3. Remove the bulb socket by
rotating it counterclockwise, then
pulling it out of the lamp assembly.

4. Pull the bulb from the socket and
push in the new bulb.

5. Install the bulb socket into the
lamp assembly by rotating it
clockwise.

6. Carefully reposition the trim back
to its original position and secure
the retainers.

Replacing high-mount brake lamp bulb

1. Make sure the ignition control is
in the off position.

2. Open the trunk and reach
underneath package tray to locate
lamp assembly.

3. Remove the bulb socket by
rotating it counterclockwise, then
pulling it out of the lamp assembly.

4. Pull the bulb straight from the
socket and push in the new bulb.

5. Install the bulb socket into the lamp assembly by rotating it clockwise.

Replacing license plate lamp bulbs

1. Make sure the headlamp switch is
in the off position.

2. Remove the screws from the
license plate lamp assembly.

3. Remove bulb socket by turning
counterclockwise.

4. Carefully pull the bulb out from
the socket.

Install new bulb(s) in reverse order.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Lights

Replacing fog lamp bulbs

1. Make sure the fog lamp switch is
in the off position.

2. From underneath the vehicle,
partially remove the tire splash
shield by removing the drive screws.

After removing to allow free access
to the front fog lamp bulb and
electrical wire harness, the splash
shield flap can be repositioned.

3. Rotate the harness/bulb assembly
counterclockwise to remove from
the fog lamp.

4. Carefully disconnect the bulb
from the harness assembly via the
two snap clips.

Install the new bulb in reverse order.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Lights

MULTI-FUNCTION LEVER

Windshield wiper: Rotate the end
of the control away from you to
increase the speed of the wipers;
rotate towards you to decrease the
speed of the wipers.

Speed dependent wipers: When the wiper control is set on the
intermittent settings, the speed of the wipers will automatically adjust
with the vehicle speed. The faster your vehicle is travelling the faster the
wipers will go.

Windshield washer: Push the end
of the stalk:
• briefly: causes a single swipe of

the wipers without washer fluid.

• a quick push and hold: the wipers

will swipe three times with
washer fluid.

• a long push and hold: the wipers

and washer fluid will be activated
for up to ten seconds.

Courtesy wipe feature: One extra wipe will occur a few seconds after
washing the front window to clear any excess washer fluid remaining on
the windshield.

Note: Do not operate the washer when the washer reservoir is empty.
This may cause the washer pump to overheat. Check the washer fluid
level frequently. Do not operate the wipers when the windshield is dry.
This may scratch the glass, damage the wiper blades and cause the wiper
motor to burn out. Before operating the wiper on a dry windshield,
always use the windshield washer. In freezing weather, be sure the wiper
blades are not frozen to the windshield before operating the wipers.

Windshield wiper rainlamp feature (if equipped with Autolamp)

When the windshield wipers are turned on during daylight, and the
headlamp control is in the autolamp position, the exterior lamps will turn
on after a brief delay and will remain on until the wipers are turned off.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

TILT/TELESCOPE STEERING WHEEL

To adjust the steering wheel:

1. Pull the lever down to unlock the
steering column.

2. While the lever is in the down
position, move the steering wheel
up or down and in or out until you
find the desired position.

3. While holding the steering wheel
in place, pull the lever up to its
original position to lock the steering
column.

WARNING: Never adjust the steering wheel when the vehicle is
moving.

ILLUMINATED VISOR MIRROR

Lift the mirror cover to turn on the
visor mirror lamps.

Slide on rod feature

Rotate the visor towards the side
window and extend it rearward for
additional sunlight coverage.

Note: To stow the visor back into
the headliner, visor must be
retracted before moving it back
towards the windshield.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

OVERHEAD CONSOLE

The appearance of your vehicle’s overhead console will vary according to
your option package.

Storage compartment

Press on the rear edge of the
compartment door to open.

The storage compartment may be
used to secure sunglasses or a
similar object.

ELECTRONIC COMPASS

The compass heading is displayed as one of N, NE, E, SE, S, SW, W and
NW in the Center Integrated Display (CID).

