Honda Civic Coupe (2019 year). Instruction - part 13

192

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

Interior Convenience Items

Pull the handle to open the glove box.

■

Glove Box

Glove Box

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

193

Interior Lights/Interior Convenience Items

Interior Convenience Items

Continued

Co
ntrols

Your vehicle has a multi-function center
console. It includes a storage compartment,
an armrest, and a sliding tray

Slide the armrest to the rearmost position. Pull
the handle to open the console compartment.

You can put small items in the sliding tray

located in the console compartment lid. Slide
the sliding tray forward or rearward.

You can create more storage space by
removing the removable beverage holder tray
and a divider.

■

Console Compartment

Sliding Tray

Removable
Beverage
Holder Tray

Divider

* Not available on all models

Interior Lights/Interior Convenience Items

Interior Convenience Items

194

Co
ntrols

■

Front seat beverage holders

Are located in the console between the front
seats.

Move the armrest rearward to use the
beverage holders.

To place a short beverage container:
Move the removable beverage holder tray
forward.

To place a tall beverage container: Move
the removable beverage holder tray rearward.

■

Beverage Holders

Beverage Holders

NOTICE

Spilled liquids damage the upholstery, carpeting, and
electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

195

Interior Lights/Interior Convenience Items

Interior Convenience Items

Continued

Co
ntrols

■

Door beverage holders

■

Rear seat beverage holders

Interior Lights/Interior Convenience Items

Interior Convenience Items

196

Co
ntrols

The accessory power socket can be used when the ignition switch is in ACCESSORY

(

q or ON

(

Open the cover to use it.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Accessory Power Socket

Accessory Power Socket

NOTICE

Do not insert an automotive type cigarette lighter
element: This can overheat the power socket.

The accessory power socket is designed to supply
power for 12-volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent battery drain, use the power socket only
when the engine is running.

Continued

197

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

To use the wireless charger, the power mode must be in ACCESSORY or ON.
Charge a compatible device on the area indicated by the

mark as follows:

1. To turn the system on and off, press and

hold the

(power) button.

When the system is activated, the green
indicator light comes on.

2. Place the device you want to charge on the

charging area.

The system will automatically start
charging the device, and the amber
indicator light will come on.

Make sure that the device is compatible
with the system and placed with the
chargeable side in the center of the
charging area.

3. When charging is completed, the green

indicator light will come on.

Depending on the device, the amber
indicator light will stay on.

■

Wireless Charger

Canadian models

Wireless Charger

FCC statement
This product complies with the appropriate
requirements or the required standards of FCC
(Federal Communication Commission), described
below:
This device complies with Part 18 of the FCC rules.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used
per the instructions, may cause harmful interference
to radio communications.
In order to use safely:

•

Remove any metal objects from the charge pad
before charging a device.

•

Do not open the charger case.

•

Do not use the charger if it malfunctions. Contact
your dealer.

If the charger interferes with radio communications,
attempt to correct the interference:

•

Press and hold the switch on the charger for a few
seconds to turn off the charger.

Green Indicator

Amber Indicator

Charging Area

(Power) Button

* Not available on all models

Interior Lights/Interior Convenience Items

Interior Convenience Items

198

Co
ntrols

■

When charging does not start

Perform one of the solutions in the following table.

Indicator

Cause

Solution

Green

Amber

Blinking
simulta-

neously

There is an obstacle(s) between
the charging area and the
device.

Remove the
obstacle(s).

The device is not within the
charging area.

Move the device to the
center of the charging
area where

located.

Amber

Blinking

The wireless charger is faulty.

Contact a dealer for
repairs.

Wireless Charger

This system consumes a lot of power. Do not use the
system for a long time when the engine is not
running. This may weaken the battery, making it
difficult to start the engine.

When using the wireless charger, check the user’s manual
that came with the compatible device you want to charge.

CAUTION

Metal objects between the charge pad
and the device to be charged will get
hot and can burn you.
• Always remove foreign objects from

the charge pad before charging the
device.

• Be sure the surface is clear of dust and

other debris before charging.

• Do not spill liquids (i. e. water, drinks,

etc.) on the charger and the device.

• Do not use oil, grease, alcohol,

benzine or thinner for cleaning the
charge pad.

• Do not cover the system with towels,

clothing, or other objects while
charging etc.

• Avoid spraying aerosols which may

come in contact with the charge pad
surface.

* Not available on all models

Continued

199

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

Wireless Charger

NOTICE

Do not place any magnetic recording media or
precision machines within the charging area while
charging.
The data on your cards such as credit cards can be
lost because of the magnetic effect. Also precision
machines such as watches can go wrong.

“Qi” and

marks are the registered trademarks

owned by Wireless Power Consortium (WPC).

In the following cases, charging may stop or not start:

•

The device is already fully charged.

