6. Remove the bolt and the brake booster vacuum hose and bracket. Fig. 383: Removing Brake Booster Vacuum Hose & Bracket - 5.4L 7. Remove the exhaust manifold to EGR valve tube. Disconnect the differential pressure feedback EGR system hoses. Disconnect the upper and lower exhaust manifold to EGR valve tube fittings.
2003 Ford Pickup F150 2003 ENGINE Engine - 4.6L & 5.4L - F150 Pickup
|