The compass reading may be affected when you drive near large
buildings, bridges, power lines and powerful broadcast antenna. Magnetic
or metallic objects placed in, on or near the vehicle may also affect
compass accuracy.

Usually, when something affects the compass readings, the compass will
correct itself after a few days of operating your vehicle in normal
conditions. If the compass still appears to be inaccurate, a manual
calibration may be necessary. Refer to Compass zone adjustment.

Most geographic areas (zones) have a magnetic north compass point that
varies slightly from the northerly direction on maps. This variation is four
degrees between adjacent zones and will become noticeable as the
vehicle crosses multiple zones. A correct zone setting will eliminate this
error. Refer to Compass calibration adjustment.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

Compass zone adjustment

1. Determine which magnetic zone
you are in for your geographic
location by referring to the zone
map.

2. Turn ignition to the on position.

3. Press and hold the 7 and 9 radio
preset buttons together for
approximately five seconds until
ZONE XX appears in the CID.

4. Press and release the 7 and 9
radio preset buttons together,
repeatedly until ZONE XX changes
to the correct zone (1–15) in the
CID.

5. The direction will display after
the buttons are released. The zone
is now updated.

Compass calibration adjustment

Perform compass calibration in an open area free from steel structures
and high voltage lines. For optimum calibration, turn off all electrical
accessories (heater/air conditioning, wipers, etc.) and make sure all
vehicle doors are shut.

1. Start the vehicle.

7 8 9 1011

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

2. To calibrate, press and hold the 7
and 9 radio preset buttons together
for approximately 10 seconds until
CAL appears. Release the buttons.

3. Slowly drive the vehicle in a
circle (less than 3 mph [5 km/h])
until the CAL display changes to the
direction value (N, S, E, W, etc.). It
may take up to five circles to
complete calibration.

4. The compass is now calibrated.

CENTER CONSOLE

Your vehicle may be equipped with a
variety of console features. These
include:

1. Cupholders with ambient lighting.

2. Secondary storage bin (on hinges
inside utility compartment).

3. Utility compartment with power
point, AIJ (Audio Input Jack), USB
port, and coin holder inside.

4. 110-Volt power outlet on the back
of the center console.

WARNING: Use only soft cups in the cup holder. Hard objects
can injure you in a collision.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

INSTRUMENT PANEL STORAGE COMPARTMENT

The storage compartment may be
used to secure sunglasses or similar
sized objects. Press the button to
open the storage compartment.

AUXILIARY POWER POINT (12VDC)
Power outlets are designed for accessory plugs only. Do not insert
any other object in the power outlet as this will damage the
outlet and blow the fuse. Do not hang any type of accessory or
accessory bracket from the plug. Improper use of the power
outlet can cause damage not covered by your warranty.

The auxiliary power points are
located on the instrument panel and
in the center console utility
compartment.

Do not use the power point for
operating the cigarette lighter
element (if equipped).

To prevent the fuse from being
blown, do not use the power
point(s) over the vehicle capacity of
12 VDC/180W. If the power point or cigar lighter socket is not working, a
fuse may have blown. Refer to Fuses and relays in the Roadside
Emergencies chapter for information on checking and replacing fuses.
To have full capacity usage of your power point, the engine is required to
be running to avoid unintentional discharge of the battery. To prevent
the battery from being discharged:
• do not use the power point longer than necessary when the engine is

not running,

• do not leave battery chargers, video game adapters, computers and

other devices plugged in overnight or when the vehicle is parked for
extended periods.

Always keep the power point caps closed when not being used.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

Cigar/Cigarette lighter (if equipped)

Do not plug optional electrical accessories into the cigarette lighter
socket.

Do not hold the lighter in with your hand while it is heating, this will
damage the lighter element and socket. The lighter will be released from
its heating position when it is ready to be used.

Note: Improper use of the lighter can cause damage not covered by your
warranty, and can result in fire or serious injury.

Power point (110 VAC)

The 110 VAC power point outlet,
located on the rear of the floor
console, is used for powering
electrical devices that require up to
150W. Exceeding the 150W limit will
cause the power point to cut off the
power temporarily to provide
overload protection.

