Replacing lost Integrated Keyhead Transmitters (IKTs)

If you would like to have your Integrated Keyhead Transmitters
reprogrammed because you lost one, or would like to buy additional
IKTs, you can either reprogram them yourself, or take all IKTs to your
authorized dealer for reprogramming.

How to reprogram your Integrated Keyhead Transmitters (IKTs)

To program a new Integrated Keyhead Transmitter yourself, refer to
Programming spare keys in the SecuriLock™ passive anti-theft
system section of this chapter.

Note: At least two IKTs are required to

perform this procedure yourself.

Illuminated entry

The interior lamps and puddle lamps (if equipped) illuminate when the
Integrated Keyhead Transmitter is used to unlock the door(s).

The illuminated entry system will turn off the interior lights if:
• the ignition is turned to the on position,
• the Integrated Keyhead Transmitter lock control is pressed,
• The vehicle is locked using the keyless entry keypad (if equipped), or
• after 25 seconds of illumination.
The inside lights will not turn off if:
• they have been turned on with the dimmer control, or
• any door is open.

Perimeter lamps illuminated entry

With the Integrated Keyhead Transmitter system, the following items will
illuminate when the

control on the transmitter is pressed:

• Head lamps
• Park lamps
• Tail lamps
The lamps will automatically turn off:
• if the ignition switch is turned to the 3 (on) position,
• The vehicle is locked using the keyless entry keypad (if equipped), or
• after 25 seconds of illumination.
Note: On some vehicles, the perimeter lamps illuminated entry feature
will not activate in daylight conditions.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

113

Deactivating/activating perimeter lamps illuminated entry

You may enable/disable this feature by having your vehicle serviced by
your authorized dealer.

You may also perform the following power door lock sequence to
enable/disable the perimeter lamps feature. Note: Before starting, ensure
the ignition is in the 1 (off) position and all vehicle doors are closed. You
must complete Steps 1–5 within 30 seconds or the procedure will have
to be repeated. If the procedure needs to be repeated, wait a minimum
of 30 seconds before beginning again.

1. Place the key in the ignition and
turn the ignition to the 3 (on)
position.

2. Press the power door unlock
control on the door panel three
times.

3. Turn the ignition from the 3 (on)
position to the 1 (off) position.

4. Press the power door unlock control on the door panel three times.

5. Turn the ignition back to the 3 (on) position. The horn will chirp one
time to confirm programming mode has been entered and is active.

6. Press the power door unlock control twice within five seconds.
Note: The horn will chirp once to indicate the perimeter lighting feature
has been deactivated. The horn will chirp once and honk once (one short
and one long) to indicate the perimeter lighting feature has been
activated.

7. Turn the ignition to the 1 (off) position to exit the procedure.
Note: The horn will chirp once to confirm the procedure is complete.

Illuminated exit
• When all vehicle doors are closed and the key is removed from the

ignition, the interior dome lamps (and the exterior mirror puddle
lamps, if equipped) will illuminate.

The lights will turn off if all the doors remain closed and
• 25 seconds elapse, or
• the key is inserted in the ignition.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

114

Battery saver

The battery saver will shut off the interior lamps 30 minutes after the
ignition has been turned to the 1 (off) position.
• If the dome lamps were turned on using the panel dimmer control, the

battery saver will shut them off 30 minutes after the ignition has been
turned to the 1 (off) position.

• If the courtesy lamps were turned on because one of the vehicle doors

or the trunk was opened, the battery saver will shut off them off
10 minutes after the ignition has been turned to the 1 (off) position.

• The battery saver will shut off the headlamps 10 minutes after the

ignition has been turned to the 1 (off) position.

SECURICODE™ KEYLESS ENTRY SYSTEM (IF EQUIPPED)

You can use the keyless entry
keypad to:
• lock or unlock the doors without

using a key.

• open the trunk.
The keypad can be operated with the factory set 5–digit entry code; this
code is located on the owner’s wallet card in the glove box and is
available from your authorized dealer. You can also create up to three of
your own 5–digit personal entry codes.

When pressing the controls on the keypad, press the middle of the
controls to ensure a good activation.

Programming a personal entry code

To create your own personal entry code:

1. Enter the factory set code.

2. Within five seconds press the 1

• 2 on the keypad.

3. Enter your personal 5-digit code. Each number must be entered
within five seconds of each other.

4. The doors will lock then unlock to confirm that your personal keycode
has been programmed to the module.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

115

Tips:
• Do not set a code that uses five of the same number.
• Do not use five numbers in sequential order.
• The factory set code will work even if you have set your own personal

code.

Erasing personal code

1. Enter the factory set 5–digit code.

2. Within five seconds, press the 1

• 2 on the keypad and release.

