256

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

Audio/Information Screen

Displays the audio status and wallpaper. From this display, you can go to various
setup options.

■

Using the

 button

Press the

 (display) button to change the display.

■

Switching the Display

1

Using the

 button

You can edit, add, and delete the contents shown on
the driver information interface.

2 Customizing the Meter P. 260

Driver Information
Interface

 (Display) Button

Continued

257

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

Using the audio/information screen

Select

 to go to the home screen.

Select Phone, Info, Audio, Settings, Navigation

*

, HondaLink, Smartphone

Connection (Apple CarPlay, Android Auto), App List, or Instrument Panel.

■

Phone

Displays the HFL information.

2 Bluetooth® HandsFreeLink®

*

 P. 407

1

Using the audio/information screen

Touchscreen operation

•

Use simple gestures - including touching, swiping
and scrolling - to operate certain audio functions.

•

Some items may be grayed out during driving to
reduce the potential for distraction.

•

You can select them when the vehicle is stopped or
use voice commands.

•

Wearing gloves may limit or prevent touchscreen
response.

You can change the touchscreen sensitivity setting.

2 Customized Features P. 348

Home Screen

Models without navigation system

Models with navigation system

* Not available on all models

258

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

Info

Displays Trip Computer or Clock/Wallpaper. Select

 on the Info Menu screen

to see all available options: Trip Computer, Voice Info, Clock/Wallpaper and
System/Device Information.

Trip Computer:
• Current Drive tab: Displays the current trip information.
• History of Trip A tab: Displays information for the three previous drives. The

information is stored every time you reset Trip A.
To delete the history manually, select Delete history on the History of Trip A
tab. The confirmation message appears on the screen, then select Yes.

Voice Info: Displays a list of all voice commands.

Clock/Wallpaper: Displays the clock and wallpaper.

System/Device Information:
• System Info: Displays the software version of the audio system.
• USB Info: Displays the memory usage of the USB device.

■

Audio

Displays the current audio information.

■

Settings

Enters the customizing menu screen.

2 Customized Features P. 348

259

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

■

Navigation

*

Displays the navigation screen.

2 Refer to the Navigation System Manual

■

HondaLink®

Connects with your smartphone

*1

 to play personalized music, information, and

social media streams.

2 HondaLink® P. 310

■

Smartphone Connection

Connects with your smartphone

*1

 and allows some apps on your smartphone to be

used on the audio system.

2 Apple CarPlay P. 318
2 Android Auto P. 321

■

App List

Adds or removes apps or widgets on the Home screen.

2 Home Screen P. 266

■

Instrument Panel

Selects from three customizable settings for the driver information interface.

*1: Available on specific phones only. Check



automobiles.honda.com/handsfreelink/



for U.S.

and



www.handsfreelink.ca



for Canada for compatible phones and



hondalink.com



for U.S. and



honda.ca/hondalink



for Canada for feature details.

* Not available on all models

uu

Audio System Basic Operation

u

Audio/Information Screen

260

Features

1. Select .
2. Select and hold an icon.

u

The screen switches to the customization
screen.

3. Drag and drop the icon to where you want

it to be.

4. Select OK.

u

The screen will return to the home
screen.

You can edit, add, or delete the meter contents on the driver information interface.

1.
2. Settings
3. System
4. Configuration of Instrument Panel

■

Changing the Home Screen Icon Layout

■

Customizing the Meter

1

Customizing the Meter

You can store up to three customized configurations.
To select or customize a configuration, press Swap
Config..
When you select Swap Config. during
customization, the settings you changed will be
saved.
When you select

 during customization, the

settings you changed will not be saved and you will
be returned to the Configuration of Instrument
Panel screen.

Continued

261

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

Editing order

To change the order of the icons on the driver information interface, first select:

1. Edit Order

2. Select the icon you want to move.

u

You will see arrows on both sides of the
selected icon.

3. Select the left or right arrow repeatedly to

move the icon to your desired position.

4. Select OK.

u

The screen will return to the
Configuration of Instrument Panel
screen.

