Ford F150 Pickup. Instruction - part 475

Fig. 77: Removing E-Ring
Courtesy of FORD MOTOR CO.

7. Disconnect the front axle actuator motor assembly (7G360).

1. Fully extend the actuator motor shaft.

2. Plug the vacuum ports.

3. Pull outward on the front axle actuator motor assembly.

4. Push the front axle actuator motor assembly to disconnect the shift lever (7K336) from the slot in

the actuator motor shaft.



2003 Ford Pickup F150

2003 DRIVELINE/AXLES Front Drive Axle/Differential - Ford 8.8-Inch - F150 Pickup



Fig. 78: Disconnecting front Axle Actuator Motor Assembly
Courtesy of FORD MOTOR CO.

8. Remove the clutch shaft rod boot, and the front axle actuator motor assembly.

1. Remove the clutch shaft rod boot.

2. Remove the front axle actuator motor assembly.



2003 Ford Pickup F150

2003 DRIVELINE/AXLES Front Drive Axle/Differential - Ford 8.8-Inch - F150 Pickup



Fig. 79: Removing Front Axle Actuator Motor Assembly
Courtesy of FORD MOTOR CO.

9. Remove the axle housing tube (3B210).



2003 Ford Pickup F150

2003 DRIVELINE/AXLES Front Drive Axle/Differential - Ford 8.8-Inch - F150 Pickup



Fig. 80: Removing Axle Housing Tube
Courtesy of FORD MOTOR CO.

10. Remove the thrust washer (3N126).



2003 Ford Pickup F150

2003 DRIVELINE/AXLES Front Drive Axle/Differential - Ford 8.8-Inch - F150 Pickup