3. Press and hold the 1

• 2 for two seconds. This must be done within

five seconds of completing Step 2.

All personal codes are now erased and only the factory set 5–digit code
will work.

Anti-scan feature

If the wrong code has been entered seven times (35 consecutive button
presses), the keypad will go into an anti-scan mode. This mode disables
the keypad for one minute and the keypad lamp will flash.

The anti-scan feature will turn off after:
• one minute of keypad inactivity.
• pressing the

control on the remote entry transmitter portion of

your Integrated Keyhead Transmitter.

• the ignition is turned on.

Unlocking and locking the doors using keyless entry

To unlock the driver’s door, enter the factory set 5-digit code or your
personal code. Each number must be pressed within five seconds of each
other. The interior lamps will illuminate. Note: If the two-stage unlocking
feature is disabled, all doors will unlock; for more information regarding
two-stage unlocking, refer to the Unlocking the doors/Two stage unlock
section earlier in this chapter.

To unlock all doors, enter the factory set code or your personal code,
then press the 3

• 4 control within five seconds.

To open the trunk, enter the factory set code or your personal code,
then press the 5

• 6 control within five seconds.

To lock all doors, press the 7

• 8 and the 9 • 0 at the same time (with

the driver’s door closed). You do not need to enter the keypad code
first.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

116

SECURILOCK™ PASSIVE ANTI-THEFT SYSTEM

SecuriLock™ passive anti-theft system is an engine immobilization
system. This system is designed to help prevent the engine from being
started unless a coded Integrated Keyhead Transmitter (IKT)
programmed to your vehicle is used. The use of the wrong type of
coded key may lead to a “no-start” condition.

Your vehicle comes with two coded Integrated Keyhead Transmitters;
additional coded IKTs may be purchased from your authorized dealer.
Standard SecuriLock™ keys without remote entry transmitter
functionality can also be purchased from your authorized dealer if
desired. The authorized dealer can program your spare IKTs to your
vehicle or you can program the IKTs yourself. Refer to Programming
spare keys for instructions on how to program the coded key.

Note: The SecuriLock™ passive anti-theft system is not compatible with
non-Ford aftermarket remote start systems. Use of these systems may
result in vehicle starting problems and a loss of security protection.

Note: Large metallic objects, electronic devices that are used to
purchase gasoline or similar items, or a second coded key on the same
key chain may cause vehicle starting issues. You need to prevent these
objects from touching the coded IKT while starting the engine. These
objects will not cause damage to the coded IKT, but may cause a
momentary issue if they are too close to the IKT when starting the
engine. If a problem occurs, turn the ignition off, remove all objects on
the key chain away from the coded IKT and restart the engine.

Note: Do not leave a duplicate coded key in the vehicle. Always
take your keys and lock all doors when leaving the vehicle.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

117

Anti-theft indicator

The anti-theft indicator is located in the instrument panel cluster.
• When the ignition is in the off

position, the indicator will flash
once every two seconds to
indicate the SecuriLock™ system
is functioning as a theft
deterrent.

• When the ignition is in the on position, the indicator will glow for

three seconds to indicate normal system functionality.

If a problem occurs with the SecuriLock™ system, the indicator will flash
rapidly or glow steadily when the ignition is in the on position. If this
occurs, turn the ignition off then back to on to make sure there was no
electronic interference with the programmed key. If the vehicle doesn’t
start, try to start it with the 2nd programmed key and if successful
contact your authorized dealership for key replacement. If the indicator
still flashes rapidly or glows steadily, the vehicle will not start, contact
your authorized dealer as soon as possible for service.

Automatic arming

The vehicle is armed immediately after switching the ignition to the off
position.

The theft indicator will flash every
two seconds to act as a theft
deterrent when the vehicle is
armed.

Automatic disarming

The vehicle is disarmed immediately after the ignition is turned to the on
position.

The theft indicator will illuminate for three seconds and then go out. If
the theft indicator stays on for an extended period of time or flashes
rapidly, contact your authorized dealer as soon as possible.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

118

Replacement Integrated Keyhead Transmitters (IKT) and coded
keys

Note: Your vehicle comes equipped with two Integrated Keyhead
Transmitters (IKTs). The IKT functions as both a programmed ignition
key that operates all the locks and starts the vehicle, as well as a remote
keyless entry transmitter. A maximum of eight coded keys can be
programmed to your vehicle; only four of these eight keys can be IKTs
with remote entry functionality.

If your IKTs or standard SecuriLock™ coded keys are lost or stolen and
you don’t have an extra coded key, you will need to have your vehicle
towed to an authorized dealer. The key codes need to be erased from
your vehicle and new coded keys will need to be programmed.

Replacing coded keys can be very costly. Store an extra programmed key
away from the vehicle in a safe place to help prevent any
inconveniences. Please visit an authorized dealer to purchase additional
spare or replacement keys.

