Fig. 38: Installing Brake Shoe Hold-Down Springs
Courtesy of FORD MOTOR CO.

3. Install the brake adjuster screw.

2003 Ford Pickup F150

2003 BRAKES Parking Brake & Actuation - F150 Pickup

Fig. 39: Installing Brake Adjuster Screw
Courtesy of FORD MOTOR CO.

4. Install the brake shoe adjusting screw spring.

2003 Ford Pickup F150

2003 BRAKES Parking Brake & Actuation - F150 Pickup

Fig. 40: Installing Brake Shoe Adjusting Screw Spring
Courtesy of FORD MOTOR CO.

5. Install the outboard brake shoe retracting spring.

2003 Ford Pickup F150

2003 BRAKES Parking Brake & Actuation - F150 Pickup

Fig. 41: Installing Outboard Brake Shoe Retracting Spring
Courtesy of FORD MOTOR CO.

6. Use Brake Adjusting Gauge to measure the inside diameter of the drum portion of the rear brake disc.
