Audio System Basic Operation

Display Setup

Features

Display Setup

You can change the brightness or color theme of the audio/information screen.

1. Press the DISP button to go to the Settings

screen.

2. Rotate

to select System Settings, then

press .

Repeat the procedure to select Display.

3. Rotate

to select Brightness, then press

4. Rotate

to adjust the setting, then press

1. Press the DISP button to go to the Settings

screen.

2. Rotate

to select System Settings, then

press .

Repeat the procedure to select Others.

3. Rotate

to select Background Color,

then press

4. Rotate

to select the setting you want,

then press

■

Changing the Screen Brightness

Changing the Screen Brightness

You can change the Contrast and Black Level
settings in the same manner.

■

Changing the Screen’s Color Theme

193

Audio System Basic Operation

Playing AM/FM Radio

Continued

Features

Playing AM/FM Radio

Audio/Information Screen

Audio with Touch Screen

Tune Up/Down Icons
Select

to tune the radio

frequency.

BACK Button
Press to go back to the previous
display.

MENU/SEL (Selector) Knob
Press and turn to select an item,
then press to set your selection.

VOL/

(Volume/Power) Knob

Press to turn the audio system on
and off.
Turn to adjust the volume.

Source
Select to change a band or change
an audio source.

To listen to a stored channel,
select 1-6 (AM) or 1-12 (FM).

Presets
Select to store a station.

Skip/Seek Icons
Select

to search up and

down the selected band for a
station with a strong signal.

More
Select to display the menu items.

Audio System Basic Operation

Playing AM/FM Radio

194

Features

To store a station:
1. Tune to the selected station.

2. Press

to switch to the Audio menu screen.

3. Rotate

select

Save Preset, then press

4. Rotate

to select the preset number you want to store that station, then press

2. Select More.
3. Select Save Preset.
4. Select the preset number you want to store that station.

■

Preset Memory

Playing AM/FM Radio

The ST indicator appears on the display indicating
stereo FM broadcasts.
Stereo reproduction in AM is not available.

Switching the Audio Mode
Press the SOURCE button on the steering wheel.

2 Audio Remote Controls P. 168

You can also switch the mode by pressing

and

selecting Change Source on the Audio menu
screen.

You can store 6 AM stations and 12 FM stations into
the preset memory.

MENU/SEL (Selector) Knob

Audio with Touch Screen

Continued

195

Audio System Basic Operation

Playing AM/FM Radio

Features

Provides text data information related to your selected RDS-capable FM station.

■

To find an RDS station from Station List

1. Press

to switch to the Audio menu screen while listening to an FM station.

2. Rotate

to select Station List, then press

3. Rotate

to select the station, then press

■

Manual update

Updates your available station list at any time.
1. Press

to switch to the Audio menu screen while listening to an FM station.

2. Rotate

to select Station List, then press

3. Rotate

to select Refresh, then press

■

Radio Data System (RDS)

Radio Data System (RDS)

When you select an RDS-capable FM station, the RDS
automatically turns on, and the frequency display
changes to the station name. However, when the
signals of that station become weak, the display
changes from the station name to the frequency.

196

Audio System Basic Operation

Playing AM/FM Radio

Features

■

Radio text

Displays the radio text information of the selected RDS station.
1. Press

to switch to the Audio menu screen.

2. Rotate

select

Radio Text, then press

■

Scan

Samples each of the strongest stations on the selected band for 10 seconds.

1. Press

to switch to the Audio menu screen.

2. Rotate

select

Scan, then press

To turn off scan, press

to select Cancel Scan, or press the BACK button.

1. Select More.
2. Select Scan.
To turn off scan, select Cancel Scan.

MENU/SEL (Selector) Knob

Audio with Touch Screen

197

Audio System Basic Operation

Playing SiriusXM® Radio

Continued

Features

Playing SiriusXM® Radio

Audio/Information Screen

Audio with Touch Screen

Category Up/Down Icons
Select

to display and

select a SiriusXM® Radio category.

BACK Button
Press to go back to the previous
display.

MENU/SEL (Selector) Knob
Press and turn to select an item,
then press to set your selection.

VOL/

(Volume/Power) Knob

Press to turn the audio system on
and off.
Turn to adjust the volume.

Source
Select to change an audio source.

To listen to a stored channel,
select 1-12.

Presets
Select to store a station.

Skip/Seek Icons
Select

the

or next channel.
In channel mode, select and hold
to change the channel rapidly.

More
Select to display the menu items.