1

Editing order

You can use an alternative method to change the
order of the icons. First select:
1. Edit Order
2. Select and hold the icon you want to move.
3. Drag and drop the icon to where you want it to

be.

4. Select OK.

u

The screen will return to the Configuration of

Instrument Panel screen.

Edit Order

Select

Arrow icons

OK

uu

Audio System Basic Operation

u

Audio/Information Screen

262

Features

■

Adding contents

You can add icons to the driver information interface. To add icons, first select:

1. Add

2. Select an icon you want to add.

u

You will see a plus mark on the upper
right hand corner of the selected icon.

3. Select OK.

u

The screen will return to the
Configuration of Instrument Panel
screen.

1

Adding contents

Icons that are grayed out cannot be selected.

If an icon has a plus mark in the upper-right corner, it
means that the icon has already been added.

12

ᾉ34

12

ᾉ34

12

ᾉ34

Range

＆

Fuel

 Maintenance
   Minder TM

 Speed unit &
    Disp Off

Turbo Meter

Phone

SMS & Mail

Navigation &
  Compass

Add

Add

Add

Select

OK

Continued

263

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

Deleting contents

To delete contents on the driver information interface, first select:

1. Delete

2. Select an icon you want to delete.

u

The icon with an

 on the upper right

hand corner can be deleted.

3. Select OK.

u

The screen will return to the
Configuration of Instrument Panel
screen.

1

Deleting contents

You can also delete contents by selecting:
1. Delete or Edit Order
2. Select and hold an icon you want to delete.
3. Drag and drop the icon to the trash icon.
4. Select OK.

u

The screen will return to the Configuration of

Instrument Panel screen.

Delete

Select

OK

X

uu

Audio System Basic Operation

u

Audio/Information Screen

264

Features

You can change, store, and delete the wallpaper on the audio/information screen.

■

Import wallpaper

You can import up to five images, one at a time, for wallpaper from a USB flash
drive.

1. Connect the USB flash drive to the USB

port.

2 USB Port(s) P. 231

2. Select Settings.
3. Select Clock.
4. Select Clock/Wallpaper Type, then open

the Wallpaper tab.

5. Select Add New.

u

The picture name is displayed on the list.

6. Select a desired picture.

u

The preview is displayed on the left side
on the screen.

7. Select Start Import to save the data.

u

The display will return to the wallpaper
list.

■

Wallpaper Setup

1

Wallpaper Setup

The wallpaper you set up on Clock Wallpaper/Type
cannot be displayed on the driver information
interface.

•

When importing wallpaper files, the image must be
in the USB flash drive’s root directory.
Images in a folder cannot be imported.

•

The file name must be fewer than 64 characters.

•

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

•

The individual file size limit is 5 MB.

•

The maximum image size is 4,096 × 4,096 pixels. If
the image size is less than 800 × 480 pixels, the
image is displayed in the middle of the screen with
the extra area appearing in black.

•

If the USB flash drive does not have any pictures,
the No files detected message appears.

After changing the screen interface design, you can
change the wallpaper by following procedure.
1. Select .
2. Select and hold empty space on the home screen.

The pop-up menu appears on the screen.

3. Select Change wallpaper.
4. Select Gallery, Live wallpapers, or Wallpapers.

Continued

265

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

Select wallpaper

1. Select Settings.
2. Select Clock.
3. Select Clock/Wallpaper Type, then open the Wallpaper tab.

u

The screen changes to the wallpaper list.

4. Select a desired wallpaper.

u

The preview is displayed on the left side on the screen.

u

The pop-up menu appears on the screen.

5. Select Set.

u

The display will return to the wallpaper list.

■

To view wallpaper once it is set

1. Select .
2. Select Info.
3. Select .
4. Select Clock/Wallpaper.

■

Delete wallpaper

1. Select Settings.
2. Select Clock.
3. Select Clock/Wallpaper Type, then open the Wallpaper tab.

u

The screen changes to the wallpaper list.

4. Select a wallpaper that you want to delete.

u

The preview is displayed on the left side on the screen.

u

The pop-up menu appears on the screen.

5. Select Delete.

u

A confirmation message appears on the screen.

