Mercury Montego (2007 year). Manual - part 3

• Press the PREV control to move

the cursor one position downward

• Press the REV control to move

the cursor left one position

• Press the FWD control to move

the cursor right one position

Next/Previous control

The NEXT (up) and PREV (down)
controls allows you to access the
next or previous track on a CD or
chapter on a DVD. When pressed,
the playing audio will mute
momentarily while the next chapter
is accessed.
Press and hold to advance or reverse multiple tracks or chapters.

REV/FWD control

Press the REV/FWD control during
playback mode to reverse or
advance at a normal speed. Press
the REV/FWD control again to
cancel the reverse/advance action
and return to normal playback mode

Enter control

The ENTER control allows you to
select highlighted items when in
MENU mode.

NEXT

PREV

REV

FWD

NEXT

PREV

REV

FWD

NEXT

PREV

REV

FWD

NEXT

PREV

REV

FWD

NEXT

PREV

REV

FWD

ENTER

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

CD play mode

Press NEXT during CD play to
advance to the next track. If you
press NEXT while the last track is
playing, the system will wrap around
to the first track and begin play.

Slow play mode

To enter slow play mode, press the
PLAY/PAUSE control. This will
pause the disc playing. Once the
system is in pause mode, press the FWD or REV control for slow motion
playback. Three different speeds in forward and one speed in reverse are
available depending on how long the control is held. Slow reverse only
has one speed. Press the control once for slow motion playback. Press
the control again to disengage slow motion playback. Press the
PLAY/PAUSE control to return to normal playback mode.

User menu mode

To adjust the display setting, press
DISP once and the player menu will
appear. Press DISP again to adjust
the display setting. Use the arrow controls and the ENTER controls to
select the various screen settings. (Available screen selections are 16x9,
4x3 and Zoom).

The DVD player will read the disc type and configure the display
accordingly. Some movies have a wide screen movie format to fit a
normal 4x3 screen. In this case, the movie will have black bars on the
top and bottom. When shown on the screen, it may appear as a small
screen within the wide screen. It may be desirable to view this type of
movie in zoom mode. To enter zoom mode, press DISP once for the
player menu and again to adjust the display setting. Select zoom from
the screen settings by using the arrow and ENTER controls.

NEXT

PREV

REV

FWD

DISP

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

Remote control

1. REV (REVERSE) control

Press to reverse the direction of the DVD movie.

2. FWD (FORWARD) control

Press to advance the direction of the DVD movie.

3. PLAY/STOP control

When playing, press PLAY/STOP to stop the disc. When stopped, press
PLAY/STOP to play the disc.

4. SEEK control

Press to reverse (

) or advance (

) the chapter of the DVD or the

track of the CD.

5. DISP (DISPLAY) control

Press to enable the on screen display of the player’s menu and display
settings. Once the display is on, use SEEK to highlight the desired
screen setting.

6. ENTER /MEMORY control

In DVD playback mode, press the control to select a highlighted item
from the menu.

In stop mode, press the control to select the next audio memory preset.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

7. MENU/MODE control

In DVD playback mode, press to access the disc menu.

In stop mode, press to change media types (e.g. AM, FM, CD . . . )

8. VOL (VOLUME) control

Press (+) to increase or (-) to decrease the volume level.

Dual play mode

Press the radio preset controls 2
and 4 at the same time to enable or
disable dual play.

During dual play, the rear vehicle speakers will be deactivated and the
wireless headphones will become active. Please note that the infrared
headphones are active only when the Family Entertainment System is
playing a movie.

During dual play mode, two different medias can be played in the
vehicle:

1. The driver can choose, and control, a source on the main radio face
(radio, CD or DVD) and listen to it using the front speakers.

2. Passengers in the rear can listen to the DVD player or AUX input via
the wireless headphones.

Single play mode

When the ignition is turned on, the radio will be in Single Play Mode.

Single play mode allows one media selection (FM/AM, CD, DVD or AUX)
to be heard on all the vehicle speakers.

If radio is in Dual Play Mode, with a DVD playing in the rear, and
another media (FM/AM, CD) playing on front speakers, changing to
single play will turn the DVD player off.

When radio is powered off and back on, it will be in Single Play mode,
even if upon power off the radio was in Dual play mode.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

Battery replacement

Batteries are provided with the remote control unit. Since all batteries
have a limited shelf life, replace them when the remote control fails to
control the DVD player. There is a LED indicator light on the remote
control that will illuminate when any control is pressed.

