Honda Civic Coupe (2019 year). Instruction

Climate Control System

Using Automatic Climate Control

208

Co
ntrols

You can set the temperature synchronously for the driver’s side and the passenger’s
side in synchronization mode.
1. Press the SYNC button.

The system switches to synchronization mode.

2. Adjust the temperature using the driver’s side temperature control dial.

Press the SYNC button to return to dual mode.

■

Synchronization Mode

Synchronization Mode

When the system is in dual mode, the driver’s side
temperature and the passenger’s side temperature
can be set separately.

When you press the

button, the system changes

to synchronization mode.

SYNC Button

Driver’s Side
Temperature
Control Dial

Passenger’s
Side
Temperature
Control Dial

* Not available on all models

212

Features

Audio System

About Your Audio System

The audio system features AM/FM radio and SiriusXM® Radio service

. It can also

play USB flash drives, and iPod, iPhone and Bluetooth® devices.

You can operate the audio system from the buttons and switches on the panel, the
remote controls on the steering wheel, or the icons on the touchscreen interface

About Your Audio System

SiriusXM® Radio

is available on a subscription basis

only. For more information on SiriusXM® Radio

contact a dealer.

2 General Information on the Audio System

P. 310

SiriusXM® Radio

is available in the United States and

Canada, except Hawaii, Alaska, and Puerto Rico.

SiriusXM®

is a registered trademark of SiriusXM

Radio, Inc.

iPod, iPhone and iTunes are trademarks of Apple Inc.

State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.

Remote Controls

iPod

USB Flash Drive

* Not available on all models

213

Audio System

USB Port(s)

Continued

Features

USB Port(s)

The USB port (1.0A) is for playing audio
files on a USB flash drive and connecting
a cellular phone and charging device.

The USB port (1.5A) is for charging
devices, playing audio files and
connecting compatible phones with
Apple CarPlay or Android Auto.

To prevent any potential issues, be sure
to use an Apple MFi Certified Lightning
Connector for Apple CarPlay, and for
Android Auto, the USB cables should be
certified by USB-IF to be compliant with
USB 2.0 Standard.

Your vehicle comes supplied with a USB
extension cable that runs from the USB port
up through to the front console.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.
*2: Pre-installed on U.S. models only.

USB Port(s)

•

Do not leave the iPod or USB flash drive in the
vehicle. Direct sunlight and high temperatures may
damage it.

•

We recommend that you use a USB cable if you are
attaching a USB flash drive to the USB port.

•

You may also use your own USB cable.

•

Do not connect the iPod or USB flash drive using a
hub.

•

Do not use a device such as a card reader or hard
disk drive, as the device or your files may be
damaged.

•

We recommend backing up your data before using
the device in your vehicle.

•

Displayed messages may vary depending on the
device model and software version.

If the audio system does not recognize the iPod, try
reconnecting it a few times or reboot the device. To
reboot, follow the manufacturer’s instructions
provided with the iPod or visit www.apple.com/ipod.

The front USB port can supply up to 1.5A of power.
It does not output 1.5A unless requested by the
device.
For amperage details, read the operating manual of
the device that needs to be charged.
Turn the ignition switch to ACCESSORY

(

q or ON

(

first.

Under certain conditions, a device connected to the
port may generate noise in the radio you are listening
to.

USB charge (1.5A)

Models with
color audio
system

Models with
Display Audio

USB Extension Cable

Models with color audio system

Models with Display Audio

U.S. models

214

Audio System

USB Port(s)

Features

■

In the console compartment

The USB port (1.0A) is for playing audio files
on the USB flash drive and connecting a
cellular phone and charging device.

Move the removable beverage holder
tray rearward.

In the console compartment

* Not available on all models

215

Audio System

Audio System Theft Protection

Features

Audio System Theft Protection

The audio system is disabled when it is disconnected from the power source, such as
when the battery is disconnected or goes dead. In certain conditions, the system
may display a code entry screen. If this occurs, reactivate the audio system.

■

Reactivating the audio system

1. Turn the ignition switch to ON

(

2. Turn on the audio system.
3. Press and hold the audio system power button for more than two seconds.

The audio system is reactivated when the audio control unit establishes a
connection with the vehicle control unit. If the control unit fails to recognize
the audio unit, you must go to a dealer and have the audio unit checked.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

216

Audio System

Audio Remote Controls

Features

Audio Remote Controls

Allow you to operate the audio system while driving. The information is shown on
the driver information interface.

Buttons

Press

to cycle through the audio

mode as follows:

FM AM USB iPod Bluetooth® Audio

FM AM SiriusXM®

USB iPod

Bluetooth® Audio Pandora®

Apps

ENTER Button
• When listening to the radio and SiriusXM®

1. Press ENTER to switch the display to a preset list you stored in the preset buttons.
2. Press

to select a preset, then press ENTER.

• When listening to a USB flash drive
1. Press ENTER to display the folder list.
2. Press

to select a folder.

3. Press ENTER to display a list of tracks in that folder.
4. Press

to select a track, then press ENTER.

Audio Remote Controls

Some modes appear only when an appropriate
device or medium is used.

Depending on the Bluetooth® device you connect,
some functions may not be available.

Press the

(Hang-up/back) button to go back

to the previous command or cancel a command.

Press the

button to switch display.

2 Switching the Display P. 114

Button

ENTER Button

Button

(

- Bar

3 4

Models with color audio system

Models with Display Audio

* Not available on all models

217

Audio System

Audio Remote Controls

Continued

Features

• When listening to an iPod
1. Press ENTER to display the iPod music list.
2. Press

to select a category.

