Honda Civic Hatchback (2018 year). Instruction - part 6

80

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Parking Brake
and Brake
System Indicator
(Amber)

●

Comes on if there is a problem
with the radar sensor.

●

Indicator may comes on
temporarily when the Maximum
Load Limit is exceeded.

●

Make sure the total load is within the
Maximum Load Limit.

2 Maximum Load Limit P. 445

●

Stays on constantly - Have your vehicle
checked by a dealer.

—

U.S.

Canada

(Amber)

Models with CMBS

TM

* Not available on all models

81

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Automatic Brake
Hold System
Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on when the automatic
brake hold system is on.

2 Automatic Brake Hold P. 536

Automatic Brake
Hold Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on when the automatic
brake hold is activated.

2 Automatic Brake Hold P. 536

—

Low Oil Pressure
Indicator

●

Comes on when you turn the
ignition switch to ON

(

w

*1

, and

goes off when the engine starts.

●

Comes on when the engine oil
pressure is low.

●

Comes on while driving - Immediately
stop in a safe place.

2 If the Low Oil Pressure Indicator

Comes On P. 661

U.S.

Canada

* Not available on all models

82

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Malfunction
Indicator Lamp

●

Comes on when you turn the
ignition switch to ON

(

w

*1

, and

goes off when the engine starts, or
after several seconds if the engine
did not start. If “readiness codes”
have not been set, it blinks five
times before it goes off.

●

Comes on if there is a problem
with the emissions control system.

●

Blinks when a misfire in the
engine's cylinders is detected.

●

Readiness codes are part of the on board
diagnostics for the emissions control
systems.

2 Testing of Readiness Codes P. 683

●

Comes on while driving - Have your
vehicle checked by a dealer.

●

Blinks while driving - Stop in a safe
place where there are no flammable
objects. Stop the engine for 10 minutes
or more, and wait for it to cool down.
Then, take your vehicle to a dealer.

2 If the Malfunction Indicator Lamp

Comes On or Blinks P. 662

Charging System
Indicator

●

Comes on when you turn the
ignition switch to ON

(

w

*1

, and

goes off when the engine starts.

●

Comes on when the battery is not
charging.

●

Comes on while driving - Turn off the
climate control system and rear defogger
in order to reduce electricity
consumption.

2 If the Charging System Indicator

Comes On P. 661

* Not available on all models

83

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Shift Lever
Position
Indicator

*

●

Indicates the current shift lever
position.

2 Shifting P. 459

—

M (7-speed
manual shift
mode) Indicator/
Shift Indicator

*

●

Comes on when 7-speed manual
shift mode is applied.

2 7-Speed Manual Shift Mode P. 463

—

Transmission
System
Indicator

*

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Blinks if the transmission system
has a problem.

●

Blinks while driving - Avoid sudden
starts and acceleration and have your
vehicle checked by a dealer immediately.

Shift Up
Indicator

*

●

Comes on when shifting up is
recommended.

2 Shift Up/Down Indicators P. 465, 468

—

Shift Down
Indicator

*

●

Comes on when shifting down is
recommended.

2 Shift Up/Down Indicators P. 465, 468

—

* Not available on all models

84

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Gear Position
Indicator

*

●

Indicates 1st to 6th gear position.

●

If you shift gears very slowly, a different
gear position may be displayed for a
moment.

2 Shifting P. 466

●

The display can be turned ON/OFF in
customized features in driver information
interface or audio/information screen.

2 Customized Features P. 133, 348

●

Under the following conditions, gear
positions and frame borders are not
displayed.
- The select lever is in

(

R position.

- The display of gear position indicator is

turned OFF in customized features.

●

Under the following conditions, gear
positions are not displayed.
- The vehicle is stopped (approximately

less than 2 mph or 3 km/h)

- The select lever is in

(

N position.

—

* Not available on all models

85

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Seat Belt
Reminder
Indicator

●

Comes on and the beeper sounds
if you are not wearing a seat belt
when you turn the ignition switch
to ON

(

w

*1

.

●

If the front passenger is not
wearing a seat belt, the indicator
comes on a few seconds later.

●

Blinks while driving if either you
and/or the front passenger has not
fastened a seat belt. The beeper
sounds and the indicator blinks at
regular intervals.

