do not hang any items on the head restraints, or
from the restraint legs.

Do not place any objects between an occupant and
the seat-back.

Install each restraint in its proper location.

3

WARNING

Improperly positioning head restraints
reduces their effectiveness and increases
the likelihood of serious injury in a crash.

Make sure head restraints are in place and
positioned properly before driving.

Position head in the centre of the
head restraint.

Continued

233

uu

Seats

u

Head Restraints

Co
ntrols

To tilt the head restraint forward:

Push the back of it forward.

To tilt the head restraint backward:

Push it backward while pressing the release
button on the side of the head restraint.

A passenger sitting in the rear seating position
should adjust the height of their head restraint
to an appropriate position before the vehicle
begins moving.

To raise the head restraint:

Pull it upward.

To lower the head restraint:

Push it down while pressing the release
button.

Changing the Rear Seat Head Restraint Position

1

Changing the Rear Seat Head Restraint Position

When you use the head restraint in the rear seating
position, pull up the head restraint to its highest
position. Do not use it in any lower position.

uu

Seats

u

Head Restraints

234

Co
ntrols

Head restraints can be removed for cleaning or repair.

To remove a head restraint:

Pull the restraint up as far as it will go. Then push the release button, and pull the
restraint up and out.

To reinstall a head restraint:

Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button. Pull up on the restraint to make sure it is locked
in position.

Removing and Reinstalling the Head Restraints

1

Removing and Reinstalling the Head Restraints

3

WARNING

Failure to reinstall, or correctly reinstall, the
head restraints can result in severe injury
during a crash.

Always replace the head restraints before
driving.

235

Continued

Co
ntrols

Interior Convenience Items

Interior Lights

ON

The interior lights come on regardless of
whether the doors are open or closed.

Door activated

The interior lights come on in the following
situations:

When any doors are opened.

You unlock the driver’s door.

When the power mode is set to VEHICLE
OFF.

When you shift to

(

P

 while power system is

on.

When you unfasten the seatbelt.

OFF

The interior lights remain off regardless of
whether the doors are open or closed.

Interior Light Switches

1

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.
The lights go off after about 30 seconds in the
following situations:

When you unlock the driver’s door but do not open
it.

When you set the power mode to VEHICLE OFF but
do not open a door.

You can change the interior lights dimming time.

2

How to Customize the Vehicle Settings



P. 336

The interior lights go off immediately in the following
situations:

When you lock the driver’s door.

When you close the driver’s door in ACCESSORY
mode.

When you set the power mode to ON by pressing
the

POWER

 button.

When you set the shift position to other than

(

P

.

If you leave any of the doors open in VEHICLE OFF
mode, the interior lights go off after about 15
minutes.

To avoid draining the battery, do not leave the
interior light on for an extended length of time when
the power system is off.

Front

a

Door activated position

b

On

c

Off

Rear

uu

Interior Convenience Items

u

Interior Lights

236

Co
ntrols

Front seat

The map lights can be turned on and off by
pressing the button.

Rear seat

The map lights can be turned on and off by
pressing the button.

Map Lights

1

Map Lights

When the front interior light switch is in the door
activated position and any door is open, the map
light will not go off when you press the buttons.

Front

Rear

237

uu

Interior Convenience Items

u

Interior Lights

Co
ntrols

The lights come on when you open the
tailgate.

Luggage Area Lights

238

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

Storage Items

Pull the handle to open the glove box.

Are located in the console between the front
seats.

You can create more storage space by
removing the divider.

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Centre Console

Continued

239

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

Front seat beverage holders

Are located at the front side of the console.

Pull the band to use it.

Front door side beverage holders

Are located on the both of front door side
pockets.

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

a

Band

240

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

Rear door side beverage holders

Are located on the both of rear door side
pockets.

Continued

241

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

The tie-down anchors on the luggage area
floor can be used to install a net for securing
items.

The luggage hooks on both sides of the
luggage area can be used to hang a light
items.

Tie-down Anchors

1

Tie-down Anchors

Do not let anyone access items in the luggage area
while driving. Loose items can cause injury if you have
to brake hard.

Luggage Hook

1

Luggage Hook

NOTICE

Do not hang a large object or an object that weighs
more than 3 kg (6 lbs) on the side luggage hook.
Hanging heavy or large objects may damage the
hook.















Content      ..     13      14      15      16     ..
