Ford F150 Pickup. Instruction - part 1890

Fig. 99: Identifying Special Tool(s)
Courtesy of FORD MOTOR CO.

Disassembly

1. Position the (B) case cover (7222) onto (A) Top Cover Holding Fixture.

Fig. 100: Positioning Case Cover Onto Top Cover Holding Fixture
Courtesy of FORD MOTOR CO.

2. Remove the lower gearshift lever (7210).

1. Remove the dust cover screws.

2. Remove the dust cover.

3. Remove the lower gearshift lever.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 101: Removing Lower Gearshift Lever
Courtesy of FORD MOTOR CO.

3. Remove the (A) backup lamp switch (15520) and (B) pin.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 102: Removing Backup Lamp Switch & Pin
Courtesy of FORD MOTOR CO.

4. Invert the (B) case cover on (A) Top Cover Holding Fixture.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 103: Inverting Case Cover On Top Cover Holding Fixture
Courtesy of FORD MOTOR CO.

5. Remove and discard the shift fork spring pins.