●

The beeper stops and the indicator goes
off when you and the front passenger
fasten their seat belts.

●

Stays on after you and/or the front
passenger has fastened the seat
belt(s) - A detection error may have
occurred in the sensor. Have your vehicle
checked by a dealer.

2 Seat Belt Reminder P. 40

Low Fuel
Indicator

●

Comes on when the fuel reserve is
running low (approximately 1.8
U.S. gal/7.0 Liter left).

●

Blinks if there is a problem with
the fuel gauge.

●

Comes on - Refuel your vehicle as soon
as possible.

●

Blinks - Have your vehicle checked by a
dealer.

* Not available on all models

86

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Anti-lock Brake
System (ABS)
Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

If it comes on at any other time,
there is a problem with the ABS.

●

Stays on constantly - Have your vehicle
checked by a dealer. With this indicator
on, your vehicle still has normal braking
ability but no anti-lock function.

2 Anti-lock Brake System (ABS) P. 539

Supplemental
Restraint System
Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on if a problem with any of
the following is detected:
- Supplemental restraint system
- Side airbag system
- Side curtain airbag system
- Seat belt tensioner

●

Stays on constantly or does not come
on at all - Have your vehicle checked by
a dealer.

* Not available on all models

87

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Vehicle Stability
Assist (VSA®)
System Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Blinks when VSA® is active.

●

Comes on if there is a problem
with the brake assist system, VSA®
system or hill start assist system.

●

Stays on constantly - Have your vehicle
checked by a dealer.

2 Vehicle Stability Assist (VSA®), aka

Electronic Stability Control (ESC),
System P. 520

●

Comes on if the VSA® system is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

Vehicle Stability
Assist (VSA®)
OFF Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on when you partially
disable VSA®.

2 VSA® On and Off P. 521

●

Comes on when you press and
hold the

 (VSA OFF) button while

+R mode is selected.

2 When the drive mode is in +R mode

P. 522

●

Comes on if the VSA® system is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

2.0 L engine models

* Not available on all models

88

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Door and Hatch
Open Indicator

*

●

Comes on for a few seconds if you
turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on if any door or the hatch
is not completely closed.

●

The beeper sounds and the
indicator comes on if any door or
the hatch is opened while driving.

●

Goes off when all doors and the hatch are
closed.

—

Electric Power
Steering (EPS)
System Indicator

●

Comes on when you turn the
ignition switch to ON

(

w

*1

, and

goes off when the engine starts.

●

Comes on if there is a problem
with the EPS system.

●

Stays on constantly or does not come
on at all - Have your vehicle checked by
a dealer.

2 If the Electric Power Steering (EPS)

System Indicator Comes On P. 665

* Not available on all models

89

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Low Tire
Pressure/TPMS
Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

.

●

May come on briefly if the ignition
switch is turned to ON

(

w

*1

 and

the vehicle is not moved within 45
seconds, to indicate the calibration
process is not yet complete.

●

Comes on and stays on when:
- One or more tires’ pressures are

determined to be significantly
low.

- The system has not been

calibrated.

●

Comes on while driving - Stop in a safe
place, check tire pressures, and inflate the
tire(s) if necessary.

●

Stays on after the tires are inflated to
the recommended pressures - The
system needs to be calibrated.

2 TPMS Calibration P. 527

●

Blinks for about one minute, and
then stays on if there is a problem
with the TPMS, or when a spare
tire

*

 is temporarily installed.

●

Blinks and remains on - Have your
vehicle checked by a dealer. If the vehicle
is fitted with a spare, get your regular tire
repaired or replaced and put back on your
vehicle as soon as you can.

●

Comes on if the TPMS is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

U.S.
models

* Not available on all models

90

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

System Message
Indicator

*

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on along with a beep
when a problem is detected. A
system message on the driver
information interface appears at
the same time.

●

While the indicator is on, press the



(display/information) button to see the
message again.

●

Refer to the Indicators information in this
chapter when a system message appears
on the driver information interface. Take
the appropriate action for the message.

●

The driver information interface does not
return to the normal screen unless the
warning is canceled, or the

 button

is pressed.

