Honda Odyssey 2004. Manual - part 290





15

*01

02

S0X4A00F00000059501KBAT00

Special Tools Required

17-48

17-48

Power Steering

Steering Gearbox Installation
(cont’d)

Tie-rod Ball Joint Boot Replacement

A

B

C

E

A

C

B

D

D

A

B

07965-SA50500

25. Install the steering joint cover (A) with the clamps

(B) and clips (C).

26. Fill the system with power steering fluid, and bleed

air from the system (see page 17-14).

27. After installation, perform the following:

• Start the engine, allow it to idle, and turn the

steering wheel from lock-to-lock several times to
warm up the fluid. Check the gearbox for leaks
(see page 17-11).

• Adjust the front toe (see step 1 on page 18-7).
• Check the steering wheel spoke angle. Adjust by

turning the right and left tie-rods equally, if
necessary.

• Do the PCM idle learn procedure (see page 11-

202).

• Do the power window control unit reset

procedure (see page 22-200).

• Set the clock.
• Enter the anti-theft codes for the radio and the

navigation system, the custmer’s radio station
presets.

Front hub dis/assembly tool 07965-SA50500

1. Remove the boot from the tie-rod end, and wipe the

old grease off the ball pin.

2. Pack the lower area of the ball pin (A) with

multipurpose grease.

3. Pack the interior of the new boot (B) and lip (C) with

multipurpose grease.

Note these items when installing new grease:

• Keep grease off the boot installation section (D)

and the tapered section (E) if the ball pin.

• Do not allow dust, dirt, or other foreign materials

to enter the boot.

4. Install the new boot (A) using the special tool. The

boot must not have a gap at the boot installation
sections (B). After installing the boot, check the ball
pin tapered section for grease contamination, and
wipe it if necessary.

03/07/29 09:49:45 61S0X050_170_0048

S0X4A000000000J1801ZCAT00

Suspension

Front and Rear Suspension

Front Suspension

Rear Suspension

................................................................

........................................

.........................................................

...........................

...........................................

......................................................

................................................................

........................................

.........................................................

...........................

...........................................

......................................................

Special Tools

. 18-2

Component Location Index

. 18-3

Wheel Alignment

. 18-5

Wheel Bearing End Play Inspection

. 18-8

Wheel Runout Inspection

. 18-9

Ball Joint Removal

. 18-10

.........................................

......................................

...............................

.....................................

.........................................

......................................

...............................

.....................................

Knuckle/Hub Replacement

. 18-11

Ball Joint Boot Replacement

. 18-16

Lower Arm Removal/Installation

. 18-17

Damper/Spring Replacement

. 18-18

..........................................

...............................

............................

.....................

.............................
.............................

...............................

..........................................

...............................

............................

.....................

.............................
.............................

...............................

Hub/Bearing Replacement

. 18-22

Upper Arm Removal/Installation

. 18-26

Lower Arm A Removal/Installation

. 18-27

Lower Arm B Removal and Installation

. 18-28

Trailing Arm Removal/Installation

. 18-29

Damper Removal and Installation

. 18-30

Spring/Bump Stop Replacement

. 18-32

03/07/29 09:50:54 61S0X050_180_0001

01

01

01

01
01

01

01

01

S0X4A000000000J1801PAAT00

Ref. No.

Tool Number

Description

Qty

18-2

Front and Rear Suspension

Special Tools

07AAF-SDAA100

Ball Joint Thread Protector, 12 mm

1

07GAF-SE00100

Hub Dis/Assembly Tool

1

07MAC-SL00200

Ball Joint Remover, 28 mm

1

07746-0010500

Attachment, 62 x 68 mm

1

07749-0010000

Driver

1

07948-SB00101

Attachment, 96 mm

1

07965-SD90100

Support Base

1

07974-SA50700

Ball Joint Boot Clip Guide

1

03/07/29 09:50:56 61S0X050_180_0002

*01

S0X4A00B20200000000DAAT00

18-3

Component Location Index

FRONT DAMPER

LOWER ARM

HUB

KNUCKLE/

Removal, page 18-19
Disassembly/Inspection, page 18-19
Reassembly, page 18-20
Installation, page 18-20

Removal/Installation, page 18-17

Replacement, page 18-11

03/07/29 09:50:57 61S0X050_180_0003