* Not available on all models

Audio System Basic Operation

Playing SiriusXM® Radio

198

Features

1. Select the SiriusXM® mode.

2 Audio Remote Controls P. 168
2 Audio with Touch Screen P. 183

2. Press

to switch to the Audio menu screen.

3. Rotate

select

XM Tune Mode, then press

4. Rotate

select

Channel Mode or Category Mode, then press

5. Rotate

select

Channel List, then press

6. Rotate

to select a channel from a list, then press

2. Select More.
3. Select XM Tune Mode.
4. Select Channel Mode or Category Mode.
5. Select a channel using the , ,

icons on the tune mode screen or the

preset numbers (1-12) on the preset mode screen.

■

To Play the SiriusXM® Radio

Playing SiriusXM® Radio

In the channel mode, all available channels are
selectable. In the category mode, you can select a
channel within a category (Jazz, Rock, Classical, etc.).

There may be instances when SiriusXM® Radio does
not broadcast all the data fields (artist name, title).
This does not indicate a problem with your audio
system.

MENU/SEL (Selector) Knob

Audio with Touch Screen

* Not available on all models

199

Audio System Basic Operation

Playing SiriusXM® Radio

Features

To store a station:
1. Tune to the selected station.

2. Press

to switch to the Audio menu screen.

3. Rotate

to select Save Preset, then press

4. Rotate

to select the preset number you want to store that station, then press

2. Select More.
3. Select Save Preset.
4. Select the preset number you want to store that station.

■

Preset Memory

Playing SiriusXM® Radio

You can store 12 SiriusXM® stations into the preset
memory.

MENU/SEL (Selector) Knob

Audio with Touch Screen

* Not available on all models

200

Audio System Basic Operation

Playing a CD

Features

Playing a CD

Your audio system supports audio CDs, CD-Rs and CD-RWs in either MP3, WMA, or
AAC

format. With the CD loaded, select the CD mode.

*1:Only AAC format files recorded with iTunes are playable on this unit.

Audio/Information Screen

Audio with Touch Screen

BACK Button
Press to go back to the previous display.

MENU/SEL (Selector) Knob
Press and turn to select an item,
then press to set your selection.

VOL/

(Volume/Power) Knob

Press to turn the audio system on
and off.
Turn to adjust the volume.

Skip/Seek Icons
Select

to change tracks

(files in MP3, WMA, or AAC).
Select and hold to move rapidly
within a track/file.

More
Select to display the menu items.

Folder Up/Down Icons
Select

to skip to the next folder, and

to skip to the beginning of the

previous folder in MP3, WMA, or AAC.

Source
Select to change an audio source.

CD Slot
Insert a CD about halfway into the
CD slot.

(CD Eject) Button

Press to eject a CD.

Continued

201

Audio System Basic Operation

Playing a CD

Features

1. Press

. Rotate

to select Music

Search, then press

2. Rotate

to select a folder.

3. Press

to change the display to a list of

files in that folder.

4. Rotate

to select a file, then press

■

How to Select a File from the Music Search List
(MP3/WMA/AAC)

Playing a CD

NOTICE

Do not use CDs with adhesive labels. The label can
cause the CD to jam in the unit.

WMA files protected by digital rights management
(DRM) cannot be played.
The audio system displays Unplayable File, then
skips to the next file.

Text data appears on the display under the following
circumstances:

•

When you select a new folder, file, or track.

•

When you change the audio mode to CD.

•

When you insert a CD.

If you eject the CD but do not remove it from the slot,
the system reloads the CD automatically after several
seconds.

Folder Selection

File Selection

Audio System Basic Operation

Playing a CD

202

Features

You can select scan, repeat, and random modes when playing a track or file.

1. Press

to switch to the Audio menu

screen.

2. Rotate

to select Scan or Random/

Repeat, then press

3. Rotate

to select a mode, then press

1. Select More.
2. Select Scan or Random/Repeat.
3. Select a mode.

■

To turn off a play mode

1. Press

to switch to the Audio menu screen.

2. Rotate

to select the mode you want to turn off, then press

1. Select More.
2. Select the mode you want to turn off.

■

How to Select a Play Mode

How to Select a Play Mode

Play Mode Menu Items
Scan
Scan Folders (MP3/WMA/AAC): Provides 10-second
sampling of the first file in each of the main folders.
Scan Tracks: Provides 10-second sampling of all
tracks on the CD (all files in the current folder in MP3,
WMA, or AAC).