Slide the battery cover off as shown on the remote control to access the
batteries.

The remote control unit uses two AAA batteries.

Parental control

Simultaneously press the preset
controls 3 and 5 to enable or disable
the rear seat controls, the controls
on your Family Entertainment DVD system including the remote control,
and the DVD screen (if equipped).

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

Wireless headphone operation

To operate the headphones:
• Press the ON/OFF button on the

earpiece to turn on the
headphones. A red LED
(indicator light) will illuminate
indicating the headphones are
powered ON. Press ON/OFF again
to turn the headphones off.

• Adjust the headphones to

comfortably fit your head using
the headband adjustment.

• Adjust the volume control to the

desired listening level.

Note: The volume level of the wireless headphones can only be
controlled by the thumbwheel. Neither the remote control nor the rear
seat controls will affect the volume output of the wireless headphones.

When not using the headphones, turn them off to preserve battery life.
The headphones will automatically turn off after five minutes if they have
not received an infrared audio signal from the Family Entertainment
System (FES).

Note: Ensure that the line of sight between the headphone and infrared
transmitter (mounted on the DVD housing) is not obstructed for optimal
performance.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

Liquid Crystal Display (LCD) flip-down screen

The LCD screen rotates down and can be adjusted to your desired
viewing angle. When not in use, rotate the screen up into the storage
housing.

Note: Ensure that the screen is securely latched into the housing when
stored.

1. 7.0” (diagonal) active matrix liquid crystal display (LCD).

2. Display housing.

3. Dimmer switch. Press +/- to increase/decrease the brightness of the
display.

Playback and format
• The DVD player of your Family Entertainment DVD System can only

be used in the “playback” mode. (The DVD player does not offer a
record feature.)

• The system plays standard CDs, DVDs and also plays most CD R/W,

DVD R/W, VCD and MP3 media.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

Saving MP3 files
• Your Family Entertainment System supports discs containing up to

255 files. Discs containing more than 255 files will not play.

• Always save MP3 files with the .mp3 extension. The player recognizes

an MP3 file by the .mp3 extension, so MP3 files saved with different
extensions will not be played. Never save a non-MP3 file with the
.mp3 extension as the file will not play properly.

• The player supports multi session discs. However, be sure to import

the previous session of the disc before you add new files. If you do not
import the previous session, only the last session will be played.

• When burning a disc, ensure that you close/finalize the disc

before playback, or the disc may not play properly or an error
message may appear.

• Some CD-RW discs may operate inconsistently and may cause an error

message to appear. We recommend burning MP3 files onto CD-R discs.

Family Entertainment DVD System protection circuits

High temperature sensor circuit
• Excessively high temperatures may cause damage to the DVD player.
• When the temperature of the DVD player becomes too hot, the high

temperature sensor circuit stops machine operation. DVD/CD HOT will
be displayed on the radio display.

• The DVD player will remain disabled until it cools to a normal

operating temperature. The length of time for the system to cool will
vary depending on the climate and operating conditions.

Operating
• Only use the system when the vehicle is started for optimal

performance and to maintain battery life.

• If the Family Entertainment System (FES) is playing and the ignition

is turned OFF, the system will turn off, and suspend playback. When
the ignition is turned on again, playback will begin from the last
selected media source when the play control is pressed.

• To disable the DVD player rear controls, simultaneously press the 3

and 5 memory presets on the radio face. To enable the DVD player
rear controls again, press the 3 and 5 presets simultaneously.

• The DVD player is only capable of reading the bottom side of a disc.

When inserting a single sided disc, the label should be up. For a
multi-sided disc, the desired play side should be down when the disc
is inserted into the player.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

• DVDs are formatted by regions. This DVD system can only play region

1 DVDs (DVDs manufactured for U.S. and Canada).

This unit is designed to play commercially pressed 4.75 (12 cm)
audio compact discs and DVDs only. Due to technical
incompatibility, certain recordable and re-recordable compact
discs may not function correctly when used in Ford DVD/CD
players. Irregular shaped discs, discs with a scratch protection
film attached, and discs with homemade paper (adhesive) labels
should not be inserted into the player. The label may peel and
cause the disc to become jammed. It is recommended that
homemade discs be identified with permanent felt tip marker
rather than adhesive labels. Ball point pens may damage discs.
Please contact your dealer for further information.

Inserting a CD/DVD

With the ignition ON, inserting a CD/DVD into the DVD player
automatically turns ON the FES and playback should begin immediately.

