Honda Odyssey 2004. Manual - part 462





*01

S0X4A00J46127000000EAAT10

22-176

Power Seats

Circuit Diagram - 8-Way Adjustable

1

2

1

2

2

1

2

1

B1

A6

A2

B4

B3

A5

A1

A4

A3

B5

(20A)

No.2

No.4
(20A)

YEL/GRN

YEL/GRN

RED/YEL

BLU

GRN

YEL

B6

B2

UNDER HOOD FUSE/RELAY BOX

POWER SEAT ADJUSTMENT SWITCH

RED

BLU

BLK

BLK

YEL/GRN

GRN/YEL

BLU/YEL

RED

G551

G551

UP

DOWN

UP

DOWN

No.55 (40A)

No.41 (120A)

BATTERY

PASSENGER’S
UNDER DASH
FUSE/RELAY BOX

BACK
WARD

FOR
WARD

BACK
WARD

FOR
WARD

FRONT UP DOWN
MOTOR

SLIDE
MOTOR

REAR UP DOWN
MOTOR

RECLINE
MOTOR

03/07/29 10:22:46 61S0X050_220_0178

01

*01

S0X4A00J46100046701FHAT00

22-177

Switch Test/Replacement

C

A

B

D

Terminal

Position

BACK
WARD

FOR
WARD

FOR
WARD
BACK
WARD

UP

DOWN

UP

DOWN

A1 A2 A3 A4 A5 A6 B1 B2 B3 B4 B5 B6

SLIDE
SWITCH

RECLINE
SWITCH

FRONT
UP-
DOWN
SWITCH

REAR
UP-
DOWN
SWITCH

1. Remove the adjustment switch cover (A) from the

driver’s seat by removing the three screws, and
pulling off the adjustment switch knobs (B).

2. Disconnect the 6P connectors (C) from the

adjustment switch (D), then remove the switch
from the cover by removing its two mounting
screws.

3. Reinstall the adjustment switch knobs.

4. Check for continuity between the terminals in each

switch position according to the table.

5. If the continuity is not as specified, replace the

switch.

03/07/29 10:22:46 61S0X050_220_0179

01

*01

*02

*03

*04

S0X4A00J46100046501FEAT00

Recline motor:

Slide motor:

Front up-down motor:

Rear up-down motor:

22-178

Power Seats

Motor Test

B

RECLINE
MOTOR

SLIDE
MOTOR

REAR
UP-DOWN
MOTOR

FRONT
UP-DOWN
MOTOR

A

Forward

Backward

Terminal

Position

B3

B4

Forward

Backward

Terminal

Position

A1

A5

A3

UP

DOWN

A4

Terminal

Position

A2

UP

DOWN

A6

Terminal

Position

1. Remove the driver’s seat (see page 20-81).

2. Remove the adjustment switch cover (A) by

removing the three screws.

3. Disconnect the 6P connectors from the adjustment

switch (B).

4. Test the motor. When the motor stops running,

disconnect battery power immediately.

5. If the motor does not run or fails to run smoothly,

check for an open in the power seat wire harness
between the 6P connector and the 2P connectors. If
the harness is OK, replace the motor.

Wire side of
female terminals

Wire side of
female terminals

03/07/29 10:22:47 61S0X050_220_0180

*01

S0X4A00J34300044051DAAT00

22-179

Power Mirrors

Component Location Index

POWER MIRRORS

POWER MIRROR SWITCH

Function Test, page 22-182
Actuator Test, page 22-184
Replacement, page 20-33
Mirror Actuator Replacement, page 22-185

Test, page 22-183

03/07/29 10:22:49 61S0X050_220_0181
