Honda Civic Hatchback (2018 year). Instruction - part 7

96

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Road Departure
Mitigation (RDM)
Indicator

*

●

Comes on when the RDM system
shuts itself off.

●

Stays on - The temperature inside the
camera is too high.
Use the climate control system to cool
down the camera.
The system activates when the
temperature inside the camera cools
down.

2 Front Sensor Camera

*

 P. 477

●

Stays on - The area around the camera is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off with
a soft cloth.

●

Have your vehicle checked by a dealer if
the indicator and message come back on
after you cleaned the area around the
camera.

2 Front Sensor Camera

*

 P. 477

●

Comes on if there is a problem
with the RDM system.

●

Indicator may comes on
temporarily when the Maximum
Load Limit is exceeded.

●

Make sure the total load is within the
Maximum Load Limit.

2 Maximum Load Limit P. 445

●

Stays on constantly - Have your vehicle
checked by a dealer.

—

* Not available on all models

97

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Adaptive Cruise
Control (ACC)
with Low Speed
Follow (LSF)

*



Indicator
(Amber)

*

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on if there is a problem
with ACC with LSF

*

.

●

Comes on while driving - Have your
vehicle checked by a dealer.

●

Comes on if the ACC with LSF

*

 is

deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

●

Comes on if there is a problem
with ACC with LSF

*

.

●

Indicator may comes on
temporarily when the Maximum
Load Limit is exceeded.

●

ACC with LSF

*

 has been

automatically canceled.

●

Make sure the total load is within the
Maximum Load Limit.

2 Maximum Load Limit P. 445

●

Stays on constantly - Have your vehicle
checked by a dealer.

—

* Not available on all models

98

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Adaptive Cruise
Control (ACC)
with Low Speed
Follow (LSF)

*



Indicator
(Green)

*

●

Comes on when you press the
MAIN button.

2 Adaptive Cruise Control (ACC) with

Low Speed Follow (LSF)

*

 P. 479

2 Adaptive Cruise Control (ACC)

*

 P. 495

—

●

Comes on when ACC with LSF

*

 is

in operation, but the temperature
inside the front sensor camera is
too high. ACC with LSF

*

 cancels

automatically. The beeper sounds
simultaneously.

●

Use the climate control system to cool
down the camera.

●

Goes off - The camera has been cooled
down and the system activates normally.

●

Comes on if anything covers the
radar sensor cover and prevents
the sensor from detecting a
vehicle in front.

●

May come on when driving in bad
weather (rain, snow, fog, etc.)

●

ACC with LSF

*

 has been

automatically canceled.

●

When the radar sensor gets dirty, stop
your vehicle in a safe place, and wipe off
dirt using a soft cloth.

●

Have your vehicle checked by a dealer if
the message does not disappear even after
you clean the sensor cover.

* Not available on all models

99

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Lane Keeping
Assist System
(LKAS) Indicator
(Amber)

*

●

Comes on for a few seconds
when you turn the ignition switch
to ON

(

w

*1

, then goes off.

●

Comes on if there is a problem
with the LKAS.

●

Stays on constantly - Have your vehicle
checked by a dealer.

Lane Keeping
Assist System
(LKAS) Indicator
(Green)

*

●

Comes on when you press the
MAIN button.

2 Lane Keeping Assist System (LKAS)

*



P. 513

—

●

Comes on when the LKAS is in
operation, or the LKAS button is
pressed, but the temperature
inside the front sensor camera is
too high. The LKAS cancels
automatically. The beeper sounds
simultaneously.

●

Use the climate control system to cool
down the camera.

●

Goes off - The camera has been cooled
down and the system activates normally.

2 Front Sensor Camera

*

 P. 477

●

Comes on when the area around
the camera is blocked by dirt,
mud, etc. Stop your vehicle in a
safe place, and wipe it off with a
soft cloth.

●

May come on when driving in bad
weather (rain, snow, fog, etc.)

●

Have your vehicle checked by a dealer if
the indicator and message come back on
after you cleaned the area around the
camera.

* Not available on all models

100

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Collision
Mitigation
Braking
System

TM



(CMBS

TM

)

Indicator

*

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on when you deactivate
the CMBS

TM

. A driver information

interface message appears for five
seconds.

●

Comes on if there is a problem
with the CMBS

TM

.

●

Stays on constantly without the
CMBS

TM

 off - Have your vehicle checked

by a dealer.