Programming spare keys

You can program your own Integrated Keyhead Transmitters or standard
SecuriLock™ coded keys to your vehicle. This procedure will program
both the engine immobilizer keycode and the remote entry transmitter
portion of the IKT to your vehicle. Note: A maximum of eight coded
keys can be programmed to your vehicle; only four of these eight can be
IKTs with remote entry functionality.

Tips:
• Only use Integrated Keyhead Transmitters (IKTs) or standard

SecuriLock™ keys.

• You must have two previously programmed coded keys (keys that

already operate your vehicle’s engine) and the new unprogrammed
key(s) readily accessible.

• If two previously programmed coded keys are not available, you must

take your vehicle to your authorized dealer to have the spare key(s)
programmed.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

119

Please read and understand the
entire procedure before you begin.

1. Insert the first previously
programmed coded key into the
ignition.

2. Turn the ignition from the 1 (off)
position to the 3 (on) position. Keep
the ignition in the 3 (on) position
for at least three seconds, but no more than 10 seconds.

3. Turn the ignition to the 1 (off) position and remove the first coded
key from the ignition.

4. Within 10 seconds of turning the ignition to the 1 (off) position, insert
the second previously coded key into the ignition.

5. Turn the ignition from the 1 (off) position to the 3 (on) position. Keep
the ignition in the 3 (on) position for at least three seconds, but no more
than 10 seconds.

6. Turn the ignition to the 1 (off) position and remove the second
previously programmed coded key from the ignition.

7. Within 20 seconds of turning the ignition to the 1 (off) position and
removing the previously programmed coded key, insert the new
unprogrammed key (new key/valet key) into the ignition.

8. Turn the ignition from the 1 (off) position to the 3 (on) position. Keep
the ignition in the 3 (on) position for at least six seconds.

9. Remove the newly programmed coded key from the ignition.

If the key has been successfully programmed it will start the vehicle’s
engine and will operate the remote entry system (if the new key is an
Integrated Keyhead Transmitter). The theft indicator light will illuminate
for three seconds and then go out to indicate successful programming.

If the key was not successfully programmed, it will not start your
vehicle’s engine and/or will not operate the remote entry features. The
theft indicator light may flash on and off. Wait 20 seconds and you may
repeat Steps 1 through 8. If failure repeats, bring your vehicle to your
authorized dealer to have the new key(s) programmed.

To program additional new unprogrammed key(s), wait 20 seconds and
then repeat this procedure from Step 1.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

120

PERIMETER ALARM SYSTEM

The perimeter anti-theft system will help protect your vehicle from
unauthorized entry.

If there is any potential perimeter anti-theft problem with your vehicle,
ensure ALL Integrated Keyhead Transmitters are brought to the
authorized dealer to aid in troubleshooting.

Arming the system

When armed, this system will respond if unauthorized entry is
attempted. When unauthorized entry occurs, the system will flash the
turn signal lamps and will sound the horn.

The system is ready to arm whenever the key is in the 1 (off) position,
or is removed from the ignition. Either of the following actions will
prearm the alarm system:
• Press the

control on the remote entry transmitter portion of your

Integrated Keyhead Transmitter.

When you press the lock control twice within three seconds on the
remote entry transmitter portion of your IKT, the horn will chirp once to
let you know that all doors, the hood and the trunk are closed. If any of
these are not closed, the horn will chirp twice to warn you that a door,
the hood or the trunk is still open.
• Press the driver or passenger

interior door lock control while
the door is open, then close the
door.

• Press the 7 • 8 and the 9 • 0

controls on the keyless entry
keypad (if equipped) at the same
time to lock the doors (driver’s
door must be closed).

There is a 20 second countdown when any of the above actions occur
before the vehicle becomes armed.

Each door, the hood or the trunk is armed individually, and if any are
open, they must be closed for the system to enter the 20 second
countdown.

The turn signal lamps will flash once when all doors, the hood and the
trunk are closed indicating the vehicle is locked and entering the
20 second countdown.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

121

Disarming the system

You can disarm the system by any of the following actions:
• Unlock the doors by using the remote entry transmitter portion of

your Integrated Keyhead Transmitter.

• Unlocking the doors using the keyless entry keypad (if equipped).
• Turn ignition to the on position with a valid SecuriLock™ key.
• Press the panic control on the remote entry transmitter portion of

your IKT. This will only shut off the horn and turn lamps when the
alarm is sounding. The alarm system will still be armed.

If using a key in the driver’s door to unlock the vehicle, a chime will
sound and the message center will display TO STOP ALARM START
VEHICLE when you open the door and you will have 12 seconds to
disarm the alarm system using any of the actions above, otherwise the
alarm will trigger.

