3. Disconnect the passenger air bag deactivation (PAD) switch electrical connector.

Fig. 8: Identifying (PAD) Switch Electrical Connector (EATC)
Courtesy of FORD MOTOR CO.

4. If equipped, disconnect the 4WD control switch connector. Remove the center instrument panel finish

panel.



2003 Ford Pickup F150

2003 HVAC Control Components - F150 Pickup



Fig. 9: Disconnecting 4WD Control Switch Connector (EATC)
Courtesy of FORD MOTOR CO.

5. Remove the screws.



2003 Ford Pickup F150

2003 HVAC Control Components - F150 Pickup



Fig. 10: Identifying Center Instrument Panel Removing Screw
Courtesy of FORD MOTOR CO.

6. Remove the EATC module.

1. Disconnect the electrical connectors.

2. Remove the nuts.

3. Disconnect the vacuum harness connector and remove the EATC module.



2003 Ford Pickup F150

2003 HVAC Control Components - F150 Pickup



Fig. 11: Removing EATC Module
Courtesy of FORD MOTOR CO.

7. To install, reverse the removal procedure.

CLIMATE CONTROL ASSEMBLY - MANUAL A/C

Removal and Installation

1. Disconnect the battery.

2. Detach the center instrument panel finish panel

1. Rotate the center instrument panel finish panel vents inward.

2. Through the vent openings, grasp the center instrument panel finish panel and pull outward.

3. Detach the center instrument panel finish panel.