2 Collision Mitigation Braking

System

TM

 (CMBS

TM

)

*

 P. 541

●

Comes on if the CMBS

TM

 is

deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

●

Comes on when the CMBS

TM



system shuts itself off.

●

Stays on - The area around the camera is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off with
a soft cloth.

2 Front Sensor Camera

*

 P. 477

●

Have your vehicle checked by a dealer if
the indicator does not go off even after
you cleaned the camera.

2 Collision Mitigation Braking

System

TM

 (CMBS

TM

)

*

 P. 541

* Not available on all models

101

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Collision
Mitigation
Braking
System

TM



(CMBS

TM

)

Indicator

*

●

Comes on when the CMBS

TM



system shuts itself off.

●

Stays on - The temperature inside the
camera is too high. Use the climate control
system to cool down the camera. The
system activates when the temperature
inside the camera cools down.

2 Front Sensor Camera

*

 P. 477

●

Indicator may comes on temporarily when
passing through an enclosed space, such
as tunnel.

●

The area around the radar sensor is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off with
a soft cloth.

●

Have your vehicle checked by a dealer if
the indicator does not go off even after
you cleaned the radar sensor.

2 Collision Mitigation Braking

System

TM

 (CMBS

TM

)

*

 P. 541

●

Comes on if there is a problem
with the CMBS

TM

.

●

Indicator may comes on
temporarily when the Maximum
Load Limit is exceeded.

●

Make sure the total load is within the
Maximum Load Limit.

2 Maximum Load Limit P. 445

●

Stays on constantly - Have your vehicle
checked by a dealer.

—

* Not available on all models

102

uu

Indicators

u

Information Display Warning and Information Messages

*

In

strum

e

nt Pa

nel

Information Display Warning and Information Messages

*

The following messages appear only on the information display.

Message

Condition

Explanation

●

Appears when there is a problem with the sensor on
the battery.

●

Have your vehicle checked by a dealer.

2 Checking the Battery P. 613

●

Appears along with the battery charging system
indicator when the battery is not charging.

●

Turn off the climate control system and rear defogger to
reduce electricity consumption.

2 If the Charging System Indicator Comes On P. 661

* Not available on all models

103

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

Continued

In

strum

e

nt Pa

nel

Driver Information Interface Warning and Information Messages

*

The following messages appear only on the driver information interface. Press the

 (display/information) button to see the message

again with the system message indicator on.

Message

Condition

Explanation

●

Appears if any door or the hatch is not completely
closed.

●

Appears if any door or the hatch is opened while
driving. The beeper sounds.

●

Goes off when all doors and the hatch are closed.

●

Appears when the washer fluid gets low.

●

Refill the washer fluid.

2 Refilling Window Washer Fluid P. 586

●

Appears when the scheduled maintenance is due
soon.

●

Consequently, Maintenance Due Now and
Maintenance Past Due follow.

2 Maintenance Minder Messages on the Driver

Information Interface P. 568

●

Appears when there is a problem with the sensor on
the battery.

●

Have your vehicle checked by a dealer.

2 Checking the Battery P. 613

●

Appears along with the battery charging system
indicator when the battery is not charging.

●

Turn off the climate control system and rear defogger to
reduce electricity consumption.

2 If the Charging System Indicator Comes On P. 661

Canadian models

* Not available on all models

104

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the engine coolant temperature gets
abnormally high.

2 Overheating P. 659

●

Appears while you are customizing the settings and
the shift lever is moved out of

(

P.

●

Appears while you are customizing the settings and
the parking brake is released.

2 Customized Features P. 133

●

Appears if the automatic brake hold is automatically
canceled while it is in operation.

●

Immediately depress the brake pedal.

Continuously
variable transmission
models

Manual transmission
models

Continuously variable transmission models

Manual transmission models

Continuously
variable transmission
models

Manual transmission
models

105

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the automatic brake hold system is
turned off.

2 Automatic Brake Hold P. 536

●

Appears when the automatic brake hold button is
pressed without wearing the driver’s seat belt.

●

Fasten the driver’s seat belt.

2 Automatic Brake Hold P. 536

●

Appears when the automatic brake hold button is
pressed without depressing the brake pedal while
the automatic brake hold is in operation.

●

Press the automatic brake hold button with the brake
pedal depressed.

2 Automatic Brake Hold P. 536

●

Appears when the parking brake is applied
automatically while it is in operation.

2 Automatic Brake Hold P. 536
2 Parking Brake P. 532

Continuously
variable transmission
models

Manual transmission
models

106

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the electric parking brake switch is
pressed without depressing the brake pedal while
the electric parking brake is in operation.

