Fig. 9: Removing Drive Cable From Accelerator Pedal Assembly
Courtesy of FORD MOTOR CO.

1. Depress the locking tabs on the accelerator pedal drive cable and remove the drive cable from the

accelerator pedal assembly.

2. Disconnect the accelerator cable from the accelerator pedal and shaft assembly.



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Acceleration Control - F150 Pickup



Fig. 10: Disconnecting Accelerator Cable From Accelerator Pedal And Shaft Assembly
Courtesy of FORD MOTOR CO.

3. Remove the bolts and remove the accelerator pedal and shaft assembly.



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Acceleration Control - F150 Pickup



Fig. 11: Removing Bolts, Accelerator Pedal And Shaft Assembly
Courtesy of FORD MOTOR CO.

4. To install, reverse the removal procedure.

ACCELERATOR CABLE - 4.2L

Removal and Installation

1. Disconnect the accelerator cable from the accelerator pedal and shaft.

NOTE:

When installing a new accelerator pedal, the pedal will come in the fully
forward or fully rearward position. Before connecting the accelerator pedal
drive cable, move the brake pedal to the same position as the accelerator
pedal.



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Acceleration Control - F150 Pickup



Fig. 12: Disconnecting Accelerator Cable From Accelerator Pedal And Shaft
Courtesy of FORD MOTOR CO.

2. Remove the accelerator cable from the dash panel.

3. From inside the vehicle, compress the retaining tabs on the cable and push the cable into the engine

compartment until the retaining tabs are disconnected from the dash panel.

4. Pull the accelerator cable through the dash panel.
