Fig. 71: Removing Output Shaft Reverse Gear & Bushing
Courtesy of FORD MOTOR CO.

15. Remove the output shaft spacer.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 72: Removing Output Shaft Spacer
Courtesy of FORD MOTOR CO.

16. Remove the countershaft reverse gear, the two countershaft reverse gear bearings and the reverse

synchronizer blocking ring.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 73: Removing Countershaft Reverse Gear, Countershaft Reverse Gear Bearings &
Reverse Synchronizer Blocking Ring
Courtesy of FORD MOTOR CO.

17. Remove the reverse gear thrust washer.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 74: Removing Reverse Gear Thrust Washer
Courtesy of FORD MOTOR CO.

18. Remove the countershaft split washer.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup
