Honda Civic Coupe (2019 year). Instruction

128

Gauges and Driver Information Interface

Driver Information Interface

strum

nt Pa

nel

*1:Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Meter Setup

Language Selection

Changes the displayed language.

English

/Français/Español

Adjust Outside Temp.
Display

Adjusts the temperature reading by a few degrees.

-5°F ~ ±0°F

~ +5°F

“Trip A” Reset Timing

Changes the setting of how the distance, average
fuel economy, average speed, and elapsed time of
trip A is reset.

When Refueled/IGN OFF/
Manually Reset

“Trip B” Reset Timing

Changes the setting of how the distance, average
fuel economy, average speed, and elapsed time of
trip B is reset.

When Refueled/IGN OFF/
Manually Reset

Adjust Alarm Volume

Changes the volume setting for buzzers, warnings,
turn signals, and other alerting systems.

High/Mid

/Low

Fuel Efficiency Backlight

Turns the ambient meter feature on and off.

/OFF

Speed/Distance Units

Selects the trip computer units.

mph∙miles

/km/h∙km

Tachometer

Selects whether the tachometer comes on the driver
information interface.

/OFF

129

Gauges and Driver Information Interface

Driver Information Interface

Continued

strum

nt Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Lighting
Setup

Interior Light Dimming
Time

Changes the length of time the interior lights stay on
after you close the doors.

60sec/30sec

/15sec

Headlight Auto OFF
Timer

Changes the length of time the exterior lights stay
on after you close the driver’s door.

60sec/30sec/15sec

/0sec

Auto Light Sensitivity

Changes the timing for the headlights to come on.

Max/High/Mid

/Low/Min

Auto Interior
Illumination Sensitivity

Changes the sensitivity of the brightness of the
instrument panel when the headlight switch is in the
AUTO position.

Max/High/Mid

/Low/Min

Auto Headlight ON With
Wiper ON

Changes the settings for the wiper operation when
the headlights automatically come on while the
headlight switch is in the AUTO position.

/OFF

130

Gauges and Driver Information Interface

Driver Information Interface

strum

nt Pa

nel

*1: Default Setting

Setup Group

Customizable Features

Description

Selectable Settings

Door Setup

Auto Door Lock

Changes the setting for when the doors
automatically lock.

With Vehicle Speed

/Shift

From P/OFF

Auto Door Unlock

Changes the setting for when the doors
automatically unlock.

When Driver’s Door Opens

When Shifting Into Park/
When Ignition Switched
OFF/OFF

Key And Remote Unlock
Mode

Sets up either the driver’s door or both doors to
unlock on the first operation of the remote or
ignition key.

Driver Door

/ All Doors

Keyless Lock Answer
Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

/OFF

Security Relock Timer

Changes the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening either door.

90sec/60sec/30sec

Maintenance
Info.

—

Resets or cancels the engine oil life display when you
have performed the maintenance service.

Cancel/All Due Items

Default All

—

Cancels customized changes you have made or
restores them to their default setting.

Cancel/Set

131

Gauges and Driver Information Interface

Driver Information Interface

Continued

strum

nt Pa

nel

■

Example of customization settings

Below are steps that explain how to change the reset timing for trip A from the
default setting (manual) so that it resets automatically when the vehicle is fully
refueled.

1. Press the

button to select Vehicle

Settings, then press the ENTER button.

2. Press the

button until Meter Setup

appears on the display.

3. Press the ENTER button.

Language Selection appears first in the
display.

3 4

132

Gauges and Driver Information Interface

Driver Information Interface

strum

nt Pa

nel

4. Press the

button until “Trip A”

Reset Timing appears on the display, then
press the ENTER button.

The display switches to the
customization setup screen, where you
can select When Refueled, IGN OFF,
Manually Reset, or Exit.

5. Press the

button and select When

Refueled, then press the ENTER button.

The When Refueled Setup screen
appears, then the display returns to the
customization menu screen.

6. Press the

button until Exit appears

on the display, then press the ENTER
button.

7. Repeat Step 6 until you return to the

normal screen.

3 4

134

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time in the clock display with the ignition switch in ON

(

■

Using the MENU/CLOCK button

1. Press and hold the MENU/CLOCK button.

Adjust Clock is selected.

2. Rotate

to change hour, then press

3. Rotate

to change minute, then press

4. To enter the selection, rotate

and select

Set, then press

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Adjusting the Time

Adjusting the Clock

The clock is automatically updated through the audio
system, so the time does not need to be adjusted.