3. Press ENTER to display a list of items in the category.
4. Press

to select an item, then press ENTER.

Press ENTER and press

repeatedly until the desired mode you want

to listen to is displayed.

• When listening to Internet Radio

1. Press ENTER to display the station list.
2. Press

to select an item, then press ENTER.

• When listening to Bluetooth® Audio
1. Press ENTER to display the track list.
2. Press

to select a track, then press ENTER.

(

- (Volume) Bar

Press

(

+: To increase the volume.

Press

(

-: To decrease the volume.

* Not available on all models

218

Audio System

Audio Remote Controls

Features

Buttons

• When listening to the radio

Press :

To select the next preset radio station.

Press :

To select the previous preset radio station.

Press and hold

: To select the next strong station.

Press and hold

: To select the previous strong station.

• When listening to an iPod, USB flash drive, or Bluetooth® Audio

Press :

To skip to the next song.

Press :

To go back to the beginning of the current or previous song.

• When listening to a USB flash drive

Press and hold

: To skip to the next folder.

Press and hold

: To go back to the previous folder.

• When listening to Internet radio

Press :

To skip to the next song.

Press and hold

: To select the next station.

Press and hold

: To select the previous station.

* Not available on all models

219

Features

Audio System Basic Operation

To use the audio system, the ignition switch must be in ACCESSORY

(

q or ON

(

Use the selector knob or MENU/CLOCK
button to access some audio functions.

Press

to switch between the normal and

extended display for some functions.

Selector knob: Rotate left or right to scroll
through the available choices. Press

to set

your selection.
MENU/CLOCK button: Press to select any
mode.
The available mode includes the wallpaper,
display, clock, language setup, and play
modes. Play modes can be also selected from
scan, random, repeat, and so on.

(Back) button: Press to go back to the previous display.
(Sound) button: Press to select the sound setting mode.
(Day/Night) button: Press to change the audio/information screen

brightness.
Press

, then adjust the brightness using

Each time you press

, the mode switches between the daytime mode,

nighttime mode and OFF mode.

Models with color audio system

Audio System Basic Operation

These indications are used to show how to operate
the selector knob.

Rotate

to select.

Press

to enter.

Menu Items

2 Adjust Clock P. 134
2 Wallpaper Setup P. 222
2 Display Setup P. 225
2 Scan P. 227, 233
2 Play Mode P. 230, 233
2 RDS Settings P. 227
2 Bluetooth P. 234

Press the buttons on the steering wheel to change
any audio setting.

2 Audio Remote Controls P. 216

(Back)

Button

Selector Knob

MENU/
CLOCK
Button

(Day/Night)

Button

(Sound)

Button

Menu Display

221

Audio System Basic Operation

Audio/Information Screen

Continued

Features

■

Audio

Shows the current audio information.

■

Clock/Wallpaper

Shows a clock screen or an image you import.

■

Change display

1. Press the MENU/CLOCK button.
2. Rotate

to select Settings, then press

3. Rotate

to select Display Change, then press

4. Rotate

to select Wallpaper, then press

If you want to return to the audio display, select Audio.

Audio System Basic Operation

Audio/Information Screen

222

Features

You can change, store, and delete the wallpaper on the audio/information screen.

■

Import wallpaper

You can import up to three images, one at a time, for wallpaper from a USB flash
drive.

1. Connect the USB flash drive to the USB

port.

2 USB Port(s) P. 213

2. Press the MENU/CLOCK button.
3. Rotate

select

Settings, then press

4. Rotate

to select Wallpaper, then press

5. Rotate

select

Import, then press

The picture name is displayed on the list.

6. Rotate

to select a desired picture, then

press .

The selected picture is displayed.

7. Press

to save the picture.

8. Press

to select OK.

9. Rotate

to select a location to save the

picture, then press

The display will return to the wallpaper
setting screen.

■

Wallpaper Setup

Wallpaper Setup

•

When importing wallpaper files, the image must be
in the USB flash drive’s root directory. Images in a
folder cannot be imported.

•

The file name must be fewer than 64 characters.

•

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

•

The individual file size limit is 2 MB.

•

The maximum image size is 1,920 x 936 pixels. If
the image size is less than 480 × 234 pixels, the
image is displayed in the middle of the screen with
the extra area appearing in black.

•

Up to 255 files can be selected.

•

If the USB flash drive does not have any pictures, a
message appears.

223

Audio System Basic Operation

Audio/Information Screen

Features

■

Select wallpaper

1. Press the MENU/CLOCK button.
2. Rotate

to select Settings, then press

3. Rotate

to select Wallpaper, then press

4. Rotate

to select Select, then press

The screen changes to the wallpaper list.

5. Rotate

to select a desired wallpaper, then press

■

To view wallpaper once it is set

1. Press the MENU/CLOCK button.
2. Rotate

to select Settings, then press

3. Rotate

to select Display Change, then press

4. Rotate

to select Wallpaper, then press

The screen changes to the wallpaper list.

5. Rotate

to select a wallpaper that you want to set, then press

■

Delete wallpaper

1. Press the MENU/CLOCK button.
2. Rotate

to select Settings, then press

3. Rotate

to select Wallpaper, then press

4. Rotate

to select Delete, then press

The screen changes to the wallpaper list.

5. Rotate

to select a wallpaper that you want to delete, then press

6. Rotate

to select Yes, then press

The display will return to the wallpaper setting screen.

Wallpaper Setup

To go back to the previous screen, press the

(Back) button.

When the file size is large, it takes a while to be
previewed.

Honda Civic Coupe (2019 year). Instruction - part 14