Note: The 110 VAC power point is equipped with a safety cap and a
safety twist tab. They both provide protection from inserting any object
into the power point other than the 110 VAC electrical device plug. The
safety cap should always be in a closed position whenever the power
point outlet is not in use.

The power outlet is not designed for the following electric appliances;
they may not work properly:
• Cathode ray tube type televisions.
• Motor loads, such as vacuum cleaners, electric saws and other electric

power tools, compressor-driven refrigerators, etc.

• Measuring devices, which process precise data, such as medical

equipment, measuring equipment, etc.

• Other appliances requiring an extremely stable power supply:

microcomputer-controlled electric blankets, touch sensor lamps, etc.

Do not keep electrical devices plugged in the power point whenever
the device is not in use. It is not recommended to use any
extension cord with the 110 VAC power point, since it will defeat
the safety protection design provided by the cap and twist tab. It

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

will also cause the power point to overload due to powering
multiple devices that can reach beyond the 150W load limit.

The power point can switch to a fault mode when it is overloaded,
overheated, or shorted. For overloading and shorting conditions, unplug
your device and turn the ignition key off then on. For an overheating
condition, let the system cool off, then turn the ignition key off then on.

The 110 VAC power point can provide power whenever the vehicle
ignition is in the run position and the power point green indicator light
located in the top left corner is turned on. Refer to the indicator light
code below for the power point status.

Note: Using the 110 VAC power point for long periods of time without
running the engine will cause your battery to drain.

Indicator light Code

Green light is On — Power point is ready to supply power

Green light is Off — Power point power supply is off. Ignition is not in
RUN position

Green light is blinking — Power point is in fault mode

POWER WINDOWS

WARNING: Do not leave children unattended in the vehicle and
do not let children play with the power windows. They may

seriously injure themselves.

WARNING: When closing the power windows, you should verify
they are free of obstructions and ensure that children and/or

pets are not in the proximity of the window openings.

Press and pull the window switches
to open and close windows.
• Push down (to the first detent)

and hold the switch to open.

• Pull up (to the first detent) and

hold the switch to close.

Rear Window Buffeting: When one or both of the rear windows are
open, the vehicle may demonstrate a wind throb or buffeting noise. This
noise can be alleviated by lowering a front window approximately
2–3 inches (5–8 cm).

AUTO

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

One touch up or down (Driver’s window only)

This feature allows the driver’s window to open or close fully without
holding the control down.

To operate ONE TOUCH DOWN:
• Press the switch completely down

to the second detent and release
quickly. The window will open
fully. Momentarily press the
switch to any position to stop the
window operation.

If the switch is pressed and held to
the normal close or ONE TOUCH UP position during a ONE TOUCH
DOWN event, the window will stop. If, after 1/2 second the switch is still
held, the window will perform a normal close or ONE TOUCH UP.

To operate ONE TOUCH UP:
• Pull the switch completely up to

the second detent and release
quickly. The window will close
fully. Momentarily press the
switch to any position to stop the
window operation.

If the switch is pressed and held to
the normal open or ONE TOUCH DOWN position during a ONE TOUCH
UP event, the window will stop. If, after 1/2 second the switch is still
held, the window will perform a normal open or ONE TOUCH DOWN.

Bounce-Back

When an obstacle has been detected in the window opening as the
window is moving upward, the window will automatically reverse
direction and move down. This is known as “bounce-back”. If the ignition
is turned off (without accessory delay being active) during bounce-back,
the window will move down until the bounce-back position is reached.

Security Override

To override a bounce-back condition, within two seconds after the
window reaches the bounce-back position, pull and hold the switch up
and the window will travel up with no bounce-back or pinch
protection. If the switch is released before the window is fully closed,
the window will stop. For example, this can be used to overcome the
resistance of ice on the window or seals.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

Window lock

The window lock feature allows only
the driver and front passenger to
operate the power windows.

To lock out all the window controls
(except for the driver and front
passenger) press the right side of
the control. Press the left side to
restore the window controls.

Accessory delay
With accessory delay, the window switches, audio system, and moon roof
(if equipped) may be used for up to 10 minutes after the ignition switch
is turned off or until either front door is opened.

