The ceiling light has a three-position
switch: ON, Door Activated, and
OFF.
In the Door Activated (center)
position, the light comes on when
you:

Open any door.
Remove the key from the ignition.
If you do not open a door, the light
fades out in about 10 seconds.
Unlock the doors with the key or
remote transmitter.

The cargo area light comes on when
you open the hatch.

The front ceiling light also contains
two spotlights. Push the button next
to the light to turn it on and off.

Interior Lights

Ceiling Light

Cargo Area Light

Inst

nt
s

Cont

FRONT

DOOR ACTIVATED

OFF

Table of Contents

Interior Convenience Items

COAT HOOK

BEVERAGE HOLDER

VANITY MIRROR

DRIVER’S POCKET

ACCESSORY POWER
SOCKET

GLOVE BOX

BEVERAGE HOLDER

CONSOLE COMPARTMENT

Table of Contents

Open the glove box by squeezing the
handle. Close it with a firm push.

To access the console compartment,
slide the lid forward, then slide the
beverage holder assembly forward.

Be careful when you are using the
beverage holders. A spilled liquid
that is very hot can scald you or your
passengers. Spilled liquids can
damage the upholstery, carpeting,
and electrical components in the
interior.

This socket is intended to supply
power for 12 volt DC accessories
that are rated 120 watts or less (10
amps). It will not power an
automotive type cigarette lighter
element.

Glove Box

Console Compartment

Beverage Holders

Accessory Power Socket

Interior Convenience Items

Inst

nt
s

Cont

CONSOLE COMPARTMENT

BEVERAGE HOLDER

An open glove box can cause
serious injury to your passenger
in a crash, even if the
passenger is wearing the seat
belt.

Always keep the glove box
closed while driving.

Table of Contents

Table of Contents

The standard audio system has
many features. This section de-
scribes those features and how to
use them. (If you selected an
optional audio system, refer to the
operating instructions that came
with it.)

The heating and air conditioning
systems in your vehicle provide a
comfortable driving environment in
all weather conditions.

Your vehicle has an anti-theft audio
system that requires a code number
to enable it.

...............

Vents, Heating, and A/C

.......................

Air Flow Controls

............................

Playing the Radio

..............................

Radio Reception

....................................

Playing a CD

.....................................

CD Changer

......................

Protecting Your CDs

...........

CD Player Error Messages

.......

CD Changer Error Messages

...............................

Playing a Tape

100

.................

Radio Theft Protection

103

..........................

Setting the Clock

104

...............................

Cruise Control

105

Features

Fe
a

Table of Contents

Vents, Heating, and A/C

MODE CONTROL DIAL

RECIRCULATION BUTTON

FAN CONTROL DIAL

TEMPERATURE
CONTROL DIAL

REAR WINDOW
DEFOGGER BUTTON

AIR CONDITIONING (A/C) BUTTON

Table of Contents

Turning this dial clockwise increases
the temperature of the airflow.

The outside air intakes for the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.

The system should be left in Fresh
Air mode under almost all conditions.
Keeping the system in Recirculation
mode, particularly with the A/C off,
can cause the windows to fog up.

Switch to Recirculation mode when
driving through dusty or smoky
conditions, then return to Fresh Air
mode.

This button turns the rear window
defogger off and on (see page

Air flows from the center

and corner vents in the dashboard.

Air flows from the floor

vents. When you select

, the

system automatically switches to
Fresh Air mode.

Air flows from the defroster

vents at the base of the windshield.

When you select

the system automatically switches to
Fresh Air mode and turns on the
A/C. (The A/C indicator will not
come on.)

Turn this dial to increase or decrease
the fan speed and airflow.

This button turns the air
conditioning on and off. The
indicator in the button comes on
when the A/C is on.

When the recirculation indicator is
on, air from the vehicle’s interior is
sent throughout the system again.
When the indicator is off, air is
brought in from the outside of the
vehicle (Fresh Air mode).

Airflow is divided between

the vents in the dashboard and the
floor vents.

Airflow is divided between

the floor vents and the defroster
vents at the base of the windshield.

Use the mode control dial to select
the vents the air flows from. Some
air will flow from the dashboard
vents in all modes.

Fan Control Dial

Temperature Control Dial

Air Conditioning (A/C) Button

Rear Window Def ogger Button

Mode Control Dial

Recirculation Button

Air Flow Controls

Fe
a

Table of Contents

The flow-through ventilation system
draws in outside air, circulates it
through the interior, then exhausts it
through vents near the rear side
panels.

Select

and Fresh Air mode.

Set the fan to the desired speed.
Adjust the warmth of the air with
the temperature control dial.

you can

cool it down more rapidly by partially
opening the windows, turning on the
A/C, and setting the fan to
maximum speed in Fresh Air mode.

Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page

). If it moves near the red zone,

turn off the A/C until the gauge
reads normally.

The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes before you
feel warm air coming through the
system.