Pressing the power door unlock control within the 20 second prearmed
mode will return the vehicle to a disarmed state.

Triggering the anti-theft system

The armed system will be triggered if:
• Any door, the hood or the trunk is opened without using the door key

or the remote entry transmitter portion of your IKT.

• The ignition is turned to the 3 (on) position with an invalid

SecuriLock™ key.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Locks and Security

122

SEATING

WARNING: Reclining the seatback can cause an occupant to
slide under the seat’s safety belt, resulting in severe personal

injuries in the event of a collision.

WARNING: Do not pile cargo higher than the seatbacks to
reduce the risk of injury in a collision or sudden stop.

WARNING: Before returning the seatback to its original
position, make sure that cargo or any objects are not trapped

behind the seatback. After returning the seatback to its original
position, pull on the seatback to ensure that it has fully latched. An
unlatched seat may become dangerous in the event of a sudden stop or
collision.

Adjustable head restraints

Your vehicle is equipped with front row outboard head restraints that are
vertically adjustable.

WARNING: To minimize the risk of neck injury in the event of a
crash, the driver and passenger occupants should not sit in

and/or operate the vehicle, until the head restraint is placed in its
proper position. The driver should never adjust the head restraint
while the vehicle is in motion.

The adjustable head restraints
consist of :
• a trimmed energy absorbing foam

and structure (1),

• two steel stems (2),
• a guide sleeve adjust/release

button (3),

• and a guide sleeve unlock/remove

button (4).

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Seating and Safety Restraints

123

To adjust the head restraint, do the following:

1. Adjust the seatback to an upright driving/riding position.

2. Raise the head restraint by
pulling up on the head restraint.

3. Lower the head restraint by
pressing and holding the guide
sleeve adjust/release button and
pushing down on the head restraint.

Properly adjust the head restraint so that the top of the head restraint is
even with the top of your head and positioned as close as possible to the
back of your head. For occupants of extremely tall stature, adjust the
head restraint to its full up position.

WARNING: The adjustable head restraint is a safety device.
Whenever possible it should be installed and properly adjusted

when the seat is occupied.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Seating and Safety Restraints

124

To remove the adjustable head restraint, do the following:

1. Pull up the head restraint until it
reaches the highest adjustment
position.

2. Simultaneously press and hold
both the adjust/release button and
the unlock/remove button, then pull
up on the head restraint.

To reinstall the adjustable head restraint, do the following:

1. Insert the two stems into the
guide sleeve collars.

2. Push the head restraint down
until it locks.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Seating and Safety Restraints

125

WARNING: To minimize the risk of neck injury in the event of a
crash, head restraints must be installed properly.

Using the manual recline function

WARNING: Never adjust the driver’s seat or seatback when the
vehicle is moving.

WARNING: Always drive and ride with your seatback upright
and the lap belt snug and low across the hips.

Pull lever up to adjust seatback.

Using the manual lumbar support

The lumbar control is located on the
side of the seat cushion.

Turn to adjust lumbar support.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Seating and Safety Restraints

126

Adjusting the front power seat

WARNING: Never adjust the driver’s seat or seatback when the
vehicle is moving.

WARNING: Do not pile cargo higher than the seatbacks to
reduce the risk of injury in a collision or sudden stop.

WARNING: Always drive and ride with your seatback upright
and the lap belt snug and low across the hips.

WARNING: Reclining the seatback can cause an occupant to
slide under the seat’s safety belt, resulting in severe personal

injuries in the event of a collision.

WARNING: Sitting improperly out of position or with the seat
back reclined too far can take off weight from the seat cushion

and affect the decision of the front passenger sensing system, resulting
in serious injury or death in a crash. Always sit upright against your
seatback, with your feet on the floor.

WARNING: To reduce the risk of possible serious injury: Do not
hang objects off seat back or stow objects in the seatback map

pocket (if equipped) when a child is in the front passenger seat. Do
not place objects underneath the front passenger seat or between the
seat and the center console (if equipped). Check the “passenger airbag
off” or “pass airbag off” indicator lamp for proper airbag status. Refer
to Front passenger sensing system section for additional details.
Failure to follow these instructions may interfere with the front
passenger seat sensing system.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Seating and Safety Restraints

127

The control is located on the outboard side of the seat cushion.

Move the switch in the direction of
the arrows to raise or lower the
front portion of the seat cushion.

Move the switch in the direction of
the arrows to raise or lower the rear
portion of the seat cushion.

Press the switch in the direction of
the arrows to move the seat
forward, backward, up or down.

Power recline (driver’s seat only)

Press the control to recline the
seatback forward or rearward.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Seating and Safety Restraints

128

Mercury Milan Hybrid (2010 year). Manual - part 8
