Fig. 163: Removing Steering Column Bearing From Steering Column Lock Cylinder Housing
Courtesy of FORD MOTOR CO.

18. Remove the brake shift interlock solenoid.

1. Remove the three bolts.

2. Remove the brake shift interlock solenoid.

Fig. 164: Removing Brake Shift Interlock Solenoid
Courtesy of FORD MOTOR CO.

19. Remove the shift tube.

1. Remove the four bolts.

2. Remove the two shift tube clamps.

3. Remove the shift tube.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 165: Removing Shift Tube
Courtesy of FORD MOTOR CO.

20. Remove the transmission selector lever arm and support (7302).

1. Remove the two bolts.

2. Remove the transmission selector lever arm and support.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 166: Removing Transmission Selector Lever Arm & Support
Courtesy of FORD MOTOR CO.

21. Remove the gearshift selector tube spring (7379).



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 167: Removing Gearshift Selector Tube Spring
Courtesy of FORD MOTOR CO.

22. Drive out the gearshift lever pin (7W441) from the shift tube.