●

Appears while driving - Press the electric parking
brake switch with the brake pedal depressed.

2 Parking Brake P. 532

Message

Condition

Explanation

●

Appears when you open the driver’s door while the
ignition key is in ACCESSORY

(

q.

●

Turn the ignition switch to LOCK

(

0, then remove the

key.

●

Appears when you open the driver’s door while the
ignition key is in LOCK

(

0.

●

Remove the key from the ignition switch.

●

Appears when the ignition key is turned to
ACCESSORY

(

q from ON

(

w. (The driver’s door is

closed.)

—

Continuously
variable transmission
models

Manual transmission
models

Models without smart entry system

107

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears after you set the power mode to
ACCESSORY or ON.

●

Appears after you unlock and open the driver’s
door.

2 Starting the Engine P. 452

●

Appears when the steering wheel is locked.

●

Move the steering wheel left and right while pressing the
ENGINE START/STOP button.

Models with smart entry system

Continuously
variable transmission
models

Manual transmission
models

Canadian models

Canadian models

108

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if you push the ENGINE START/STOP
button to turn the engine off without the shift lever
in

(

P.

●

Move the shift lever to

(

P. The power mode changes to

VEHICLE OFF.

●

Move the shift lever to

(

P, then press the ENGINE

START/STOP button twice.

●

Appears when the power mode is in ACCESSORY.

—

●

Appears after the driver’s door is opened when the
power mode is in ACCESSORY.

●

Press the ENGINE START/STOP button twice with your
foot off the brake pedal (automatic transmission) or the
clutch pedal (manual transmission) to change the power
mode to VEHICLE OFF (LOCK).

●

Appears when you close the door with the power
mode in ON without the smart entry remote inside
the vehicle.

●

Disappears when you bring the smart entry remote back
inside the vehicle and close the door.

2 Smart Entry Remote Reminder P. 179

●

Appears when the smart entry remote battery
becomes weak.

●

Replace the battery as soon as possible.

2 Replacing the Button Battery P. 615

Continuously
variable transmission
models

U.S. models

Canadian models

109

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if the smart entry remote battery is too
weak to start the engine or the key is not within
operating range to start the engine.
A beeper sounds six times.

●

Bring the smart entry remote in front of the ENGINE
START/STOP button to be touched with.

2 If the Smart Entry Remote Battery is Weak P. 653

●

Appears when the starter system has a problem.

●

As a temporary measure, press and hold the ENGINE
START/STOP button for up to 15 seconds while pressing
the brake pedal and clutch pedal (manual transmission
only), manually start the engine.
Have your vehicle checked by a dealer.

●

Appears as soon as a problem is detected in the
smart entry system or push button starting system.

●

Appears constantly - Have your vehicle checked by a
dealer.

U.S.

*

Canada

* Not available on all models

110

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if there is a problem with the headlights.

●

Appears while driving - The headlights may not be on.
When conditions allow you to drive safely, have your
vehicle checked by a dealer as soon as possible.

Message

Condition

Explanation

●

Appears if there is a problem with a system related
to Rev Match System while the system is activated by
customization.

●

Have your vehicle checked by a dealer.

2 Rev Match System P. 467

●

Appears if there is a problem with the adaptive
damper system.

●

Have your vehicle checked by a dealer. With this message
appeared, your vehicle has normal damping ability
without the adaptive damper feature.

●

Appears if the drive mode cannot be changed due to
certain situations, such as a system error or adverse
driving conditions.

2 Drive Mode Switch P. 471

Models with LED headlight

2.0 L engine models

111

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if there is a problem with the auto high-
beam.

●

Manually operate the headlight switch.

●

If you are driving with the high-beam headlights when
this happens, the headlights are changed to low beams.

●

Appears when the Auto high-beam is in operation,
or the headlight switch is turned in AUTO, but there
the temperature inside the camera is too high. The
auto high-beam cancels automatically.

●

Use the climate control system to cool down the camera.

●

Goes off - The camera has been cooled down. Turing
the headlight switch in AUTO can resume the system.

2 Front Sensor Camera

*

 P. 477

●

Appears when the area around the camera is
blocked by dirt, mud, etc. Stop your vehicle in a safe
place, and wipe it off with a soft cloth.

●

May appear when driving in bad weather (rain,
snow, fog, etc.)

●

Have your vehicle checked by a dealer if the message
comes back on after you cleaned the area around the
camera.

Models with auto high-beam

* Not available on all models