—

Turn Signal and
Hazard Warning
Indicators

●

Blink when you operate the turn
signal lever.

●

Blink along with all turn signals
when you press the hazard
warning button.

●

Does not blink or blinks rapidly

2 Replacing Light Bulbs P. 591, 595

—

High Beam
Indicator

●

Comes on when the high beam
headlights are on.

—

—

Lights On
Indicator

●

Comes on whenever the light
switch is on, or in AUTO when the
exterior lights are on.

●

If you remove the key from the ignition
switch

*1

 while the exterior lights are on, a

chime sounds when the driver's door is
opened.

—

* Not available on all models

91

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Fog Light
Indicator

*

●

Comes on when the fog lights are
on.

—

—

Auto High-Beam
Indicator

*

●

Comes on when all the operating
conditions of the Auto high-beam
are met.

2 Auto High-Beam

*

 P. 185

—

Drive Mode
Indicator

*

●

Comes on when each drive mode
is selected by drive mode switch.

2 Drive Mode Switch P. 471

* Not available on all models

92

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.
*2:Canadian models only: Apply and hold the brake pedal before turning the ignition on.

Indicator

Name

On/Blinking

Explanation

Message

*2

Immobilizer
System Indicator

●

Blinks if the immobilizer system
cannot recognize the key
information.

●

Blinks - You cannot start the engine. Turn
the ignition switch to LOCK

(

0

*1

, pull the

key out

*2

, and then insert the key and turn

it to ON

(

w

*1

 again.

●

Repeatedly blinks - The system may be
malfunctioning. Have your vehicle
checked by a dealer.

●

Do not attempt to alter this system or add
other devices to it. Electrical problems can
occur.

Indicator

Models without
smart entry system

Models with smart
entry system

93

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with information display
*2:Models with driver information interface

Indicator

Name

On/Blinking

Explanation

Message

*

Security System
Alarm Indicator

●

Blinks when the security system
alarm has been set.

2 Security System Alarm P. 169

—

ECON Mode
Indicator

*

●

Comes on when ECON mode is
on.

2 ECON Button

*

 P. 470

CRUISE MAIN
Indicator

*

●

Comes on when you press the
CRUISE button.

2 Cruise Control

*

 P. 473

—

CRUISE
CONTROL
Indicator

*

●

Comes on if you have set a speed
for cruise control.

2 Cruise Control

*

 P. 473

—

Indicator

*1

*2

*1

*2

* Not available on all models

94

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Maintenance
Minder
Indicator

*

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on when the scheduled
maintenance is due soon.

2 Maintenance Minder

TM

 P. 563

—

Brake
Depressing
Indicator

*

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Blinks when the electric parking
brake switch is pressed without
depressing the brake pedal while
the electric parking brake is in
operation.

●

Blinks while driving - Press the electric
parking brake switch with the brake pedal
depressed.

2 Parking Brake P. 532

—

●

Blinks when the automatic brake
hold button is pressed without
depressing the brake pedal while
the automatic brake hold is in
operation.

●

Blinks if the automatic brake hold
is automatically canceled while it
is in operation. The beeper
sounds.

●

Blinks while driving - Press the
automatic brake hold button with the
brake pedal depressed.

2 Automatic Brake Hold P. 536

●

Immediately depress the brake pedal.

—

Continuously
variable
transmission
models

Manual
transmission
models

Electric Parking Brake System

Automatic Brake Hold System

* Not available on all models

95

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Road Departure
Mitigation (RDM)
Indicator

*

●

Comes on for a few seconds
when you turn the ignition switch
to ON

(

w

*1

, then goes off.

●

Comes on if there is a problem
with the RDM system.

●

Stays on constantly - Have your vehicle
checked by a dealer.

●

Comes on if the RDM is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

●

Comes on when the RDM system
shuts itself off.

●

Indicator may comes on temporarily when
passing through an enclosed space, such
as tunnel.

●

The area around the radar sensor is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off with
a soft cloth.

●

Have your vehicle checked by a dealer if
the indicator does not go off even after
you cleaned the radar sensor.

2 Collision Mitigation Braking

System

TM

 (CMBS

TM

)

*

 P. 541

* Not available on all models