You cannot adjust the time while the vehicle is
moving.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

2 Customized Features P. 328, 335

Models with navigation system

Models with Display Audio

Models without navigation system

Using the MENU/CLOCK button

These indications are used to show how to operate
the LIST/SELECT (List/Selector) knob.
Rotate

to select.

Press

to enter.

Models with color audio system

135

Clock

Adjusting the Clock

Co
ntrols

■

Using the Settings menu on the audio/
information screen

1. Press the

(HOME) button, then select

Settings.

2. Select Clock.
3. Select Clock Adjustment.
4. Select

change

hour.

5. Select

to change minute, then

select OK.

Models with Display Audio

Using the Settings menu on the audio/information screen

You can turn the clock display on and off.

2 Customized Features P. 335

The clock is automatically updated when your
smartphone is connected to the audio system.
You can also adjust the clock by touching the clock
displayed on the upper right corner of the display.
1. Touch the clock on the display for a few seconds.
2. Select Clock Adjustment.
3. Select

to change hour.

4. Select

to change minute, then select OK.

136

Co
ntrols

Locking and Unlocking the Doors

Key Types and Functions

This vehicle comes with the following keys:

Use the key to start and stop the engine, to lock and unlock the doors and to open
the trunk. You can also use the remote transmitter or smart entry system

to lock

and unlock the doors and to open the trunk.

The built-in key can be used to lock/unlock the
doors when the smart entry remote battery
becomes weak and the power door lock/
unlock operation is disabled.

To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
smart entry remote until it clicks.

Key Types and Functions

All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.

2 Immobilizer System P. 153

Follow the advice below to prevent damage to the
keys:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids, dust or sand.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely start the engine using the remote
engine start.

2 Remote Engine Start with Vehicle

Feedback

P. 437

Models with remote engine starter

■

Built-in Key

Ignition key with
remote transmitter

Smart entry remote with
remote engine starter

Smart entry remote

Built-in Key

Release Knob

* Not available on all models

137

Locking and Unlocking the Doors

Key Types and Functions

Co
ntrols

Contains a number that you will need if you
purchase a replacement key.

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

138

Locking and Unlocking the Doors

Low Smart Entry Remote Signal Strength

Co
ntrols

Low Smart Entry Remote Signal Strength

The vehicle transmits radio waves to locate the smart entry remote when locking/
unlocking the doors and fuel fill door, opening the trunk, or starting the engine.

In the following cases, locking/unlocking the doors, opening the trunk, or starting
the engine may be inhibited or operation may be unstable:
• Strong radio waves are being transmitted by nearby equipment.
• You are carrying the smart entry remote together with telecommunications

equipment, laptop computers, cell phones, or wireless devices.

• A metallic object is touching or covering the smart entry remote.

Low Smart Entry Remote Signal Strength

Communication between the smart entry remote and
the vehicle consumes the smart entry remote’s
battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the smart entry
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

* Not available on all models

139

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the smart entry remote, you
can lock/unlock the doors, fuel fill door, and
open the trunk.
You can lock/unlock the doors and fuel fill
door within a radius of about 32 inches (80
cm) of the outside door handle. You can open
the trunk within about 32 inches (80 cm)
radius from the trunk release button.

■

Locking the doors and trunk

Press the door lock button on either door.

Some exterior lights flash; the beeper
sounds; both doors and the trunk lock;
and the security system sets.

■

Using the Smart Entry with Push Button Start System

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated position,
the interior lights come on when you unlock the doors.
No doors opened: The lights fade out after 30 seconds.
Doors relocked: The lights go off immediately.

2 Interior Lights P. 190

Using the Smart Entry with Push Button Start System

If you do not open a door within 30 seconds of
unlocking the vehicle with the smart entry system,
the doors and trunk will automatically relock.

You can lock or unlock doors using the smart entry
system only when the power mode is in VEHICLE OFF.

Door Lock Button

* Not available on all models

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

140

Co
ntrols

■

Unlocking the doors and trunk

Grab the driver’s door handle:

The driver’s door and fuel fill door
unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

Both doors unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Press the trunk release button:

The trunk unlocks and opens.

Some exterior lights flash and the beeper
sounds.

2 Using the Trunk Release Button

P. 151

Using the Smart Entry with Push Button Start System

•

Do not leave the smart entry remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the smart entry remote,
you can lock/unlock the doors while someone else
with the remote is within range.

•

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the smart entry remote is within range.

•

If you grip either door handle wearing gloves, the
door sensor may be slow to respond or may not
respond by unlocking the doors.