•

The temperature of the device is extremely high
while charging.

•

You are at a place that emits strong
electromagnetic waves or noises, such as a TV
station, electric power plant, or gas station.

A device may not charge if the size or shape of its
chargeable side is not appropriate for use with the
charging area.

Not all devices are compatible with the system.

During the charging phase, it is normal for the
charging area and device to heat up.

Charging may be briefly interrupted when:

•

Both doors and the trunk are closed
- to avoid interference with the proper functioning
of the smart entry system.

•

The position of the device is altered.

Do not charge more than one device at a time on a
charging area.

* Not available on all models

Interior Lights/Interior Convenience Items

Interior Convenience Items

200

Co
ntrols

There are coat hooks behind the center pillar
on both sides. Pull them down to use them.

■

Coat Hooks

Coat Hooks

The coat hook is not designed for large or heavy
items.

201

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

The ignition switch must be in ON

(

to use

the seat heaters.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Seat Heaters

Seat Heaters

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

202

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the temperature control dial.
3. Press the

(on/off) button to cancel.

Using Automatic Climate Control

If any buttons/icons

are pressed while using the

climate control system in auto, the function of the
button/icon

that was pressed will take priority.

The AUTO indicator will go off, but functions
unrelated to the button/icon

that were pressed will

be controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the AUTO
button is pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh air mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit, Lo or Hi is displayed.

Models with color audio system

Dashboard
vents

Dashboard
and floor
vents

Floor vents

Floor and
defroster
vents

AUTO Button

Temperature
Control Dial

A/C (Air
Conditioning)
Button

(Recirculation) Button

(On/Off) Button

Fan Control
Dial

* Not available on all models

Continued

203

Climate Control System

Using Automatic Climate Control

Co
ntrols

Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the temperature control dial.
3. Press the

(on/off) button to cancel.

Using Automatic Climate Control

Pressing the

button switches the climate control

system between on and off. When turned on, the
system returns to your last selection.

While ECON mode is active, the climate control
system may have reduced cooling performance.

Press the

(CLIMATE) button

to display A/C, MODE, fan control information on
the audio/information screen to operate manually.
Select icon to turn on or off A/C, change the vent
mode, or change the fan speed.

Models with ECON button

Models with Display Audio

Models without SYNC button

AUTO Button

Temperature
Control Dial

A/C (Air Conditioning) Icon

(Recirculation) Button

(On/Off) Button

Fan Control
Dial

(Fresh Air) Button

Fan Control Icon

MODE Control
Icon
(Dashboard vents)

(Floor vents)

MODE Control
Icon

MODE Control Icon

(Floor and
defroster vents)

(Dashboard and
floor vents)

(CLIMATE)

Button

204

Climate Control System

Using Automatic Climate Control

Co
ntrols

Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the driver’s side or passenger’s side

temperature control dial.

3. Press the

(on/off) button to cancel.

Models with Display Audio

Models with SYNC button

AUTO Button

Driver’s Side
Temperature
Control Dial

A/C (Air Conditioning) Icon

(Recirculation) Button

(On/Off) Button

Passenger’s
Side
Temperature
Control Dial

Fan Control Icon

MODE Control
Icon
(Dashboard vents)

(Floor vents)

MODE Control
Icon

MODE Control Icon

(Floor and
defroster vents)

(Dashboard and
floor vents)

(CLIMATE)

Button

SYNC (Synchronization) Button

Fan Control Buttons

205

Climate Control System

Using Automatic Climate Control

Continued

Co
ntrols

■

Switching between the recirculation and fresh air modes

Press the

(recirculation) button and switch the mode depending on

environmental conditions.
Recirculation mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh air mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

Press the

(recirculation) or

(fresh air) button to switch the mode

depending on environmental conditions.

Recirculation mode (indicator on): Recirculates air from the vehicle’s interior

through the system.

Fresh air mode (indicator on): Maintains outside ventilation. Keep the system

in fresh air mode in normal situations.

Models without fresh air button

Models with fresh air button

Climate Control System

Using Automatic Climate Control

206

Co
ntrols

Pressing the

(windshield defroster) button

turns the air conditioning system on and
automatically switches the system to fresh air
mode.

Press the

button again to turn off, the

system returns to the previous settings.

■

Defrosting the Windshield and Windows

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

Models with color audio system

Models with Display Audio

Models without SYNC button

Models with Display Audio

Models with SYNC button

Continued

207

Climate Control System

Using Automatic Climate Control

Co
ntrols

■

To rapidly defrost the windows

1. Press the

button.

2. Press the

button.

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode. If you keep the system in recirculation mode,
the windows may fog up from humidity. This
impedes visibility.

Models with color audio system

Models with Display Audio

Models without SYNC button

Models with Display Audio

Models with SYNC button

Content .. 11 12 13 14 ..