INTERIOR MIRROR
The interior rear view mirror has two pivot points on the support arm
which lets you adjust the mirror UP or DOWN and from SIDE to SIDE.

WARNING: Do not adjust the mirror while the vehicle is in
motion.

Automatic dimming interior rear view mirror
Your vehicle is equipped with an interior rear view mirror that has an
auto-dimming function. The electronic day/night mirror will change from
the normal (high reflective) state to the non-glare (darkened) state
when bright lights (glare) reach the mirror. When the mirror detects
bright light from behind the vehicle, it will automatically adjust (darken)
to minimize glare.

The mirror will automatically return
to the normal state whenever the
vehicle is placed in R (Reverse) to
ensure a bright clear view when
backing up.

Do not block the sensors on the front and back of the interior
rear view mirror since this may impair proper mirror
performance.
Do not clean the housing or glass of any mirror with harsh
abrasives, fuel or other petroleum-based cleaning products.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

Note: If equipped with a rear view camera system, a video image will be
displayed in the mirror or the Navigation system display (if equipped)
when the vehicle is put in (R) reverse. Refer to Rear view camera
system in the Driving chapter.

EXTERIOR MIRRORS

Power side view mirrors

WARNING: Do not adjust the mirror while the vehicle is in
motion.

To adjust your mirrors:

1. Rotate the control clockwise to
adjust the right mirror and rotate
the control counterclockwise to
adjust the left mirror.

2. Move the control in the direction
you wish to tilt the mirror.

3. Return to the center position to lock mirrors in place.

Heated mirrors (if equipped)

Both mirrors are heated automatically to remove ice, mist and fog when
the rear window defrost is activated.

Do not remove ice from the mirrors with a scraper or attempt to
readjust the mirror glass if it is frozen in place. These actions
could cause damage to the glass and mirrors.

Blind spot mirrors (if equipped)

Your vehicle may be equipped with blind spot information mirrors. See
Blind spot information system in the Driving section.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

SPEED CONTROL

With speed control set, you can maintain a set speed without keeping
your foot on the accelerator pedal.

WARNING: Do not use the speed control in heavy traffic or on
roads that are winding, slippery or unpaved.

Setting speed control

The controls for using your speed
control are located on the steering
wheel for your convenience.

1. Press the ON control and release
it.

2. Accelerate to the desired speed.

3. Press the SET + control and
release it.

4. Take your foot off the accelerator
pedal.

5. The indicator

light on the

instrument cluster will turn on.

Note:
• Vehicle speed may vary momentarily when driving up and down a

steep hill.

• If the vehicle speed increases above the set speed on a downhill, you

may want to apply the brakes to reduce the speed.

• If the vehicle speed decreases more than 10 mph (16 km/h) below

your set speed on an uphill, your speed control will disengage.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

Disengaging speed control

To disengage the speed control:
• Tap the brake pedal or clutch pedal (if equipped)
Disengaging the speed control will not erase previous set speed.

Resuming a set speed

Press the RSM (resume) control and
release it. This will automatically
return the vehicle to the previously
set speed.

Increasing speed while using speed control

There are two ways to set a higher
speed:
• Press and hold the SET + control

until you get to the desired
speed, then release the control.
You can also use the SET +
control to operate the Tap-Up
function. Press and release this
control to increase the vehicle set
speed in small amounts by 1 mph
(1.6 km/h).

• Use the accelerator pedal to get to the desired speed. When the

vehicle reaches that speed press and release the SET + control.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

Reducing speed while using speed control

There are two ways to reduce a set
speed:
• Press and hold the SET - control

until you get to the desired
speed, then release the control.
You can also use the SET -
control to operate the Tap-Down
function. Press and release this
control to decrease the vehicle
set speed in small amounts by
1 mph (1.6 km/h).

• Depress the brake pedal until the desired vehicle speed is reached and

press the SET + control.

Turning off speed control

There are two ways to turn off the speed control:
• Press the OFF control.
• Turn off the ignition.
Note: When you turn off the speed
control or the ignition, your speed
control set speed memory is erased.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Driver Controls

Mercury Milan Hybrid (2010 year). Manual - part 6