Turn on the A/C by pressing the
button. The indicator in the button
comes on when a fan speed is
selected.
Make sure the temperature is set
to maximum cool.
Select

If the outside air is humid, select
Recirculation mode. If the outside
air is dry, select Fresh Air mode.
Set the fan to the desired speed.

Set the temperature to the lower
limit.
Make sure the A/C is off.
Select

and Fresh Air mode.

Set the fan to the desired speed.

2.
3.
4.

3.
4.

1.
2.
3.

If the interior is very warm,

Vents, Heating, and A/C

Ventilation

Using the Heater

Using the A/C

Table of Contents

Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.

This setting is suitable for all driving
conditions whenever the outside
temperature is above 32°F (0°C).

To remove fog from the inside of the
windows:

Select

. The system

automatically switches to Fresh
Air mode and turns on the A/C.
The A/C indicator will not come
on in U.S. vehicles.
Select

Set the fan and temperature
controls to maximum level.

To clear the windows faster, you can
close the dashboard corner vents by
rotating the wheel below each vent.
This sends more warm air to the
windshield defroster vents. Once the
windshield is clear, select Fresh Air
mode to avoid fogging the windows.

For your safety, make sure you have
a clear view through all the windows
before driving.

Turn the fan on.
Turn on the air conditioning.
Select

and Fresh Air mode.

Adjust the temperature control
dial or buttons to your preference.

Set the fan to high.
Select

. The system

automatically switches to fresh air
mode and turns on the A/C. The
A/C indicator will not come on in
U.S. vehicles.
Adjust the temperature control
dial so the airflow feels warm.
Select

to help clear the

rear window.
To increase airflow to the
windshield, close the corner vents.

When you switch to another mode
from

, the A/C stays on.

Press the A/C button to turn it off.

1.
2.
3.
4.

2.
3.

1.
2.

Vents, Heating, and A/C

Dehumidif y the Interior

To Def og and Def rost

To Remove Exterior Frost or Ice
From the Windows

Fe
a

Table of Contents

Playing the Radio

SCAN BUTTON

TUNE KNOB

SEEK BAR

SCAN INDICATOR

AM/FM BUTTON

PRESET BUTTONS

STEREO INDICATOR

AUTO SELECT
BUTTON

POWER/VOLUME KNOB

Table of Contents

−

The ignition switch must be in the
ACCESSORY (I) or ON (II) position.
Turn the system on by pushing the
PWR/VOL knob or the AM/FM
button. Adjust the volume by turning
the PWR/VOL knob.

The band and frequency that the
radio was last tuned to is displayed.
To change bands, press the AM/FM
button. On the FM band, ST will be
displayed if the station is broadcast-
ing in stereo. Stereo reproduction on
AM is not available.

You can use these five methods to
find radio stations on a selected
band:

the

preset buttons, and

Use the TUNE knob to

tune the radio to a desired frequency.
Turn the knob right to tune to a
higher frequency, or left to tune to a

lower frequency.

The SEEK function

searches up and down from the
current frequency to find a station
with a strong signal. To activate it,
press the

side of the

bar, then release it.

Each preset button can

store one frequency on AM, and two
frequencies on FM.

Select the desired band, AM or
FM. FM1 and FM2 let you store
two frequencies with each preset
button.
Use the TUNE, SEEK, or SCAN
function to tune the radio to a
desired station.
Pick a preset button, and hold it
until you hear a beep.
Repeat steps 1 through 3 to store a
total of six stations on AM and
twelve stations on FM.

The preset frequencies will be lost if
your vehicle’s battery goes dead, is
disconnected, or the radio fuse is
removed.

If you do nothing, the system will
scan for the next strong station and
play it for 5 seconds. When it plays a
station you want to listen to, press
the SCAN button again.

The SCAN function

samples all stations with strong
signals on the selected band. To
activate it, press the SCAN button,
then release it. You will see SCAN in
the display. The system will scan for
a station with a strong signal. When
it finds one, it will stop and play that
station for about 5 seconds.

Playing the Radio

To Play the Radio

To Select a Station

TUNE, SEEK, SCAN,

AUTO SELECT

TUNE

SEEK

Preset

SCAN

Fe
a

Table of Contents

−

If you are

traveling far from home and can no
longer receive your preset stations,
you can use the Auto Select feature
to find stations in the local area.

Press the A. SEL button. ‘‘A.SEL’’
flashes in the display, and the system
goes into scan mode for several
seconds. It stores the frequencies of
six AM, and twelve FM stations in
the preset buttons.

You will see a ‘‘0’’ displayed after
pressing a preset button if Auto
Select cannot find a strong station
for every preset button.

press the

A. SEL button. This restores the
presets you originally set.

Press the SOUND/TUNE knob
repeatedly to display the Bass (BAS),
Treble (TRE), Fader (FAD), and
Balance (BAL) setting.

If you do not like the stations Auto
Select has stored, you can store
other frequencies on the preset
buttons as previously described.

Adjust the Balance, or side-

to-side strength of the sound.

Adjust the Fader, or the

front-to-back strength of the sound.

