Fig. 15: Removing Vehicle Speed Sensor
Courtesy of FORD MOTOR CO.

7. Use (A) the High-Lift Jack to support the (B) transmission.

z

Secure the transmission with the (C) strap.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 16: Securing Transmission With Strap
Courtesy of FORD MOTOR CO.

8. Remove the transmission mount nuts.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 17: Removing Transmission Mount Nuts
Courtesy of FORD MOTOR CO.

9. Remove the heat shield bolts (one each side).



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 18: Removing Heat Shield Bolts (One Each Side)
Courtesy of FORD MOTOR CO.

10. Remove the crossmember.

1. Remove the bolts (three each side).

2. Remove the crossmember.