6. Select Yes to delete completely.

u

The display will return to the wallpaper list.

1

Wallpaper Setup

From the pop-up menu, select Preview to see a
preview at full-size screen.

To go back to the previous screen, select OK, or
select .

When the file size is large, it takes a while to be
previewed.

To delete all wallpapers you add, select Delete All,
then Yes.

uu

Audio System Basic Operation

u

Audio/Information Screen

266

Features

■

To change to a next screen

Selecting   or  , or swiping the screen left or right changes to the next screen.

■

Home Screen

1

Home Screen

The home screen has 5 pages (fixed). You cannot add
any more pages.

Select

 to go directly back to the first page of the

home screen from any page.

Swipe

 Icon

 Icon

Current page position

Continued

267

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

To use apps or widgets

1. Select .
2. Select App List or

 icon.

u

The App screen appears.

3. Select the app or widget you want to use.

Preinstall app list:
• Browser:  Displays the web browser utilized

by smartphone and Wi-Fi connection.

• Calculator: Displays Calculator.
• Gallery: Displays images.
• Downloads: Displays the data

downloaded from the web browser and so
on.

• App Installer: Check with a Honda dealer

for apps that are available for installation.

• Search: Displays various retrieval screen.

1

To use apps or widgets

Select and hold a selected app or widget to add that
app’s or widget’s shortcut on the home screen.

Pre-installed apps may not start up normally. If this
occurs, you need to reset the system.

2 Defaulting All the Settings P. 380

If you perform Factory Data Reset, it may reset all
the settings to their factory default.

2 Defaulting All the Settings P. 380

In case those apps still do not startup normally even
after Factory Data Reset, contact your dealer.

There is a possibility that a browser is shut down in
the situation of the use. In that situation, the screen
will return to before the browser startup.

Do not install apps other than those confirmed by a
Honda dealer. Installation of unauthorized apps may
introduce data corruption risks to your vehicle's
information and your privacy.

You can delete user installed apps by the following
procedure.
1. Select .
2. Select Settings.
3. Select System.
4. Select the Others tab.
5. Select Detail Information.
6. Select Apps.
7. Select an app that you want to delete.
8. Select Delete.
Pre-installed apps cannot be deleted.

Models without navigation system

App List Icon

Models with navigation system

 (App list) Icon

268

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

To add app or widget icons on the home screen

App or widget icons can be added on the home screen.

1. Select .
2. Select .
3. Select and hold empty space on the home

screen.

u

The pop-up menu appears on the screen.

4. Select Add App or Add Widget.

u

The App/Widget screen appears.

Select and hold.

269

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

5. Select and hold an app or widget icon you

want to add.

u

The screen switches to the customization
screen.

6. Drag and drop the icon to where you want

it to be.

7. Select OK.

u

The screen will return to the home
screen.

Select and hold.

Drag and drop.

uu

Audio System Basic Operation

u

Audio/Information Screen

270

Features

■

To move icons on the home screen

You can change location on the home screen.

1. Select and hold an icon.

u

The screen switches to the customization
screen.

2. Drag and drop the icon to where you want

it to be.

3. Select OK.

u

The screen will return to the home
screen.

1

To move icons on the home screen

You can also move the Phone, Info, Audio,
Settings, Navigation

*

, HondaLink, Smartphone

Connection, App List, and Instrument Panel icons
in the same manner.

Select and hold.

Drag and drop.

* Not available on all models

Continued

271

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

To remove icons on the home screen

You can delete the icons on the home screen.

1. Select and hold an icon.

u

The screen switches to the customization
screen.

2. Drag and drop the icon you want to remove

to the trash icon.

u

The icon is removed from the home
screen.

3. Select OK.

u

The screen will return to the home
screen.

1

To remove icons on the home screen

You cannot delete the Phone, Info, Audio,
Settings, Navigation

*

, HondaLink, Smartphone

Connection, App List, and Instrument Panel
icons.

Apps or widgets will not be deleted by deleting the
icon on the home screen.

Select and hold.

Drag and drop to
the trash icon.

* Not available on all models