The counter is automatically reset to 0:00:00 when any disc is inserted
into the FES.

Removing a CD/DVD (while playing)

1. Press the STOP/EJECT control to stop playback if a disc is playing.

2. Press the STOP/EJECT control again to eject the CD/DVD.

If the CD/DVD is not removed within the allotted time, the system will
pull the CD/DVD back into the system for safety purposes.

If the CD/DVD will not eject from the system, press and hold the EJECT
control for approximately 2 seconds. The disc should eject whether the
vehicle ignition is ON or OFF.

Playing an auxiliary device

1. Connect the video line from your video device to the YELLOW
auxiliary input jack.

2. Connect the left and right audio lines to the WHITE (left) and RED
(right) auxiliary input jacks respectively.

3. Press the MODE control repeatedly until DVD/CD AUX (no disc in
player) or DVD/CD play (disc in player) illuminates in the radio display.
If a disc is in the system, playback should begin. To enable the aux
inputs, press the STOP control or press the AUX control on the DVD
player.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

On-screen indicators

Each time a control is pressed, the operational status of the DVD player
is shown on the screen. The following are some possible indicators:

1. DVD/ CD STATUS (PLAY/FWD/REV/PAUSE)

2. CD track number / DVD title

3. DVD chapter number

4. MEDIA COUNTER — displays current viewing time of desired media.
(HOURS:MINUTES:SECONDS)

5. Viewing angle (of picture) - Adjustable with cursor controls and
ENTER control.

6. Subtitles (specific language type - English, Spanish or French,
dependent on disc capability and ON/OFF selection.)

7. AUDIO OUTPUT (not changeable)

8. AUDIO VERSION — (01 ENG., etc.)

9. DISPLAY SETTING (4x3, Zoom, 16x9)

10. STATUS ICON (FWD, x4, x8, x32, REV, x4, x8, x32, etc.)

Safety information

Read all the safety and operating instructions before operating the
system and retain for future reference.
• Do not attempt to service, repair or modify the Family Entertainment

DVD System. See your Ford or Lincoln Mercury dealer.

• Do not insert foreign objects into the DVD compartment.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

The front glass on the flip-down liquid crystal display (LCD) may
break when hit with a hard surface. If the glass breaks, do not

touch the liquid crystalline material. In case of contact with skin, wash
immediately with soap and water.

Do not expose the flip-down liquid crystal display (LCD) to direct
sunlight or intensive ultraviolet rays for extensive periods of
time. Ultraviolet rays deteriorate the liquid crystal.
• Ensure that you review User Manuals for video games and video game

equipment when used as auxiliary inputs for your Family
Entertainment DVD System.

• Do not operate video games or video equipment if the power cords

and/or cables are broken, split or damaged. Carefully place cords
and/or cables where they will not be stepped on or interfere with the
operation of seats and/or compartments.

• Disconnect video games and video equipment power cords and/or

cables when not in use.

• Avoid touching auxiliary input jacks with your fingers. Do not blow on

them or allow them to get wet or dirty.

• Do not clean any part of the DVD player with benzene, paint thinner

or any other solvent.

Whenever a warning notice is received, the radio volume will be
lowered to a volume that will allow the tones to be heard. The
radio volume will return to the previous level after the warning
notice is complete.

Federal Communication Commission (FCC) Compliance

Changes or modifications not approved by Ford or Lincoln Mercury could
void user’s authority to operate the equipment. This equipment has been
tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy. If not installed and used in accordance with the
instructions, the Family Entertainment System (FES) may cause harmful
interference with radio communications.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, (which can be determined by turning the
equipment off and on), the user is encouraged to consult the dealer or
an experienced radio/TV technician for help.

Care and service of the DVD player

Environmental extremes

DVD players that are subjected to harsh environmental conditions may
be damaged or perform at less than optimal capability. To avoid these
outcomes, whenever possible avoid exposing your DVD player to:
• extremely hot or cold temperatures.
• direct sunlight.
• high humidity.
• a dusty environment.
• locations where strong magnetic fields are generated.
Temperature extremes

When the vehicle is parked under direct sunlight or in an extremely cold
place for a long period of time, wait until the cabin temperature of the
vehicle is at normal temperature before operating the system.

Humidity and moisture condensation

Moisture in the air will condense in the DVD player under extremely
humid conditions or when moving from a cold to a warm location. If
moisture condensation occurs, do not insert a CD or DVD into the
player. If one is already in the player, remove it and turn the DVD player
ON to dry the moisture before inserting a DVD. This could take an hour
or more depending on the amount of moisture.