Random/Repeat
Repeat Folder (MP3/WMA/AAC): Repeats all files in
the current folder.
Repeat Track: Repeats the current track/file.
Random in Folder (MP3/WMA/AAC): Plays all files
in the current folder in random order.
Random All Tracks: Plays all tracks/files in random
order.

Random/Repeat is selected.

MENU/SEL (Selector) Knob

Random/Repeat is selected.

Audio with Touch Screen

MENU/SEL (Selector) Knob

Audio with Touch Screen

203

Audio System Basic Operation

Playing an iPod

Continued

Features

Playing an iPod

Connect the iPod using your dock connector to the USB adapter cable, then select
the iPod mode.

2 USB Adapter Cable P. 165

Audio/Information Screen

Audio with Touch Screen

BACK Button
Press to go back to the previous
display.

Selector Knob
Press and turn to select an item,
then press to set your selection.

VOL/

(Volume/Power) Knob

Press to turn the audio system
on and off.
Turn to adjust the volume.

Skip/Seek Icons
Select

to change songs.

Select and hold to move rapidly
within a song.

More
Select to display the menu items.

Album Art Icon

Source
Select to change an audio source.

Album Bar
Select to search for an album.

Album Art

USB Indicator
Appears when an iPod is connected.

Audio System Basic Operation

Playing an iPod

204

Features

1. Select the album bar.

The image of the current album is displayed.

2. Select or icon to search for an album.

When the album image you are looking for appears, select it to play.

■

How to Select an Album

How to Select an Album

You cannot select an album while the vehicle is
moving.

Select

to go back to the previous screen.

Select an album
image.

Select the
album bar.

Album Bar

Album Image

Continued

205

Audio System Basic Operation

Playing an iPod

Features

1. Press

. Rotate

to select Music

Search, then press

2. Rotate

to select a menu.

3. Press

to display the items on that menu.

4. Rotate

to select an item, then press

■

How to Select a Song from the Music Search List

How to Select a Song from the Music Search List

Available operating functions vary on models or
versions. Some functions may not be available on the
vehicle’s audio system.

If there is a problem, you may see an error message
on the audio/information screen.

2 iPod/USB Flash Drive P. 271

Folder Selection

File Selection

Audio System Basic Operation

Playing an iPod

206

Features

You can select repeat and shuffle modes when playing a file.

1. Press

to switch to the Audio menu

screen.

2. Rotate

to select Shuffle/Repeat, then

press .

3. Rotate

to select a mode, then press

1. Select More.
2. Select Shuffle/Repeat.
3. Select a mode.

■

To turn off a play mode

1. Press

to switch to the Audio menu screen.

2. Rotate

to select the mode you want to turn off, then press

1. Select More.
2. Select the mode you want to turn off.

■

How to Select a Play Mode

How to Select a Play Mode

Play Mode Menu Items
Repeat Song: Repeats the current track.
Shuffle Albums: Plays all available albums in a
selected list (playlists, artists, albums, songs, genres,
or composers) in random order.
Shuffle All Songs: Plays all available files in a
selected list (playlists, artists, albums, songs, genres,
or composers) in random order.

MENU/SEL (Selector) Knob

Audio with Touch Screen

MENU/SEL (Selector) Knob

Audio with Touch Screen

207

Audio System Basic Operation

Playing Internet Radio

Continued

Features

Playing Internet Radio

Connect a compatible phone through Bluetooth®.

You can also connect the phone using your dock connector to the USB adapter cable.
Select Source to select Pandora

or Aha mode.

Compatible phones only

Playing Internet Radio

Pandora®, the Pandora logo, and the Pandora trade
dress are trademarks or registered trademarks of
Pandora Media, Inc., used with permission. Pandora
is currently available exclusively in the United States.

U.S. models

iPhone

Audio/Information Screen

Album Art

USB Indicator
Appears when a phone is
connected.

Rating Icon

Audio with Touch Screen

BACK Button
Press to go back to the previous
display.

MENU/SEL (Selector) Knob
Press and turn to select an item,
then press to set your selection.

VOL/

(Volume/Power) Knob

Press to turn the audio system on
and off.
Turn to adjust the volume.

Skip Icon
Select to skip a song.

More
Select to display the menu items.

Station Up/Down Icons
Select to change a station.

Source
Select Pandora®

or Aha

Like/Dislike Icons
Select to evaluate a song.

Play/Pause Icon
Select to resume or play a song.

* Not available on all models

Honda Crosstour (2015 year). Instruction - part 13
