Ｓ０Ｘ４Ａ００Ｊ５４２８３２５６９１１ＤＢＡＴ１０

Starter Cable

Battery Ground Cable

Engine Ground Cable

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

22-16

Connectors and Harnesses

Connector to Harness Index

T1
T2

1
4

Right side of engine compartment
Left side of engine compartment

Under-hood fuse/relay box
Starter motor

(

)

Battery

Battery positive terminal

T3

3

Left side of engine compartment

Transmission housing

G1

2

Left side of engine compartment

Body ground via battery
ground cable

(

)

Battery

Battery positive terminal

T4

6

Right side of engine compartment

Transmission housing

G2

5

Right side of engine compartment

Body ground via engine
ground cable

03/07/29 10:17:56 61S0X050_220_0018

２０

＋

−

22-17

1

2

(

)

(

)

BATTERY GROUND
CABLE

3

4

5

6

ENGINE GROUND
CABLE

STARTER CABLE

03/07/29 10:17:56 61S0X050_220_0019

Ｓ０Ｘ４ＡＺ４Ｊ５４２８３２２５１０１ＤＢＡＴ１０

Engine Wire Harness (’99-01 models)

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

22-18

Connectors and Harnesses

Connector to Harness Index (cont’d)

Alternator

48

4

Middle of engine compartment

A/T clutch pressure control valve A

30

2

On transmission housing

A/T clutch pressure control valve B

31

2

On transmission housing

CKP sensor

55

2

Right side of engine compartment

Coolant temperature gauge sending
unit

41

1

Middle of engine compartment

1

EGR valve and EGR valve lift sensor

39

6

Left side of engine compartment

Engine coolant temperature (ECT)
sensor

40

2

Middle of engine compartment

Engine oil pressure switch

53

1

Right side of engine compartment

Idle air control (IAC) valve

22

3

Left side of engine compartment

Ignition coil No. 1

5

3

Middle of engine compartment

Ignition coil No. 2

7

3

Middle of engine compartment

Ignition coil No. 3

9

3

Middle of engine compartment

Ignition coil No. 4

47

3

Middle of engine compartment

Ignition coil No. 5

44

3

Middle of engine compartment

Ignition coil No. 6

42

3

Middle of engine compartment

Injector No. 1

4

2

Middle of engine compartment

Injector No. 2

6

2

Middle of engine compartment

Injector No. 3

8

2

Middle of engine compartment

Injector No. 4

46

2

Middle of engine compartment

Injector No. 5

45

2

Middle of engine compartment

Injector No. 6

43

2

Middle of engine compartment

Input shaft (Countershaft) speed
sensor

25

2

On transmission housing

Intake air temperature (IAT) sensor

14

2

Middle of engine compartment

MAP sensor

18

3

Left side of engine compartment

Output shaft (Mainshaft) speed sensor

32

2

On transmission housing

PCM connector B

10

25

Under middle of dash

1

PCM connector C

11

31

Under middle of dash

1

PCM connector D

12

16

Under middle of dash

1

PCM connector A

10

31

Under middle of dash

2

PCM connector B

11

24

Under middle of dash

2

PCM connector C

12

22

Under middle of dash

2

1: ’99-00 models
2: ’01 model

03/07/29 10:17:57 61S0X050_220_0020

０１

22-19

ENGINE WIRE
HARNESS

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

1

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

KNOCK SENSOR
SUBHARNESS

2

21

(cont’d)

03/07/29 10:17:57 61S0X050_220_0021