•

After locking the door, you have up to 2 seconds
during which you can pull the door handle to
confirm whether the door is locked. If you need to
unlock the door immediately after locking it, wait
at least 2 seconds before gripping the handle,
otherwise the door will not unlock.

•

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may not
be able to lock/unlock the doors with the smart entry
remote if it is above or below the outside handle.

•

The smart entry remote may not operate if it is too
close to the door and door glass.

The light flash, beep, and door unlock mode settings

can be customized.

2 Customized Features P. 335

Trunk Release
Button

* Not available on all models

Continued

141

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the doors and trunk (Walk
away auto lock®)

When you walk away from the vehicle while
carrying the smart entry remote, the doors will
automatically lock.
The auto lock function activates when both
doors are closed, and the smart entry remote
is within about 5 feet (1.5 m) radius of the
outside door handle.
Exit vehicle while carrying smart entry remote
and close door(s).
1. While within about 5 feet (1.5 m) radius of

the vehicle.

The beeper sounds; the auto lock
function will be activated.

2. Carry the smart entry remote beyond about

5 feet (1.5 m) from the vehicle and remain
outside this range for 2 or more seconds.

Some exterior lights flash; the beeper
sounds; both doors will then lock.

Locking the doors and trunk (Walk away auto lock®)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the audio/information screen.
If you set the auto lock function to ON using the
audio/information screen, only the remote
transmitter that was used to unlock the driver’s door
prior to the setting change can activate auto lock.

2 Customized Features P. 335

After the auto lock function has been activated,
when you stay within the locking/unlocking
operation range, the indicator on the smart entry
remote will continue to flash until the doors are
locked.

When you stay beside the vehicle within the
operation range, the doors will automatically lock
approximately 30 seconds after the auto lock
function activating beeper sounds.

When you open a door after the auto lock function
activating beeper sounds, the auto lock function will
be delayed until both doors are closed.

Under the following circumstances, the auto-lock
function will not activate:

•

The smart entry remote is inside the vehicle.

The beeper will not sound.

•

The remote is taken out of its operational range
before all the doors are closed.

The beeper will sound.

The activation range of
the auto lock function is
about 5 feet (1.5 m)

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

142

Co
ntrols

To temporarily deactivate the function:
1. Set the power mode to OFF.
2. Open the driver’s door.
3. Using the master door lock switch, operate

the lock as follows:
Lock

Unlock

Lock

Unlock.

The beeper sounds and the function is
deactivated.

To restore the function:
• Set the power mode to ON.
• Lock the vehicle without using the auto lock

function.

• With the smart entry remote on you, move

out of the auto lock function operation
range.

• Open either door.

Locking the doors and trunk (Walk away auto lock®)

The auto lock function does not operate when any of
the following conditions are met.

•

The smart entry remote is inside the vehicle.

•

A door or the hood is not closed.

•

The power mode is set to any mode other than
OFF.

•

The smart entry remote is not located within a
radius of about 5 feet (1.5 m) from the vehicle
when you get out of the vehicle and close the
doors.

Auto lock function operation stop beeper
After the auto lock function has been activated, the
auto lock operation stop beeper sounds for
approximately two seconds in the following cases.

•

The smart entry remote is put inside the vehicle
through a window.

•

You are located too close to the vehicle.

•

The smart entry remote is put inside the trunk.

If the warning beeper sounds, check that you are
carrying the smart entry remote. Then, open/close a
door and confirm the auto lock activation beeper
sounds once.

In the case that the smart entry remote is out of
operating range when you close a door or the trunk,
a beeper will sound to indicate that the auto lock
function has been canceled.

Continued

143

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the doors

Press the lock button.
Once:

Some exterior lights flash, both doors
and fuel fill door lock, and the security
system sets.

Twice (within five seconds after the first
push):

The beeper sounds and verifies the
security system is set.

■

Using the Remote Transmitter

Using the Remote Transmitter

If you do not open a door within 30 seconds of
unlocking the vehicle with the remote transmitter,
the doors will automatically relock.

You can change the relock timer setting.

2 Customized Features P. 124, 335

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

The remote transmitter will not work when the key is
in the ignition switch.

You can lock or unlock doors using the remote
transmitter only when the power mode is in VEHICLE
OFF.

The remote will not lock the vehicle when a door is
open.

Models without smart entry system

Models with smart entry system

All models

LED

Unlock Button

Lock Button

Honda Civic Coupe (2019 year). Instruction - part 9