Cleaning the liquid crystal display (LCD) flip-down screen

Clean the display screen by applying a small amount of water or any
ammonia-based household glass cleaner directly to a soft cloth. Rub the
screen gently until the dust, dirt or fingerprints are removed. Do not
spray the screen directly with water or glass cleaning solvents. Overspray
from these fluids could drip down into the internal electronics of the
screen and cause damage. Do not apply excessive pressure while
cleaning the screen.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

Foreign substances

Exercise care to prevent dirt and foreign objects from entering the DVD
player compartment. If liquid is accidentally spilled onto the system,
immediately turn the system OFF and consult a qualified service
technician.

Cleaning compact discs

Inspect all discs for contamination before playing. If necessary, clean
discs only with an approved CD cleaner and wipe from the center out to
the edge. Do not wipe in a circular motion.

Cleaning the DVD player

Clean the exterior of the DVD player with a damp cloth. Do not use CD
cleaning kits or CDs intended to clean the interior of your DVD player.
Use of these products may damage your system.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

DUAL ZONE AUTOMATIC TEMPERATURE CONTROL
(IF EQUIPPED)

Defrost: Distributes outside air through the windshield defroster

and demister vents. Can be used to clear thin ice or fog from the
windshield. To exit

select another mode.

2. Passenger temperature control: Press to increase/decrease the
airflow temperature for the passenger in the front of the vehicle.

Rear defroster: Press to activate/deactivate rear window

defroster. Refer to Rear window defroster in this section for more
information.

Recirculated air: Press to activate/deactivate air recirculation

in the cabin. Recirculated air may reduce the amount of time to cool
down the interior of the vehicle and may also help reduce undesired
odors from reaching the interior of the vehicle. Recirculation can be
engaged manually in any other airflow selection except defrost.
Recirculation may turn off automatically in all airflow selections.

5. A/C: Press to activate/deactivate air conditioning. Use with
recirculated air to improve cooling performance and efficiency. Engages
automatically in AUTO, defrost and floor/defrost.

: Distributes air through the windshield defroster, demister and

floor vents.

: Distributes air through the floor vents. Note: You may notice a

small amount of air flowing from the demister and defroster vents.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Climate Controls

: Distributes air through the instrument panel and floor vents.

: Distributes air through the instrument panel vents.

10. Manual override controls: Allows you to manually select where
airflow is directed. To return to full automatic control, press AUTO.

11.

Front fan speed control: Press to manually increase or

decrease the fan speed. To return to automatic fan operation, press
AUTO.

12. EXT: Press to display outside temperature. Press again to display
cabin temperature settings.

13. F/C (Temperature conversions): Press to switch temperature
display between ° Fahrenheit and ° Celsius.

14. OFF: Outside air is shut out and the climate control system is turned
off.

15. Driver temperature control: Press to increase/decrease the
temperature on the driver side of the cabin. Sets the passenger side
temperature also when DUAL is disengaged. The recommended vehicle
cabin setting is between 72°F (22°C) and 75°F (24°C).

Dual temperature control: Press and hold the AUTO button to
engage-disengage separate passenger side temperature control.

16. AUTO: To engage automatic temperature control, press AUTO and
select the desired temperature using the temperature control. The
system will automatically determine fan speed, airflow location, A/C on
or off, and outside or recirculated air, to heat or cool the vehicle to reach
the desired temperature.

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Climate Controls

Dual Zone Automatic Temperature Control with heated seats
(if equipped)

Defrost: Distributes outside air through the windshield defroster

and demister vents. Can be used to clear thin ice or fog from the
windshield. To exit

select another mode.

2. Passenger temperature control: Press to increase/decrease the
airflow temperature for the passenger in the front of the vehicle.

Rear defroster: Press to activate/deactivate rear window

defroster. Refer to Rear window defroster in this section for more
information.

4. DUAL (Dual temperature control): Press to engage/disengage
separate passenger side temperature control.

Passenger heated seat control: Press once to activate high heat

setting (2 indicator lights), press again to activate low heat setting (1
indicator light), and press again to deactivate the passenger heated seat.
Note: The heated seat feature will remain on for approximately ten
minutes.

Recirculated air: Press to activate/deactivate air recirculation

2007 Montego (mgo)
Owners Guide (post-2002-fmt)
USA (fus)

Climate Controls

Content .. 1 2 3 4 ..