Adjust the Treble in the

sound.

Adjust the Bass in the sound.

You can use the instrument panel
brightness control knob to adjust the
illumination of the audio system (see
page

). The audio system

illuminates when the parking lights
are on, even if the radio is turned off.

Each mode is shown in the display as
it changes. Turn the SOUND/TUNE
knob to adjust the setting to your
liking. When the level reaches the
center, you will see ‘‘C’’ in the display.
The system will automatically return
the display to the selected audio
mode about 5 seconds after you stop
adjusting a mode.

To turn off Auto Select,

Playing the Radio

AUTO SELECT

Adjusting the Sound

BAL

FAD

TRE

BAS

Audio System Lighting

Table of Contents

The radio can receive the complete
AM and FM bands.
Those bands cover these frequen-
cies:

How well the radio receives stations
is dependent on many factors, such
as the distance from the station’s
transmitter, nearby large objects,
and atmospheric conditions.

Driving very near the transmitter of
a station that is broadcasting on a
frequency close to the frequency of
the station you are listening to can
also affect your radio’s reception.
You may temporarily hear both
stations, or hear only the station you
are close to.

A radio station’s signal gets weaker
as you get farther away from its
transmitter. If you are listening to an
AM station, you will notice the sound
volume becoming weaker and the
station drifting in and out. If you are
listening to an FM station, you will
see the stereo indicator flickering off
and on as the signal weakens.
Eventually, the stereo indicator will
go off and the sound will fade
completely as you get out of range of
the station’s signal.

AM band:
530 to 1,710 kilohertz

FM band:
87.7 to 107.9 megahertz

Radio stations on the AM band are
assigned frequencies at least ten
kilohertz apart (530, 540, 550).
Stations on the FM band are
assigned frequencies at least 0.2
megahertz apart (87.9, 88.1, 88.3).

Stations must use these exact
frequencies. It is fairly common for
stations to round-off the frequency in
their advertising, so your radio could
display a frequency of 100.9 even
though the announcer may identify
the station as ‘‘FM101.’’

Radio Frequencies

Radio Reception

Fe
a

Table of Contents

Radio signals, especially on the FM
band, are deflected by large objects
such as buildings and hills. Your
radio then receives both the direct
signal from the station’s transmitter,
and the deflected signal. This causes
the sound to distort or flutter. This is
a main cause of poor radio reception
in city driving.

Radio reception can be affected by
atmospheric conditions such as
thunderstorms, high humidity, and
even sunspots. You may be able to
receive a distant radio station one
day and not receive it the next day
because of a change in conditions.

Electrical interference from passing
vehicles and stationary sources can
cause temporary reception problems.

As required by the FCC:
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s
authority to operate the equipment.

Radio Reception

Table of Contents

Playing a CD

Fe
a

SEEK/SKIP BAR

CD BUTTON

REPEAT INDICATOR

RANDOM BUTTON

CD EJECT BUTTON

CD SLOT

POWER/VOLUME KNOB

SCAN/REPEAT BUTTON

RANDOM INDICATOR

Table of Contents

−

＋

−

With the ignition switch in the
ACCESSORY (I) or ON (II) position,
insert a CD into the CD slot. The
drive will pull the CD in the rest of
the way and begin to play it. The
number of the track playing is shown
in the display. The system will
continuously play a CD until you
change modes.

Each time you press and

release

, the player skips

forward to the beginning of the next
track. Press and release

to skip

backward to the beginning of the
previous track.
To move rapidly within a track, press
and hold the

. You will

see CUE or REW in the display.

This feature plays the

tracks in random order. To activate
Random Play, press and release the
RDM button. You will see RDM in
the display. Press it again to return
to normal play.

Press the eject button (

) to

remove the CD. If you eject the CD,
but do not remove it from the slot,
the system will automatically reload
the CD after 15 seconds and put it in
pause mode. To begin playing, press
the CD button.
Press the AM/FM button to switch
to the radio while a CD is playing.
Press the CD button to play the CD.

If you turn the system off while a CD
is playing, either with the PWR/VOL
knob or by turning off the ignition,
the disc will stay in the drive. When
you turn the system back on, the CD
will begin playing where it left off.

A CD changer is available for your
vehicle. It holds up to six CDs. You
operate the CD changer with the
same controls used for the in-dash
CD player.

Load the desired CDs in the
magazine, and load the magazine in
the changer according to the
instructions that came with the unit.

To select the CD changer, press the
CD button. The CD and track
numbers will be displayed. To select
a different CD, use the preset 5
(DISC

) or preset 6 (DISC

)

button. If you select an empty slot in
the magazine, the changer will, after
finding that slot empty, try to load
the CD in the next slot.

To continuously replay

a track, press the RPT button. You
will see RPT in the display. Press it
again to turn it off.

Playing a CD, CD Changer

To Play a CD

SKIP

RANDOM

To Stop Playing a CD

Operating the Optional CD
Changer

REPEAT

Table of Contents

Content .. 4 5 6 7 ..
