F150 PICKUP .

Total Backlash Check

1. Raise and support the vehicle.

2. Remove the driveshaft. Refer to DRIVESHAFT & UNIVERSAL JOINTS - F150 PICKUP .

3. Install the special tool.

z

Clamp a rigid bar or pipe to the tool. Clamp the other end of the bar or pipe to the frame or a body
member in order to prevent movement of the pinion flange.

Fig. 21: Installing Pinion Flange Holding Tool
Courtesy of FORD MOTOR CO.

4. Lower the vehicle so that one rear wheel is resting on a wheel chock to prevent it from turning. The other

rear wheel will be used to measure total rear axle backlash.

5. Rotate the free wheel slowly, by hand, until the feeling of driving the rear axle is encountered. Place a

mark on the side of the tire, 305 mm (12 inches) from the center of the wheel, with a crayon or chalk.

6. While holding the crayon or chalk against the tire, rotate the wheel slowly in the opposite direction until

the feeling of driving the rear axle is encountered again.

7. Measure the length of the crayon or chalk mark on the tire.



2003 Ford Pickup F150

2003 GENERAL INFORMATION Driveline System - General Information - F150 Pickup



z

If the length of the mark is 25.4 mm (1 inch) or less, the rear axle backlash is within allowable limits.

z

If the chalk mark is greater than 25.4 mm (1 inch), check for these conditions:

z

Elongation of the differential pinion shaft and holes in the differential case (4204).

z

Missing differential pinion thrust washer (4230) or differential side gear thrust washer (4228).

z

Galling of the differential pinion shaft (4211) and bore.

z

Excessive ring gear and pinion backlash. Follow the procedure for the type of rear axle to check backlash.

Axle Shaft Bearing Noise

Axle shaft bearing noise is similar to gear noise and differential pinion bearing whine. Axle shaft bearing noise
will usually distinguish itself from gear noise by occurring in all driving modes (drive, coast, and float), and
will persist with the transmission in NEUTRAL while the vehicle is moving at the speed in which the concern is
occurring. If the vehicle makes this noise, remove the suspect axle shaft and install a new bearing and axle seal.
Re-evaluate the vehicle for noise before removing any internal components.

Bearing Rumble

Bearing rumble sounds like marbles being tumbled. This condition is usually caused by a worn/damaged wheel
bearing. The lower pitch is because the wheel bearing turns at only about one-third of the driveshaft speed.
Wheel bearing noise also may be high-pitched, similar to gear noise, but will be evident in all four driving
modes.

Symptom Chart

DRIVELINE ANGLES CURB SPECIFICATIONS

Condition

Possible Sources

Action

z

Traction-Lokohm
Does Not Work
in Snow, Mud or
on Ice

z

Differential.

z

CARRY OUT the TRACTION-LOKohm

DIFFERENTIAL OPERATION CHECK .

REPAIR as necessary. REFER to REAR

DRIVE AXLE/DIFFERENTIAL-FORD

8.8-INCH or REAR DRIVE

AXLE/DIFFERENTIAL-FORD 9.75-

INCH .

z

Lubricant
Leaking from the
Pinion Seal, Axle
Shaft Oil Seals or
Support Arm to
the Housing

z

Vent.

z

Damage in the

seal contact area

or dust slinger on

the pinion flange

dust shield.

z

CLEAN the axle housing vent.

z

INSTALL a new pinion flange and the pinion

seal if damage is found.

z

Front Axle Will
Not Engage

z

Switches.

z

Wiring (DTC

1844 or 1845).

z

Linkage.

z

REFER to TRANSFER CASE - GENERAL

INFORMATION .

z

REFER to TRANSFER CASE - GENERAL

INFORMATION .



2003 Ford Pickup F150

2003 GENERAL INFORMATION Driveline System - General Information - F150 Pickup



z

Vacuum system.

z

Shift motor.

z

GO to PINPOINT TEST A .

z

Front Axle Will
Not Disengage

z

Switches.

z

Wiring (DTC

1844 or 1845).

z

Linkage.

z

Vacuum system.

z

Shift motor.

z

REFER to TRANSFER CASE - GENERAL

INFORMATION .

z

REFER to TRANSFER CASE - GENERAL

INFORMATION .

z

GO to PINPOINT TEST B .

z

Differential side
gears/pinion gears
are scored

z

Insufficient
lubrication.

z

Incorrect or

contaminated

lubricant type.

z

INSTALL new gears. REFER to REAR

DRIVE AXLE/DIFFERENTIAL-FORD

8.8-INCH , REAR DRIVE

AXLE/DIFFERENTIAL-FORD 9.75-INCH

or FRONT DRIVE

AXLE/DIFFERENTIAL-FORD 8.8-INCH .

FILL the axle to specification.

z

INSTALL new gears. REFER to REAR

DRIVE AXLE/DIFFERENTIAL-FORD

8.8-INCH , REAR DRIVE

AXLE/DIFFERENTIAL-FORD 9.75-INCH

or FRONT DRIVE

AXLE/DIFFERENTIAL-FORD 8.8-INCH .

CLEAN and REFILL the axle to specification.

z

Axle overheating

z

Lubricant level

too low.

z

Incorrect or

contaminated

lubricant type.

z

Bearing preload

adjusted too tight.

z

Excessive gear

wear.

z

Incorrect ring

gear backlash.

z

CHECK the lubricant level. FILL the axle to

specification.

z

INSPECT the axle for damage. REPAIR as

necessary. CLEAN and REFILL the axle to

specification.

z

CHECK the ring and pinion for damage.

INSPECT the ring and pinion wear pattern.

ADJUST the preload as necessary.

z

INSPECT all the axle gears for wear or

damage. INSTALL new components as

necessary.

z

INSPECT the ring gear for scoring. INSPECT

the ring and pinion wear pattern. ADJUST the

ring gear backlash as necessary.

z

Broken gear teeth
on the ring gear
or pinion

z

Overloading the

vehicle.

z

INSTALL a new ring and pinion. REFER to

REAR DRIVE AXLE/DIFFERENTIAL-

FORD 8.8-INCH , REAR DRIVE

AXLE/DIFFERENTIAL-FORD 9.75-INCH

or FRONT DRIVE

AXLE/DIFFERENTIAL-FORD 8.8-INCH .



2003 Ford Pickup F150

2003 GENERAL INFORMATION Driveline System - General Information - F150 Pickup



Pinpoint Tests

PINPOINT TEST A: FRONT AXLE WILL NOT ENGAGE

Fig. 22: Pinpoint Test A: Front Axle Will Not Engage Step (A1)
Courtesy of FORD MOTOR CO.

z

Axle shaft broken

z

Overload the

vehicle.

z

Misaligned axle

shaft tube.

z

INSTALL a new axle shaft. REFER to REAR

DRIVE AXLE/DIFFERENTIAL-FORD

8.8-INCH , REAR DRIVE

AXLE/DIFFERENTIAL-FORD 9.75-INCH

or FRONT DRIVE

AXLE/DIFFERENTIAL-FORD 8.8-INCH .

z

INSPECT the axle for damage. CHECK axle

shaft tube alignment. INSTALL a new axle

shaft. REFER to REAR DRIVE

AXLE/DIFFERENTIAL-FORD 8.8-INCH ,

REAR DRIVE AXLE/DIFFERENTIAL-

FORD 9.75-INCH or FRONT DRIVE

AXLE/DIFFERENTIAL-FORD 8.8-INCH .
